A/C COMPRESSOR SERVICING
1998 Mitsubishi Montero
1998 GENERAL SERVICING
Mitsubishi - Compressor Servicing
Diamante, Eclipse, Galant, Mirage, Montero, Montero Sport &
3000GT
A/C COMPRESSOR APPLICATIONS
A/C COMPRESSOR APPLICATION TABLE








\









\









\









\









\









\






Application Compressor
Diamante ......................... Sanden MSC105CVS Scroll
Eclipse
2.0L Non-Turbo ............. Nippondenso 10PA17C 10-Cyl.
2.0L Turbo & 2.4L .............. Sanden MSC105CVS Scroll
Galant ............................ Sanden MSC90C12 Scroll
Mirage ............................... Sanden MSC90 Scroll
Montero ....................... Nippondenso 10PA15 10-Cyl.
Montero Sport ...................... Sanden MSC105C Scroll
3000GT .............................. Sanden MSC105 Scroll









\









\









\









\









\









\






NOTE: Due to variety of clutch and shaft seal configurations,
obtain appropriate A/C compressor service tools for
compressor being serviced. Land Rover and Jaguar compressor
service information not available at time of publication.
NIPPONDENSO
CLUTCH COIL
Removal
1) Hold clutch plate stationary. Remove clutch plate center
bolt and clutch plate. If clutch plate cannot be removed by hand,
tighten an 8-mm or 10-mm bolt into clutch plate center bolt hole to
remove clutch plate.
2) Remove shim(s) and pulley snap ring from compressor shaft\
.
Tap pulley using a plastic hammer and remove pulley from compressor
shaft. See Fig. 1 or 2. Remove retaining screw for clutch coil lead.
Remove clutch coil snap ring and clutch coil.
Installation
1) To install, reverse removal procedure. Ensure clutch coil
pin is aligned with hole in compressor housing. Ensure clutch coil
lead is positioned properly. Ensure NEW snap rings are installed with
beveled side facing out. Tighten shaft bolt to 10-13 ft. lbs. (14-17
N.m).
2) Check air gap between clutch plate and pulley. Position
dial indicator on clutch plate. Energize clutch coil and zero dial
indicator. De-energize clutch coil and measure air gap (clutch plate
movement). Ensure air gap between clutch plate and pulley is 0.014-0.
026" (0.35-0.65 mm). If air gap is incorrect, add or remove shim(s) \
as
necessary. Ensure pulley rotates freely.
NOTE: On some compressors, it is necessary to use a dial indicator
on clutch plate to check air gap. Energize clutch coil and
zero dial indicator. De-energize clutch coil and measure air
gap. Ensure air gap is as specified.

FRICTION MATERIAL
NOTE: Original Equipment Manufacturer (OEM) specifications
designate replacement at different thicknesses.
CAUTION: It is required that friction material be matched in axle
sets for consistent braking characteristics.
FRICTION MATERIAL INSPECTION









\









\









\









\









\









\









\


Condition Code Procedure
Contaminated, for example,
fluid that leaked from
caliper, wheel cylinder,
or axle seal ........... A ........ ( 1) Require replacement.
Cracked through ......... B Require replacement.
Flaking or chunking ..... B Require replacement.
Glazed (shiny) .......... .. ........ No service suggested or
required.
Grooves or ridges ....... .. .... ( 2) No service suggested or
required.
Permanently attached
hardware bent .......... A ............ Require replacement.
Permanently attached
hardware broken ........ A ............ Require replacement.
Permanently attached
hardware loose ......... A ............ Require replacement.
Permanently attached
hardware missing ....... C ............ Require replacement.
Permanently attached
hardware seized ........ A .. Require repair or replacement.
Rivets loose ............ B ............ Require replacement.
Separating from backing . B ............ Require replacement.
Shoe table or web bent .. B ............ Require replacement.
Shoe table or web
cracked ................ A ............ Require replacement.
Shoe table or web worn,
affecting performance .. A ............ Require replacement.
Surface cracking ........ .. ........ No service suggested or
required. Further inspection
may be necessary to determine
cause.
Tapered wear ............ B ........ ( 3) Suggest replacement.
Thickness of one pad is
greater than opposite pad
in the same caliper
(uneven wear) .......... .. .... ( 4) Replacement of friction
material not suggested or
required. Further inspection
required. See CALIPERS
and CALIPER HARDWARE.
Wear indicator device
(electronic) contacts
rotor .................. B ...... ( 5) Require replacement of
appropriate parts.
Wear indicator device
(mechanical) bent ....... .. .......... ( 6) Further inspection
required.
Wear indicator device
(mechanical) broken .... .. ......... ( 6) Further inspection
required.

