1999 PONTIAC GRAND PRIX warning lights

yellowblue
v
For example,
these symbols
are used on an
original battery:
CAUTION
POSSIBLE
INJURY
PROTECT
EYES BY
SHIELDING
CAUSTIC
BATTERY
ACID COULD
CAUSE
BURNS
AVOID
SPARKS OR
FLAMES
SPARK OR
FLAME
COULD
EXPLODE
BATTERY
These symbols
are important
for you and
your passengers
whenever your
vehicle is
driven:
DOOR LOCK
UNLOCK
FASTEN
SEAT
BELTS
POWER
WINDOW
AIR BAG
These symbols
have to do with
your lamps:
MASTER
LIGHTING
SWITCH
TURN
SIGNALS
PARKING
LAMPS
HAZARD
WARNING
FLASHER
DAYTIME
RUNNING
LAMPS
FOG LAMPS
These symbols
are on some of
your controls:
WINDSHIELD
WIPER
WINDSHIELD
WASHER
WINDSHIELD
DEFROSTER
REAR
WINDOW
DEFOGGER
VENTILATING
FAN
These symbols
are used on
warning and
indicator lights:
ENGINE
COOLANT
TEMP
BATTERY
CHARGING
SYSTEM
BRAKE
COOLANT
ENGINE OIL
PRESSURE
ANTI-LOCK
BRAKES
Here are some
other symbols
you may see:
FUSE
LIGHTER
HORN
SPEAKER
FUEL
Vehicle Symbols
These are some of the symbols you may find on your vehicle.

2-
yellowblue
2-1
Section 2 Features and Controls
Here you can learn about the many standard and optional features on your vehicle, and information on starting,
shifting and braking. Also explained are the instrument panel and the warning systems that tell you if everything is
working properly
-- and what to do if you have a problem.
2
-2 Keys
2
-4 Door Locks
2
-8 Keyless Entry System (If Equipped)
2
-12 Multifunction Alarm Locks and
Lighting Choices
2
-22 Trunk
2
-23 Theft
2
-24 Content Theft-Deterrent (If Equipped)
2
-26 New Vehicle ªBreak-Inº
2
-26 Ignition Positions
2
-28 Starting Your Engine
2
-30 Engine Coolant Heater (If Equipped)
2
-32 Automatic Transaxle Operation
2
-36 Parking Brake
2
-37 Shifting Into PARK (P)
2
-40 Shifting Out of PARK (P)
2
-43 Parking Over Things That Burn2
-43 Engine Exhaust
2
-44 Running Your Engine While You're Parked
2
-45 Power Windows
2
-46 Turn Signal/Multifunction Lever
2
-51 Exterior Lamps
2
-54 Interior Lamps
2
-57 Mirrors
2
-59 Storage Compartments
2
-64 OnStar
System (Option)
2
-65 Sunroof (If Equipped)
2
-66 The Instrument Panel -- Your Information
System
2
-70 Warning Lights, Gages and Indicators
2
-82 Head-Up Display (Option)
2
-86 Driver Information Center (DIC)
(If Equipped)

yellowblue
2-27
ACCESSORY (A): This position lets you use things
like the radio and windshield wipers when the engine is
off. To use ACCESSORY, push in the key and turn it
toward you. The steering wheel will stay locked.
LOCK (B): Before you put the key into the ignition
switch, the switch is in LOCK. It's also the only position
from which you can remove the key. This position locks
the ignition, steering wheel and transaxle. It's a
theft
-deterrent feature.
OFF (C): This position lets you turn off the engine but
still turn the steering wheel. It doesn't lock the steering
wheel like LOCK. Use OFF if you must have the
vehicle pushed or towed.RUN (D): This position is where the key returns after you
start the vehicle. With the engine off, you can use RUN to
display some of the warning and indicator lights.
START (E): This position starts the engine.
A warning chime will sound if you open the driver's
door when the ignition is in OFF, LOCK or
ACCESSORY and the key is in the ignition.
NOTICE:
If your key seems stuck in LOCK and you can't
turn it, be sure you are using the correct key; if
so, is it all the way in? If it is, then turn the
steering wheel left and right while you turn the
key hard. But turn the key only with your hand.
Using a tool to force it could break the key or the
ignition switch. If none of this works, then your
vehicle needs service.
Retained Accessory Power (RAP)
With Retained Accessory Power, the power windows,
audio system and sunroof will continue to work up to
10 minutes after the ignition key is turned to OFF and
none of the doors are opened.

