Dimensions and weight
Engine
Fuel
Service specifications

Ti r es
Fuses Dimensions and weight
Normal cab models Xtra-cab models4540 (178.7) *
1
5010(197.2) *
1
4690 (184.6) *
2
5155(203.0) *
2
Overall width mm (in.) 1690 (66.5) 1690 (66.5) 1575 (62.0)*
3
1 580 (62.2)
1580 (62.2) *
4
Wheelbase mm (in.) 2625 (103.3) 3095(121.9) 1395 (54.9)*
3
1425 (56.1)
1425 (56.1) *
4
1415 (55.7) *
3
1440 (56.7)
1440 (56.7) *
4
500 (1100) *
6
500 (1100) *
6
430 (950) *
7
430 (950) *
7
295 (650) *
8
*
1
: Without rear step bumper
* 2
: With rear step bumper
* 3
: With P195/75R 14 tires
* 4
: With P215/70R 14 tires
* 5
: Unladen vehicle
* 6
: With 1 or 2 occupants
* 7
: With 3 occupants
* 8
: With 5 occupants
TWO-WHEEL DRIVE MODELS EXCEPT PRE RUNNER
Overall length mm (in.)
Overall height *
5
mm (in.)
Front tread mm (in.)
Rear tread mm (in.)
Cargo weight rating kg (lb.)

'98 Tacoma (U)227
Engine
Model:
2RZ- FE, 3RZ- FE and 5VZ- FE
Type:
2RZ- FE and 3RZ- FE engine4 cylinder in line, 4 cycle, gasoline
5VZ- FE engine
6 cylinder V type, 4 cycle, gasoline
Bore and stroke, mm (in.): 2RZ- FE engine
95.0 x 86.0 (3.74 x 3.39)
3RZ- FE engine 95.0 x 95.0 (3.74 x 3.74)
5VZ- FE engine 93.5 x 82.0 (3.68 x 3.23)
Displacement, cm 3
(cu. in.):
2RZ- FE engine 2438 (148.8)
3RZ- FE engine
2694 (164.3)
5VZ- FE engine
3378 (206.1)
*1
: With P225/75R 15 tires
* 2
: With P265/75R 15 or 31 10.5R 15 LT tires
* 3
: With wheel opening extension
* 4
: Unladen vehicle
* 5
: With steel wheels
* 6
: With aluminum wheels
* 7
: With 3 occupants
* 8
: With 5 occupants Normal cab models Xtra-cab models
Overall length mm (in.) 4665 (183.7) 5135(202.2) 1690 (66.5)*
1
1690 (66.5) *
1
1720 (67.7) *
2
1720 (67.7) *
2
1765 (69.5) *
3
1765 (69.5) *
3
1715 (67.5) *
1
1720 (67.7) *
1
1745 (68.7) *
2
1750 (68.9) *
2
Wheelbase mm (in.) 2625 (103.3) 3095(121.9) 1460 (57.5)*
5
1460 (57.5) *
5
1500 (59.1) *
6
1500 (59.1) *
6
1455 (57.3) *
5
1455 (57.3) *
5
1495 (58.9) *
6
1495 (58.9) *
6
500 (1100) 500 (1100) *
7
317 (700) *
8
FOUR-WHEEL DRIVE MODELS AND PRE RUNNER
Overall width mm (in.)
Overall height *
4
mm (in.)
Front tread mm (in.)
Rear tread mm (in.)
Cargo weight rating kg (lb.)