CRUISE CONTROL SYSTEM
1998 Mitsubishi Montero
1998 ACCESSORIES & EQUIPMENT
Mitsubishi - Cruise Control Systems
Montero
DESCRIPTION & OPERATION
WARNING: Deactivate air bag system before performing any service
operation. See AIR BAG RESTRAINT SYSTEMS article. Do not
apply electrical power to any component on steering column
without first deactivating air bag system. Air bag may
deploy.
Cruise control system is electronically and vacuum
controlled. System components include a control unit, actuator, vacuum
pump, cruise control switch, clutch pedal position switch (M/T),
cruise indicator light, diode, Park/Neutral (P/N) switch (A/T),
stoplight switch, vehicle speed sensor and A/T control unit (if
equipped).
System has self-diagnostic capability. When self-diagnostic
mode is activated, each switch and sensor is checked for defects. When
cruise control system has been canceled without using a normal cancel
method, a trouble code will be set and stored in control unit. Trouble
codes can be retrieved to help determine which circuit is
malfunctioning.
COMPONENT LOCATIONS
COMPONENT LOCATIONS TABLE








\









\









\









\









\









\






Component Location
Cruise Control ECU .............. Behind Dash, On Steering
Column Bracket
Data Link Connector (DLC) ....... Under Left Side Of Dash,
Near Steering Column
Vehicle Speed Sensor ........... On Speedometer Assembly &
On Transmission
Throttle Position Sensor ........ Mounted On Throttle Body









\









\









\









\









\









\






ADJUSTMENTS
CRUISE CONTROL CABLE
Remove link protector. Loosen lock nut. Hold link "A" so that
it touches link "B". Adjust free play by turning adjusting nut until
free play is.04-.08" (1-2 mm). Tighten lock nut. See Fig. 1 or 2.

CRUISE CONTROL INDICATOR TEST under COMPONENT TESTS. If cruise control
indicator is defective, replace indicator. If indicator checks okay,
go to next step.
2) If cruise control indicator illuminates when cruise
control connector C-50 terminal No. 23 is grounded at harness side,
replace cruise control ECU. If indicator does not illuminate, check
combination meter connector C-12 and cruise control ECU connector C-
50. Repair as necessary. If connectors are okay and malfunction
remains, check harness between combination meter and cruise control
ECU. Repair as necessary.
Test No. 13
1) Perform stoplight switch test. See
BRAKELIGHT/STOPLIGHT SWITCH TEST under COMPONENT TESTS. If switch is
okay, go to next step. If switch is defective, replace brakelight
switch.
2) Check cruise control ECU connector C-50, stoplight switch
connector C-55 and joint connector C-131. Repair as necessary. See
Figs. 13 , 14, 16 and 29. If connectors are okay and malfunction
remains, check harness between joint connector C-131 and cruise
control ECU.
Test No. 14 (A/T)
1) Perform park/neutral switch test. See
PARK/NEUTRAL SWITCH TEST under COMPONENT TESTS. If switch is okay, go
to next step. If switch is defective, replace switch.
2) Check starter relay. Replace if defective. If relay is
okay, check cruise control ECU connector C-50 and joint connector C-
130. Repair as necessary. See Figs. 13, 16 and 28. If connectors are
okay and malfunction remains, check harness between cruise control ECU
and power supply.
COMPONENT TESTS
ACTUATOR TEST
Remove actuator. Apply vacuum to actuator. Actuator linkage
holder should move more than 1.38" (35 mm). Actuator diaphragm should
hold vacuum. Replace actuator if actuator does not test as specified.
BRAKELIGHT/STOPLIGHT SWITCH TEST
Disconnect stoplight switch connector C-55. When brake pedal
is pressed, continuity should be present between terminals No. 2 and
3. See Fig. 14. When brake pedal is released, continuity should be
present between terminals No. 1 and 4. Replace switch if it does not
test as specified.
CLOCKSPRING TEST
WARNING: Deactivate air bag system before performing any service
operation. See AIR BAG RESTRAINT SYSTEMS article. Do not
apply electrical power to any component on steering column
without first deactivating air bag system. Air bag may
deploy.
If clockspring fails any check, replace with a NEW
clockspring.
1) Check connectors and protective tube for damage and
deformities.
2) Visually check case for damage or deformities.

