1998 NISSAN FRONTIER mirror

3 Pre-driving checks and adjustments
Key .........................................................................3-2
Door locks ..............................................................3-2
Power door lock (if so equipped) ...........................3-3
Multi-remote control system (if so equipped).........3-4
Battery replacement ...............................................3-7
Hood release ..........................................................3-8
Glove box ...............................................................3-9
Fuel filler cap ..........................................................3-9Tailgate latch ........................................................3-10
Tie down hooks ....................................................3-12
Tilting steering wheel (if so equipped) .................3-12
Outside mirror remote control (if so equipped) ....3-13
Outside mirrors .....................................................3-13
Inside mirror .........................................................3-14
Vanity mirror (if so equipped)...............................3-14
ZX

Push the right or left side of the switch to
adjust the right or left side mirror, then
control the lever.
WARNING
Objects viewed in the outside mirror on
the passenger side are closer than they
appear. Be careful when moving to the
right. Using only this mirror could cause
an accident. Use the inside mirror or
glance over your shoulder to properly
judge distances to other objects.
Folding outside mirror
Push the mirror backward to fold it.
APD1039IC0266MIC0248M
OUTSIDE MIRROR REMOTE
CONTROL (if so equipped)OUTSIDE MIRRORS
Pre-driving checks and adjustments3-13
ZX

The night position reduces glare from the
headlights of vehicles behind you at night.
WARNING
Use the night position only when nec-
essary because it reduces rear view
clarity.A vanity mirror is located on the rear side of
the passenger sunvisor.
AIC0703AIC0710
INSIDE MIRROR VANITY MIRROR
(if so equipped)
3-14Pre-driving checks and adjustments
ZX

cMake sure the area around the vehicle is
clear.
cCheck fluid levels such as engine oil,
coolant, brake and clutch fluid, and win-
dow washer fluid as frequently as pos-
sible, at least whenever you refuel.
cCheck that all windows and lights are
clean.
cVisually inspect tires for their appearance
and condition. Also check tires for proper
inflation.
cLock all doors.
cPosition seat and adjust head restraints.
cAdjust inside and outside mirrors.
cFasten seat belts and ask all passengers
to do likewise.
c
Check the operation of warning lights when
key is turned to the ON (3) position. See
``Warning/indicator lights and chimes'' in
the ``Instruments and controls'' section.
WARNING
cDo not depress the accelerator pedal
while shifting from P (Park) or N
(Neutral) to R (Reverse), D (Drive), 2
or 1. Always depress the brake pedal
until shifting is completed. Failure to
do so could cause you to lose con-
trol and have an accident.
cCold engine idle speed is high, so
use caution when shifting into a for-
ward or reverse gear before the en-
gine has warmed up.
cNever shift to P (Park) or R (Reverse)
while the vehicle is moving. This
could cause an accident.
CAUTION
cWhen stopping the vehicle on an
uphill grade, do not hold the vehicle
by depressing the accelerator pedal.
The foot brake should be used for
this purpose.
cOn slippery roads, do not downshift.
This may cause a loss of control.
The automatic transmission in your vehicle
is electronically controlled by a transmission
control module to produce maximum power
and smooth operation.
The recommended operating procedures for
this transmission are shown on the following
pages. Follow these procedures for maximum
vehicle performance and driving enjoyment.
Starting the vehicle
cAfter starting the engine, fully depress
the foot brake pedal to ensure the vehicle
is at a complete stop before attempting to
shift the selector lever.
cKeep the foot brake pedal depressed and
shift the selector lever into a driving gear.
cRelease the foot brake, then gradually
start the vehicle in motion.
This automatic transmission is designed
so the foot brake pedal MUST be de-
pressed before shifting from P (Park) to
any drive position while the ignition
switch is ON.
The shift lever cannot be moved out of P
(Park) and into any of the other gear
positions if the ignition key is turned to
LOCK or if the key is removed.
If the battery charge is low, the shift lever
can be moved if the ignition switch is in
the ACC position.
BEFORE STARTING THE
ENGINEDRIVING WITH AUTOMATIC
TRANSMISSION (if so
equipped)
5-6Starting and driving
ZX