yellowblue
2-70
Warning Lights, Gages
and Indicators
This part describes the warning lights and gages that
may be on your vehicle. The pictures will help you
locate them.
Warning lights and gages can signal that something is
wrong before it becomes serious enough to cause an
expensive repair or replacement. Paying attention to
your warning lights and gages could also save you or
others from injury.
Warning lights come on when there may be or is a
problem with one of your vehicle's functions. As you
will see in the details on the next few pages, some
warning lights come on briefly when you start the
engine just to let you know they're working. If you are
familiar with this section, you should not be alarmed
when this happens.
Gages can indicate when there may be or is a problem
with one of your vehicle's functions. Often gages and
warning lights work together to let you know when
there's a problem with your vehicle.When one of the warning lights comes on and stays on
when you are driving, or when one of the gages shows
there may be a problem, check the section that tells you
what to do about it. Please follow this manual's advice.
Waiting to do repairs can be costly
-- and even
dangerous. So please get to know your warning lights
and gages. They're a big help.
Your vehicle may also have a driver information system
that works along with the warning lights and gages.
See ªDriver Information Systemº in the Index.
Safety Belt Reminder Light
When the key is turned to RUN or START, a chime will
come on for about eight seconds to remind people to
fasten their safety belts, unless the driver's safety belt is
already buckled.
The safety belt light will
also come on and stay on
for about 70 seconds, or
until the driver's seatbelt
is buckled.
If the driver's belt is already buckled, neither the chime
nor the light will come on.

yellowblue
2-82
Head-Up Display (Option)
CAUTION:
If the HUD image is too bright, or too high in
your field of view, it may take you more time to
see things you need to see when it's dark outside.
Be sure to keep the HUD image dim and placed
low in your field of view.
If you have the Head-Up
Display (HUD), you can see
the speedometer reading (in
English or metric units) and
a brief display of the current
radio station or CD track,
displayed ªthroughº
the windshield.The HUD also shows these lights when they are lit on
the instrument panel:

Turn Signal Indicators

High
-Beam Indicator Symbol

Low Fuel Symbol
The HUD will display ªCHECK GAGEº when the
following items are lit on the instrument panel:

Oil Warning Symbol

Coolant Temperature Symbol

Charging System Symbol
When you sit straight in your seat, the HUD image will
appear straight ahead near the front bumper.

yellowblue
4-39 Turn Signals When Towing a Trailer
When you tow a trailer, your vehicle may need a
different turn signal flasher and/or extra wiring. Check
with your dealer. The arrows on your instrument panel
will flash whenever you signal a turn or lane change.
Properly hooked up, the trailer lamps will also flash,
telling other drivers you're about to turn, change lanes
or stop.
When towing a trailer, the arrows on your instrument
panel will flash for turns even if the bulbs on the trailer
are burned out. Thus, you may think drivers behind
you are seeing your signal when they are not. It's
important to check occasionally to be sure the trailer
bulbs are still working.
Your vehicle has bulb warning lights. When you plug
a trailer lighting system into your vehicle's lighting
system, its bulb warning lights may not let you know
if one of your lamps goes out. So, when you have a
trailer lighting system plugged in, be sure to check your
vehicle and trailer lamps from time to time to be sure
they're all working. Once you disconnect the trailer
lamps, the bulb warning lights again can tell you if one
of your vehicle lamps is out.
Driving On Grades
Reduce speed and shift to a lower gear before you start
down a long or steep downgrade. If you don't shift
down, you might have to use your brakes so much that
they would get hot and no longer work well.
On a long uphill grade, shift down and reduce your
speed to around 45 mph (70 km/h) to reduce the
possibility of engine and transaxle overheating.
If you have overdrive, you may want to drive in
THIRD (3), instead of DRIVE (D).
Parking on Hills
CAUTION:
You really should not park your vehicle, with a
trailer attached, on a hill. If something goes
wrong, your rig could start to move. People can
be injured, and both your vehicle and the trailer
can be damaged.

