1999 CHEVROLET ASTRO service indicator

yellowblue
2-64 Malfunction Indicator Lamp (Service
Engine Soon Light in the United States
or Check Engine Light in Canada)
United States Canada
Your vehicle is equipped with a computer which
monitors operation of the fuel, ignition and emission
control systems.
This system is called OBD II (On
-Board
Diagnostics
-Second Generation) and is intended to assure
that emissions are at acceptable levels for the life of the
vehicle, helping to produce a cleaner environment. The SERVICE ENGINE SOON or CHECK ENGINE
light comes on to indicate that there is a problem and
service is required. Malfunctions often will be indicated by
the system before any problem is apparent. This may
prevent more serious damage to your vehicle. This system
is also designed to assist your service technician in
correctly diagnosing any malfunction.
NOTICE:
If you keep driving your vehicle with this light
on, after a while, your emission controls may not
work as well, your fuel economy may not be as
good and your engine may not run as smoothly.
This could lead to costly repairs that may not be
covered by your warranty.

yellowblue
2-68 Service AWD Light (If Equipped)
This light should come on
briefly when you turn on the
ignition, as a check to show
you it is working.
The SERVICE AWD light comes on to indicate that
there may be a problem with the drive system and
service is required. Malfunctions can be indicated by the
system before any problem is apparent, which may
prevent serious damage to the vehicle. This system is
also designed to assist your service technician in
correctly diagnosing a malfunction.
Daytime Running Lamps Indicator Light
You will have this light on
the instrument panel. It goes
on whenever the Daytime
Running Lamps (DRL)
are on.
When it begins to get dark, the DRL indicator light is a
reminder to turn on your headlamps.
Check Gages Light
This light will come on
briefly when you are
starting the engine.
If the light comes on and stays on while you are driving,
check your various gages to see if they are in the
warning zones.

yellowblue
3-31
After you clean the player, press and hold EJECT for
five seconds to reset the CLN indicator. The radio will
display
--- to show the indicator was reset.
Cassettes are subject to wear and the sound quality
may degrade over time. Always make sure the cassette
tape is in good condition before you have your tape
player serviced.
Care of Your Compact Discs
Handle discs carefully. Store them in their original cases
or other protective cases and away from direct sunlight
and dust. If the surface of a disc is soiled, dampen a
clean, soft cloth in a mild, neutral detergent solution and
clean it, wiping from the center to the edge.
Be sure never to touch the signal surface when handling
discs. Pick up discs by grasping the outer edges or the
edge of the hole and the outer edge.
Care of Your Compact Disc Player
The use of CD lens cleaner discs is not advised, due to
the risk of contaminating the lens of the CD optics with
lubricants internal to the CD mechanism.
Fixed Mast Antenna
The fixed mast antenna can withstand most car washes
without being damaged. If the mast should ever become
slightly bent, you can straighten it out by hand. If the
mast is badly bent, as it might be by vandals, you should
replace it.
Check every once in a while to be sure the mast is still
tightened to the fender.

yellowblue
6-4
If your vehicle is certified to meet California Emission
Standards (indicated on the underhood emission control
label), it is designed to operate on fuels that meet
California specifications. If such fuels are not available
in states adopting California emissions standards, your
vehicle will operate satisfactorily on fuels meeting
federal specifications, but emission control system
performance may be affected. The malfunction indicator
lamp on your instrument panel may turn on and/or your
vehicle may fail a smog
-check test. (See ªMalfunction
Indicator Lampº in the Index.) If this occurs, return to
your authorized GM dealer for diagnosis to determine
the cause of failure. In the event it is determined that the
cause of the condition is the type of fuels used, repairs
may not be covered by your warranty.
Some gasolines that are not reformulated for low
emissions may contain an octane
-enhancing additive
called methylcyclopentadienyl manganese tricarbonyl
(MMT); ask your service station operator whether or not
the fuel contains MMT. General Motors does not
recommend the use of such gasolines. If fuels containing
MMT are used, spark plug life may be reduced and your
emission control system performance may be affected.
The malfunction indicator lamp on your instrument
panel may turn on. If this occurs, return to your
authorized GM dealer for service.To provide cleaner air, all gasolines in the United States
are now required to contain additives that will help
prevent deposits from forming in your engine and fuel
system, allowing your emission control system to
function properly. Therefore, you should not have to add
anything to the fuel. In addition, gasolines containing
oxygenates, such as ethers and ethanol, and
reformulated gasolines may be available in your area to
contribute to clean air. General Motors recommends that
you use these gasolines, particularly if they comply with
the specifications described earlier.
NOTICE:
Your vehicle was not designed for fuel that
contains methanol. Don't use it. It can corrode
metal parts in your fuel system and also damage
plastic and rubber parts. That damage wouldn't
be covered under your warranty.

