1999 TOYOTA 4RUNNER Owners Manual

4RUNNER ()265
17. HEAD (HI LH) 10 A:
Left- hand head-
light (high beam)
18. HEAD (LO RH) 10 A: Right- hand
headlight (low beam)
19. HEAD (LO LH) 10 A: Left- hand head-
light (low beam)
20. ECU- IG 10 A: Cruise control system,
anti- lock brake system, electronically
controlled automatic transmission sys-
tem, power antenna, power window,
electric moon roof, power back window,
back window defogger, back window
wiper
21. TURN 10 A: Turn signals lights, emer-
gency flashers
22. WIPER 20 A: Windshield wipers and
washer, power door lock control sys-
tem, back window defogger, horns,
theft deterrent system
23. 4WD 20 A: A.D.D. control system,
four- wheel drive control system, rear
differential lock system
24. ACC 15 A: Car audio system, power
antenna, clock, power rear view mirror
control, cigarette lighter, SRS airbag
system, seat belt pretensi oners, elec-
tronically controlled automatic transmis-
sion system, power outlets, theft deter-
rent system 25. GAUGE 10 A:
Gauges and meters,
back window defogger, daytime running
light system, air conditioning system,
cruise control system, rear differential
lock system, electronically controlled
automatic transmission, back- up lights
26. IGN 10 A: SRS airbag system, seat
belt pretensioners, multiport fuel injec-
tion system/sequential multiport fuel in-
jection system, discharge warning light
27. ECU- B 7.5 A: Gauges and meters,
SRS airbag system, seat belt preten-
sioners
28. HORN,HAZ 15 A: Horns, emergency
flashers
29. STA 7.5 A: Starting system
30. STOP 10 A: Stop lights, high- mounted
stoplight
Fuses (type B)
31. HEATER 50 A: Air conditioning system,
all components in ºA.Cº fuse
32. AM1 40 A: Starting system, all compo-
nents in ºACCº, ºGAUGEº, ºTURNº,
ºECU- IGº, ºWIPERº, º4WDº fuses
33. J/B 50 A: All components in ºPOWERº,
ºHORN,HAZº, ºSTOPº, ºECU- Bº fuses 34. AM2 30 A:
Starting system, multiport
fuel injection system/sequential multi-
port fuel injection system, all compo-
nents in ºSTAº, ºIGNº fuses
35. POWER 30 A: Power window, power
back window, electric moon roof, power
seat, back door lock
Fuses (type C)
36. ABS 60 A: Anti- lock brake system
37. ALT 120 A: Charging system, all com-
ponents in ºAM1º, ºHEATERº, ºTAILº,
ºRR HTRº, ºALT- Sº, ºDEFOGº, ºMIR
HTRº and ºACCº fuses

4RUNNER ()
266

4RUNNER ()267
Part 9
REPORTING SAFETY
DEFECTS FOR U.S.
OWNERS AND
UNIFORM TIRE
QUALITY GRADING
Reporting safety defects for U.S.
owners
Uniform tire quality grading
If you believe that your vehicle has
a defect whi ch coul d cause a cr ash
or could cause injury or death, you
should immediately inform the Na-
tional Highway Traffic Safety Ad-
ministration (NHTSA) in addition to
notifying Toyota Motor Sales,
U.S.A., Inc.
(Toll- free: 1- 800- 331- 4331).
If NHTSA receives similar com-
plaints, it may open an investiga-
tion, and if it finds that a safety de-
fect exists in a group of vehicles, it
may order a recall and remedy
campaign. However, NHTSA cannot
become involved in individual prob-
lems between you, your dealer, or
Toyota Motor Sales, U.S.A., Inc.
To contact NHTSA, you may either
call the Auto Safety Hotline toll- free
at 1- 800- 424- 9393 (or 366- 0123 in
Washington, D.C. area) or write to:
NHTSA. U.S. Department of Trans-
portation. Washington, D.C. 20590.
You can also obtain other information
about motor vehicle safety from the
Hotline.
Reporting safety defects
for U.S. owners

4RUNNER ()
268
Uniform tire quality grading
This information has been prepared in ac-
cordance with regulations issued by the
National Highway Traffic Safety Adminis-
tration of the U.S. Department of Trans-
portation. It provides the purchasers and/
or prospective purchasers of Toyota
vehicles with information on uniform tire
quality grading.
Your Toyota dealer will help answer any
questions you may have as you read this
information.
DOT quality gradesÐAll passenger ve-
hicle tires must conform to Federal
Safety Requirements in addition to
these grades. These quality grades are
molded on the sidewall.
Treadwear
ÐThe treadwear grade is a
comparative rating based on the wear rate
of the tire when tested under controlled
conditions on a specified government test
course. For example, a tire graded 150
would wear one and a half (1- 1/2) times
as well on the government course as a
tire graded 100. The relative performance
of tires depends upon the actual condi-
tions of their use, however, and may de-
part significantly from the norm due to
variations in driving habits, service prac-
tices and differences in road characteris-
tics and climate. Traction AA, A, B, C
ÐThe traction
grades, from highest to lowest, are AA, A,
B, and C, and they represent the tire's
ability to stop on wet pavement as mea-
sured under controlled conditions on spe-
cified government test surfaces of asphalt
and concrete. A tire marked C may have
poor traction performance.
Warning: The traction grade assigned to
this tire is based on braking (straight
ahead) traction tests and does not include
cornering (turning) traction.
Temperature A, B, C ÐThe temperature
grades are A (the highest), B, and C,
representing the tire's resistance to the
generation of heat and its ab ility to dissi-
pate heat when tested under controlled
conditions on a specified indoor laboratory
test wheel. Sustained high temperature
can cause the material of the tire to de-
generate and reduce tire life, and exces-
sive temperature can lead to sudden tire
failure. The grade C corresponds to a lev-
el of performance which all passenger car
tires must meet under the Federal Motor
Vehicle Safety Standard No. 109. Grades
B and A represent higher levels of perfor-
mance on the laboratory test wheel than
the minimum required by law. Warning: The temperature grades for this
tire are established for a tire that is prop-
erly inflated and not overloaded. Exces-
sive speed, underinflation, or excessive
loading, either separately or in combina-
tion, can cause heat buildup and possible
tire failure.
