1998 VOLVO V90 roof

1998 Volvo S90
Chapter 2 - Instruments, switches and controlsInstruments, switches and controls
pg. 14

Instruments, switches and controls pg. 15
Shiftlock

When your car is parked, the gear selector is
locked in the (P)ark position. To release the
selector from this position, turn the ignition key
to position II (or start the engine), depress the
brake pedal, press the button on the front side of
the gear selector and move the selector from (P)
ark.
If it is necessary to manually override the
Shiftlock system:
l Turn the starting (ignition) key to position
I
l Press firmly on the OVERRIDE" button
located near the base of the gear selector.
l While holding the override button down,
move the gear selector from the (P)ark
position.

Keylock
Some of the items below are available on certain
models only.


1
Air vent...pg. 25
2
Headlights, parking lights...pg. 20
3
Rear fog light...pg. 22
4
Front fog lights...pg. 22
5 Space for additional equipment
6
Power antenna (sedans only)...pg. 22
7
Instruments...pg. 15-17
8
Electrically operated sun roof...pg. 23,
Electrically operated sun roof...pg. 49
9
Heated rear window/side door mirrors...pg. 23
10
Hazard warning flasher...pg. 23
11
Central lock switch...pg. 23
12
Air vents...pg. 25
13
Heating and ventilation...pg. 25-27
14
Passenger's side SRS (air bag)...pg. 6
15
Audio system...pg. 131
file:///K|/ownersdocs/1998/1998_SV90/98S90_014.htm (1 of 3)12/30/2006 \
1:52:36 PM

1998 Volvo S90
A - Rear fog light*

The indicator light in the
instrument panel will light
up when the rear fog light
is on. This fog light is
considerably brighter than
the normal tail light and
should be used only when
the atmospheric
conditions, such as fog,
rain, snow, smoke or dust
reduce the daytime or
nighttime visibility of
other vehicles to less than
500 ft (150 meters).

*By design, there is one
rear fog light only, located
in the driver's side tail light
cluster.

B- Instrument
illumination

To increase the brightness,
rotate the switch upward.
To decrease the brightness,
rotate the switch
downward.

C- Front fog lights

The indicator light in the
switch will light up when
the front fog lights are on.
The front fog lights will
only function when the low
beam headlights are on.

NOTE:Local regulations
governing the use of fog
lights may vary.
D- Power antenna (sedans only)

This button can be used to lower the antenna
when, for example, you are listening to a tape or
CD, or when you are driving into a low-roof
garage or car wash. CAUTION: The antenna must be lowered
before washing the car in an automatic car wash. E- Steering
wheel adjustment

The steering wheel
can be adjusted to 3
different positions.
Move the control on
the left side of the
steering column
downward and hold
it in place. Adjust
the steering wheel
to the position
desired. Release the
control and check
that the steering
wheel is locked in
position.

WARNING!Do
not adjust the
steering wheel
while driving.

file:///K|/ownersdocs/1998/1998_SV90/98S90_017.htm (6 of 7)12/30/2006 \
1:52:36 PM

1998 Volvo S90
Chapter 2 - (cont.)
Sun roof, Hazard warning flasher, Tailgate wiper/washer, heated rear window
pg. 23
C- Heated rear window,
heated side-door mirrors
(certain models)

Depress the switch to start
heating of rear window and side
mirrors. Both orange control
lights in the switch will
illuminate. A timer switches off
the side mirror heating after
approx. 6 minutes and the rear
window demister after 12
minutes. The control lights go
out correspondingly.

D- Hazard warning flasher

The four-way flasher should be
used to indicate that the vehicle
has become a traffic hazard.

NOTE:Regulations regarding the
use of the hazard warning flasher
may vary from state to state.

E-Central lock switch

Press the switch to lock/unlock
the doors and trunk/tailgate.
Lock: press the lower section of
the switch
Unlock: press the upper section
of the switch.

NOTE: The lock function only
operates if the doors are closed.
file:///K|/ownersdocs/1998/1998_SV90/98S90_023.htm (1 of 7)12/30/2006 \
1:52:37 PM

1998 Volvo S90
A- Tailgate window wiper/
washer (wagon)

The tailgate window wiper/
washer is operated by a switch
at the end of the wiper level.
1. The wiper operates
continuously.
2. Intermittent position: the
wiper strokes approximately
every 10 seconds.
3. Tailgate washer (note that the
wiper also operates when this
button is depressed): after the
button is released the wiper
strokes 2-3 additional times
before stopping.
The electrical circuit is
protected by fuse 19, located in
the central electrical unit. See
the section entitled "Fuses". B- Electrically operated
sun roof (certain models)

The sun roof can be operated in
two ways; as a conventional
sliding roof; or the rear edge can
be raised to provide increased
ventilation. On models equipped
with the power glass sun roof, a
manually operated sun shade is
also provided.
See page 49 for operating
instructions.