prevent load shift while driving.
cBe certain your outside mirrors conform
to all federal, state or local regulations. If
not, install any mirrors required for towing
before driving the vehicle.
Trailer towing tips
In order to gain skill and an understanding
of the vehicle's behavior, you should prac-
tice turning, stopping and backing up in an
area which is free from traffic. Steering,
stability and braking performance will be
somewhat different than under normal driv-
ing conditions.
cAlways secure items in the trailer to
prevent load shift while driving.
c
Avoid abrupt starts, acceleration or stops.
cAvoid sharp turns or lane changes.
cAlways drive your vehicle at a moderate
speed.
cAlways block the wheels on both vehicle
and trailer when parking. Parking on a
slope is not recommended; however, if
you must do so, and if your vehicle is
equipped with automatic transmission,
first block the wheels and apply the park-ing brake, and then move the transmis-
sion shift selector lever into the P (Park)
position. If you move the shift lever to the
P (Park) position before blocking the
wheels and applying the parking brake,
transmission damage could occur.
cWhen going down a hill, shift into a lower
gear and use the engine braking effect.
When ascending a long grade, downshift
the transmission to a lower gear and
reduce speed to reduce chances of en-
gine overloading and/or overheating.
However, for long steep grades, do not
stay in 1st or 2nd gear when driving
above 35 MPH (56 km/h).
cIf the engine coolant rises to an ex-
tremely high temperature when the air
conditioning system is on, turn off the air
conditioner. Coolant heat can be addi-
tionally vented by opening the windows,
switching the fan control to high and
setting the temperature control to the
HOT position.
cTrailer towing requires more fuel than
normal circumstances.
cAvoid towing a trailer for your vehicle's
first 500 miles (805 km).cHave your vehicle serviced more often
than at intervals specified in the recom-
mended Maintenance Schedule.
cWhen making a turn, your trailer wheels
will be closer to the inside of the turn than
your vehicle wheels. To compensate for
this, make a larger than normal turning
radius during the turn.
cCrosswinds and rough roads adversely
affect vehicle/trailer handling, possibly
causing vehicle sway. When being
passed by larger vehicles, be prepared
for possible changes in crosswinds that
could affect vehicle handling. If swaying
does occur, firmly grip the steering
wheel, steer straight ahead, and immedi-
ately (but gradually) reduce vehicle
speed. This combination helps to stabi-
lize the vehicle. Never increase speed.
cBe careful when passing other vehicles.
Passing while towing a trailer requires
considerably more distance than normal
passing. Remember the length of the
trailer must also pass the other vehicle
before you can safely change lanes.
cTo maintain engine braking efficiency
and electrical charging performance, do
Technical and consumer information
10-23
ZX

