2000 BUICK LESABRE Owner's Manual

yellowblue
2-56 Convenience Net (If Equipped)
Your vehicle may have a convenience net. You'll see it
just inside the back wall of the trunk.
Put small loads, like grocery bags, behind the net. It can
help keep them from falling over during sharp turns or
quick starts and stops. For heavier loads, store them in
the trunk as far forward as you can.
You can unhook the net so that it will lie flat when
you're not using it.
Ashtrays and Cigarette Lighter
Pull down the front center tray to reveal the front
ashtray, cigarette lighter and accessory power outlet.
The front center and rear ashtrays may be removed for
cleaning. Hold the sides of the ashtray and then pull the
ashtray up and out.
NOTICE:
Don't put papers or other flammable objects into
your ashtrays. Hot cigarettes or other smoking
materials could ignite them, causing a
damaging fire.
To use a lighter, push the center all the way in and let it
go. When it is ready, the center will pop back by itself.
Pull out the entire unit to use it.
NOTICE:
Don't hold a cigarette lighter in with your hand
while it is heating. If you do, it won't be able to
back away from the heating element when it's
ready. That can make it overheat, damaging the
lighter and the heating element.
Sun Visors
Illuminated Visor Vanity Mirrors
(If Equipped)
When you open the cover to either the passenger's or
driver's visor vanity mirror, the lamps will turn on. The
brightness of the lamp can be adjusted by sliding the
switch up or down.

yellowblue
2-57 Dual Sun Visors
Each sun visor has two parts, so that both the windshield
and door glass can be shaded at the same time. To use
the dual sun visors, flip the first visor down and turn
toward the window. Then, flip the second visor down
toward the windshield.
OnStar
System (Option)
Your vehicle may have the optional OnStar
Communications service. The following services are
available 24 hours a day from an OnStar representative:

Roadside Service with Location

Emergency Services Button

Remote Door Unlock

Theft Detection/Notification and
Stolen
-Vehicle Tracking

Automatic Notification of Air Bag Deployment

Concierge/Customer Conveniences Services
NOTE: Installation of aftermarket equipment is
possible, however, the features described above will not
be compatible with any portable phone other than the
OnStar cellular phone available from your dealer.
For more information, contact your dealer.
Sunroof (Option)
If you have this feature, the switch is located between
the sun visors.
The sunroof switch can be operated in four directions to
control sunroof movement. The switch will only work
when the ignition is on or when the retained accessory
power is active.
The sunroof has both manual and express features for
opening the glass panel and sunshade.
Press and hold the switch rearward to the first position
to open the glass panel and sunshade. The sunshade can
also be opened by hand. To close the glass panel, press
and hold the switch forward. As the glass panel closes, it
will open slightly towards the vent position to provide a
better seal. The sunshade can only be closed by hand.
Press and release the switch rearward to the second
position to express open the glass panel. It will stop in a
partially open position. The glass panel may be fully
opened by pressing the switch rearward again. When the
glass panel is express opening, pressing the switch in
any direction will stop it. Note that if you press and hold
the switch in the express open position for more than
one and a half seconds, the express open operation will
be overridden and the sunroof will operate manually.

yellowblue
2-58
To vent open the glass panel, press and hold the switch
upward. The sunshade must be opened by hand. To close
the glass panel, pull and hold the switch downward.
Universal Transmitter (If Equipped)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
This device complies with RSS
-210 of Industry Canada.
Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this
device must accept any interference, including interference
that may cause undesired operation of the device.
Changes and modifications to this system by other than
an authorized service facility could void authorization to
use this equipment.
Programming the Universal Transmitter
Do not use the Universal Transmitter with any garage
door opener that does not have the ªstop and reverseº
safety feature. This includes any garage door opener
model manufactured before April 1, 1982.Be sure that people and objects are clear of the garage
door you are programming.
Your vehicle's engine should be turned off while
programming the transmitter. Follow these steps to
program up to three channels:
1. If you have previously programmed a transmitter
channel, proceed to Step 2. Otherwise, hold down
the two outside buttons on the Universal Transmitter
until the indicator light begins to flash rapidly (after
20 seconds). Then release the buttons. This
procedure initializes the memory and erases any
previous settings for all three channels.
2. Decide which one of the three channels you want to
program. Hold the end of the hand
-held transmitter
about 2 to 5 inches (5 to 13 cm) away from the
surface of the Universal Transmitter so that you can
still see the indicator light.
3. Using both hands, press the hand
-held transmitter button
and the desired button on the Universal Transmitter.
Continue to press both buttons through Step 4.

