1999 CADILLAC ELDORADO sensor

yellowblue
1-26
In many crashes severe enough to inflate an air bag,
windshields are broken by vehicle deformation.
Additional windshield breakage may also occur from the
right front passenger air bag.

Air bags are designed to inflate only once. After they
inflate, you'll need some new parts for your air bag
system. If you don't get them, the air bag system
won't be there to help protect you in another crash.
A new system will include air bag modules and
possibly other parts. The service manual for your
vehicle covers the need to replace other parts.

Your vehicle is equipped with a crash sensing and
diagnostic module, which records information about
the air bag system. The module records information
about the readiness of the system, when the sensors
are activated and driver's safety belt usage at
deployment. Some modules also record speed,
engine rpm, brake and throttle data.

Let only qualified technicians work on your air bag
system. Improper service can mean that your air bag
system won't work properly. See your dealer
for service.
NOTICE:
If you damage the covering for the driver's air
bag, it may not work properly. You may have to
replace the air bag module. Do not open or break
the air bag covering.
Servicing Your Air Bag-Equipped Vehicle
Air bags affect how your vehicle should be serviced.
There are parts of the air bag system in several places
around your vehicle. You don't want the system to
inflate while someone is working on your vehicle. Your
dealer and the Eldorado Service Manual have
information about servicing your vehicle and the air bag
system. To purchase a service manual, see ªService and
Owner Publicationsº in the Index.

yellowblue
2-23
NEUTRAL (N): In this position, the engine doesn't
connect with the wheels. To restart when you're
already moving, use NEUTRAL (N) only. Also, use
NEUTRAL (N) when your vehicle is being towed.
CAUTION:
Shifting out of PARK (P) or NEUTRAL (N) while
your engine is ªracingº (running at high speed) is
dangerous. Unless your foot is firmly on the
brake pedal, your vehicle could move very
rapidly. You could lose control and hit people or
objects. Don't shift out of PARK (P) or
NEUTRAL (N) while your engine is racing.
NOTICE:
Damage to your transaxle caused by shifting out
of PARK (P) or NEUTRAL (N) with the engine
racing isn't covered by your warranty.
OVERDRIVE (
): This position is for normal driving.
If you need more power for passing, and you're:

Going less than 35 mph (55 km/h), push the
accelerator pedal about halfway down.

Going about 35 mph (55 km/h) or more, push the
accelerator all the way down.
The transaxle will shift down to the next gear and
have more power.
NOTICE:
If your vehicle seems to start up rather slowly, or
if it doesn't seem to shift gears as you accelerate,
something may be wrong with a transaxle system
sensor. If you drive very far that way, your
vehicle can be damaged. So if this happens, have
your vehicle serviced right away. Until then, you
can use SECOND (2) when you are driving less
than 35 mph (55 km/h) and OVERDRIVE (
)
for higher speeds.

yellowblue
2-35 Windshield Wipers
WIPER: Turn the band on the turn signal lever to
control the wipers.
MIST: Turn the band toward you and then release it for
a single wiping cycle. For more cycles, hold the band on
MIST longer.
LO or HI: Turn the band away from you to either LO
(low speed) or to HI (high speed), depending on the
wiper speed you want.
DELAY: You can set the wiper speed for a long or short
delay between wipes with this setting. Turn the band to
the DELAY position. The closer you turn it to LO, the
shorter the delay.OFF: Turn the band to OFF to turn off the wipers.
Be sure to clear ice and snow from the wiper blades
before using them. If they're frozen to the windshield,
carefully loosen or thaw them. If the blades do become
damaged, get new blades or blade inserts.
Heavy snow or ice can overload the wiper motor. A
circuit breaker will stop the motor until it cools. Clear
away snow or ice to prevent an overload.
Rainsense
Wipers (ETC Only)
This moisture sensor is mounted on the passenger's
interior side of the windshield behind the rearview
mirror and is used to automatically operate the wipers
by monitoring the amount of moisture that is on
the windshield.

