2000 BUICK LESABRE display

yellowblue
2-89
You can also program this feature to recall your
memory seat position or the exit seat position.

Memory Position: Choose ON when the SEAT
RECALL choice appears, and then choose MEMORY
when the RECALL POSITION choice appears.

Exit Position: Choose ON when the SEAT RECALL
choice appears, and then choose EXIT when the
RECALL POSITION choice appears. The seat will
move when you enter the vehicle after unlocking it
with a remote keyless entry transmitter. This will
allow for easy entry.
For more information on this feature, see
ªMemory Seatsº in the Index.Parallel Park Assist (If Equipped)
The parallel park assist mirror, which tips the passenger
mirror down while the vehicle is in REVERSE (R), can
be made active or inactive through the DIC. When TILT
MIRRORS
-OFF/ON appears on the display, use the
ENG/MET button to toggle the arrow between OFF and
ON. When you have made your choice, press the
RESET button to record your selection. For more
information on this feature, see ªParallel Park Assist
Mirrorº in the Index.
Driver ID
This feature displays the DRIVER ID, as identified by
the DIC. If this feature is ON, the DRIVER ID will be
displayed every time the ignition is turned on. If the
DRIVER ID is OFF, the DRIVER ID can be displayed
by pressing either a button on the remote keyless entry
transmitter or a memory seat button. Vehicles are
delivered with this feature ON.

yellowblue
3-4 Dual Automatic Comfortemp
Climate Control (If Equipped)
If your vehicle is equipped with the Dual Automatic
Comfortemp Climate Control system, the following
information tells you how it works.You will hear a beep each time a button is pushed and a
light on the button will indicate which function is active.
The lights are on all buttons except TEMP, FAN and
AIR FLOW. The display will show fan speed, comfort
level setting and airflow direction for a few seconds
whenever AUTO is selected, and then it will display the
outside temperature. The outside temperature reading is
most accurate when the vehicle is moving. During stops,
the display shows the previous temperature for best
accuracy and system control.
If the display is flashing after the climate control system
is started, there is a problem with the system and you
should see your dealer for service.
Sun and temperature sensors automatically adjust the
air temperature, the airflow direction and the fan speed
to maintain your comfort setting. The system may
supply cooler air to the side of the vehicle toward the
sun. Be careful not to put anything over the sensor on
top of the dash.

yellowblue
3-5
Temperature Button
To adjust the comfort level you want maintained inside
the vehicle, push the TEMP button. If you want a
warmer comfort level, push the up arrow. If you want a
cooler comfort level, push the down arrow. Your
comfort setting is shown in the display. The display will
then return to the outside temperature.
Fan Button
The speed of the blower fan is controlled automatically if
you have the system set for AUTO. Pressing the FAN
button will display and hold the current blower fan setting.
If you want the blower fan to run at a lower speed, push
the bottom of the FAN button. The fan speed will
decrease with every push of the button until the lowest
speed is reached. If you want to increase the fan speed,
push the top of the FAN button. Notice the fan
indicators in the display.
Mode Controls
Press the AIR FLOW button to deliver air through the
floor, middle or windshield outlets. The system will stay
in the selected mode until the AUTO button is pushed.
Use the up and down arrows on the AIR FLOW button
to cycle through the available modes.Automatic Operation
Press the AUTO button when you want the system to
automatically adjust to changes in the temperature inside
the vehicle, the outside temperature and the sun load on
the vehicle. When the system is set for automatic
operation, air will come from the floor, middle or
windshield outlets depending on the temperature inside
the vehicle, the outside temperature and sun load.
Fan speed will vary as the system gets to and maintains
the comfort setting you have selected through the use of
the TEMP button.
To find your comfort setting, start with the system in
AUTO mode and the TEMP button adjusted to 75
F
(24
C), give the vehicle about 20 minutes to stabilize,
and adjust your comfort setting if necessary, by using
the TEMP button. The display will show the comfort
setting for a few seconds and then it will display the
outside temperature. If you want to see your current
automatic fan speed, airflow direction and comfort
setting, press the AUTO button.
In cold weather, the system will delay turning on the
fan, to avoid blowing cold air. The length of the delay
depends on the engine coolant temperature and the
outside temperature. Pushing the FAN, AIR FLOW or
FRONT buttons will override this delay, turn off the
AUTO setting and change the fan speed.

yellowblue
3-6
Manual Operation
You may also manually adjust the air delivery or fan speed.
AIR FLOW: This button is used to change the direction
of the airflow. The airflow choices available are
WINDSHIELD
-FLOOR, MID, MID-FLOOR, and
FLOOR. If the system is set for AUTO, pressing the
AIR FLOW button will display and hold the current
airflow direction and the comfort setting. Press the AIR
FLOW up or down button again to change the direction
of the airflow.
If the AIR FLOW up button is selected while in the
FRONT defrost mode, the system will direct the air
toward the windshield and the floor. If the AIR FLOW
down button is selected while in the FRONT defrost
mode, the system will direct the air toward the floor, and
the FRONT defrost mode will cancel. Notice the arrows
in the display.
OFF: If the passenger comfort control is turned on, it
can be turned off by pressing the OFF button once.
Pressing the OFF button a second time will turn off the
main system. Turning off the main system causes the fan
to turn off and the airflow to be directed toward the
floor. The system will still try to keep the interior of the
vehicle at the previous chosen comfort setting. The
outside temperature will show on the display when the
system is OFF.The ventilation system always allows fresh air to flow
through your vehicle when the vehicle is moving even
with the system in the OFF mode.
VENT: The VENT button allows outside air to flow
through your vehicle without the air conditioning
compressor working. Selecting VENT and the AUTO
button at the same time allows the system to control
automatically without the use of the RECIRC mode.
To turn off the VENT selection, push the VENT button
again. If you select VENT while in FRONT defrost, the
VENT light will flash three times to let you know this is
not allowed. This is to prevent fogging.
RECIRC: When RECIRC is selected, the system will
limit the amount of outside air entering your vehicle.
This is helpful when you are trying to cool the interior
of the vehicle quickly or limit the amount of outside air
entering your vehicle. RECIRC and AUTO may be
selected at the same time. The system will remain in
RECIRC until the ignition is turned off, then the system
will return back to the previously selected mode.
Deselecting the RECIRC button will also turn off the
RECIRC function. RECIRC can be selected in all
manual airflow modes except FRONT defrost and
VENT. If you select RECIRC while in FRONT defrost,
the RECIRC light will flash three times to let you know
this is not allowed. This is to prevent fogging.

