1999 CADILLAC ELDORADO seat adjustment

yellowblue
1-2
Seats and Seat Controls
This section tells you about the power seats -- how to
adjust them, and also about the reclining front seatbacks,
lumbar adjustments, head restraints, heated seats and
seatback latches.
Power Seats
The power seat controls are located on the outboard side
of the front seat cushion.

Move the front of the control in the direction of the
arrows to adjust the front portion of the cushion up
or down.

Move the rear of the control in the direction of the
arrows to adjust the rear portion of the cushion up
or down.

Lift up or push down on both outer arrows at the
same time to move the entire seat up or down.

To move the whole seat forward or rearward, slide
the control in the direction of the center arrow.

yellowblue
1-3 Power Lumbar Control (If Equipped)
The lumbar control is
located on the outboard
side of each front seat. It
provides additional support
to your lower back and it
works independently of the
other seat controls.
Use the power seat control first to get the proper
position. Then proceed with the lumbar adjustment.
To reshape the lower seatback, press the lumbar control
forward to increase support and rearward to decrease
support. Press the control up or down to raise or lower
the support mechanism.
Keep in mind that as your seating position changes, as it
may during long trips, so should the position of your
lumbar support. Adjust the seat as needed.
If you have the optional personalization package, the
power lumbar control can be programmed for memory
recall. For more information, see ªMemory and
Personalization Featuresº in the Index.
Massaging Lumbar (If Equipped)
Push the power lumbar control up for half a second to
activate the massage feature. The massage cycle will run
for 10 minutes. The cycle can be interrupted by pushing
the lumbar control down and holding for not more than
half a second. The cycle will continue to run even if the
ignition is turned to OFF. The lumbar support can be
adjusted during the massage cycle by moving the
switch forward to increase support and rearward to
decrease support.
Memory Seat and Mirrors (If Equipped)
Automatic seat and mirror movement will occur if the
Remote Keyless Entry (RKE) transmitter is used to
enter the vehicle. The number on the back of the
transmitter corresponds to the 1 or 2 seat and mirror
position. After the unlock button is pressed on the RKE
transmitter (the ignition must be in LOCK) or when the
key is placed in the ignition, the seat and mirrors will
automatically adjust to the appropriate position.
Automatic seat and mirror movement is programmed
through the Driver Information Center (DIC) so that the
driver can select whether or not movement will occur
using the RKE transmitter or by placing the ignition key
in the ignition. For programming information, see
ªMemory and Personalization Featuresº in the Index.

yellowblue
1-14
Shoulder Belt Tightness Adjustment
Your car has a shoulder belt tightness adjustment
feature. If the shoulder belt seems too tight, adjust it
before you begin to drive.
1. Sit well back in the seat.
2. Start pulling the shoulder belt out.
3. Just before it reaches the end, give it a quick pull.4. Let the belt go back all the way. You should hear a
slight clicking sound. If you don't, the adjustment
feature won't set, and you'll have to start again.
5. Now you can add a small amount of slack. Lean
forward slightly, then sit back. If you've added more
than 1 inch (25 mm) of slack, pull the shoulder belt
out as you did before and start again.
If you move around in the vehicle enough, pull out the
shoulder belt, or open your door, the belt will become
tight again. If this happens, you can reset it.

yellowblue
2-48 Driver's Outside Auto-Dimming
Rearview Mirror
Only the driver's side outside mirror will adjust for the
glare of headlamps behind you. This feature is
controlled by the on and off settings on the
electrochromic mirror. See ªElectrochromic Day/Night
Rearview Mirror with Compassº in the Index.
Curb View Assist Mirror (If Equipped)
If your mirror is equipped with memory mirrors, it will
also be equipped with the curb view assist mirror
feature. This feature will cause the passenger's mirror to
tilt when the vehicle is moving in REVERSE (R). This
feature may be useful in allowing you to view the curb
when you are parallel parking (selected/programmed
through personalization on the DIC).
When the vehicle is shifted out of REVERSE (R) and a
five second delay has occurred, the passenger's mirror
will return to its original position. If further adjustment
is needed after the mirror is tilted, the mirror switch may
be used. The mirror then returns to its original position.
Convex Outside Mirror
Your passenger's side mirror is convex. A convex mirror's
surface is curved so you can see more from the driver's
seat. This mirror does not have a dimming feature.
CAUTION:
A convex mirror can make things (like other
vehicles) look farther away than they really are.
If you cut too sharply into the right lane, you
could hit a vehicle on your right. Check your
inside mirror or glance over your shoulder before
changing lanes.

yellowblue
2-79
VEHICLE OVERSPEED - 52: A failure in the
suspension control system has occurred when this
message appears. The Powertrain Control Module (PCM)
determines the speed your vehicle is limited to.
Have your vehicle serviced if this message appears.
VEHICLE SPEED LIMITED TO XXX MPH
(KM/H)
- 113: A failure in the suspension control
system has occurred when this message appears. The
Powertrain Control Module (PCM) determines the speed
your vehicle is limited to. Have your vehicle serviced if
this message appears. (The XXX indicates the speed
your vehicle is limited to.)
Memory and Personalization Features
(If Equipped)
Your vehicle may be equipped with the following
features that can be individually programmed,
memorized or personalized for up to two drivers. For
a brief description of each feature, see each feature in
the Index.Memory Seat and Mirrors
To begin programming,
adjust the driver's seat
(including lumbar
adjustments) and both
outside mirrors to a
comfortable position
and then press the
SET button. Within five
seconds, press button ª1.º
A second mirror and seating position may be
programmed by repeating the above steps and pressing
button ª2º instead of button 1. Note that each time a
memory button is pressed, a single beep will sound
through the left front speaker.
If your vehicle is in PARK (P), you can recall mirror and
seating positions by briefly pressing button 1 or 2. This
will adjust the seat and mirrors to where you have
previously programmed them. If you have accidentally
pressed one of the memory recall buttons and want to stop
seat or mirror movement, press one of the manual seat or
mirror control buttons. This cancels a memory recall.