yellowblue
6-34
NOTICE:

Using the wrong fluid can badly damage
brake system parts. For example, just a few
drops of mineral
-based oil, such as engine
oil, in your brake system can damage brake
system parts so badly that they'll have to be
replaced. Don't let someone put in the
wrong kind of fluid.

If you spill brake fluid on your vehicle's
painted surfaces, the paint finish can be
damaged. Be careful not to spill brake fluid
on your vehicle. If you do, wash it off
immediately. See ªAppearance Careº in
the Index.
Brake Wear
Your vehicle has front disc brakes and rear drum brakes.
Disc brake pads have built
-in wear indicators that make a
high
-pitched warning sound when the brake pads are worn
and new pads are needed. The sound may come and go or
be heard all the time your vehicle is moving (except when
you are pushing on the brake pedal firmly).
CAUTION:
The brake wear warning sound means that soon
your brakes won't work well. That could lead to
an accident. When you hear the brake wear
warning sound, have your vehicle serviced.
NOTICE:
Continuing to drive with worn-out brake pads
could result in costly brake repair.
Some driving conditions or climates may cause a brake
squeal when the brakes are first applied or lightly
applied. This does not mean something is wrong with
your brakes.
Properly torqued wheel nuts are necessary to help
prevent brake pulsation. When tires are rotated, inspect
brake pads for wear and evenly torque wheel nuts in the
proper sequence to GM specifications.

yellowblue
6-46
When It's Time for New Tires
One way to tell when it's
time for new tires is to
check the treadwear
indicators, which will
appear when your tires have
only 1/16 inch (1.6 mm) or
less of tread remaining.
You need a new tire if any of the following statements
are true:

You can see the indicators at three or more places
around the tire.

You can see cord or fabric showing through the
tire's rubber.

The tread or sidewall is cracked, cut or snagged deep
enough to show cord or fabric.
The tire has a bump, bulge or split.

The tire has a puncture, cut or other damage that
can't be repaired well because of the size or location
of the damage.
Buying New Tires
To find out what kind and size of tires you need, look at
the Certification/Tire label.
The tires installed on your vehicle when it was new had
a Tire Performance Criteria Specification (TPC Spec)
number on each tire's sidewall. When you get new tires,
get ones with that same TPC Spec number. That way
your vehicle will continue to have tires that are designed
to give proper endurance, handling, speed rating,
traction, ride and other things during normal service on
your vehicle. If your tires have an all
-season tread
design, the TPC number will be followed by an ªMSº
(for mud and snow).
If you ever replace your tires with those not having a
TPC Spec number, make sure they are the same size,
load range, speed rating and construction type (bias,
bias
-belted or radial) as your original tires.