yellowblue
3-10
Adjust the direction of
airflow by moving the
louvered vents.
If you have the optional rear
passenger comfortemp, you
can adjust the direction of
the airflow to the rear
seating area.Ventilation Tips

Keep the hood and front air inlet free of ice, snow or
any other obstruction such as leaves. The heater and
defroster will work better, reducing the chance of
fogging your windows.

Keep the air path under the front seats clear of
objects. This helps air to circulate throughout
your vehicle.

When the engine idles for a long time, the exterior
temperature sensor may cause the system to blow air
that is too cool. Once the vehicle is moving again,
the system will try to maintain the set temperature
inside your vehicle.

When you start your vehicle and the EXT display
flashes (Dual Automatic Comfortemp system only)
for some time, the system may need repair.
See your dealer.

yellowblue
3-13 AM-FM Stereo
Playing the Radio
VOLUME: This knob turns the system on and off and
controls the volume. To increase volume and turn the
radio on, turn the knob clockwise. Turn it
counterclockwise to decrease volume.RECALL: Press the upper knob briefly to recall the
station being played or to display the clock. To change
what is normally shown on the display (station or time),
press the knob until you see the display you want, then
hold the knob until the display flashes. If you press the
knob when the ignition is off, the clock will show for a
few seconds.
Finding a Station
AM
-FM: Press the AM-FM button to switch between
AM, FM1 and FM2. The display shows your selection.
TUNE: Turn the lower knob to choose radio stations.
SEEK: Press the right or left arrow to go to the next
higher or lower station and stay there. The sound will
mute while seeking.
SCAN: Press one of the SEEK arrows for two seconds,
and SCAN will appear on the display. Use SCAN to
listen to stations for a few seconds. The radio will go to
a station, stop for a few seconds, then go on to the next
station. Press one of the SEEK arrows again to stop
scanning. The sound will mute while scanning.

yellowblue
3-15 AM-FM Stereo with Cassette Tape Player
(If Equipped)
Playing the Radio
VOLUME: This knob turns the system on and off and
controls the volume. To increase volume and turn the
radio on, turn the knob clockwise. Turn it
counterclockwise to decrease volume.RECALL: Press the upper knob briefly to recall the
station being played or to display the clock. To change
what is normally shown on the display (station or time),
press the knob until you see the display you want, then
hold the knob until the display flashes. If you press the
knob when the ignition is off, the clock will show for a
few seconds.
Finding a Station
AM
-FM: Press the lower knob to switch between AM,
FM1 and FM2. The display shows your selection.
TUNE: Turn the lower knob to choose radio stations.
SEEK: Press the right or left arrow to go to the next
higher or lower station and stay there. The sound will
mute while seeking.
SCAN: Press one of the SEEK arrows for two seconds,
and SCAN will appear on the display. Use SCAN to
listen to stations for a few seconds. The radio will go to
a station, stop for a few seconds, then go on to the next
station. Press one of the SEEK arrows again to stop
scanning. The sound will mute while scanning.

yellowblue
3-17
While the tape is playing, use the VOLUME, FADE,
BAL, BASS and TREB controls just as you do for the
radio. Other controls may have different functions when
a tape is inserted. The display will show an arrow to
show which side of the tape is playing.
If you want to insert a tape when the ignition or radio is
off, first press EJECT or RECALL. Note that the
cassette tape adapter kits for portable compact disc
players will work in your cassette tape player.
Your tape bias is set automatically.
If E and a number appear on the radio display, the tape
won't play because of an error.

E10: The tape is tight and the player can't turn the
tape hubs. Remove the tape. Hold the tape with the
open end down and try to turn the right hub
counterclockwise with a pencil. Turn the tape over
and repeat. If the hubs do not turn easily, your tape
may be damaged and should not be used in the
player. Try a new tape to make sure your player is
working properly.
E11: The tape is broken. Try a new tape.
If any error occurs repeatedly or if an error can't be
corrected, please contact your dealer. If your radio
displays an error number, write it down and provide it to
your dealer when reporting the problem.
PREV (1): Press this button to search for the previous
selection on the tape. Your tape must have at least three
seconds of silence between each selection for PREV to
work. The sound will mute while seeking.
NEXT (2): Press this button to search for the next
selection on the tape. Your tape must have at least three
seconds of silence between each selection for NEXT to
work. The sound will mute while seeking.
The SEEK left and right arrows will also find the
previous and next selections on the tape.
 (3): Press this button to reverse the tape rapidly.
Press it again to return to playing speed. The radio will
play while the tape reverses.


(4): Press this button to advance quickly to another
part of the tape. Press the button again to return to playing
speed. The radio will play while the tape advances.
