TORQUE WRENCH SETTINGS
06-11
Transfer box - LT230SE
† New nut must be fitted
* New Patchlok nut must be fitted
+ Apply sealant, Part No. STC 50552 to threads
TORQUE DESCRIPTION METRIC IMPERIAL
High/low selector cable 30 Nm (22 lbf.ft)
Bottom cover plate bolts + 25 Nm (18 lbf.ft)
Transfer box to gearbox bolts - Petrol and diesel + 45 Nm (33 lbf.ft)
Rear cover plate stud nut/bolts + 25 Nm (18 lbf.ft)
Differential lock warning lamp switch locknut - Up to 03 MY 11 Nm (8 lbf.ft)
Differential lock warning lamp switches - 03 MY onwards + 25 Nm (18 lbf.ft)
Drive flange nut 148 Nm (109 lbf.ft)
Output shaft housing bolts + 45 Nm (33 lbf.ft)
Oil temperature sensor - If fitted + 25 Nm (18 lbf.ft)
Inhibitor switch to transfer box 26 Nm (19 lbf.ft)
Intermediate shaft nut † 88 Nm (65 lbf.ft)
Intermediate shaft retaining plate bolt + 25 Nm (18 lbf.ft)
Differential bearing retaining nut * 72 Nm (53 lbf.ft)
Output flange nut 162 Nm (119 lbf.ft)
High/Low selector housing bolts + 25 Nm (18 lbf.ft)
Bearing housing/cover bolts + 25 Nm (18 lbf.ft)
Blanking plug + 25 Nm (18 lbf.ft)
High/Low selector warning lamp switch 25 Nm (18 lbf.ft)
Differential lock selector housing bolts + 25 Nm (18 lbf.ft)
Neutral sensor 25 Nm (18 lbf.ft)
Interlock solenoid bolts - Up to 03 Model Year 10 Nm (7 lbf.ft)

TORQUE WRENCH SETTINGS
06-12
Automatic gearbox - ZF4HP22
+ Apply sealant, Part No. STC 50553 to threads
TORQUE DESCRIPTION METRIC IMPERIAL
Selector lever to selector shaft nut 26 Nm (19 lbf.ft)
Starter inhibitor switch bolts 10 Nm (7 lbf.ft)
Engine to torque converter bolts - Td5 & V8 + 50 Nm (37 lbf.ft)
Closing plate to gearbox housing bolt - V8 7 Nm (5.2 lbf.ft)
Fluid pump to intermediate plate bolts 10 Nm (7 lbf.ft)
Intermediate plate Allen plugs (M14) 40 Nm (30 lbf.ft)
Intermediate plate Allen plugs (M20) 50 Nm (37 lbf.ft)
Oil cooler adaptors42 Nm (31 lbf.ft)
Extension housing bolts 25 Nm (18 lbf.ft)
Oil sump to gearbox housing bolts 8 Nm (6 lbf.ft)
Oil filter Torx screws8 Nm (6 lbf.ft)
Oil pick-up tube Torx screw 8 Nm (6 lbf.ft)
Parking pawl guide Torx screw 10 Nm (7 lbf.ft)
Pressure regulator to valve body assembly 8 Nm (6 lbf.ft)
Lock-up solenoid valve, retaining fork Torx screw 8 Nm (6 lbf.ft)
Lock-up solenoid valve assembly to valve body Torx screws 8 Nm (6 lbf.ft)
Gearbox bell housing (intermediate plate and converter housing to gearbox casing) bolts 46 Nm (34 lbf.ft)
Speed sensor bracket screws 8 Nm (6 lbf.ft)

TORQUE WRENCH SETTINGS
06-16
Rear suspension
TORQUE DESCRIPTION METRIC IMPERIAL
Wheel nuts140 Nm (103 lbf.ft)
Wheel hub to axle 100 Nm (74 lbf.ft)
Damper to axle125 Nm (92 lbf.ft)
SLS height sensor link to radius arm 25 Nm (18 lbf.ft)
Radius arm230 Nm (170 lbf.ft)
Transverse links to pivot housing 155 Nm (114 lbf.ft)
Pivot housing to axle bolts 230 Nm (170 lbf.ft)
Transverse link to chassis 140 Nm (103 lbf.ft)
SLS height sensor 6 Nm (4.4 lbf.ft)
SLS compressor25 Nm (18 lbf.ft)
ACE actuator to short arm 185 Nm (136 lbf.ft)
ACE actuator to long arm 48 Nm (35 lbf.ft)
ACE actuator pipe cap nuts 29 Nm (21 lbf.ft)
Anti-roll bar link - upper 50 Nm (37 lbf.ft)
Anti-roll bar link - lower 100 Nm (74 lbf.ft)
ACE long arm to torsion bar 180 Nm (133 lbf.ft)

