1999 BUICK REGAL Owners Manual

yellowblue
6-65
Electrical System
Add-On Electrical Equipment
NOTICE:
Don't add anything electrical to your vehicle
unless you check with your dealer first. Some
electrical equipment can damage your vehicle
and the damage wouldn't be covered by your
warranty. Some add
-on electrical equipment can
keep other components from working as
they should.
Your vehicle has an air bag system. Before attempting to
add anything electrical to your vehicle, see ªServicing
Your Air Bag
-Equipped Vehicleº in the Index.
Headlamp Wiring
The headlamp wiring is protected by a circuit breaker in
the underhood electrical center. An electrical overload
will cause the lamps to go on and off, or in some cases
to remain off. If this happens, have your headlamp
system checked right away.
Windshield Wipers
The windshield wiper motor is protected by a circuit
breaker and a fuse. If the motor overheats due to heavy
snow, etc., the wiper will stop until the motor cools. If
the overload is caused by some electrical problem, have
it fixed.
Power Windows and Other Power Options
Circuit breakers in the fuse panel protect the power
windows and other power accessories. When the current
load is too heavy, the circuit breaker opens and closes,
protecting the circuit until the problem is fixed.
ProCarManuals.com

yellowblue
6-66 Fuses and Circuit Breakers
The wiring circuits in your vehicle are protected from
short circuits by a combination of fuses, circuit breakers
and fusible thermal links in the wiring itself. This
greatly reduces the chance of fires caused by
electrical problems.
Look at the silver
-colored band inside the fuse. If the
band is broken or melted, replace the fuse. Be sure you
replace a bad fuse with a new one of the identical size
and rating.
Instrument Panel Fuse Block
Some fuses are located in a
fuse block on the
passenger's side of the
instrument panel. Pull off
the cover labeled FUSES to
expose the fuses.
Circuit Description
Breaker
A Tire Inflation Monitor Reset
Button
B Power Windows/Sunroof
C Rear Defog
D Power Seats
ProCarManuals.com

yellowblue
6-67
Fuse Description
1 Ignition Key Solenoid
4 Ignition Signal
-- Hot in Run and
Start
-- PCM, BCM U/H Relay
5 Remote Radio Premium Sound
6 Power Mirrors
8 Panel Dimming
10 Ignition Signal
-- Hot in Run,
Unlock and Start
-- Cluster,
Powertrain Control Module,
Body Control Module
13 DRL Module
14 Interior Lamps
15 Door Locks
17 Taillamps, License Lamp
18 Radio
19 Heated Mirror
20 Cruise Control
22 ClustersFuse Description
23 Cigarette Lighter
-- Auxiliary
Power Connection (Power Drop),
Data Link
24 Stoplamps
26 Parking Lamps
27 Auxiliary Power Connection
(Power Drop)
-- Hot in ACC
and Run
28 Crank Signal
-- Body Control
Module, Cluster, Powertrain
Control Modules
29 Ignition Signal
-- HVAC
Control Head
30 Shifter Lock Solenoid
31 Air Bag
32 Body Control Module
33 Hazard Flashers
34 Driver's Heated Seat
36 Ignition Signal
-- Hot in ACC and
Run
-- Body Control Module
ProCarManuals.com

yellowblue
6-68
Fuse Description
38 Low Blower
39 Anti
-Lock Brakes
40 Turn Signals, Cornering Lamps
41 Radio, HVAC Head, Remote
Keyless Entry, Cluster, CEL TEL
42 High Blower
43 Passenger's Heated Seat
44 Audio Steering Wheel Controls
45 WipersUnderhood Electrical Center
-- Passenger's Side
Some fuses and relays are located in the underhood electrical
center on the passenger's side of the engine compartment.
Fuse Description
1 ABS
2 Starter Solenoid
ProCarManuals.com