yellowblue
6-26
Engine Coolant
The cooling system in your vehicle is filled with
DEX
-COOL
engine coolant. This coolant is designed
to remain in your vehicle for 5 years or 150,000 miles
(240 000 km), whichever occurs first, if you add only
DEX
-COOL
extended life coolant.
The following explains your cooling system and how to
add coolant when it is low. If you have a problem with
engine overheating or if you need to add coolant to your
radiator, see ªEngine Overheatingº in the Index.
A 50/50 mixture of clean, drinkable water and
DEX
-COOL
coolant will:

Give freezing protection down to
-34F (-37C).

Give boiling protection up to 265F (129C).

Protect against rust and corrosion.

Help keep the proper engine temperature.

Let the warning lights and gages work as
they should.
NOTICE:
When adding coolant, it is important that you use
only DEX
-COOL (silicate-free) coolant.
If coolant other than DEX-COOL is added to the
system, premature engine, heater core or
radiator corrosion may result. In addition, the
engine coolant will require change sooner
-- at
30,000 miles (50 000 km) or 24 months,
whichever occurs first. Damage caused by the use
of coolant other than DEX
-COOL is not
covered by your new vehicle warranty.

yellowblue
9-6
Instrument Panel 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brightness Control 2-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cleaning 6-53 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Cluster 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuse Block 6-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior Lamps 2-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inspections
Brake System 7
-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Cooling System 7-18 . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust Systems 7-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Front Drive Axle Boot 7-18 . . . . . . . . . . . . . . . . . . . . . . . . .
Front Drive Axle Seal 7-18 . . . . . . . . . . . . . . . . . . . . . . . . .
Steering 7-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inspections (Continued)
Suspension 7
-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Throttle System 7-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jack, Tire 5-24 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Jump Starting 5-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key in the Ignition 2-23 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Key Lock Cylinders Service 7-15 . . . . . . . . . . . . . . . . . . . . .
Key Reminder Warning 2-27 . . . . . . . . . . . . . . . . . . . . . . . . . .
Keyless Entry
Operation 2
-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Battery Replacement 2-10 . . . . . . . . . . . . . . . . . . . . . . . . . .
Matching Transmitter(s) to Your Vehicle 2-10 . . . . . . . . . . .
Resynchronization 2-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keys 2-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Labels
Certification/Tire 4-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Parts Identification 6-59 . . . . . . . . . . . . . . . . . . . . . Tire
-Loading Information 4-32 . . . . . . . . . . . . . . . . . . . . . .
Vehicle Identification Number 6-59 . . . . . . . . . . . . . . . . . . .
Lamps
Courtesy 2
-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Delayed Illumination 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . .
Exit Lighting 2-13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior 2-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior 2-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reading 2-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Latches, Seatback 1-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle with the Engine Running 2-39 . . . . . . .
Lighter 2-62 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lights
Air Bag Readiness 1
-24, 2-71 . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock Brake System Warning 2-73, 4-7 . . . . . . . . . . . .
Brake System Warning 2-72 . . . . . . . . . . . . . . . . . . . . . . . . .
Change Oil Soon 2-87 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System 2-71 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door Ajar 2-87, 2-91 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Coolant Temperature 2-79 . . . . . . . . . . . . . . . . . . . .
Enhanced Traction System Warning 2-74, 4-10 . . . . . . . . .
Interior 2-54 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Coolant Warning 2-80 . . . . . . . . . . . . . . . . . . . . . . . . .
Low Fuel 2-81 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Oil Level 2-79 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Low Trac 2-74, 2-87, 2-91 . . . . . . . . . . . . . . . . . . . . . . . . .
Low Traction 2-74, 4-10 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Warning 2-78 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Performance Shift 2-90 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Belt Reminder 1-9, 2-70 . . . . . . . . . . . . . . . . . . . . . .
Service Engine Soon 2-75 . . . . . . . . . . . . . . . . . . . . . . . . . .
TCS Off 2-73, 2-91 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trac Off 2-74, 2-87, 2-91 . . . . . . . . . . . . . . . . . . . . . . . . . .