.060 (1.52) .................................................... Red\
.067 (1.70) ................................................. Purple\
.073 (1.85) ................................................... Blue\
.079 (2.01) ................................................. Yellow\
.085 (2.16) ................................................ Neutral\









\









\









\









\









\









\









\







DIFFERENTIAL ASSEMBLY (CONVENTIONAL)
Pre-Disassembly Inspection
1) Secure differential assembly in appropriate holder. Secure
drive pinion from turning. Mount dial indicator on case and check ring
gear backlash at 4 positions. See Fig. 6. Backlash should be .005-.
007" (.13-.18 mm).
2) Remount dial indicator and measure ring gear runout. See
Fig. 7 . On all models, runout should not exceed .002" (.05 mm).
Remount dial indicator and measure pinion gear backlash on models
without limited slip differential. See Fig. 8. Secure side gear from
turning with wedge. Backlash should be 0-.003" (0-.08 mm). Pinion gear\
backlash service limit is .008" (.20 mm).
3) Check gear tooth contact pattern between ring gear and
drive pinion gear. Apply Prussian Blue to both surfaces of ring gear
teeth. Insert brass rod between differential housing and carrier
assembly to provide resistance while turning drive pinion.
4) Turning resistance of drive pinion should be 28-33 INCH
lbs. (2.5-3.0 N.m). Rotate drive pinion until ring gear completes one
revolution. Reverse direction of rotation and return to original
starting point. Check wear pattern. See GEAR TOOTH CONTACT PATTERNS
article in GENERAL INFORMATION.
5) On Montero models with differential lock, connect air
supply hose with pressure gauge and regulator to actuator air pipe.
Apply 4 psi (.28 kg/cm
) of pressure. Using Adapter Shaft (MB990992),
turn side gear on one side of carrier assembly only. Locking mechanism
should engage. To disengage, release air pressure and turn side gear
1/4-1/2 turn.
6) With lock mechanism engaged, measure turning torque of
drive pinion. Turning torque should not be less than 36 ft. lbs. (50
N.m). With lock mechanism disengaged, turning torque should not be
more than 36 ft. lbs. (50 N.m).
Fig. 6: Measuring Ring Gear Backlash
Courtesy of Mitsubishi Motor Sales of America.

