1999 CADILLAC ELDORADO radio controls

yellowblue
2-57
The main components of the instrument panel are:
A. Air Outlets
B. Turn Signal/Multifunction Lever
C. Instrument Panel Cluster
D. Radio (Audio System)
E. Driver Information Center Control Buttons
F. Lamp Controls
G. HVAC Steering Wheel Controls (or Cellular
Telephone Controls, If Equipped)H. Hood Release
I. Horn
J. Audio Steering Wheel Controls
K. Shift Lever
L. Climate Control System
M. Glove Box

yellowblue
2-84
Your vehicle will stay in the storage mode until the
ignition key is turned out of LOCK. The system will
ªwake
-upº when the door key is inserted into the door,
however, your vehicle will remain in the storage mode.
The ignition must be out of LOCK before the battery
guard is disabled.
Comfort Controls and Radio System Personalization
These features allow both drivers to personalize their
own climate control settings as well as their radio
settings. For more information, see ªClimate Control
Personalizationº and ªRadio Personalizationº in
the Index.
Continuous Variable Road Sensing
Suspension (CVRSS) (ETC Only)
The CVRSS automatically adjusts the ride of your
vehicle. Automatic ride control is achieved through a
computer used to control and monitor the suspension
system. The controller receives input from various
sensors to determine the proper system response. If the
controller detects a problem within the system, the
Driver Information Center (DIC) will display a
SERVICE RIDE CONTROL message. If this message
appears, have your vehicle serviced at your dealership.
Oil Life Indicator
This feature lets you know when to change the engine
oil. It's based on the engine oil temperatures and your
driving patterns. To see the display, press the SKIP
INFO button several times until XX OIL LIFE LEFT
appears. If you see 99% OIL LIFE LEFT, 99 percent of
your current oil life remains.

3-
yellowblue
3-1
Section 3 Comfort Controls and Audio Systems
In this section, you'll find out how to operate the comfort control and audio systems offered with your vehicle. Be
sure to read about the particular systems supplied with your vehicle.
3
-2 Comfort Controls
3
-2 Climate Control Panel
3
-6 Electronic Solar Sensor
3
-6 Air Conditioning
3
-6 Heating
3
-7 Defrosting
3
-7 Rear Window Defogger
3
-8 Ventilation System
3
-9 HVAC Steering Wheel Controls
3
-9 Climate Control Personalization (If Equipped)
3
-9 Audio Systems
3
-9 Setting the Clock
3
-10 AM-FM Stereo with Cassette Tape Player
3
-13 AM-FM Stereo with Cassette Tape and
Compact Disc Player with Radio Data
Systems (RDS) and Digital Signal Processing
(DPS) (If Equipped)3
-22 Radio Data Systems (RDS) Program Type
(PTY) Selections
3
-23 CD Adapter Kits
3
-23 Trunk-Mounted CD Changer (If Equipped)
3
-27 Radio Personalization with Home and Away
Feature (If Equipped)
3
-28 Theft-Deterrent Feature
3
-28 Audio Steering Wheel Controls
3
-29 Understanding Radio Reception
3
-29 Tips About Your Audio System
3
-30 Care of Your Cassette Tape Player
3
-31 Care of Your Compact Discs
3
-31 Care of Your Compact Disc Player
3
-32 Power Antenna Mast Care

yellowblue
3-2
Comfort Controls
This section tells you how to make your air system work
for you. Your Electronic Climate Control (ECC) system
uses ozone
-friendly R-134a refrigerant.
With the ECC system, you can control the heating,
cooling and ventilation in your vehicle. Your vehicle
also has a flow
-through ventilation system described
later in this section.
Climate Control Panel
Fan Button
The button with the fan symbol adjusts the fan speed.
Press the up arrow to increase fan speed and the down
arrow to decrease fan speed.Driver's Side Temperature Knob
The TEMP/AUTO knob adjusts the air temperature coming
through the system. Turn the TEMP/AUTO knob clockwise
to increase the temperature and counterclockwise to decrease
the temperature. Press the TEMP/AUTO knob to put the
system in the automatic mode.
Passenger's Side Temperature Button
With this dual
-zone feature, the right front passenger
can control the temperature of air for his/her own zone.
The passenger can select a four degree warmer or cooler
temperature from the driver's setting. To turn the system
on, press the PASS/TEMP button. Press the up arrow to
increase the temperature and press the down arrow to
decrease the climate setting. Pressing the OFF button
will turn off the dual
-zone function.
Outside Temperature Display
The outside temperature is always displayed when your
vehicle is running. You can change it from Fahrenheit to
Celsius by pressing the SKIP INFO button (above the
radio) until ENGLISH/METRIC RESET displays. Once
displayed, press the NO INFO RESET button to select.

yellowblue
3-12
Playing a Cassette Tape
With the radio on, insert a cassette tape. The tape will begin
playing as soon as it is inserted. When one side of your
cassette tape is done playing, auto reverse plays the other side
of your cassette tape. If you want to insert a cassette tape
when the ignition is off, first press the eject button.
While the tape is playing, use the VOL, FADE, BAL,
BASS and TREB controls just as you do for the radio.
Other controls may have different functions when a tape is
inserted. The display will show TAPE with an arrow to
indicate which side of the tape is playing. PLAY will
appear on the display temporarily when a tape is playing.
The display will then revert back to showing the time.
If an error occurs while trying to play a cassette tape, it
could be that:

The cassette tape is tight and the cassette player
cannot turn the hubs of the tape. Hold the cassette
tape with the open end down and try turning the right
hub counterclockwise with a pencil. Flip the tape
over and repeat. If the hubs do not turn easily, your
cassette tape may be damaged and should not be
used in the player. Try a new tape to be sure your
player is working properly.