yellowblue
2-43
If it's dark enough outside and the Twilight Sentinel
control is off, a HEADLAMPS SUGGESTED message
will display on the Driver Information Center (DIC).
This message informs the driver that turning on the
exterior lamps is recommended (it's become dark
enough outside to require the headlamps and/or other
exterior lamps). Turning on the Twilight Sentinel, the
headlamps or the fog lamps will remove the
HEADLAMPS SUGGESTED message.
Light Sensor
The light sensor for the Daytime Running Lamps (DRL)
and the Twilight Sentinel is located in the center of the
front defogger grille. If you cover the sensor, it will read
ªdarkº and the lamps will come on.
Exterior Lighting Battery Saver
If the manual parking lamp control has been left on, the
exterior lamps will turn off approximately 10 minutes
after the ignition is turned to LOCK or ACCESSORY.
This protects draining the battery in case you have
accidentally left the headlamps or parking lamps on. If
you need to purposely leave the lamps on for more than
10 minutes with the ignition in LOCK or ACCESSORY,
turn the exterior lamps control knob off and then back
on. To delay the lamps from turning off, see ªTwilight
Sentinelº in the Index.
Interior Lamps
Instrument Panel Intensity/Brightness
Control
The digital displays automatically dim when it becomes
dark outside and your lights are on. When it's dark, the
brightness control can be manually adjusted by turning
the exterior lamps control knob counterclockwise to dim
and clockwise to brighten the lighting. The digital
displays automatically brighten when it becomes light
outside, although backlighting will remain active at the
selected brightness as long as the lights are on.

yellowblue
2-44 Illuminated Entry
The illuminated entry system turns on the courtesy lamps
and the backlighting to the door controls and to the
exterior lamps control knob when a door is opened or if
you press a remote keyless entry transmitter button. Since
the illuminated entry system has a photocell, this means
that it must be dark outside in order for the courtesy lamps
or backlighting to turn on. The courtesy lamps turn off
approximately 20 seconds after the last door is closed or
after the ignition key is placed in the ignition.
Parade Dimming
This feature prohibits the dimming of the instrument
panel lights during daylight while the headlamps are on.
This feature operates with the light sensor for the
Twilight Sentinel and is fully automatic. When the light
sensor reads darkness outside, the instrument panel
lights can be adjusted by turning the exterior lamps
control knob counterclockwise to dim and clockwise to
brighten lighting. Backlighting to the instrument panel
will turn on, regardless of light conditions.
Reading Lamps
The reading lamps are located in the roof unless your
vehicle has the optional sunroof where the lamps are
located above the windows. To turn them on, turn the
exterior lamps control knob all the way clockwise.
These lamps and the interior courtesy lamps
automatically come on when either door is opened and it
is dark outside. For manual operation, press the button
to turn them on. Press it again to turn them off.
If the reading lamps are left on, they automatically shut
off 10 minutes after the ignition has been turned off.
Inadvertent Power Battery Saver
This feature is designed to protect your vehicle's battery
against drainage from the interior lamps, trunk lamp,
glove box lamp, cigarette lighters or the garage door
opener. When the ignition is turned off, the power to
these features will automatically turn off after 10
minutes (three minutes if a new car has 15 miles
(24 km) or less). Power will be restored for an additional
10 minutes if either door is opened, the trunk is opened
or the courtesy lamps are turned on.

yellowblue
2-62 Air Bag Readiness Light
There is an air bag readiness light on the instrument
panel, which shows AIR BAG. The system checks the
air bag's electrical system for malfunctions. The light
tells you if there is an electrical problem. The system
check includes the air bag sensors, the air bag modules,
the wiring and the crash sensing and diagnostic module.
For more information on the air bag system, see ªAir
Bagº in the Index.
This light will come on
when you start your engine,
and it will flash for a few
seconds. Then the light
should go out. This means
the system is ready.
If the air bag readiness light stays on after you start the
engine or comes on when you are driving, your air bag
system may not work properly. Have your vehicle
serviced right away.
The air bag readiness light should flash for a few
seconds when you turn the ignition key to RUN. If the
light doesn't come on then, have it fixed so it will be
ready to warn you if there is a problem.
Charging System Indicator Light
When you turn the ignition
key to RUN, this light will
come on briefly to show
that the generator and
battery charging systems
are working.
If this light stays on, you need service and you should
take your vehicle to the dealer at once. To save your
battery until you get there, turn off all accessories.
Brake System Warning Light
Your vehicle's hydraulic brake system is divided into
two parts. If one part isn't working, the other part can
still work and stop you. For good braking, though, you
need both parts working well.
If the warning light comes on, there is a brake problem.
Have your brake system inspected right away.

