1999 DODGE RAM engine

converter lock-up. ECM uses various input signals such as transmission
temperature, output shaft speed, central module timer, engine speed,
APPS and brake switch position to determine operation of transmission
torque converter clutch solenoid. Transmission torque converter clutch
solenoid is located on transmission valve body.
FUEL SYSTEM
FUEL DELIVERY
Fuel Injection Pump
A camshaft-driven Bosch VP44 in-line fuel injection pump is
used to supply high pressure fuel to each fuel injector in precise
metered amounts at the correct time. See Fig. 2. The pump is timed to
camshaft gear. Pump output is controlled by integral Fuel Pump Control
Module (FPCM). Because of electronic control, idle speeds and pump
timing are not adjustable. See ON-VEHICLE ADJUSTMENTS - TRUCKS -
DIESEL article. FPCM can operate engine if crankshaft position sensor
signal does not exist. Fuel injection occurs near completion of
compression stroke for each cylinder.
Fuel injection pump contains an overflow valve which allows
excess fuel to return to the fuel tank. Overflow valve is located on
side of fuel injection pump and is used to attach the fuel return line
to the fuel injection pump.
Fuel Transfer Pump
Fuel transfer pump is located on driver's side of cylinder
block, above starter. See Fig. 2. A 12 volt, 12-amp electric vane-type
pump supplies low fuel pressure from fuel tank, through fuel
heater/fuel filter/water separator to fuel injection pump. Fuel
transfer pump contains internal check valves to prevent fuel from
bleeding back into fuel tank during engine shutdown. Pump will self
prime with ignition on for 2 seconds. Pump has 2 modes, 100 percent
duty cycle (10 psi) when engine is running and 25 percent duty cycle
(7 psi) when engine is cranking.
Fuel Filter/Water Separator
Fuel filter/water separator, located on left side of engine,
protects injection pump by removing water and contaminants from fuel.
See Fig. 2 . Assembly also includes fuel heater and Water-In-Fuel (WIF)
sensor.
In-Tank Fuel Filter
A separate in-tank fuel filter is attached to bottom of fuel
tank module. In-tank fuel filter does not require service under normal
conditions.
FUEL CONTROL
Fuel Injector
Fuel injector delivers atomized fuel into the cylinder.
During fuel injection, fuel pressure from fuel injection pump
increases to fuel injector opening pressure or pop pressure of 4500
psi (316 kg/cm

). This is the pressure required to lift fuel injector
needle valve from its seat, allowing fuel to be injected into the
cylinder. Once fuel pressure decreases to less then the opening
pressure, a spring forces needle valve closed and stops fuel injection
into the cylinders. Each fuel injector is connected to injection pump
by a high pressure (as much as 17,405 psi) line.
Fuel Injection Timing
Pump output is controlled by integral Fuel Pump Control

Module (FPCM). Because of electronic control, pump timing is not
adjustable. See ON-VEHICLE ADJUSTMENTS - TRUCKS - DIESEL article.
FUEL FILTER/WATER SEPARATOR
Fuel filter/water separator is located on left side of engine
and contains fuel heater, Water-In-Fuel (WIF) sensor and drain valve.
See Fig. 2 . The WIF sensor delivers an input signal to Engine Control
Module (ECM) when water exists in fuel filter/water separator. ECM
will then turn on WATER-IN-FUEL warning light. WATER-IN-FUEL warning
light is located on instrument panel, just below tachometer. The
WATER-IN-FUEL warning light informs the operator to drain water from
fuel filter/water separator to prevent damage to fuel system
components. Water may be drained from fuel filter/water separator by
using drain valve on fuel filter/water separator.
FUEL HEATER
Fuel heater is used to prevent diesel fuel from waxing during
cold temperatures. Fuel heater is located in fuel filter/water
separator. See Fig. 2. Fuel flows from fuel tank to fuel transfer pump
and then to fuel filter/water separator. Fuel heater contains a fuel
heater temperature sensor that senses the fuel temperature. When
temperature is less than 37-53
F (3-12C), fuel heater temperature
sensor allows current to flow to the fuel heater to warm the fuel.
When temperature is more than 67-83
F (19-28C), fuel heater
temperature sensor turns off the current flow to the fuel heater.
Voltage to operate fuel heater is provided from ignition switch,
through fuel heater relay and to fuel heater. Fuel heater and fuel
heater relay are not controlled by Engine Control Module (ECM).
EMISSION SYSTEMS
INTAKE MANIFOLD AIR HEATER SYSTEM
Intake manifold air heater is used to warm intake air during
cold starting conditions. Heater system consists of 2 relays and 2
grid heaters installed on top of intake manifold. See Fig. 5.
Engine Control Module (ECM) energizes intake manifold air
heater relays to provide voltage to intake manifold air heater before
and after starting depending on input signals from intake manifold air
temperature sensor, engine speed sensor and vehicle speed. Intake
manifold air heater relays are not energized when intake manifold air
temperature is greater than 59
F (15C) or during engine cranking.
Intake manifold air heater relays are mounted on left inner wheelwell,
below left side battery. See Fig. 6.
Intake manifold air temperature sensor monitors intake
manifold air temperature and delivers an input signal to ECM for
controlling intake manifold air heater. Intake manifold air
temperature sensor is located in intake manifold. See Figs. 2 and 4.
SELF-DIAGNOSTIC SYSTEM
DATA LINK CONNECTOR
The Data Link Connector (DLC) is a 16-pin connector located
at lower edge of driver's side of instrument panel, just above the
accelerator pedal. The Engine Control Module (ECM) contains a self-
diagnostic system which stores a Diagnostic Trouble Code (FTC) if an
incorrect signal or no signal is received from certain sensors or
components. FTC may be retrieved from ECM for system diagnosis by