CAPACITIES, FLUIDS, LUBRICANTS AND SEALANTS
09-4
Gearbox oil
Manual Gearbox: Use Texaco MTF 94 oil for refill
and topping-up.
Automatic Gearbox: Use Texamatic 9226, ATF
Dexron 11D or Dexron 111 for refill and topping-up
Transfer box
Use Texaco Multi-Gear 75W/90R or oil meeting
specification API GL5.
Front and rear axles
Use Texaco Multi-Gear 75W/90R.
Air Conditioning
Use lubricating oil Nippon Denso ND-8.
General Greasing
Use Multipurpose Lithium Base Grease N.L.G.I.
consistency No. 2.
Bonnet latch
Lubricate cable and latch with oil.
Sealants
The following table lists those sealants which are
used during repair / overhaul procedures covered in
this manual; it is essential that the sealant specified
for a particular procedure is used at all times.
Component Application Land Rover
Part No.
Td5 Engine Timing chain fixed
guide Allen screwSTC 50552
Td5 Engine Camshaft cover
gasket joint lineSTC 50550
Td5 Engine Oil pick-up strainer
Torx screwsSTC 50552
Td5 Engine Oil pump drive
sprocket retaining
boltSTC 50552
Td5 Engine Timing chain cover,
crankshaft rear oil
seal and sump
gasket joint linesSTC 50550
Td5 Engine Oil pressure relief
valve plugSTC 50552
Td5 Engine Camshaft carrier to
cylinder headSTC 4600
Td5 Engine Timing cover STC 50550
V8 Engine Sump gasket to
cylinder blockSTC 50550
V8 Engine 'V' grooves at end
of cylinder head -
Inlet manifold
gasketSTC 50550
V8 Engine Cruciform seal
endsSTC 50550
V8 Engine Dipstick tube STC 50554
V8 Engine Timing cover bolts STC 50552
Engine
Management
System - V8Engine coolant
temperature (ECT)
sensor threadsSTC 50552
Manifolds and
Exhaust
System - V8'V' grooves at end
of cylinder head -
Inlet manifold
gasketSTC 50550
Manual
Gearbox -
R380Gear selector
housingSTC 4404
Manual
Gearbox -
R380Selector housing
boltsSTC 50552
Manual
Gearbox -
R380Input shaft oil seal
housingSTC 4404
Manual
Gearbox -
R380Reverse inhibitor
shaft threadsSTC 50552