as matched set. Side gears and pinion gears must be replaced as
matched set.
Reassembly & Adjustment
1) Install thrust spacers, side gears, pinion washers and
pinion gears in differential case. DO NOT install thrust block (if
equipped) at this time.
2) Install pinion shaft without lock pin. Check pinion and
side gear backlash. Install wooden wedge to lock side gears. See
Fig. 8 . Using dial indicator, measure gear backlash. Backlash should
be .0004-.0030" (.010-.080 mm). Service limit is .008" (.20 mm).
3) Adjust backlash by using different side gear spacers.
Ensure both sides are equally shimmed. Install thrust block (if
equipped) once correct backlash is obtained. Install pinion shaft lock
pin from ring gear side of carrier housing. Securely stake pin in 2
places. Ensure adhesive is removed from ring gear mounting bolts and
gear mounting surface. Clean internal threads with tap.
4) Ensure alignment marks on differential case and ring gear
align. Apply Loctite 271 to bolts, and install ring gear on
differential case. Tighten bolts in diagonal sequence to
specification. See TORQUE SPECIFICATIONS . Using appropriate adapter,
press on carrier side bearings.
DIFFERENTIAL ASSEMBLY (LIMITED SLIP)
NOTE: Manufacturer does not provide disassembly or reassembly
procedures for locking type differential. Use illustrations
for exploded views of assembly. See Figs. 11 and 12.
NOTE: See PRE-DISASSEMBLY INSPECTION under
DIFFERENTIAL ASSEMBLY (CONVENTIONAL) before disassembling
carrier assembly. For carrier assembly and drive pinion
removal, see DIFFERENTIAL ASSEMBLY (CONVENTIONAL) .
Disassembly
1) Once ring gear is removed, loosen carrier housing screws
in diagonal pattern. Separate cases and remove components. See Fig. 10
. Maintain parts in order of disassembly. Clean all parts in new
solvent.
2) Inspect condition of friction and spring plates and
friction discs. Replace disc and/or plates if worn or heat damaged.
Distortion of discs will cause incorrect clutch pressure. Scratches,
nicks or burrs on components can be repaired with an oil stone.
3) Discs must be flat and free of distortion. Check discs on
surface plate with dial indicator. Maximum warpage of friction plate
or disc is .003" (.08 mm). Inspect thickness of discs and plates.
Thickness limit between discs and plates is .004" (.10 mm).
Fig. 10: Exploded View Of Limited Slip Differential
Courtesy of Mitsubishi Motor Sales of America.

* DRIVETRAIN SYSTEMS UNIFORM INSPECTION GUIDELINES *
1998 Mitsubishi Montero
GENERAL INFORMATION
Drivetrain/Transmission Motorist Assurance Program
Standards For Automotive Repair
All Makes and Models
INTRODUCTION TO MOTORIST ASSURANCE PROGRAM (MAP)
CONTENTS
OVERVIEW OF MOTORIST ASSURANCE PROGRAM
OVERVIEW OF SERVICE REQUIREMENTS & SUGGESTIONS
Drive/Power Train Assemblies
AUTOMATIC TRANSMISSION/TRANSAXLE ASSEMBLIES
DIFFERENTIAL AND FINAL DRIVE ASSEMBLIES
MANUAL TRANSMISSION/TRANSAXLE ASSEMBLIES
TRANSFER CASE ASSEMBLIES
Drive/Power Train Components
ACTUATORS (ELECTRICAL)
ACTUATORS (VACUUM)
AXLES
BEARINGS AND RACES
BELL CRANKS
BELL HOUSINGS
BUSHINGS (EXTERNAL)
CABLES (SPEEDOMETER)
CABLES (TV, DETENT AND SHIFT)
CARRIER BEARINGS
CLUTCH CABLES AND CABLE HOUSINGS
CLUTCH DISCS (MANUAL TRANSMISSION)
CLUTCH FORKS
CLUTCH LINKAGES (MECHANICAL)
CLUTCH MASTER CYLINDERS
CLUTCH PEDALS
CLUTCH PIVOTS
CLUTCH PRESSURE PLATES
CLUTCH RELEASE BEARINGS
CLUTCH SLAVE CYLINDERS (CONCENTRIC)
CLUTCH SLAVE CYLINDERS (CONVENTIONAL OR EXTERNAL)
COMPANION FLANGES
CONNECTORS
COOLER BYPASS VALVES
COOLER LINES
COOLERS
CV JOINTS
DIP STICK TUBES
DIP STICKS (FLUID LEVEL INDICATORS)
DOWEL PINS, GUIDES AND PILOT HOLES
DRIVE SHAFT FLANGES
DRIVE SHAFTS AND HALF SHAFTS
DUST BOOTS
ENGINE MOUNTS
EXCITER RINGS
FILLER TUBES
FILTERS AND SCREENS
