1999 TOYOTA RAV4 Owners Manual

'99 Rav4.U1
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1- 1
Overview of instruments
and controls
Instrument panel overview
Instrument cluster overview
Indicator symbols on the
instrument panel

'99 Rav4.U
2
Instrument panel overview
1. Side vents
2. Instrument cluster
3. Center vents
4. Electric moon roof switch and personallights
5. Glove box
6. Power door lock switches (with power windows)
7. Power window switches
8. Parking brake lever
9. Automatic transmission selector lever or manual transmission gear shift lever
10. Ashtray
11. Lower vent
12. Hood lock release lever

'99 Rav4.U3
1. Instrument panel light control knob
2. Headlight and turn signal switch
3. Wiper and washer switches
4. Clock
5. Center differential lock button or driving
pattern selector button
6. Air conditioning controls
7. Emergency flasher switch
8. Rear window defogger switch
9. Car audio
10. Cigarette lighter
11. Ignition switch
12. Cruise control switch
13. Tilt steering lock release lever
14. Power door lock switch (without power windows)
15. Power rear view mirror control switch

'99 Rav4.U
4
Instrument cluster overview
1. Speedometer
2. Fuel gauge
3. Service reminder indicators and
indicator lights 4. Engine coolant temperature gauge
5. Tachometer
6. Trip meter reset knob
7. Odometer and two trip meters

'99 Rav4.U5
Indicator symbols on the instrument panel
Brake system warning light
*
1
Discharge warning light *
1
Low oil pressure warning light *
1
Malfunction indicator lamp *
1
Headlight high beam indicator light
SRS airbag warning light
*
1
Turn signal indicator lights
Seat belt reminder light
*
1
Open door warning light*
1
Low fuel level warning light *
1 Automatic transmission fluid temperature warning
light
*
1
Anti-lock brake system warning light
*
1
(type A)
(type B)
(type A)
(type B) (type A)
(type B)
Low windshield washer fluid level warning light
*
1

'99 Rav4.U
6
* 1
: For details, see ºService reminder indicators and warning
buzzersº in Chapter 1- 5.
* 2
: If this light flashes, see ºCruise controlº in Chapter 1- 6. Cruise control indicator light
*
2
Center differential lock indicator light
Driving pattern indicator light
Overdrive- off indicator light
Automatic transmission indicator light

'99 Rav4.U7
Part 1
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1- 2
Keys and Doors
Keys
Side doors
Power windows
Quarter window

Back door and tailgate

Hood
Fuel tank cap
Electric moon roof
Detachable sun roof
Soft- top
Keys
Your vehicle is supplied with two kinds
of key. 1. Master keyÐThis key works in every lock.
2. Sub keyÐThis key will not work in the glove box.
To protect things locked in the glove box
when you have your vehicle parked, leave
the sub key with the attendant.
Since the side doors, back door (hardtop)
and tailgate (soft- top) can be locked with-
out a key, you should always carry a
spare master key in case you accidentally
lock your keys inside the vehicle. KEY NUMBER PLATE
Your key number is shown on the plate.
Keep the plate in a safe place such as
your wallet, not in the vehicle.
If you should lose your keys or if you
need additional keys, duplicates can be
made by a Toyota dealer using the key
number.
We recommend you to write down the key
number and keep it in safe place.

'99 Rav4.U
8
Side doors
LOCKING AND UNLOCKING WITH KEY
Insert the key into the keyhole and turn it.
To lock: Turn the key forward.
To unlock: Turn the key backward.
Vehicles with power door lock systemÐAll
the side doors, back door (hardtop) and
tailgate (soft- top) lock and unlock simulta-
neously with either front door. In the driv-
er's door lock, turning the key once will
unlock the driver's door and twice in suc-
cession will unlock all the side doors,
back door (hardtop) and tailgate (soft- top)
simultaneously.LOCKING AND UNLOCKING WITH
INSIDE LOCK KNOB
Move the lock knob.
To lock: Push the knob forward.
To unlock: Pull the knob backward.
Closing the door with the lock knob in the
lock position will also lock the door. Be
careful not to lock your keys in the ve-
hicle.With power windows (Driver's side)
With power windows (Passenger's side)