CAPACITIES, FLUIDS, LUBRICANTS AND SEALANTS
09-5
Manual
Gearbox -
R380Gate plate bolts STC 50552
Manual
Gearbox -
R380Gear case to
extension housingSTC 4404
Manual
Gearbox -
R380Extension housing
boltsSTC 50552
Manual
Gearbox -
R380Gear change lever
yoke Allen screwSTC 50552
Manual
Gearbox -
R380Gear case to centre
plateSTC 4404
Manual
Gearbox -
R380Detent plugs STC 50552
Manual
Gearbox -
R380Bias spring
adjustment plate
boltsSTC 50552
Transfer Box -
LT230SEBottom cover plate STC 4600
Transfer Box -
LT230SEBottom cover plate
boltsSTC 50552
Transfer Box -
LT230SEFront output
housing core plugSTC 3811
Transfer Box -
LT230SETransfer box to
gear case bolts -
Petrol and Diesel
enginesSTC 50552
Transfer Box -
LT230SETransfer box to
gear case studs -
Petrol and Diesel
enginesSTC 50552
Transfer Box -
LT230SERear cover STC 4600
Transfer Box -
LT230SEDifferential warning
lamp switch(es)STC 50552
Transfer Box -
LT230SEHigh/Low selector
warning lamp
switchSTC 50552
Transfer Box -
LT230SERear output shaft
housingSTC 4600
Transfer Box -
LT230SERear output shaft
housing boltsSTC 50552
Transfer Box -
LT230SEHigh/Low selector
fork set screwSTC 50552
Transfer Box -
LT230SEInterlock solenoid
selector cover - Up
to 03 MYSTC 4600
Transfer Box -
LT230SEInterlock solenoid
circlip - 03 MY
onwardsSTC 50551
Transfer Box -
LT230SENeutral sensor STC 50552
Transfer Box -
LT230SEIntermediate shaft
retaining plate boltSTC 50552Transfer Box -
LT230SESide cover STC 4600
Transfer Box -
LT230SESide cover bolts STC 50552
Transfer Box -
LT230SEDifferential lock
selector shaft
detent plugSTC 50552
Transfer Box -
LT230SEDifferential lock
selector housing
boltsSTC 50552
Transfer Box -
LT230SEFront output shaft
housingSTC 4600
Transfer Box -
LT230SEFront output shaft
housing boltsSTC 50552
Transfer Box -
LT230SEHigh/Low selector
shaft detent plugSTC 50552
Transfer Box -
LT230SEInput gear bearing
housingSTC 4600
Transfer Box -
LT230SERear cover stud nut
and boltSTC 50552
Transfer Box -
LT230SEHigh/Low cross
shaft housingSTC 4600
Transfer Box -
LT230SEHigh/Low cross
shaft housing boltsSTC 50552
Automatic
gearbox -
ZFHP22-24Torque converter
housing to engine
boltsSTC 50553
Rear Axle and
Final DriveDifferential cover to
casingSTC 3811
Rear Axle and
Final DriveDifferential cover to
casing boltsSTC 50552
Front axle Differential cover to
casingSTC 3811
Front axle Differential cover to
casing boltsSTC 50552
Front
suspensionDrive shaft to hub STC 50554
Rear
suspensionDrive shaft to hub STC 50554
Rear
suspensionSLS air compressor
boltsSTC 50552

MAINTENANCE
PROCEDURES 10-7
Road wheel speed sensors
Inspect
Front wheel
Rear wheel
1.Inspect each sensor harness for damage.
Brake fluid
Replace
1.Replace brake fluid.

+ BRAKES, ADJUSTMENTS, Brake
system bleeding.
Fuel filter - diesel engine
Replace
1.Replace filter element.

+ ENGINE MANAGEMENT SYSTEM -
Td5, REPAIRS, Element - fuel filter.
Fuel filter sedimenter
Drain
1.Position suitable container beneath fuel filter.
2.Disconnect multiplug from sedimenter.
3.Rotate sedimenter anti-clockwise until water
flows from drain tube.
4.Allow to drain until diesel fuel flows from drain
tube.
5.Rotate sedimenter fully clockwise.
6.Connect multiplug.

MAINTENANCE
10-8 PROCEDURES
Road wheels
Refit
1.Apply anti-seize compound to wheel hub
centre.
2.Refit road wheels to original hub position.
Tighten wheel nuts to 140 Nm (103 lbf.ft).
Radiator/Intercooler
Check
1.Visually check radiator/intercooler for external
obstructions, remove debris.
2.Visually check fan blades for damage.
Ambient air Temperature and pressure
sensor
Check
1.Check ambient air temperature and pressure
sensor for damage.
Doors, bonnet and fuel filler flap
Check
1.Check operation of each door, door lock,
bonnet catch and fuel filler flap. Ensure doors
close securely.
Lubricate
1.Lubricate door locks, hinges, check straps,
bonnet catch and fuel filler flap.

+ CAPACITIES, FLUIDS,
LUBRICANTS AND SEALANTS,
Lubrication.

MAINTENANCE
PROCEDURES 10-27
Steering rod ball joints
Check
1.Check condition of ball joints and dust covers,
and security of fixings.

+ TORQUE WRENCH SETTINGS,
Steering.
2.Attempt to move the ball joints forwards,
backwards, side to side and up and down. No
end float in any direction should be detected. If
end float is present, the ball joint must be
renewed.
Dampers and SLS height sensors
Check – Dampers
Front dampers
Rear dampers
1.Check dampers for security and signs of
leakage.