yellowblue
9-6
Key Lock Cylinders Service 7-42 . . . . . . . . . . . . . . . . . . . . .
Keyless Entry System 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Keys 2-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Labels
Certification/Tire 4-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Parts Identification 6-59 . . . . . . . . . . . . . . . . . . . . .
Tire-Loading Information 4-28 . . . . . . . . . . . . . . . . . . . . . .
Vehicle Identification Number 6-59 . . . . . . . . . . . . . . . . . . .
Lamps
Dome 2
-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Interior 2-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
On Reminder 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Latches, Seatback 1-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle 2-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Leaving Your Vehicle with the Engine Running 2-25 . . . . . . .
Lighter 2-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lights
Air Bag Readiness 1
-28, 2-60 . . . . . . . . . . . . . . . . . . . . . . .
Anti-Lock Brake System Warning 2-63, 4-7 . . . . . . . . . . . .
Brake System Warning 2-62 . . . . . . . . . . . . . . . . . . . . . . . . .
Charging System 2-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check Engine 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Check Gages 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Daytime Running Lamps Indicator 2-68 . . . . . . . . . . . . . . .
Safety Belt Reminder 1-13, 2-60 . . . . . . . . . . . . . . . . . . . . .
Security 2-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service AWD 2-68 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service Engine Soon 2-64 . . . . . . . . . . . . . . . . . . . . . . . . . . Loading Your Vehicle 4
-28 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Locks
Cylinders 7
-42 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Door 2-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ignition Transmission Lock Check 7-44 . . . . . . . . . . . . . . .
Key Lock Cylinder Service 7-42 . . . . . . . . . . . . . . . . . . . . .
Power Door 2-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sliding Door Child Security 2-11 . . . . . . . . . . . . . . . . . . . . .
Lubricants and Fluids 7-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lubrication Service, Body 7-42 . . . . . . . . . . . . . . . . . . . . . . . .
Luggage Carrier 2-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lumbar Controls 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance, Normal Replacement Parts 6-69 . . . . . . . . . . .
Maintenance Record 7-49 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance Schedule 7-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Long Trip/Highway 7-29 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Long Trip/Highway Definition 7-6 . . . . . . . . . . . . . . . . . . .
Long Trip/Highway Intervals 7-6 . . . . . . . . . . . . . . . . . . . . .
Owner Checks and Services 7-41 . . . . . . . . . . . . . . . . . . . . .
Periodic Maintenance Inspections 7-45 . . . . . . . . . . . . . . . .
Recommended Fluids and Lubricants 7-47 . . . . . . . . . . . . .
Scheduled Maintenance Services 7-4 . . . . . . . . . . . . . . . . . .
Short Trip/City 7-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Short Trip/City Definition 7-5 . . . . . . . . . . . . . . . . . . . . . . .
Short Trip/City Intervals 7-5 . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance, Underbody 6-57 . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance When Trailer Towing 4-38 . . . . . . . . . . . . . . . . .
Malfunction Indicator Lamp 2-64 . . . . . . . . . . . . . . . . . . . . . .
Manual Front Seat 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

yellowblue
9-11
Temperature 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Traction 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Treadwear 6-48 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Uniform Quality Grading 6-47 . . . . . . . . . . . . . . . . . . . . . . .
Wear Indicators 6-46 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wheel Replacement 6-49 . . . . . . . . . . . . . . . . . . . . . . . . . . .
When It's Time for New 6-46 . . . . . . . . . . . . . . . . . . . . . . .
Top Strap 1-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Torque Lock 2-26 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Torque, Wheel Nut 5-30, 6-67 . . . . . . . . . . . . . . . . . . . . . . . . .
Towing
Recreational 4
-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Your Vehicle 5-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Trailer
Brakes 4
-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving on Grades 4-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving with 4-35 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Hitches 4-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maintenance When Towing 4-38 . . . . . . . . . . . . . . . . . . . . .
Parking on Hills 4-38 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Chains 4-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tongue Weight 4-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Total Weight on Tires 4-33 . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing 4-30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signals 4-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weight 4-32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wiring Harness 4-39 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Transmission Fluid, Automatic 6
-20 . . . . . . . . . . . . . . . . . . . .
Transmitters, Keyless Entry 2-7 . . . . . . . . . . . . . . . . . . . . . . . .
Transportation, Courtesy 8-8 . . . . . . . . . . . . . . . . . . . . . . . . . .
Trip Odometer 2-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TTY Users 8-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signal and Lane Change Signals 2-32 . . . . . . . . . . . . . . .
Turn Signal/Multifunction Lever 2-31 . . . . . . . . . . . . . . . . . . .
Turn Signals When Towing a Trailer 4-37 . . . . . . . . . . . . . . . .
Tw o-Way Manual Seat 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Underbody Flushing Service 7-44 . . . . . . . . . . . . . . . . . . . . .
Underbody Maintenance 6-57 . . . . . . . . . . . . . . . . . . . . . . . . .
Underhood Electrical Center 6-64 . . . . . . . . . . . . . . . . . . . . . .
Universal Transmitter 2-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle
Control 4-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Damage Warnings iv. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Dimensions 6
-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification Number 6-59 . . . . . . . . . . . . . . . . . . . . . . . . .
Loading 4-28 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage 6-36 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Ventilation System 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Visor Vanity Mirrors 2-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Visors, Sun 2-51 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltmeter 2-61 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