yellowblue
2-59
4. Hold down both buttons until you see the indicator
light on the Universal Transmitter flash slowly and
then rapidly. The rapid flashing indicates that the
Universal Transmitter has been programmed.
Release both buttons once the indicator light starts
to flash rapidly.
If you have trouble programming the Universal
Transmitter, make sure that you have followed the
directions exactly as described. The Universal
Transmitter may not work with older garage door
openers that do not meet current Federal Consumer
Safety Standards. If you cannot program the transmitter
after repeated attempts, refer to ªRolling Code
Programmingº later in this section or contact the
Universal Transmitter manufacturer at 1
-800-355-3515.
Be sure to keep the original hand
-held transmitter in case you
need to erase and reprogram the Universal Transmitter.
Note to Canadian Owners: During programming, the
hand
-held transmitter may automatically stop
transmitting after one or two seconds. In this case, you
should press and re
-press the button on the hand-held
transmitter every two seconds without ever releasing the
button on the Universal Transmitter. Release both
buttons when the indicator light on the Universal
Transmitter begins to flash rapidly.
Operating the Universal Transmitter
Press and release the appropriate button on the Universal
Transmitter. The indicator light comes on while the
signal is being transmitted.
If the hand
-held transmitter appears to program the
Universal Transmitter but does not open your garage
door, and if the garage door opener was manufactured
after 1996, the garage door opener may have a ªrolling
codeº system. A rolling code system changes the code
of the garage door opener every time you open or close
the garage door.
To determine if you have this system, press the button
on the Universal Transmitter that you have programmed
already. If the indicator light on the Universal
Transmitter flashes rapidly for two seconds and then
turns solid, the garage door opener has a rolling code
system. In a rolling code system, the garage door motor
head unit must be trained to the Universal Transmitter.

yellowblue
2-60 ªRolling Codeº Programming (If Equipped)
If you have not previously programmed the hand-held
transmitter to the Universal Transmitter, see
ªProgramming the Universal Transmitterº listed
previously. If you have completed this programming
already, you now need to train the garage door opener
motor head unit to recognize the Universal Transmitter.
Refer to your garage door opener owner's manual for
the proper transmitter training procedure for your garage
door opener brand.
1. Find the training button on the garage door opener
motor head unit. The exact location and color of the
button may vary by garage door opener brand. If you
have difficulty finding the training button, refer to
your garage door opener owner's manual.
2. Press the training button on the garage door opener
motor head unit.
Note: Following this step, you have 30 seconds to
start Step 3.
3. Return to the Universal Transmitter in your
vehicle and firmly press and release the Universal
Transmitter button you have already programmed
for two to three seconds. Press and release the button again (you may need to
do this step up to three times) to make sure that the
Universal Transmitter has been trained to the garage
door opener motor head unit. Check that the training
was successful.
The garage door opener should now recognize the
Universal Transmitter. You may either use the Universal
Transmitter or the hand
-held transmitter to open the
garage door.
If after following these instructions, you still have
problems training the garage door opener, contact the
Universal Transmitter manufacturer at 1
-800-355-3515.
Erasing Channels
To erase all three programmed channels, hold down the
two outside buttons until the indicator light begins to
flash (after 20 seconds). Release both buttons.
Accessories
Accessories for the Universal Transmitter are available
from the manufacturer of the unit. If you would like
additional information, please call 1
-800-355-3515.

yellowblue
2-61
Auxiliary Power Outlets
Your vehicle may have one or three power outlets
depending on the type of front seat you have. If your
vehicle has front bucket seats with a center console, you
will find one outlet inside the storage compartment
and the other on the lower front edge of the console.
(An extra power outlet can be found in the ashtray.)
The power outlets can be used to plug in electrical
equipment such as a cellular telephone or CB radio.
Follow the proper installation instructions that are
included with the equipment you install.NOTICE:
When using an accessory outlet:

The maximum load of any electrical
equipment should not exceed 15 amps.

Be sure to turn off any electrical equipment
when not in use. Leaving electrical
equipment on for extended periods of time
can drain your battery.

yellowblue
2-62
The Instrument Panel - Your Information System

yellowblue
2-63
A. Air Outlets
B. Driver Information Center Buttons (If Equipped)
C. Multifunction Lever
D. Steering Wheel Controls (If Equipped)
E. Hazard Warning Flashers
F. Instrument Cluster
G. Traction Control Button (If Equipped)H. Exterior Lamps
I. Head
-Up Display (HUD) Controls (If Equipped)
J. Hood Release
K. Parking Brake
L. Cruise Controls
M. Audio System
N. Climate Controls
O. Glove Box