using DLC and a scan tool. The DLC also provides a means to
communicate with various vehicle control modules, check system
operating conditions and to operate various system components.
MALFUNCTION INDICATOR LIGHT (MIL)
The MIL is located on the instrument panel, just below
tachometer and may also be referred to as the CHECK ENGINE light. MIL
comes on for a short period and then goes off as a bulb and wiring
circuit test each time ignition switch is turned to the ON position.
If Engine Control Module (ECM) receives an incorrect signal or
receives no signal from certain sensors or components, ECM will turn
on the MIL to warn the driver that a malfunction exists in the
electronic system.
MISCELLANEOUS CONTROLS
TRANSMISSION
Transmission Overdrive Solenoid (A/T Models)
Engine Control Module (ECM) operates transmission overdrive
solenoid for controlling transmission overdrive shifts. Transmission
overdrive solenoid is located on transmission valve body.
Transmission Torque Converter Clutch Solenoid (A/T Models)
Engine Control Module (ECM) operates transmission torque
converter clutch solenoid for torque converter lock-up. ECM uses
various input signals such as transmission temperature, output shaft
speed, central module timer, engine speed, APPS and brake switch
position to determine operation of transmission torque converter
clutch solenoid. Torque converter clutch solenoid is located on
transmission valve body.


E - T H EO RY/O PER ATIO N - R W D - G ASO LIN E

1999 D odge P ic ku p R 1500
1999 ENGINE PERFORMANCE
CHRY - Theory & Operation - Trucks & RWD Vans - Gasoline
Dakota, Durango, Ram Pickup, Ram Van, Ram Wagon
INTRODUCTION
This article covers the basic description and operation of
engine performance related systems and components. Read this article
before working on unfamiliar systems.
COMPUTERIZED ENGINE CONTROLS
POWERTRAIN CONTROL MODULE (PCM)
The PCM is a digital computer that controls ignition timing,
air/fuel ratio, fuel injector pulse width, ignition coil(s), spark
advance, emission control devices, cooling fan, charging system, idle
speed, cruise control (if equipped), fuel pump and tachometer. For PCM\
location, see PCM LOCATION. PCM uses data from various input sources
to control output devices in order to achieve optimum engine
performance for all operating conditions.
PCM has voltage converters that convert battery voltage to
regulated 5-volt output. The 5-volt output powers battery temperature
sensor, Camshaft Position (CMP) sensor on models equipped with
Distributorless Ignition System (DIS) or distributor on models without\
DIS, Crankshaft Position (CKP) sensor, Engine Coolant Temperature
(ECT) sensor, Intake Air Temperature (IAT) sensor, logic circuits,
Manifold Absolute Pressure (MAP) sensor, Throttle Position (TP) sens\
or
and Vehicle Speed Sensor (VSS) on some models.
PCM LOCATION









\









\









\









\









\









\









\







Application Location
Dakota & Durango ................. Right Front Fender, Near Firewall
Ram Pickup, Ram Van & Ram Wagon .... On Firewall, Near Wiper Motor









\









\









\









\









\









\









\







NOTE: Components are grouped into 2 categories. The first category,
INPUT DEVICES, includes components that control or produce
voltage signals monitored by the PCM. The second category,
OUTPUT SIGNALS, includes components controlled by the PCM
(this is accomplished by the PCM grounding individual
circuits).
INPUT DEVICES
Vehicles are equipped with different combinations of input
devices. Not all devices are used on all models. To determine
component location and input usage on a specific model, see
appropriate wiring diagram in WIRING DIAGRAMS article. Available input
signals include:
A/C Switch
Switch signals PCM that A/C has been selected. PCM then
activates A/C compressor clutch relay and maintains idle speed at a
preprogrammed RPM. This is done through control of Idle Air Control