yellowblue
6-69
Fuse Description
3 Power Seats, Rear Defog,
Heated Seats
4 High Blower, Hazard Flasher,
Stoplamps, Power Mirror,
Door Locks
5 Ignition Switch, BTSI, Stoplamps,
ABS, Turn Signals, Cluster, Air
Bag, DRL Module
6 Cooling Fan
7 Interior Lamps, Retained
Accessory Power, Keyless Entry,
CEL TEL, Data Link, HVAC
Head, Cluster, Radio, AUX Power
(Power Drop), Cigarette Lighter
8 Ignition Switch, Wipers, Radio,
Steering Wheel Controls, Body
Control Module, AUX Power
(Power Drop), Power Windows,
Sunroof, HVAC Controls, DRL,
Rear Defog Relay
9 Cooling Fan 2
10 Cooling Fan 3Relay Description
11 Starter Solenoid
12 Cooling Fan 1
13 Ignition Main
14 Not Used
15 A/C Clutch
16 Horn
17 Fog Lamps
18 Fuel Pump, Speed Control
(L67 only)
19 Fuel Pump
20 Not Used
21 Generator
22 ECM
23 A/C Compressor Clutch
24 Cooling Fan
25 Electronic Ignition
26 Transaxle
ProCarManuals.com

yellowblue
6-70
Fuse Description
27 Horn
28 Fuel Injector
29 Oxygen Sensor
30 Engine Emissions
31 Fog Lamps
32 Headlamp (Right)
33 Rear Compartment Release
34 Parking Lamps
35 Fuel PumpFuse Description
36 Headlamp (Left)
37 Spare
38 Spare
39 Spare
40 Spare
41 Spare
42 Spare
43 Fuse Puller
SYMBOL A/C Compressor Clutch Diode
ProCarManuals.com

yellowblue
6-71
Replacement Bulbs
Exterior Lamps Bulb Number
Back
-Up 1156. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Center High
-Mounted Stop 3155. . . . . . . . . . . . . . . .
Front Parking/Turn Signal 4175 NAK. . . . . . . . . . . . .
Headlamp, High Beam 9005. . . . . . . . . . . . . . . . . . . .
Headlamp, Low Beam 9006. . . . . . . . . . . . . . . . . . . .
Stop/Tail/Turn Signal 3057. . . . . . . . . . . . . . . . . . . . .
Tail (Applique) 194. . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Lamps BulbNumber
Dome Lamp 9425542. . . . . . . . . . . . . . . . . . . . . . . . .
*For service information on these bulbs, contact your
dealer service department.
Capacities and Specifications
4T65E:
Automatic Transaxle
Pan Removal and Replacement 7.4 quarts (7.0 L). .
After Complete Overhaul 10.0 quarts (9.5 L). . . . .
* When draining/replacing converter, more fluid will
be needed.
Cooling System Including Reservoir
3800 (Code K) V6 12.3 quarts (11.6 L). . . . . . . . . . .
3800 Supercharged (Code 1) V6 12.3 quarts (11.6 L)
Refrigerant (R
-134a), Air Conditioning*1.88 lbs.
(0.85 kg)
*See ªAir Conditioning Refrigerantsº later in this
section.
Engine Crankcase
Oil and Filter Change 4.5 quarts (4.3 L). . . . . . . . . . .
Wheel Nut Torque100 lb
-ft (140 N´m) . . . . . . . . . .
Fuel Tank17.5 gallons (66.2 L) . . . . . . . . . . . . . . . . .
*Note: All capacities are approximate. When adding, be
sure to fill to the approximate level, as recommended in
this manual. See ªRecommended Fluids and Lubricantsº
in the Index.
ProCarManuals.com

yellowblue
6-72 Engine Specifications
3800 Supercharged 3800 (Code K) V6
(Code 1) V6
Type V6 V6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Displacement 231 CID 231 CID. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Firing Order 1
-6-5-4-3-21-6-5-4-3-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Thermostat Temperature 195
F (91
C) 195
F (91
C) . . . . . . . . . . . . . . . . . . . . . .
Horsepower 240 @ 5200 200 @ 5200. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Air Conditioning Refrigerants
Not all air conditioning refrigerants are the same.
If the air conditioning system in your vehicle needs
refrigerant, be sure the proper refrigerant is used.
If you're not sure, ask your dealer.
