1998 VOLVO V90 trunk

1998 Volvo S90
Chapter 2 - (cont.)
Sun roof, Hazard warning flasher, Tailgate wiper/washer, heated rear window
pg. 23
C- Heated rear window,
heated side-door mirrors
(certain models)

Depress the switch to start
heating of rear window and side
mirrors. Both orange control
lights in the switch will
illuminate. A timer switches off
the side mirror heating after
approx. 6 minutes and the rear
window demister after 12
minutes. The control lights go
out correspondingly.

D- Hazard warning flasher

The four-way flasher should be
used to indicate that the vehicle
has become a traffic hazard.

NOTE:Regulations regarding the
use of the hazard warning flasher
may vary from state to state.

E-Central lock switch

Press the switch to lock/unlock
the doors and trunk/tailgate.
Lock: press the lower section of
the switch
Unlock: press the upper section
of the switch.

NOTE: The lock function only
operates if the doors are closed.
file:///K|/ownersdocs/1998/1998_SV90/98S90_023.htm (1 of 7)12/30/2006 \
1:52:37 PM

1998 Volvo S90
Chapter 3 - Body and interior
pg. 31
Body and
interior
The seats,
doors, sun
roof, mirrors,
etc. are
described on
the following
pages.
Keys, Doors and Locks pg. 32

Remote keyless entry system pg. 32
Front seats pg. 34
Rear/side view mirrors, Vanity mirror pg. 35
Interior light, Rear reading lights pg. 36
Child safety locks, Trunk lid pg. 37
Passenger compartment storage spaces pg. 38
Hood pg. 39
Trunk light, spare tire, jack (sedan) pg. 40
Wagon tailgate/child safety lock pg. 41
Concealed storage bins, Folding rear seat (wagon) pg. 42
Removing seat cushions, Securing cargo (wagon) pg. 44
Cargo space lighting, spare tire, jack (wagon) pg. 45
Cargo space - loading pg. 46
Cargo barrier pg. 47
Luggage cover pg. 48
Sun roof pg. 49
Long load storage pg. 50
Alarm pg. 51
Keys, Doors and Locks pg. 32
file:///K|/ownersdocs/1998/1998_SV90/98S90_031.htm (1 of 6)12/30/2006 \
1:52:39 PM

1998 Volvo S90


Master key
This key operates all locks



Service key
Front doors, starting (ignition)
switch/steering wheel lock Number tag

The key number codes are
stamped on a separate tag supplied
with the keys. This tag should be
separated from the key ring and
kept in a safe place. In the event
the original keys are lost,
duplicates may be ordered from
your Volvo retailer.
Doors and locks

Your car is equipped with a central
locking system.
The key used on either of the front
doors will lock/unlock all doors and
trunk/tailgate.
Turn the key once in the driver's
door to unlock that door only.
Turn the key in the same direction
again (within 10 seconds) to unlock
all doors, trunk/tailgate.
One turn with the key towards
locking in either of the front doors
locks all doors, trunk/tailgate.
Use the switch on the instrument
panel (with the doors closed) to
lock/unlock the car from the inside.

Check the action of the buttons on
the other doors to verify their
correct function (lock/unlock). The
driver's door can be locked only by
using the key when outside the
vehicle.
On vehicles equipped with the
optional remote control locking
system, refer to the following
page.

WARNING!
The doors should not be locked
while driving. In case of an
accident, this may hinder rapid
access to the occupants of the
vehicle. (Also see information
on "child safety locks").
Remote keyless entry system pg. 33
file:///K|/ownersdocs/1998/1998_SV90/98S90_031.htm (2 of 6)12/30/2006 \
1:52:39 PM

1998 Volvo S90


Remote keyless entry
system

As an option, your car can be
equipped with a remote
control transmitter. This
transmitter uses a radio
frequency which will allow
"keyless" entry into the
passenger compartment or the
trunk. You will be supplied
with two coded key ring
transmitters, which will
enable you to lock/unlock all
doors and the trunk/tailgate
from a distance of 10-15 feet
(3-5 meters).