yellowblue
2-80
You can also recall a seat and mirror position if your
vehicle is not in PARK (P). Press and hold either the
1 or 2 button until seat and mirror movement is
complete. Releasing the buttons will stop adjustment.
The EXIT button can be programmed to allow easy exit
for up to two drivers. Adjust the seat to a comfortable
ªexitº position and then press the SET button followed
by the EXIT button. While your vehicle is in PARK (P),
briefly press the EXIT button to recall your programmed
exit position.
Programmable Automatic Door Locks
Your vehicle's ignition must be in RUN. To begin
programming, press and hold the SKIP INFO and NO
INFO RESET buttons at the same time to display the
following prompts.
DOORS LOCK IN GEAR: All doors automatically
lock when shifted out of PARK (P). No automatic
door unlock.DRIVR UNLOCK IN PARK: All doors automatically
lock when shifted out of PARK (P). Only the driver's
door automatically unlocks when shifted into PARK (P).
DRIVR UNLOCK KEY OFF: All doors automatically
lock when shifted out of PARK (P). Only the driver's
door automatically unlocks when the ignition key is
turned to OFF.
DOORS UNLOCK IN PARK: All doors automatically
lock when shifted out of PARK (P) and unlock when
shifting into PARK (P).
DOORS UNLOCK KEY OFF: All doors
automatically lock when shifted out of PARK (P). All
doors automatically unlock when the ignition key is
turned to OFF.
A ªyesº or ªnoº response must be made after each
prompt is displayed in order to continue on to the next
prompt or personalization feature. Press the YES TRIP
RESET button to choose yes, press the NO INFO
RESET button to choose no or press the SKIP INFO
button to ªskipº to the next personalization feature.
FEATURE ON appears when a yes response is made
and FEATURE OFF appears with a no response.

yellowblue
8-11
Right Front Passenger Position 1-20 . . . . . . . . . . . . . . . . . .
Shoulder Belt Tightness Adjustment 1-14 . . . . . . . . . . . . . .
Smaller Children and Babies 1-32 . . . . . . . . . . . . . . . . . . . .
Use During Pregnancy 1-19 . . . . . . . . . . . . . . . . . . . . . . . . .
Why They Work 1-8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Chains 4-34 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Safety Defects, Reporting 7-10, 7-11 . . . . . . . . . . . . . . . . . . .
Safety Warnings and Symbols iii. . . . . . . . . . . . . . . . . . . . . . .
Seatback
Latches 1
-6 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reclining Front 1-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seats
Heated 1
-4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lumbar Control 1-3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Memory Function 1-3, 2-79 . . . . . . . . . . . . . . . . . . . . . . . . .
Power 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Restraint Systems 1-1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat Controls 1-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Securing a Child Restraint 1-40, 1-42, 1-44 . . . . . . . . . . . .
Second Gear, Automatic Transaxle 2-24 . . . . . . . . . . . . . . . . .
Security System 2-14, 2-16 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Service 6-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A/C System Message 2-76 . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Bag Message 2-76 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Brake Fluid Switch Message 2-76 . . . . . . . . . . . . . . . . . . . .
Bulletins, Ordering 7-11, 7-12 . . . . . . . . . . . . . . . . . . . . . . .
Charging System Message 2-76 . . . . . . . . . . . . . . . . . . . . . .
Electrical Sys Message 2-76 . . . . . . . . . . . . . . . . . . . . . . . . .
Engine Soon Light 2-66 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fuel System Message 2-76 . . . . . . . . . . . . . . . . . . . . . . . . . . Idle Control Message 2
-76 . . . . . . . . . . . . . . . . . . . . . . . . . .
Manuals, Ordering 7-11, 7-12 . . . . . . . . . . . . . . . . . . . . . . .
Parts Identification Label 6-55 . . . . . . . . . . . . . . . . . . . . . . .
Publications, Ordering 7-11, 7-12 . . . . . . . . . . . . . . . . . . . .
Ride Sys Message 2-76 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Stability Sys Message 2-77 . . . . . . . . . . . . . . . . . . . . . . . . .
Steering Sys Message 2-76 . . . . . . . . . . . . . . . . . . . . . . . . . .
Transmission Message 2-76 . . . . . . . . . . . . . . . . . . . . . . . . .
Vehicle Soon Message 2-76 . . . . . . . . . . . . . . . . . . . . . . . . .
Work, Doing Your Own 6-2 . . . . . . . . . . . . . . . . . . . . . . . . .
Service and Appearance Care 6-1 . . . . . . . . . . . . . . . . . . . . . .
Service and Owner Publications 7-11, 7-12 . . . . . . . . . . . . . .
Servicing Your Air Bag-Equipped Vehicle 1-26 . . . . . . . . . . .
Setting the Clock 3-9 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sheet Metal Damage 6-52 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shift Lever 2-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shift Lever, Positions 2-21 . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shifting
Automatic Transaxle 2
-21 . . . . . . . . . . . . . . . . . . . . . . . . . .
Into PARK (P) 2-27 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Out of PARK (P) 2-29 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Shoulder Belt Tightness Adjustment 1-14 . . . . . . . . . . . . . . . .
Signaling Turns 2-33 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SIR 1-20 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Skidding 4-14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Solar Sensor, Electronic 3-6 . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sound Equipment, Adding 3-30 . . . . . . . . . . . . . . . . . . . . . . . .
Spare Tire, Compact 5-31 . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Speaker Covers, Cleaning 6-49 . . . . . . . . . . . . . . . . . . . . . . . .