drive plate. PCM uses this information to determine fuel injection
sequence, ignition signal and spark timing.
Cruise Control Switch
Cruise control switch provides PCM with 3 separate inputs.
ON/OFF switch input informs PCM that cruise control system has been
activated. SET/COAST switch input informs PCM that set vehicle speed
has been selected, or if depressed will decelerate until switch is
released. RESUME/ACCEL switch input informs PCM that a previously set
speed has been selected or, if depressed, will increase speed until
released. PCM uses these inputs to control cruise control servo.
Engine Coolant Temperature (ECT) Sensor
ECT sensor monitors engine coolant temperature. PCM uses ECT
sensor information to adjust air/fuel mixture and idle speed and to
control radiator cooling fans as necessary.
Fuel Level Sensor
PCM supplies a 5-volt reference signal to fuel module in gas
tank. Fuel level sensor sends a signal to PCM indicating fuel level.
PCM monitors this signal to prevent a false misfire signal if fuel
level is less than 15 percent. PCM also sends this signal to fuel
gauge.
Heated Oxygen Sensor (HO2S)
HO2S produces a small electrical voltage (0-1 volt) when
exposed to heated exhaust gas. HO2S is electrically heated for faster
warm-up. Heating element is powered through Auto Shutdown (ASD) relay.\
HO2S acts like a rich/lean (air/fuel ratio) switch by
monitoring oxygen content in exhaust gas. This information is used by
PCM to adjust air/fuel ratio by adjusting injector pulse width.
HO2S produces low voltage when oxygen content in exhaust gas
is high. When oxygen content in exhaust gas is low, HO2S produces a
higher voltage.
Ignition Switch
Ignition switch sends signal to PCM indicating whether switch
is on, off or cranking (ST). When PCM receives ON signal, it energizes\
ASD relay coil and supplies power to sensors and actuators. When PCM
receives ST signal, it controls fuel injection rate, idle speed,
ignition timing, etc. for optimum cranking conditions.
Intake Air Temperature (IAT) Sensor
IAT sensor measures temperature of incoming intake air. This
information is used by PCM to adjust air/fuel mixture.
Manifold Absolute Pressure (MAP) Sensor
MAP sensor monitors intake manifold vacuum. Sensor transmits
information on manifold vacuum and barometric pressure to PCM. MAP
sensor information is used with information from other sensors to
adjust air/fuel mixture.
Oil Pressure Sensor
Sensor sends a signal to PCM to indicate oil pressure.
Park/Neutral (P/N) Switch (A/T Models)
This switch may also be referred to as a Park/Neutral
Position (PNP) switch. P/N switch is available on vehicles equipped
with A/T only. Switch prevents engine starter from engaging if vehicle
is in any gear except Park or Neutral.
P/N switch input (varied with gear selection) is used to
determine idle speed, fuel injector pulse and ignition timing.

Power Steering Pressure Switch
On 2.5L Dakota only, power steering pressure switch sends a
signal to PCM. PCM will raise idle speed to prevent stalling during
high power steering pressure (375-575 psi), low RPM conditions.
Serial Communication Interface (SCI) Receive
SCI receive circuit is a serial communication link used when
diagnosing vehicle using scan tool. PCM receives data and device
activation commands from scan tool on this circuit.
Throttle Position (TP) Sensor
TP sensor monitors opening angle of throttle blade. TP sensor
will vary output voltage from about .26 volt at minimum throttle
opening (idle), to about 4.5 volts at Wide Open Throttle (WOT). PCM
uses this information and other sensor inputs to determine engine
operation. In response, PCM will adjust fuel injection pulse width and
ignition timing.
Transmission Governor Pressure Sensor (A/T Models)
Sensor sends PCM a signal indicating governor pressure. PCM
uses signal as feedback for governor solenoid control.
Transmission Overdrive/Override (OD/OR) Switch (A/T Models)
On models with Overdrive (OD), PCM regulates 3-4 OD upshift
and downshift through OD solenoid. Transmission OD/OR switch is
mounted in instrument panel.
OD/OR switch is normally closed. If OD/OR switch is depressed
and it opens, transmission will not enter OD. Transmission will
downshift if it is in OD and OD/OR switch is depressed.
OD/OR switch circuit includes a transmission fluid
temperature sensor. If this sensor opens, transmission will not shift
into overdrive, or will downshift if already in overdrive.
Transmission Temperature Sensor (A/T Models)
Transmission temperature sensor monitors transmission fluid
temperature and sends an input signal to PCM. Input signal is used for
controlling torque converter clutch operation, overdrive shifts, low
temperature shift compensation, wide open throttle shift strategy and
governor pressure. Transmission temperature sensor is located in
transmission valve body, incorporated into governor pressure sensor.
If transmission fluid temperature is more than 260
F (126C),
PCM forces a 4-3 downshift and engages torque converter clutch until
fluid cools. Once fluid cools to less than 230
F (110C), PCM allows a
3-4 shift. PCM prevents torque converter clutch engagement and
overdrive operation when fluid temperature is less than 50
F (10C).
Vehicle Speed Sensor (VSS)
VSS generates 8 pulses per sensor revolution. VSS input is
used by PCM to determine vehicle speed and distance traveled, and to
maintain set speed during cruise control operation.
PCM interprets speed sensor input along with TP sensor closed
throttle input. This enables PCM to determine if a closed throttle
deceleration or normal throttle idle (vehicle stopped) condition
exists. During deceleration, PCM controls IAC motor to maintain a
desired MAP value. During idle (vehicle stopped), PCM controls IAC
motor to maintain a desired idle speed.
OUTPUT SIGNALS
NOTE: Each vehicle may be equipped with different combinations of
computer-controlled components. The following components may
NOT be used on all models. To determine component location
and output usage on a specific model, see appropriate wiring