To lock :
Press the lock button once to
lock all doors and trunk/
tailgate.

To unlock :
Press the unlock button once
to unlock the driver's door
only.
Press the unlock button again
(within 10 seconds) to unlock
all doors and trunk/tailgate.


Aim the base of the remote control unit at
the car to get the best range.

On vehicles equipped with an alarm, the
alarm will also be activated/deactivated by
this system.
As an extra security precaution in certain
situations (valet parking, etc.), Volvo
recommends that the transmitter not be
included when the keys are given to
anyone. The service key can be used
instead. If one of the transmitters is
misplaced, contact the nearest authorized
Volvo retailer for assistance.

Batteries

The remote transmitter is powered by 2
three-volt batteries, type CR 1220. If three
short signals are audible from the
transmitter each time you lock/unlock the
car, this indicates that the batteries are
weak.
Replacement: Remove the battery cover
on the back of the transmitter with a coin.
Replace the batteries. Reinstall the cover,
making sure it is secured tightly to help
protect the transmitter. New transmitters

If you purchase additional
transmitters, they must be
programmed to function with
your remote keyless entry
system. Please refer to page 49
for instructions.

This device complies with
FCC rules Part 15.
Operations is subject to the
following two conditions:
(1) This device may not
cause harmful interference
and (2) this device must
accept any interference that
may be received, including
interference that may cause
undesired operation.

WARNING! Volvo does
not recommend using the
transmitter to lock the doors
from inside the car. On cars
equipped with an alarm, the
alarm would be activated
and would sound when one
of the doors is opened. The
doors must not be locked
using the remote transmitter
while the vehicle is
occupied. In case of an
accident, this may hinder
rapid access to the
occupants of the vehicle.
The alarm will also sound
on models equipped with
this feature.
Front seats pg. 33
file:///K|/ownersdocs/1998/1998_SV90/98S90_031.htm (3 of 6)12/30/2006 \
1:52:39 PM

1998 Volvo S90
Chapter 3 - Body and interior (cont.)
Child safety locks, Trunk lid (sedan)
pg. 37


Child safety locks

The buttons are located on the rear door
jams.

A The door lock functions normally.
B The door cannot be opened from the
inside.
Normal operation from outside.
WARNING!
Remember, in the event of an
accident, the rear seat passengers
cannot open the doors from the inside
with the buttons in
position B.

Trunk lid

The trunk lock is incorporated in the
central locking system. This means that
you can either lock or unlock the trunk
by means of either of the front doors.
You can also operate the trunk lock
directly with the master key even if the
vehicle is centrally locked.

Unlocking Locking


Withdraw key in vertical position.
The trunk lock can also be disconnected
from
the central locking system by turning the
key counterclockwise as shown below:

Withdraw key in
horizontal position.

The trunk is now
always locked. This
option can be used for
e.g., valet parking. If you give only the
service key to the driver it will not be
possible to open the trunk. Please be
aware that this setting may preclude
access to the spare tire and jack.

To reconnect the lock to the central
locking system:

Withdraw key in
vertical position
Storage spaces pg. 38
file:///K|/ownersdocs/1998/1998_SV90/98S90_037.htm (1 of 4)12/30/2006 \
1:52:39 PM

1998 Volvo S90
Hood pg. 39





To open the hood

Pull the release handle (located under the left side
of the dash).
Lift the hood slightly, insert a hand under the
center line of the hood and depress the safety
catch handle. Open the hood.
WARNING!
Check that the hood locks properly when
closed.