The cassette tape is broken. (Check to see if your
tape is broken. Try a new tape.)REV: Press the left arrow to rewind the tape rapidly.
The radio will play while the tape reverses and REV
will appear on the display. You may use your station
pushbuttons to tune to another radio station while in
REV mode. Press the left arrow again to return to
playing speed.
FF: Press the right arrow to fast forward to another part
of the tape. The radio will play while the tape advances
and FF will appear on the display. You may use your
station pushbuttons to tune to another radio station while
in FF mode. Press the right arrow again to return to
playing speed.
SEEK
-TUNE: Press the right arrow to seek to the next
selection on the tape. Press the left arrow to search for
the previous selection on the tape (REP will appear on
the display). Your tape must have at least three seconds
of silence between each selection for SEEK
-TUNE to
work. The sound will mute while seeking.
SCAN: Press this button. SCAN FF will appear on the
display until the next selection is found and then SCAN
PLAY will appear on the display. Use SCAN to listen to
selections for a few seconds. The tape will go to a
selection, stop for a few seconds, then go on to the next
selection. Press this button again to stop scanning.
SIDE: Press this button to change the side of the tape
that is playing. (PLAY shows on the display.)

yellowblue
3-19
Using DSP Mode
DSP: The Digital Signal Processing (DSP) feature is used
to provide a choice of four different listening experiences:
TALK, DRIVER SEAT, LIVE and AUDITORIUM. DSP
can be used while listening to the radio, the cassette tape
player or the CD player. Press this button to turn DSP on.
Press and release this button until you reach the desired
selection. To turn DSP off, press and hold this button until
DSP OFF appears on the display. When DSP OFF is
displayed, the system will provide the best overall Bose

performance. The radio keeps separate DSP settings for
each band (except weather band, which is always set to
TALK), preset and source.

TALK: This setting is used when listening to
non
-musical material such as news, talk shows,
sports broadcasts and books on tape. TALK makes
spoken words sound very clear.

DRIVER SEAT: This setting adjusts the audio to
give the driver the best possible sound qualities.
DRIVER SEAT can be used at any time for any
material. Rear seat passengers in the vehicle may not
get the same effect.

LIVE: This setting is used to enhance the stereo effect.

AUDITORIUM: This setting is used to make the
listening space seem larger.Adjusting the Speakers
TONE: Press and release this button until the desired
BALANCE or FADE control is found.
LEVEL: After selecting the desired BALANCE or
FADE control, press the plus (+) or minus (
-) symbol
on this button to select the desired level.
Playing a Cassette Tape
With the radio on, insert a cassette tape. The tape will
begin playing as soon as it is inserted. When one side of
your cassette tape is done playing, auto reverse plays the
other side of your cassette tape. Cassette tapes may be
loaded with the radio off but they will not start playing
until the radio is on. If you want to insert a cassette tape
when the ignition is off, first press the eject button.
While the tape is playing, use the VOL, TONE, LEVEL
and DSP controls just as you do for the radio. Other
controls may have different functions when a tape is
inserted. The display will show an underlined tape
symbol. TAPE PLAY will appear on the display when a
tape is playing, with an arrow to indicate which side of
the tape is playing.

yellowblue
3-28 Theft-Deterrent Feature
THEFTLOCK
is designed to discourage theft of your
radio. Your vehicle has a ªbuilt
-inº theft-deterrent
feature on each radio that is automatic
-- there is no
programming required. The radio in your vehicle cannot
be used in any other vehicle. When the radio was
originally installed in your vehicle at the factory, it
stored the Vehicle Identification Number (VIN). Each
time the ignition is turned on, the VIN is verified. If the
vehicle's VIN does not match the VIN stored in the
radio, THEFTLOCK will be activated and the audio
system will not play. If the radio is removed from your
vehicle, the original VIN in the radio can be used to
trace the radio back to your vehicle.
Audio Steering Wheel Controls
Some audio controls
can be adjusted at the
steering wheel. They
include the following:
VOLUME: Press the up arrow lever to increase volume
and the down arrow lever to decrease volume.

yellowblue
6-63
Fuse Usage
COMFORT CD Player, Remote Keyless Entry
(RKE), Controlled Power Relay,
Air Control Module (ACM), PZM
AMP (Bose
Only) (Optional)Right and Left Hand Bose Relay,
Right and Left Front Speakers
(On Door), Right and Left Rear
Speakers, Bose Amplifier
PZM Passenger Zone Module (PZM)
RADIO/PHONE Radio Receiver, Radio Interface
Module (RIM) (Bose Only),
Phone, DAB Relay, Trunk Release
Relay, Fuel Door Release Relay,
High/Low
-Beam Relay
CLUSTER Steering Wheel Controls, Cluster
ACC PZM, Electrochromic Mirror,
Rain Sensor (Optional),
Accessory Relay
SPARE Not Used
HTD MIR Right and Left Outside
Heated MirrorFuse Usage
HTD SEAT R Passenger Heated Seat
Relay (Optional)
HTD SEAT L Driver Heated Seat
Relay (Optional)
PULL DOWN Trunk Pull
-Down Motor
HDLP WASH Headlamp Washers
ANTENNA Power Mast Antenna
RSS Damper Relay (ETC Only)
CONVENC Trunk Release Relay, Trunk
Release Solenoid, Fuel Door
Release Relay, Fuel Filler Door
Release Solenoid, Door Lock
Relay, Left Front Door Motors,
PZM, Door Unlock Relay
BATT Driver and Passenger Seat Lumbar
Switch (Optional), Driver and
Passenger Seat Belt Comfort
Solenoid, Memory Seat Module
RSS Road Sensing Suspension (RSS)
Module (ETC Only)