yellowblue
2-72
BATTERY NOT CHARGING - 7: This message will
appear if the battery is not being charged. Have the
electrical system checked by your dealership at your
earliest convenience.
BATTERY VOLTAGE HIGH
- 8: This message
shows that the electrical charging system is
overcharging (more than 16 volts). To avoid being
stranded, have the electrical system checked by your
dealership. You can reduce the charging overload by
using the accessories. Turn on the lamps and radio, set
the climate control on AUTO and the fan speed on HI,
and turn the rear window defogger on. You can monitor
battery voltage on the DIC by pressing the SKIP INFO
button. The normal range is 11.5 to 15.5 volts when the
engine is running.
BATTERY VOLTAGE LOW
- 6: This message will
appear when the electrical system is charging less than
10 volts or if the battery has been drained. If this
message appears immediately after starting, it is possible
that the generator can still recharge the battery. The
battery should recharge and may take a few hours to do
so. Consider using an auxiliary charger to boost the
battery after returning home or to a final destination.
(Be sure to follow the manufacturer's instructions when
using a battery charger.)If this message appears and stays on while driving or
after starting your vehicle, have it checked immediately
to determine the cause of this problem. To help the
generator recharge the battery quickly, you can reduce
the load on the electrical system by turning off the
accessories. You can monitor battery voltage on the DIC
by pressing the SKIP INFO button. The normal range
is 11.5 to 15.5 volts.
BRAKE VACUUM PROBLEM
-108: The circuit in
the brake booster vacuum has shorted or is loose when
this message appears. Your vehicle may lose power
brakes but you will still have the use of manual brakes.
The power brakes will not be affected if the problem is
caused by a failed sensor. Have your vehicle serviced
immediately at your dealership.
CHANGE ENGINE OIL
- 82: This means that the life
of the engine oil has expired and it should be changed
within 200 miles (322 km). See ªEngine Oilº and ªFilter
Recommendationsº in the Maintenance Schedule booklet.
After an oil change, the Oil Life Indicator must be reset.
See ªOil Life Indicator, How to Resetº in the Index.
CHANGE TRANS FLUID
- 47: This message will
appear when it is time to replace the transaxle fluid. See
the Maintenance Schedule booklet for the proper fluid
and change intervals.

yellowblue
2-76
SERVICE A/C SYSTEM - 14: This message appears
when the electronic sensors that control the air
conditioning and heating systems are no longer working.
Have the climate control system serviced if you notice a
drop in heating and air conditioning efficiency.
SERVICE AIR BAG
- 83: There is a problem with the
Supplemental Inflatable Restraint (air bag) system when
this message appears. Let only a qualified technician
work on your vehicle. See your dealership for service
at once.
SERVICE BRAKE FLUID SWITCH
- 37: A problem
in the brake fluid detection circuit causes this message
to display if the ignition is in RUN. Have the brake
system serviced by a technician as soon as possible. If
the brake warning light is on, refer to the directions
listed in that part.
SERVICE CHARGING SYSTEM
- 102: This
message will display when a problem with the charging
system has been detected. Have your vehicle serviced at
your dealership.
SERVICE ELECTRIC SYS
- 106: This message will
display if an electrical problem has occurred within the
Powertrain Control Module (PCM). Have your vehicle
serviced by your dealership.SERVICE FUEL SYSTEM
- 101: The PCM has
detected a problem within the fuel system when this
message appears. See your dealership for service.
SERVICE IDLE CONTROL
- 107: A problem
with the idle control has occurred when this
message displays. Drive your vehicle to the
dealership for service.
SERVICE RIDE SYS
- 84: This message is displayed
to indicate that the suspension system is not operating
properly. To correct this problem, have your vehicle
serviced at your dealership.
SERVICE STEERING SYS
- 127: This message is
displayed when a problem has been detected in the
Magnasteer

variable effort steering system. Service is
required. A single chime will also sound when this
message is displayed.
SERVICE TRANSMISSION
- 100: If a problem is
detected with the transaxle, this message will appear.
Have your vehicle checked by your dealership.
SERVICE VEHICLE SOON
- 3: If a problem is
detected with the transaxle, this message will appear.
Have your vehicle checked by your dealership.