'98 Tacoma (U)
228
Fuel
Fuel type:
Unleaded gasoline, Octane Rating 87
(Research Octane Number 91) or high- er
Fuel tank capacity, L (gal., Imp. gal.):
Two-wheel drive models
except Pre Runner57 (15.1, 12.5)
Four-wheel drive models
and Pre Runner 68 (18.0, 15.0) Service specifications
ENGINE
Valve clearance (engine cold), mm (in.):
2RZ- FE and 3RZ- FE enginesIntake 0.15Ð0.25 (0.006Ð0.010)
Exhaust 0.25Ð0.35 (0.010Ð0.014)
5VZ- FE engine Intake 0.13Ð0.23 (0.006Ð0.009)
Exhaust 0.27Ð0.37 (0.011Ð0.014)
Spark plug type: 2RZ- FE and 3RZ- FE enginesDENSO K16R- U
NGK BKR5EYA
5VZ- FE engine DENSO K16TR11
NGK BKR5EKB11
Spark plug gap, mm (in.): 2RZ- FE and 3RZ- FE engines0.8 (0.031)
5VZ- FE engine 1.1 (0.043) Drive belt tension measured with Bor-
roughs drive belt tension gauge No.
BT- 33- 73F (used belt), lbf:
2RZ- FE and 3RZ- FE enginesGenerator belt 115 20
Air conditioning
compressor belt 100 20
Power steering
pump belt 100 +20
-15
5VZ- FE engine
Generator belt 100 20
Air conditioning compressor belt 100 20
Power steering
pump belt 100 +20
-15

'98 Tacoma (U)229
ENGINE LUBRICATION
Oil capacity (drain and ref
ill),
L (qt., Imp. qt.):
Two-wheel drive models
except Pre Runner2RZ- FE engineWith filter 5.5 (5.8, 4.8)
Without filter 4.8 (5.0, 4.2)
5VZ- FE engine With filter 5.4 (5.7, 4.8)
Without filter 5.1 (5.4, 4.5)
Four-wheel drive models
and Pre Runner 3RZ- FE engine
With filter 5.4 (5.7, 4.8)
Without filter 4.7 (5.0, 4.1)
5VZ- FE engine
With filter 5.2 (5.5, 4.6)
Without filter 4.9 (5.2, 4.3)
Oil grade:
API grade SH, ºEnergy-Conserving IIº or
SJ, Energy- Conservingº multigrade engine
oil or ILSAC multigrade engine oil is re-
commended. Recommended oil viscosity (SAE):
COOLING SYSTEM
Total capacity, L (qt., Imp. qt.):
Two-wheel drive models
except Pre RunnerWith manual transmission
2RZ- FE engine 8.0 (8.5, 7.0)
5VZ- FE engine
9.7 (10.3, 8.5)
With automatic transmission 2RZ- FE engine
7.8 (8.2, 6.9)
5VZ- FE engine 9.5 (10.0, 8.4) Four-wheel drive models
and Pre Runner
With manual transmission
3RZ- FE engine 8.3 (8.8, 7.3)
5VZ- FE engine
10.1 (10.7, 8.9)
With automatic transmission 3RZ- FE engine
8.2 (8.7, 7.2)
5VZ- FE engine 10.0 (10.5, 8.8)
Coolant type: With ethylene-glycol antifreeze (Do not
use alcohol type.)
BATTERY
Open voltage *
at 20 5C (68 5F):
12.6Ð12.8 V Fully charged
12.2Ð12.4 V Half charged
11.8Ð12.0 V Discharged
* : Voltage that is checked 20 minutes after
the key is removed with all the lights
turned off
Charging rates: 5 A max.

