1999 CHEVROLET ASTRO turn signal bulb

yellowblue
2-32 Turn and Lane Change Signals
The turn signal has two upward (for right) and two
downward (for left) positions. These positions allow you
to signal a turn or a lane change.
To signal a turn, move the lever all the way up or down.
When the turn is finished, the lever will return automatically.
An arrow on the
instrument panel will flash
in the direction of the turn
or lane change.
To signal a lane change, just raise or lower the lever
until the arrow starts to flash. Hold it there until you
complete your lane change. The lever will return by
itself when you release it.
As you signal a turn or a lane change, if the arrows don't
flash but just stay on, a signal bulb may be burned out
and other drivers won't see your turn signal.If a bulb is burned out, replace it to help avoid an
accident. If the arrows don't go on at all when you
signal a turn, check the fuse (see ªFuses and Circuit
Breakersº in the Index) and for burned
-out bulbs.
If you have a trailer towing option with added wiring for
the trailer lamps, a different turn signal flasher is used.
With this flasher installed, the signal indicator will flash
even if a turn signal bulb is burned out. Check the front
and rear turn signal lamps regularly to make sure they
are working.
Headlamp High/Low Beam Changer
To change the headlamps from low beam to high or high
to low, pull the multifunction lever all the way toward
you. Then release it.
When the high beams are
on, this indicator light on
the instrument panel also
will be on.

yellowblue
4-37 Making Turns
NOTICE:
Making very sharp turns while trailering could
cause the trailer to come in contact with the
vehicle. Your vehicle could be damaged. Avoid
making very sharp turns while trailering.
When you're turning with a trailer, make wider turns than
normal. Do this so your trailer won't strike soft shoulders,
curbs, road signs, trees or other objects. Avoid jerky or
sudden maneuvers. Signal well in advance.
Turn Signals When Towing a Trailer
When you tow a trailer, your vehicle has to have extra
wiring (included in the optional trailering package).
The arrows on your instrument panel will flash
whenever you signal a turn or lane change. Properly
hooked up, the trailer lamps will also flash, telling other
drivers you're about to turn, change lanes or stop.When towing a trailer, the arrows on your instrument
panel will flash for turns even if the bulbs on the trailer
are burned out. Thus, you may think drivers behind you
are seeing your signal when they are not. It's important
to check occasionally to be sure the trailer bulbs are
still working.
Driving On Grades
Reduce speed and shift to a lower gear before you start
down a long or steep downgrade. If you don't shift
down, you might have to use your brakes so much that
they would get hot and no longer work well.
When towing at high altitude on steep uphill grades,
consider the following: Engine coolant will boil at a
lower temperature than at normal altitudes. If you turn
your engine off immediately after towing at high altitude
on steep uphill grades, your vehicle may show signs
similar to engine overheating. To avoid this, let the
engine run while parked (preferably on level ground)
with the automatic transmission in PARK (P) for a few
minutes before turning the engine off. If you do get the
overheat warning, see ªEngine Overheatingº in
the Index.

yellowblue
6-40
6. Remove the
composite assembly.
7. Turn the halogen
bulb counterclockwise
to remove from
the assembly.
8. Install the new bulb into the composite assembly by
turning it clockwise until it is completely tightened.
9. Replace the composite assembly by installing and
tightening all of the screws previously removed.Front Turn Signal Lamps
1. Remove the two screws at the inside edge of the
parking/turn signal lamp assembly.
2. Remove the
lamp assembly.
3. Squeeze the tab on the
side of the lamp socket
while turning the socket
counterclockwise.
4. Pull the socket out of the lamp assembly.
5. Pull the bulb from the socket.
6. Gently push the new bulb into the socket.
7. Put the socket back into the lamp assembly and turn
it clockwise until it locks.
8. Put the parking/turn signal lamp assembly back into
the vehicle and tighten the screws.

yellowblue
6-66
Replacement Bulbs
Exterior Lamps Quantity Trade No.
Halogen Headlamps
- Sealed Beam2 H6054
Halogen Headlamps
- Composite2
9006 (Low-Beam)
Halogen Headlamps
- Composite2
9005 (High-Beam)
Parking, Turn Signal Lamps 2 3157NA
Rear, Stoplamps 2 2057
Sidemarker Lamps 4 194
Back
-up Lamps2 1156

yellowblue
9-4
Electrical Equipment, Adding 2-18, 3-29, 6-60 . . . . . . . . . .
Electrical System 6-60 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine 6-10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Cleaner/Filter 6-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant 6-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Heater 2-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Coolant Level Check 7-41 . . . . . . . . . . . . . . . . . . . . . . . . . .
Cooling System Capacity 6-67 . . . . . . . . . . . . . . . . . . . . . . .
Cover 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust 2-13, 2-27, 2-28, 2-30, 4-27, 4-34, 4-35 . . . . . . .
Fuse Block 6-64 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Identification 6-59 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Oil Level Check 7-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Overheating 5-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Running While Parked 2-28 . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications 6-67 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Starting Your 2-17 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Temperature Gage 2-63 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Oil 6-11 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Adding 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Additives 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Checking 6-12 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pressure Gage 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Used 6-15 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
When to Change 6-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Exhaust, Engine 2-13, 2-27, 2-28, 2-30, 4-27, 4-34, 4-35 . .
Express-Down Window 2-30 . . . . . . . . . . . . . . . . . . . . . . . . . .
Exterior Lamps 2-37 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fabric Cleaning 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Fuel Container 6-7 . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filter
Air Cleaner Replacement 6
-69 . . . . . . . . . . . . . . . . . . . . . . .
Engine Oil 6-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Care 6-56 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Finish Damage 6-57 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
First Gear 2-22 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Flashers, Hazard Warning 5-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Flat Tire, Changing 5-19 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluid Capacities 6-67, 6-68 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fluids and Lubricants 7-47 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foreign Countries, Fuel 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
French Language Manual ii. . . . . . . . . . . . . . . . . . . . . . . . . . .
Front
Axle 6
-25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage Area 2-41 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Towing 5-7 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Turn Signal Lamp Bulb Replacement 6-40 . . . . . . . . . . . . .
Fuel 6-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Filling a Portable Container 6-7 . . . . . . . . . . . . . . . . . . . . . .
Filling Your Tank 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Gage 2-69 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
In Foreign Countries 6-5 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Regulator 2-18 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuses and Circuit Breakers 6-61 . . . . . . . . . . . . . . . . . . . . . . .
