1998 TOYOTA TACOMA Owners Manual

'98 Tacoma (U)17
ÐRemoving
1. Pull the handle down while pushing
in one of the lock buttons.2. Push in the retaining spring arms asshown and push up the moon roof.3. Push back the auxiliary catch to re-lease it from the hook. Then lift the
moon roof panel and pull it out.

'98 Tacoma (U)
18
ÐInstalling
1. Insert the flat hinges of the moon
roof panel into the cutouts on the
body. Then slowly lower it while
holding the roof with your hands.
Make sure both flat hinges are inserted
into the cutouts.2. Press in the retaining spring arms and insert them into the holes. Then
push the handle up with the palm of
your hand and lock the roof. Detachable sun shadeTo remove: Support the sun shade pan-
el with your hand while you unlock the
sun shade by turning the knob counter-
clockwise.
To install: Hang the two hinges of the
sun shade panel onto the hooks pro-
vided. Then push up the sun shade
panel while turning the knob counter-
clockwise.
CAUTION
For safety, do not remove the sun
shade while driving.

'98 Tacoma (U)19
Part 1
OPERATION OF
INSTRUMENTS
AND CONTROLSÐ
Chapter 1- 3
Seats, Seat belts,
Steering wheel
and Mirrors
Seats
Front seats
Rear seats
Head restraints
Armrest
Seat belts
SRS driver and front passenger
airbags
Passenger airbag cutoff system
Child restraint
Tilt steering wheel
Outside rear view mirrors
Anti- glare inside rear view mirror
Seats
While the vehicle is being driven, all ve-
hicle occupants should have the seatback
upright, sit well back in the seat and prop-
erly wear the seat belts provided.
CAUTION

Do not drive the vehicle unless the
occupants are properly seated. Do
not allow sitting on top of a folded-
down seatback, or in the luggage
compartment. Persons not properly
seated and not properly restrained
by seat belts can be severely in-
jured in the event of emergency
braking or a collision.
During driving, do not allow pas-
sengers to stand up or move
around between seats. Severe inju-
ries can occur in the event of emer-
gency braking or a collision.
Adjust the driver's seat so that the foot
pedals, steering wheel and instrument
panel controls are within easy reach of
the driver.
CAUTION
Adjustments should not be made
while the vehicle is moving, as the
seat may unexpectedly move and
cause the driver to lose control of
the vehicle.
When adjusting the seat, be careful
not to hit the seat against a pas-
senger or luggage.
After adjusting the seat position, try
sliding it forward and backward to
make sure it is locked in position.
After adjusting the seatback, exert
body pressure to make sure it is
locked in position.
Do not put objects under the seats.
The objects may interfere with the
seat-lock mechanism or unexpected-
ly push up the seat position adjust-
ing lever; the seat may suddenly
move, causing the driver to lose
control of the vehicle.
Front seatsÐ
ÐSeat adjustment precautions

'98 Tacoma (U)
20
While adjusting the seat, do not put
your hands under the seat or near
the moving parts. You may catch
and injure your hands or fingers.1. SEAT POSITION ADJUSTING LEVER
Pull the lever up. Then slide the seat
to the desired position with slight
body pressure and release the lever.
2. SEATBACK ANGLE ADJUSTING LEVER (except bench seat)
Lean forward and pull the lever up.
Then lean back to the desired angle
and release the lever.
CAUTION
To reduce the risk of sliding under
the lap belt during a collision, avoid
reclining the seatback any more than
needed. The seat belts provide maxi-
mum protection in a frontal or rear
collision when the driver and the pas-
senger are sitting up straight and
well back in the seats. If you are
reclined, the lap belt may slide past
your hips and apply restraint forces
directly to the abdomen. Therefore, in
the event of a frontal collision, the
risk of personal injury may increase
with increasing recline of the seat- back.
ÐAdjusting front seats

'98 Tacoma (U)21
3. DRIVER'S SEAT CUSHION ANGLE
ADJUSTING KNOB (on some models)
Turn the knob either way.
4. DRIVER'S SEAT LUMBAR SUPPORT ADJUSTING LEVER (on some models)
Pull the lever forward or backward.
For easy access to the rear seat, do this.
1. Lift the seatback angle adjusting lever or press the pedal behind the seat-
back.
The seat will slide forward.
2. Move the seat to the front-most posi- tion.
After passengers are in, lift up the seat-
back and return the seat until it locks.
CAUTION
After putting back the seat, try
pushing the seat forward and rear-
ward to make sure it is secured in
place.
Never allow anyone to rest their
foot on the press pedal while the
vehicle is moving.
ÐMoving passenger 's seat for
rear seat entry (Xtra-cab
models)