'98 Tacoma (U)
230
CLUTCH
Pedal freeplay, mm (in.):
5Ð15 (0.2Ð0.6)
Fluid type: SAE J1703 or FMVSS No. 116 DOT 3
MANUAL TRANSMISSION
Oil capacity, L (qt., Imp. qt.): 2RZ- FE engine 2.6 (2.7, 2.3)
3RZ- FE engine 2.5 (2.6, 2.2)
5VZ- FE engine Two-wheel drive models 2.6 (2.7, 2.3)
Four-wheel drive models
2.2 (2.3, 1.9)
Oil type: Gear Oil API GL-4 or GL-5
Recommended oil viscosity: SAE 75W- 90 AUTOMATIC TRANSMISSION
Fluid capacity (drain and ref
ill), L (qt.,
Imp. qt.):
Two-wheel drive models2RZ- FE engine Up to 2.4 (2.5, 2.1)
5VZ- FE and 3RZ- FE engines Up to 1.6 (1.7, 1.4)
Four-wheel drive models
Up to 2.0 (2.1, 1.8)
Fluid type: Automatic transmission fluid
D-II or DEXRON III (DEXRON II)
TRANSFER
Oil capacity, L (qt., Imp. qt.): 1.0 (1.1, 0.9)
Oil type:
Gear Oil API GL-4 or GL-5
Recommended oil viscosity:
SAE 75W- 90 DIFFERENTIAL
Oil capacity, L (qt., Imp. qt.):
Two-wheel drive models except
Pre Runner2RZ- FE engine 1.35 (1.4, 1.2)
5VZ- FE engine 2.55 (2.7, 2.2)
Four-wheel drive models and
Pre Runner Front (except Pre- runner) A.D.D. 1.15 (1.2, 1.0)
Except A.D.D. 1.1 (1.2, 1.0)
Rear Short wheel base
With rear differential lock system 2.65 (2.8, 2.3)
Without rear differential lock
system 2.55 (2.7, 2.2)
Extra long wheel base
With rear differential lock system 2.95 (3.1, 2.6)
Without rear differential lock
system 2.45 (2.6, 2.2)
Oil type:
Hypoid Gear Oil API GL- 5

'98 Tacoma (U)231
Recommended oil viscosity:
Front
A.D.D.
SAE 75W- 90
Except A.D.D. Above -18 5C (0 5F)
SAE 90
Below -18 5C (0 5F)
SAE 80W or 80W- 90
Rear Above -18 5C (0 5F)
SAE 90
Below -18 5C (0 5F)
SAE 80W or 80W- 90
CHASSIS LUBRICATION
Wheel bearings: Lithium base wheel bearing grease,
NLGI No. 2
Front drive shaft thrust bushings: Synthetic oil and lithium soap base
chassis grease, NLGI No.1
Propeller shafts: SpidersLithium base chassis grease,
NLGI No. 2
Slide yoke and double cardan joint Molybdenum-disulfide lithium base
chassis grease, NLGI No. 2
BRAKES Minimum pedal clearance when depressed
with the pressure of 490 N (50 kgf, 110
lbf) with the engine running, mm (in.):
72 (2.8)
Pedal freeplay, mm (in.): 3Ð6 (0.12Ð0.24)
Pad wear limit, mm (in.): 1.0 (0.04)
Lining wear limit, mm (in.):
1.0 (0.04)
Parking brake adjustment when pulled with
the force of 196 N (20 kgf, 44 lbf):
12Ð18 clicks
Fluid type: SAE J1703 or FMVSS No. 116 DOT 3
STEERING
Wheel freeplay: Less than 30 mm (1.2 in.)
Power steering fluid type: Automatic transmission fluid DEXRON II or III

'98 Tacoma (U)
232
Tires
Fuses
Engine compartment (U.S.A.)
Fuses (type A) 1. PWR OUTLET 15 A: Power outlet
2. DRL 7.5 A: Daytime running light
system
3. HEAD (HI RH) 10 A: Right-hand head-
light (high beam), hi-beam indicator
light
4. HEAD (HI LH) 10 A: Left-hand head-
light (high beam)
5. HEAD (LO RH) 10 A: Right-hand head-
light (low beam)
Wheel nut torque, N´m (kgf´m, ft´lbf):
110 (11.5, 83)Tire size
Tire pressure
kPa (kgf/cm 2
or bar, psi)
Wheel size
Front Rear
P195/75R14 200 (2.0, 29) 240 (2.4, 35) 14 x 5J
P215/70R14 200 (2.0, 29) 200 (2.0, 29) 14 x 6J
14 x 6JJ
P225/75R15 180 (1.8, 26) 200 (2.0, 29)15 x 6J
15 x 7J
15 x 7JJ
31x10.5R15LT 180 (1.8, 26) 200 (2.0, 29) 15 x 7J
15 x 7JJP265/75R15
180 (1.8, 26) 180 (1.8, 26) 15 x 7J
15 x 7JJ