Fuel pump is a positive displacement, immersible pump with a
permanent magnet electric motor. Fuel is drawn in through a separate
filter/strainer at bottom of fuel pump and pushed through filter to
fuel outlet line (to fuel injectors). Voltage to operate pump is
supplied from fuel pump relay. On some models, fuel pump relay is
activated by ASD relay.
Fuel pump module includes a combination fuel filter/fuel
pressure regulator, fuel pump reservoir, a separate in-tank fuel
filter, pressure relief/rollover valve, fuel gauge sending unit and
fuel supply line. See Fig. 3.
Fig. 3: Identifying Fuel Pump Module Components (Typical)
Courtesy of Chrysler Corp.
FUEL CONTROL
Fuel Injectors
Fuel injectors are electric solenoid valves controlled by
PCM. PCM determines when and length of time (pulse width) injectors
should operate by switching ground path on and off. During start-up,
battery voltage is supplied to injectors through ASD relay. On some
models, battery voltage is supplied by charging system once engine is

operating. When ground is supplied to injector by PCM, armature and
pintle inside injector move a short distance against spring and open a
small orifice. Since fuel is under high pressure, a fine spray is
developed.
Modes Of Operation
As input signals to PCM change, PCM adjusts its response to
output devices. Modes of operation come in 2 types, open loop and
closed loop. In open loop mode, PCM is not using input from HO2S and
is responding to preset programming to determine injector pulse width
and ignition timing. In closed loop mode, PCM adjusts ignition timing
and uses input from HO2S to fine tune injector pulse width.
The following inputs may be used to determine PCM mode:
* A/C Control Positions
* A/C Switch
* Battery Voltage
* Brake Switch
* Camshaft Position (CMP) Sensor
* Crankshaft Position (CKP) Sensor
* Engine Coolant Temperature (ECT) Sensor
* Engine Speed (RPM)
* Heated Oxygen Sensor (HO2S)
* Intake Air Temperature (IAT) Sensor
* Manifold Absolute Pressure (MAP) Sensor
* Park/Neutral (P/N) Switch
* Starter Relay
* Throttle Position (TP) Sensor
* Vehicle Speed Sensor (VSS)
From these inputs, PCM determines which mode vehicle is in
and responds appropriately. Not all inputs are used in all modes or by
all models. Modes of operation are:
* Ignition Switch On (Engine Not Running) - This is an open
loop mode. PCM pre-positions IAC motor based on ECT sensor
input. PCM determines atmospheric pressure from MAP sensor
and determines basic fuel strategy. PCM modifies fuel
strategy according to IAT sensor, ECT sensor and TP sensor
inputs. PCM activates ASD relay, which in turn activates fuel
pump for only 2 seconds unless engine is cranked. PCM also
energizes HO2S heater element for approximately 2 seconds
unless engine is cranked.
* Engine Start-Up - This is an open loop mode. When starter is
engaged, PCM receives input from battery voltage, ignition
switch, CKP sensor, CMP sensor, ECT sensor, IAT sensor, MAP
sensor and TP sensor. Based on these inputs, voltage is
applied to fuel injectors with PCM controlling injection
sequence, rate, and pulse width. PCM provides ground for
injectors to fire in proper order.
PCM determines proper ignition timing according to input
received from CKP sensor. If PCM does not receive CKP sensor signal
within 3 seconds after engine begins cranking, fuel injection system
is shut down and a Diagnostic Trouble Code (FTC) is set in PCM memory.\
* Engine Warm-Up - This is an open loop mode. PCM determines
injector pulse width using input information from battery
voltage, CKP sensor, CMP sensor, ECT sensor, IAT sensor, MAP
sensor and TP sensor. PCM also monitors A/C request and P/N
switch (A/T only) for fuel calculation. PCM controls engine
idle speed through IAC motor. PCM controls ignition timing
based on CKP sensor input.