'98 Tacoma (U)
22
ÐFolding seatback (bench seat)
Pull the seatback lock release lever and
fold down the seatback.
Hold the lever until you have swung the
seatback forward slightly.
CAUTION
When returning the seatback to the
upright position:
Make sure the seat belts are not
twisted or caught in the seatback
and are arranged in their proper
position for ready use.
Make sure the seatback is securely
locked by pushing forward and rear-
ward on the top of the seatback.
Rear seats (jump seats)
To raise the bottom cushion, pull it up.
To lower the bottom cushion, push it down.
See ºLuggage stowage precautionsº in
Part 2 for precautions to observe in load-
ing luggage.
CAUTION
When returning the bottom cushion to
its original position: Make sure the seat belts are not
twisted or caught under the bottom
cushion and are arranged in their
proper position for ready use.
Make sure the bottom cushion is
securely locked by trying to pull up
the edge of the bottom cushion.

'98 Tacoma (U)23
Head restraints
For your safety, adjust the head re-
straint before driving.
To raise: Pull it up.
To lower: Push it down while pressing the
lock release button.
On some models, you can also move the
head restraint forward or backward. If
such adjustment is desired, pull or push
the head restraint.
The head restraint is most effective when
it is close to your head. Therefore, using
a cushion on the seatback is not recom-
mended.
CAUTION

Adjust the center of the head re-
straint so that it is closest to the
top of your ears.
After adjusting the head restraint,
make sure it is locked in position.
Do not drive with the head re-
straints removed.
Armrest
To use the armrest, pull it out as
shown above.
NOTICE
To prevent damage to the armrest,
avoid putting heavy loads on it.

'98 Tacoma (U)
24
Toyota strongly urges that the driver and
passengers in the vehicle be properly re-
strained at all times with the seat belts
provided. Failure to do so could increase
the chance of injury and/or the severity of
injury in accidents.
Child.
Use a child restraint system ap-
propriate for the child until the child be-
comes large enough to properly wear the
vehicle's seat belts. See ºChild restraintк
for details.
NORMAL-CAB MODELSÐ
If a child is too large for a child restraint
system, the child s hould sit in the seat
and must be restrained using the vehicle's
seat belt.
XTRA-CAB MODELSÐ
If a child is too large for a child restraint
system, the child s hould sit in the rear
seat and must be restrained using the
vehicle's seat belt. According to accident
statistics, the child is safer when properly
restrained in the rear seat than in the
front seat. If a child must sit in the front
seat, the seat belts should be worn prop-
erly. If a child must sit in the front seat, the
seat belts should be worn properly. If an
accident occurs and the seat belts are not
worn properly, the force of the rapid infla-
tion of the airbag may cause death or
serious injury to the child.
Do not allow the child to stand up or
kneel on either rear or front seats. An
unrestrained child could suffer serious in-
jury during emergency braking or a colli-
sion. Also, do not let the child sit on your
lap. It does not provide sufficient restraint.
Small-framed person or youth in a
3-point type seat belt.
On models with a
bench seat, have a small-framed person
or youth sit slightly closer to the center
of the vehicle (so the shoulder belt does
not cross over the neck). On models with
separate seats, move the seat fully back-
ward.
Pregnant woman. Toyota recommends the
use of a seat belt. Ask your doctor for
specific recommendations. The lap belt
should be worn securely and as low as
possible over the hips and not on the
waist.
Injured person. Toyota recommends the
use of a seat belt. Depending on the inju-
ry, first check with your doctor for specific
recommendations.
CAUTION
Persons should ride in their seats
properly wearing their seat belts
whenever the vehicle is moving.
Otherwise, they are much more likely
to suffer serious bodily injury or
death in the event of sudden braking
or a collision.
When using the seat belts, observe
the following: Use the belt for only one person at
a time. Do not use a single belt for
two or more peopleÐeven children.
Avoid reclining the seatbacks too
much. The seat belts provide maxi-
mum protection when the seatbacks
are in the upright position. (Refer
to the seat adjustment instructions.)
Be careful not to damage the belt
webbing or hardware. Take care that
they do not get caught or pinched
in the seat or side doors.
Inspect the belt system periodically.
Check for cuts, fraying, and loose
parts. Damaged parts should be re-
placed. Do not disassemble or
modify the system.
Seat beltsÐ
ÐSeat belt precautions
