1999 HONDA CIVIC COUPE Owners Manual

Emergency Towing

plugged into the accessory powersocket are turned off so they do not
run down the battery.
Trying to lift or tow your vehicle by
the bumpers will cause serious
damage. The bumpers are not designed to support the vehicle's

weight.

Taking Care of the Unexpected

The steering system can be
damaged if the steering wheel is locked. Leave the ignition switch in
Accessory (I), and make sure the steering wheel turns freely before
you begin towing.
NOTICE
NOTICEMain Menu Table of Contents s t

Technical Information

The diagrams in this section give you the dimensions and capacities of
your Honda, and the locations of the identification numbers. The expla-
nations of several electronic and
mechanical systems on your Honda
are for the more technically-oriented
owner. Identification Numbers................. 244
Specifications................................. 246
Tire Information............................ 249 Tire Size Designation................ 249
Wheel Size Designation............ 249
Tire Speed Ratings.................... 249
Tire Pressure Adjustment For High Speed Driving............... 250
DOT Tire Quality Grading....... 250
Treadwear.............................. 250
Traction.................................. 251Temperature.......................... 251
Oxygenated Fuels.......................... 252
Driving in Foreign Countries....... 253 Emissions Controls........................ 254
The Clean Air Act...................... 254Crankcase Emissions Control System..................................... 254
Evaporative Emissions Control System..................................... 254
Onboard Refueling Vapor Recovery................................. 254
Exhaust Emissions Controls.... 255 PGM-FI System..................... 255
Ignition Timing ControlSystem................................. 255
Exhaust Gas Recirculation (EGR) System.................... 255
Three Way Catalytic Converter............................ 255
Replacement Parts..................... 255
Three Way Catalytic Converter... 256

Technical InformationMain Menu s t

Identification Numbers

Your car has several identifying numbers located in various places.
The Vehicle Identification Number (VIN) is the 17-digit number your
Honda dealer uses to register your
car for warranty purposes. It is also
necessary for licensing and insuring
your car. The easiest place to find the VIN is on a plate fastened to the
top of the dashboard. You can see it
by looking through the windshieldon the driver's side. It is also on theCertification label attached to the
driver's doorjamb, and is stamped on
the engine compartment bulkhead.
The VIN is also provided in bar code on the Certification label.

Technical Information
VEHICLE IDENTIFICATION NUMBER
CERTIFICATION LABELMain Menu Table of Contents s t

Identification Numbers

The Engine Number is stamped into the engine block.
The Transmission Number is on a label on top of the transmission.

Technical Information
TRANSMISSION NUMBER
ENGINE NUMBERMain Menu Table of Contents s t

Specifications

*
1
: DX
* 2 : U.S.: HX, EX, Canada: Si
* 3 : U.S.: DX, HX, Canada: DX
* 4 : U.S.: EX, Canada: Si
* 5 : U.S.: Si, Canada: SiR

Technical Information
page 188Main Menu Table of Contents s t

Specifications

* 1 : Including the coolant in the reserve tank and that remaining in the

engine.
Reserve tank capacity: 0.11 US gal (0.4 , 0.09 Imp gal)
* 2 : Excluding the oil remaining in the engine.
* 3: U.S.: DX, Canada: DX

* 4: U.S.:HX, EX, Canada: Si
* 5: DX

* 6: U.S.: HX, EX, Canada: Si

* 7 : U.S.: Si, Canada: SIR

* 8 : Canadian Car
* 9:
U.S.:
HX
(CVT)

Technical InformationCONTINUEDMain Menu Table of Contents s t

Specifications

* 1 : U.S.: DX and HX without ABS, Canada: DX without ABS
* 2 : U.S.: EX without ABS, Canada: Si without ABS
* 3 : U.S.: Cars equipped with ABS, Canada: Cars equipped with ABS

* 4: U.S.: Si, Canada: SiR

Technical Information
page 239

page 240Main Menu Table of Contents s t

Tire Information

Tire Size Designation A tire's sidewall is marked with a tire size designation. You will need this
information when selecting replace-
ment tires for your vehicle. The
following explains what the letters and numbers in the tire size
designation mean.
(Example tire size designation)
P185/65R14 85S
P — Applicable vehicle type (tires
marked with the prefix "P" are
intended for use on passenger cars;
however, not all tires have this
marking).
185 — Tire width in millimeters.
65 — Aspect ratio. The tire's section
height as a percentage of its width.
R — Tire construction code (Radial). 14 — Rim diameter in inches. 85 — Load Index, a numerical code
associated with the maximum load
the tire can carry.
S — Speed Symbol. See the speed
rating chart in this section for additional information.
Wheel Size Designation Wheels are also marked with important information that you need
if you ever have to replace one. The
following explains what the letters and numbers in the wheel size
designation mean.
(Example wheel size designation)
14x5J
14 — Rim diameter in inches.
5 — Rim width in inches.
J — Rim contour designation. Tire Speed Ratings
The chart below shows many of the different speed ratings currently
being used for passenger vehicle
tires. The speed symbol is part of the tire size designation on the sidewallof the tire. This symbol corresponds
to that tire's designed maximum safe
operating speed.

Technical InformationMain Menu Table of Contents s t