The hood opens normally to an angle of
approximately 55°. To open it to a completely
vertical position, press both red catches upward as
shown in the illustration. Make sure that the
catches return to their normal position. When
closing the hood, lift it slightly first and then press
the catches downward.
Ensure adequate clearance in low-roof garages to
avoid damaging the hood.
Trunk light, Spare tire (sedan) pg. 40
file:///K|/ownersdocs/1998/1998_SV90/98S90_037.htm (2 of 4)12/30/2006 \
1:52:39 PM

1998 Volvo S90


Trunk light

A Light always off.
B Light is on when trunk lid is opened.

NOTE:See pages 78-79 for information on how
the jack should be used.
Tailgate, Child safety lock (wagon) pg. 41

Opening the tailgate


Tailgate

The tailgate is opened by pressing up
the catch on the handle.

To unlock - turn the key clockwise and
allow it to spring back.

To lock - turn the key counter-
clockwise and allow it to spring back.

NOTE:The tailgate is also unlocked
and locked at the same time as either of
the front doors.
Opening from the inside


To open the tailgate from the inside of
the vehicle move the lever to the left and
push outwards.
The handle can be used to pull the
tailgate closed from the inside.
WARNING! Do not drive with
tailgate open! Poisonous exhaust
gases may enter via the open tailgate.
Location and setting of child safety lock


Child Safety lock

The tailgate incorporates a safety catch
which is located to the side of the lock.

A the tailgate functions normally
B the tailgate cannot be opened from the
inside.

WARNING!Remember, in the event
of an accident, the tailgate cannot be
opened from the inside when the
safety catch is in position B.


file:///K|/ownersdocs/1998/1998_SV90/98S90_037.htm (3 of 4)12/30/2006 \
1:52:39 PM

1998 Volvo S90
WARNING!
Always turn engine off and apply
parking brake when loading/
unloading the vehicle. Place
transmission selector in P (PARK)
position to help prevent
inadvertent movement of selector.
Alarm pg. 51

Alarm LED


Alarm

To lock: Press the lock/panic button
once to lock all doors and trunk/tailgate
and arm the security system. Lamps will
flash to acknowledge that the vehicle is
locked and the security system is armed.
To unlock: Press the unlock button once
to unlock the driver's door only and
disarm the security system.
Press the unlock button again (within 10
seconds) to unlock all doors and trunk/
tailgate.
Emergency function

To activate the " panic alarm
"function:
Press and hold lock/panic button for at
least 3 seconds. The car's lights will
flash and an alarm will sound for
approximately 30 seconds.







This function can be switched off at
any time by pressing either of the
buttons.

Programming a transmitter

New transmitters (max. 4) must be
programmed to function with your
alarm system. To do this:
l Make sure all doors, hood and
trunk/tailgate are closed.
l Turn the ignition on and off 5
times within 10 seconds. On the
fifth try, leave the ignition on.
l Press either button on the
transmitter. NOTE: The first transmitter must be
programmed within 15 seconds, the
others within 10 second intervals.
When the alarm system accepts the
codes from each transmitter, the
LED on the dash will glow steadily
for several seconds.
l Switch the ignition off and test the
transmitter(s).

Batteries

The remote transmitter is powered
by 2 three-volt batteries, type CR
1220. If three short signals are
audible from the transmitter each
time you lock/unlock the car, this
indicates that the batteries are weak.
Replacement: Remove the battery
cover on the back of the transmitter
with a coin. Replace the batteries.
Reinstall the cover, making sure it is
secured tightly to help protect the
transmitter.

NOTE: If only the driver's door is
unlocked, the lock will automatically
reengage (re-lock) and the alarm will
reset after 30 seconds unless the
door has been opened.
If all of the doors were unlocked (by
pushing button 2 twice within 10
seconds) and no door/trunk/tailgate
was opened within two minutes, all
locks will reengage and the alarm
will reset. This is to prevent the
vehicle from being left unlocked if
the unlock button is inadvertently
pressed.
The lock/unlock and alarm features
file:///K|/ownersdocs/1998/1998_SV90/98S90_048.htm (3 of 4)12/30/2006 \
1:52:40 PM
