2000 BMW 328Ci COUPE Owner's Manual

23n
RepairsIndexOverview Controls Car care Technology Data
Indicator and warning lamps
Electronic Engine output-adjust-
ment (EML)
* l
Malfunction in engine timing.
Higher brake application pressure may
be necessary and brake pedal travel
may be significantly longer.
Please have the system inspected by
your authorized BMW center.
Add coolant
The coolant level is too low. Top
up the coolant at the earliest
opportunity.
For additional information: Refer to
page 126.
Green: For your information
Turn signal
Flashes when the turn signal is
switched on. Rapid flashing in-
dicates a system malfunction.
For additional information: Refer to
page 69.
Cruise control
*
Comes on when the cruise con-
trol is activated. Available for
operation via the multi-function steering
wheel.
For additional information: Refer to
page 72.
Fog lamps
*
Lights up whenever you switch
on the fog lamps.
For additional information: Refer to
page 85.
Blue: For your information
High beam
Lights up when the high beams
are on or the headlamp flasher
is actuated.
For additional information: Refer to
page 69, 85.

24n
Multi-function steering wheel (MFL)

The controls integrated in the multi-
function steering wheel are provided so
that you can operate a number of ac-
cessories quickly and without being
distracted from traffic conditions. You
may operate:
>selected radio functions
>the cruise control and
>selected cellular phone functions.
In order to operate a system via
the MFL, the corresponding sys-
tem controls must be switched on.<
The illustration shows the maximum
possible number of controls, corre-
sponding to a full range of optional
equipment. Refer to the individual
accessory manuals for more detailed
descriptions.
1 Switch between the radio and the
cellular phone
2 Cellular phone: Receive a call, start
dialing, terminate a call
3 Radio/Cellular phone volume
4 Radio/Cellular phone: Search in re-
verse or station keys (or browse in list
of names)
5 Radio/Cellular phone: Search for-
wards or station keys (or browse in
list of names)463de057
6 Horn: The entire surface
7 Cruise control: Resume stored
setting
8 Cruise control: Store and accelerate
(+); decelerate and store (–)
9 Cruise control: Activate/Interrupt/
Cancel.

25n
RepairsIndexOverview Controls Car care Technology Data
Hazard warning flashers Warning triangle
*
First aid kit
*
The push button flashes rhythmically
when the hazard flashers are on.
To help you locate the switch in an
emergency, the button is also illumi-
nated whenever the car lamps are on.460us002
The hazard warning triangle is stored
in a recess on the left-hand side of the
luggage compartment where it is
quickly available.
Comply with legal requirements
that cover the availability of a
hazard warning triangle in the car.<460de071
The first aid kit is located under the
passenger seat.
To open: Pull the handle and fold the
cover down.
To close: Fold the cover up.
Some of the articles in the first aid
kit may be used within a limited
time only. For this reason, check the ex-
piration dates of each of the items regu-
larly, and replace any whose expiration
dates have passed. You can get re-
placements in any drugstore or phar-
macy. Comply with legal requirements
which cover availability of a first aid kit
in the car.< 462de196

26n
Refueling Fuel specificationsFuel filler doorPress on the rear edge of the fuel filler
door to open and close it.
To unlock the fuel filler door if the cen-
tral locking system malfunctions, refer
to page 155.
When handling fuels, comply with
all of the applicable safety precau-
tions and regulations pertaining to
fuels. Never carry spare fuel containers
in your vehicle. Whether empty or full,
these containers can leak, cause an ex-
plosion, or lead to fire in the event of a
collision.<462de275
Simple and environmentally
friendly
Carefully open the fuel filler cap,
as otherwise fuel could spray out.
Fuel spray may cause injury.<
Keep the filler cap in the bracket
attached to the fuel filler door.
When refueling, insert the filler nozzle
completely into the filler pipe. Pulling
the nozzle out of the pipe during refuel-
ing
>results in premature pump shutoff
>and will reduce the effect of the vapor
recovery system on the pump.
Close the fuel filler cap carefully
after refueling. A loose or missing
cap will activate the Check Engine
lamp.<
460de005
Use unleaded gasoline only.
Recommended fuel: premium with a
minimum octane rating of 91 AKI.
BMW engines are equipped with knock
sensors and will adapt automatically to
different octane ratings, provided that
the minimum octane requirement
(87 AKI) is met.
Fuels with higher octane ratings will pro-
vide enhanced performance and lower
fuel consumption, while the use of fuels
with lower octane ratings will have the
opposite effect.
Do not use leaded fuels. The use of
leaded fuels will cause permanent
damage to the system's oxygen sensor
and the catalytic convertor.<
AKI = Anti Knock Index

27n
RepairsIndexOverview Controls Car care Technology Data
Tire inflation pressure The inflation pressures are indicated on
a sticker attached to the B-pillar behind
the driver's door (visible with door
open).Check tire pressuresAll pressure specifications are stated in
psi (kilopascal) with cold tires (cold =
ambient temperature). Refer to the next
page as well.
For trailer towing, the inflation pressure
for heavier loads always applies.
For vehicles with RDC (Tire Pressure
Control)
*:
After a correction of the tire inflation
pressure, reactivate the system. Refer
to page 82.
462de197
Check tire inflation pressures reg-
ularly – at least every two weeks
and before beginning a longer trip. In-
correct tire pressure can otherwise lead
to tire damage and accidents.
Also check the inflation pressure of the
space-saver tire or spare tire
*. Inflate
the spare tire to the highest inflation
specified for your vehicle.<
Comply with tire approval
specificationsThe inflation pressures in the table apply
to tires from BMW-approved manufac-
turers. Your BMW center is familiar with
these pressures. Higher pressures may
be specified for tires from other manu-
facturers. You will find a list of approved
tires beginning on page 117.

28n
Tire inflation pressureBMW Tires
Inflation pressures in psi (kilopascal)
323CiSummer tires 29 (200) 33 (230) 33 (230) 41 (280)
Winter tires 32 (220) 36 (250) 36 (250) 44 (300)
328CiSummer tires 29 (200) 33 (230) 33 (230) 41 (280)
Winter tires 32 (220) 36 (250) 36 (250) 44 (300)
All Space-saver spare tire 61 (420) 61 (420) 61 (420) 61 (420)
For all-season tires, use the same tire inflation pressure as for summer tires.

29n
RepairsIndexOverview Controls Car care Technology Data

30n
Locks and security systems:
Keys32
Electronic vehicle
immobilizer33
Central locking system34
Door locks – from outside34
Using the key34
Using the remote control35
Door locks – from inside38
Luggage compartment lid39
Luggage compartment41
Alarm system42
Electric power windows44
Sliding/tilt sunroof45
Adjustments:
Seats47
Seat and mirror memory50
Steering wheel51
Mirrors52
Car Memory, Key Memory54
Passenger safety systems:
Safety belts55
Child restraint systems56
Airbags57
Driving:
Steering/ignition lock62
Starting the engine62
Switching off the engine63
Parking brake64