Hubs
Auto-lock free-running hubs ................. 5-16
Manual-lock free-running hubs ............. 5-19
I
Ignition switch .............................................. 5-4
Indicator lights and chimes (See warning/
indicator lights and chimes) ......................... 2-7
Inside mirror ............................................... 3-14
Instrument brightness control .................... 2-16
Interior light and cargo light ....................... 2-19
J
Jack
Pantograph type ..................................... 6-5
Jump seat .................................................... 1-6
Jump starting ............................................... 6-7
K
Key ............................................................... 3-2
Keyless entry system (See multi-remote control
system) ........................................................ 3-4
L
Labels
Air conditioner specification label ....... 10-14Emission control information label...... 10-13
Engine serial number ......................... 10-13
F.M.V.S.S. certification label .............. 10-13
Vehicle identification number (VIN)
plate .................................................... 10-12
Warning labels (for SRS) ..................... 1-15
Light
Air bag warning light............................. 1-15
Brake light (See stop light) ................... 8-24
Bulb check/instrument panel .................. 2-7
Bulb replacement.................................. 8-24
Headlight and turn signal switch .......... 2-14
Headlights ............................................. 8-23
Interior light and cargo light .................. 2-19
Light bulbs ............................................ 8-23
Passenger supplemental air bag ON/OFF
switch and light ..................................... 1-12
Spotlights (See map light) .................... 2-19
Warning/indicator lights and chimes ...... 2-7
Lock
Door locks............................................... 3-2
Power door lock...................................... 3-3
Luggage (See vehicle loading
information ............................................... 10-15
M
Maintenance
General maintenance ............................. 9-2
Inside the vehicle.................................... 9-3
Maintenance precautions ....................... 8-2
Outside the vehicle ................................. 9-2Periodic maintenance schedules ............ 9-5
Seat belt maintenance.......................... 1-25
Under the hood and vehicle ................... 9-4
Malfunction indicator light .......................... 2-10
Manual antenna ......................................... 4-21
Manual windows ........................................ 2-20
Manual-lock free-running hubs .................. 5-19
Map light .................................................... 2-19
Meters and gauges ...................................... 2-2
Mirror
Inside mirror.......................................... 3-14
Outside mirror control ........................... 3-13
Outside mirrors ..................................... 3-13
Vanity mirror ......................................... 3-14
Multi-remote control system ........................ 3-4
O
Octane rating (See fuel octane rating) ...... 10-5
Odometer ..................................................... 2-3
Oil
Capacities and recommended fuel/
lubricants .............................................. 10-2
Changing engine oil................................ 8-7
Changing engine oil filter........................ 8-9
Checking engine oil level ....................... 8-6
Engine oil ................................................ 8-6
Engine oil and oil filter
recommendation ................................... 10-6
Engine oil viscosity ............................... 10-7
Outside mirror control ................................ 3-13
Outside mirrors .......................................... 3-13
11-3
ZX

switch and light ..................................... 1-12
Windshield wiper and washer switch ... 2-15
T
Tachometer .................................................. 2-5
Tailgate latch ............................................. 3-10
Theft warning ............................................. 2-12
Three way catalyst....................................... 5-2
Tie down hooks ......................................... 3-12
Tilting steering wheel ................................. 3-12
Tire
Flat tire.................................................... 6-2
Spare tire .............................................. 8-30
Tire chains ............................................ 8-27
Tire placard......................................... 10-14
Tire pressure ........................................ 8-26
Tire rotation .......................................... 8-28
Tires of 4-wheel drive ........................... 8-29
Types of tires ........................................ 8-26
Uniform tire quality grading ................ 10-24
Wheels and tires................................... 8-26
Wheel/tire size .................................... 10-10
Towing
2-wheel drive models ........................... 6-11
4-wheel drive models ........................... 6-11
Tow truck towing .................................. 6-10
Towing load/specification chart .......... 10-21
Trailer towing ...................................... 10-19
Transfer case ............................................. 5-15
Transmission
Automatic transmission fluid (ATF) ........ 8-9Driving with automatic transmission ....... 5-6
Driving with manual transmission ........... 5-8
Travel (See registering your vehicle in another
country) .................................................... 10-12
Truck - camper loading............................ 10-17
Tuning ........................................................ 4-11
Turn signal switch (See headlight and turn
signal switch) ............................................. 2-14
U
Uniform tire quality grading ..................... 10-24
V
Vanity mirror .............................................. 3-14
Vehicle dimensions and weights ............. 10-11
Vehicle identification number (VIN) (chassis
number).................................................... 10-12
Vehicle identification number (VIN)
plate ......................................................... 10-12
Vehicle loading information ..................... 10-15
Vehicle recovery ........................................ 6-12
Ventilators .................................................... 4-2
W
Warning
Air bag warning light............................. 1-15
Hazard warning flasher switch ............. 2-16
Theft warning ........................................ 2-12Warning labels (for SRS) ..................... 1-15
Warning/indicator lights and chimes ...... 2-7
Weights (See dimensions and weights) .. 10-11
Wheels and tires ........................................ 8-26
Wheel/tire size ......................................... 10-10
When traveling or registering your vehicle in
another country ........................................ 10-12
Window washer fluid.................................. 8-12
Windows
Manual windows ................................... 2-20
Power windows..................................... 2-20
Rear sliding window ............................. 2-21
Windshield wiper and washer switch ........ 2-15
Wiper
Windshield wiper and washer switch ... 2-15
Wiper blades......................................... 8-17
11-5
ZX
