1999 HONDA ODYSSEY headlight bulb

Maintenance

This section explains why it is important to keep your vehicle well
maintained and to follow basic
maintenance safety precautions.
This section also includes Maintenance Schedules for normaldriving and severe driving conditions,
a Maintenance Record, and instruc-
tions for simple maintenance tasks
you may want to take care of yourself.
If you have the skills and tools to per-
form more complex maintenance tasks on your Honda, you may want
to purchase the Service Manual. See page 333 for information on how toobtain a copy, or see your Honda
dealer.
Maintenance Safety.......................
220

Important Safet
y
Precautions ..

221

Maintenance Schedule.................
.
222

Required Maintenance Record.... 229
Owner Maintenance Checks........ 231

Fluid Locations............................... 232

Engine Oil....................................... 233
Adding Oil................................... 233
Recommended Oil..................... 233
Synthetic Oil............................... 234

Additives..................................... 235
Changing the Oil and Filter...... 235

Cooling System.............................. 237
Adding Engine Coolant............. 237Replacing Engine Coolant........ 239

Windshield Washers..................... 242
Automatic Transmission Fluid..... 243
Brake Fluid..................................... 244
Brake System............................. 244

Power Steering............................... 245

Air Cleaner Element...................... 246
Hood Latch..................................... 248

Spark Plugs..................................... 248
Replacement............................... 248
Specifications............................. 250

Battery............................................ 251
Wiper Blades.................................. 253
Air Conditioning System............... 255

Air Conditioning Filter.................. 256

Drive Belts...................................... 256

Timing Belt..................................... 257

Tires................................................ 257 Inflation....................................... 257
Inspection................................... 259Maintenance............................... 260
Tire Rotation.............................. 260
Replacing Tires and Wheels.... 261

Wheels and Tires....................... 262 Winter Driving........................... 262
Snow Tires.............................. 263

Tire Chains............................. 263

Lights..............................................264
Headlight Aiming...................... 266
Replacing Bulbs......................... 266

Storing Your Vehicle..................... 275

MaintenanceProCarManuals.comMain Menu s t

Lights

Check the operation of your vehicle's
exterior lights at least once a month.
A burned out bulb can create an unsafe condition by reducing your
vehicle's visibility and the ability to signal your intentions to other

drivers.
HEADLIGHT

TURN SIGNAL/

SIDE MARKER/
PARKING LIGHTS
MaintenanceProCarManuals.comMain Menu Table of Contents s t

Lights

STOP/TAILLIGHTS/
SIDE MARKER LIGHTS
TAILLIGHT


HIGH-MOUNT BRAKE LIGHT
TURN SIGNAL LIGHT

BACK-UP LIGHT
LICENSE PLATE LIGHT
Check the following: Headlights (low and high beam)
Parking lights
Taillights Brake lights High-mount brake light
Turn signals
Back-up lights
Hazard light function
License plate light
Side marker lights
Daytime running lights
(Canadian models)
If you find any bulbs are burned out,
replace them as soon as possible. Refer to the chart on page 317 to
determine what type of replacement
bulb is needed.
MaintenanceProCarManuals.comMain Menu Table of Contents s t

Lights

Headlight Aiming
The headlights were properly aimed when your vehicle was new. If youregularly carry heavy items in thecargo area or pull a trailer,

readjustment may be required.

Adjustment of the headlights should be performed by a Honda technicianor other qualified mechanic. Replacing a Headlight Bulb
Your vehicle has halogen headlight bulbs, one on each side. When
replacing a bulb, handle it by its steel
base and protect the glass fromcontact with your skin or hard
objects. If you touch the glass, clean
it with denatured alcohol and a clean cloth.
Halogen headlight bulbs get very hot when lit. Oil, perspiration, or a scratch
on the glass can cause the bulb to

overheat and shatter.

1. Open the hood. If you need to change the head-
light bulb on the driver's side, remove the air intake cover (see
page 246). HOLD-DOWN WIRE

WEATHER

SEAL

BULB
CONNECTOR
2. Remove the electrical connector from the bulb by pulling theconnector straight back.
3. Remove the rubber weather seal by pulling on the tab.
4. Unclip the end of the hold-down wire from its slot. Pivot it out ofthe way and remove the bulb.
Maintenance
NOTICEProCarManuals.comMain Menu Table of Contents s t

Lights

5. Insert the new bulb into the hole, making sure the tabs are in theirslots. Pivot the hold-down wire
back in place and clip the end into
the slot.
6. Install the rubber seal over the back of the headlight assembly.
Make sure it is right side up; it is
marked "TOP."
7. Push the electrical connector onto the new bulb.
Turn on the headlights to test the new bulb.
8. (Driver's side) Reinstall the air intake cover. Replacing the Front Side Marker/
Turn Signal and Parking Light Bulb
HOLDING CLIP
1. If you are changing the bulb on the driver's side, start the engine,turn the steering wheel all the way
to the right, and turn off theengine. If you are changing the
bulb on the passenger's side, turn
the steering wheel to the left. 2. Use a flat-tipped screwdriver to
remove the two holding clips fromthe inner fender.
3. Pull the inner fender away from the fender and bumper.

CONTINUED

MaintenanceProCarManuals.comMain Menu Table of Contents s t

Lights

4. Remove the socket from the headlight assembly by turning itone-quarter turn counterclockwise.
5. Remove the burned out bulb from the socket by pushing it in and
turning counterclockwise until it

unlocks.

6. Install the new bulb in the socket. Turn it clockwise to lock it in place.
7. Insert the socket back into the headlight assembly. Turn it
clockwise to lock it in place.
8. Test the lights to make sure the new bulb is working.
9. Put the inner fender in place. Install the two holding clips. Lock
each clip in place by pushing on
the center. Replacing Rear Bulbs
(in Fenders)
1. Open the tailgate. Pull out the covers by carefully prying on the
edge with a small flat-tippedscrewdriver.
2. Use a Phillips-head screwdriver to remove the taillight assembly
mounting screw under each cover.
3. Pull the taillight assembly out of the body by sliding it backward.
4. Determine which of the two bulbs

is burned out: stop/taillight/side

marker light or turn signal light.
