1999 TOYOTA SOLARA Owners Manual

SOLARA_U225
Types A fuses can be pulled out by the
pull- out tool. The location of the pull- out
tool is shown in the illustration.
If you are not sure whether the fuse has
blown, try replacing the suspected fuse
with one that you know is good.
If the fuse has blown, push a new fuse
into the clip.
Only install a fuse with the amperage rat-
ing designated on the fuse box lid.
If you do not have a spare fuse, in an
emergency you can pull out the
ºMIRROR- HEATERº, ºDOMEº or ºA/Cº
fuse, which may be dispensable for
normal driving, and use it if its amperage
rating is the same.
If you cannot use one of the same amper-
age, use one that is lower,but as close as
possible to, the rating. If the amperage is
lower than that specified, the fuse might
blow out again but this does not indicate
anything wrong. Be sure to get the correct
fuse as soon as possible and return the
substitute to its original clip.
It is a good idea to purchase a set of
spare fuses and keep them in your ve-
hicle for emergencies.
If the new fuse immediately blows out,
there is a problem with the electrical sys-
tem. Have your Toyota dealer correct it as
soon as possible.
CAUTION
Never use a fuse with a higher am-
perage rating, or any other object, in
place of a fuse. This may cause ex-
tensive damage and possibly a fire.
Adding washer fluid
If any washer does not work or low
windshield washer fluid level warning
light comes on, the washer tank may be
empty. Add washer fluid.
You may use plain water as washer fluid.
However, in cold areas where tempera-
tures range below freezing point, use
washer fluid containing antifreeze. This
product is available at your Toyota dealer
and most auto parts stores. Follow the
manufacturer 's directions for how much to
mix with water.
NOTICE
Do not use engine antifreeze or any
other substitute because it may dam-age your vehicle's paint.

SOLARA_U
226
Replacing light bulbsÐ
The following illustrations show how to
gain access to the bulbs. When replacing
a bulb, make sure the ignition switch and
light switch are off. Use bulbs with the
wattage ratings given in the table.
CAUTION
Halogen bulbs have pressurized gas
inside and require special handling.
They can burst or shatter if scratched
or dropped. Hold a bulb only by its
plastic or metal case. Do not touch
the glass part of a bulb with barehands.
NOTICE
Only use a bulb of the listed type.
Light bulbsBulb
No.WTy p e
HeadlightsHB260/55A
Front fog lightsHB451B
Parking, front side
marker and front
turn signal lights
Ð27/8C
Rear turn signal
lights315627D
Stop and tail lights315727/8D
Back- up lights92118D
License plate lightsÐ5D
High mounted
stop light21CP18D
Personal lightÐ10E
Interior lightÐ10E
Vanity lightsÐ3E
Glovebox lightÐ1.2D
Trunk lightÐ3.8D
A: HB2 halogen bulbs
B: HB4 halogen bulbs
C: Single end bulbs
D: Wedge base bulbs
E: Double end bulbs

SOLARA_U227
ÐHeadlights
1. Open the hood. Unplug the connec-
tor. Remove the rubber cover.
If the connector is tight, wiggle it.2. Release the bulb retaining spring and remove the bulb. Install a new
bulb and the bulb retaining spring.
To install a bulb, align the tabs of the
bulb with the cutouts of the mounting
hole.3. Install the rubber cover with the ºTOPº mark upward, and snuggle on
the boss. Insert the connector. Then
install the plastic cover.
Make sure the rubber cover fits snugly on
the connector and the headlight body.
Aiming is not necessary after replacing
the bulb. When aiming adjustment is nec-
essary, contact your Toyota dealer.

SOLARA_U
228
ÐFront fog lights
1. Remove the bolts, take out the en-
gine under cover.2. Turn the bulb and remove it.3. Unplug the connector while depress-ing the lock release.
If the connector is tight, wiggle it.

SOLARA_U229
Use a Phillips- head screwdriver.Use a flat- bladed screw driver. To protect
the surface, place several sheets of paper
over the surface.
ÐParking, front side marker
and front turn signal lights

SOLARA_U
230
Type A Type B
Use a phillips- head screw driver. Remove
and install the cover clips as shown in
the following illustrations.
Removing cover clips Installing cover clips
Ty p e ARemoving cover clips Installing cover clips
Ty p e B
ÐRear turn signal, stop and
tail, and back- up lights

SOLARA_U231
a: Rear turn signal light
b: Stop and tail light
c: Back- up light
ÐLicense plate lights
( lef t sid e)

SOLARA_U
232
ÐLicense plate lights
(right side)