NOTE:In case of sun roof
malfunction, see page 49.
Cruise control pg. 24
NOTE:
When driving in hilly terrain,
the gearbox may tend to jump
between different gears. This
can be avoided by selecting
gear selector position 3
(intermediate position).
Normally, the (E)conomy
mode should be used when
the cruise control is engaged.

Acceleration
Momentary acceleration, such
as for passing, does not
interrupt cruise control
operation. The previously
selected speed will be
maintained without having to
set the switch to RESUME.
To disengage the cruise
file:///K|/ownersdocs/1998/1998_SV90/98S90_023.htm (2 of 7)12/30/2006 \
1:52:37 PM

1998 Volvo S90
heating positions.
Water under the vehicle in hot weather
can be the result of condensation from
the air conditioning system.

Optimum defrosting



Set the function dial to
.
The air conditioning light will NOT go
on.
When the windows have cleared, set the
blower control to position 2.
conditions, heavy rain, sleet,
etc., it may be better to use
the manual rather than the
automatic setting to defrost
the windows. Set the mode
selector to "Defrost" or
"Defrost/floor" and the fan
speed to 3 or higher. Also
shut the middle air vents. NOTE:
l Do not place any
objects over the
sensor in the
passenger side
speaker grille as
this will cause the
ECC system to
respond incorrectly
to ambient
conditions.
l To help maintain
stable passenger
compartment
temperature when
driving with the sun
roof or windows
open, place the
blower control in
position "0" and
adjust the desired
temperature
manually.
l The air
conditioning
compressor only
engages at
temperatures above
41°F (5°C).
l Always keep the air
intake grille at the
base of the
windshield free of
snow.




Contents | Top of Page
file:///K|/ownersdocs/1998/1998_SV90/98S90_023.htm (7 of 7)12/30/2006 \
1:52:37 PM

1998 Volvo S90
Chapter 3 - Body and interior
pg. 31
Body and
interior
The seats,
doors, sun
roof, mirrors,
etc. are
described on
the following
pages.
Keys, Doors and Locks pg. 32

Remote keyless entry system pg. 32
Front seats pg. 34
Rear/side view mirrors, Vanity mirror pg. 35
Interior light, Rear reading lights pg. 36
Child safety locks, Trunk lid pg. 37
Passenger compartment storage spaces pg. 38
Hood pg. 39
Trunk light, spare tire, jack (sedan) pg. 40
Wagon tailgate/child safety lock pg. 41
Concealed storage bins, Folding rear seat (wagon) pg. 42
Removing seat cushions, Securing cargo (wagon) pg. 44
Cargo space lighting, spare tire, jack (wagon) pg. 45
Cargo space - loading pg. 46
Cargo barrier pg. 47
Luggage cover pg. 48
Sun roof pg. 49
Long load storage pg. 50
Alarm pg. 51
Keys, Doors and Locks pg. 32
file:///K|/ownersdocs/1998/1998_SV90/98S90_031.htm (1 of 6)12/30/2006 \
1:52:39 PM

1998 Volvo S90
Hood pg. 39





To open the hood

Pull the release handle (located under the left side
of the dash).
Lift the hood slightly, insert a hand under the
center line of the hood and depress the safety
catch handle. Open the hood.
WARNING!
Check that the hood locks properly when
closed.





The hood opens normally to an angle of
approximately 55°. To open it to a completely
vertical position, press both red catches upward as
shown in the illustration. Make sure that the
catches return to their normal position. When
closing the hood, lift it slightly first and then press
the catches downward.
Ensure adequate clearance in low-roof garages to
avoid damaging the hood.
Trunk light, Spare tire (sedan) pg. 40
file:///K|/ownersdocs/1998/1998_SV90/98S90_037.htm (2 of 4)12/30/2006 \
1:52:39 PM

1998 Volvo S90
Chapter 3 - Body and interior (cont.)Luggage cover (wagon)
pg. 48



Luggage cover

Your car can be fitted with a luggage cover as
an optional extra. The pull-out luggage cover
is like a blind behind the rear seat. Pull it out
and attach it at the rear of the luggage
compartment to conceal the cargo and keep it
out of sight.
(See picture.)



Removing luggage cover
(see illustration above)

If, as a result of the size of the cargo, you
want to remove the luggage cover
temporarily:
l Push the end of the luggage cover towards
the middle
l Pull the luggage cover backwards
l When installing, reverse this procedure
Sun roof/sun shade (certain models) pg. 49


Electrically-operated sun
roof

The switch for operating the
sun roof is located on the
instrument panel. The starting
(ignition) key must first be
turned to position II.
Sun shade

l The sun shade will open automatically


NOTE:
l The electrically-operated sun roof has
