1998 Mercury Mystique Owner's Manuals

Contents
Before driving
Introduction 2
Instrumentation 4
Controls and features 14
Seating and safety restraints 44
Starting and driving
Starting 76
Driving 84
Roadside emergencies 107
Servicing
Maintenance and care 125
Capacities and specifications 183
Reporting safety defects (U. S. only) 189
Index 190
1
CDW I_IIImpr_Cont_en MM 5/15/97 7:41 PM Page 2

Introduction
2ICONS
Indicates a warning. Read the
following section on
Warnings for
a full explanation.
Indicates that vehicle information
related to recycling and other
environmental concerns will follow.
We must all play our part in
protecting the environment.
Correct vehicle usage and the
authorized disposal of waste
cleaning and lubrication materials
are significant steps toward this
aim.
BREAKING IN YOUR VEHICLE
There are no particular breaking-in
rules for your vehicle. Simply avoid
driving too fast during the first
1600 km (1000 miles). Vary
speeds frequently. This is
necessary to give the moving parts
a chance to break in.
WARNINGS
How can you reduce the risk of
personal injury and prevent
possible damage to others, your
vehicle and its equipment?
In this owner’s guide, answers to
such questions are contained in
comments highlighted by the
warning triangle symbol.
CDW II_A1_en MM 5/15/97 7:41 PM Page 2

Introduction
3 INFORMATION ABOUT THIS
GUIDE
The information found in this guide
was in effect at the time of
printing. Ford may change the
contents without notice and
without incurring obligation. If possible, you should avoid hard
braking for the first 1600 km
(1000 miles).
From 1600 km (1000 miles)
onwards you can gradually increase
the performance of your vehicle up
to the permitted maximum speeds.
CDW II_A1_en MM 5/15/97 7:41 PM Page 3

4
Instrumentation
Page 27
Turn signal/high beam
Page 6
Instrument clusterPage 26
Hazard flasher
control
Page 28
Windshield
wiper/washer
control
Page 129
Hood release
Page 14
Headlamp control/
Foglamp control*Page 26
Horn
Page 25
Tilt steering
wheel leverPage 16
Instrument panel
dimmer switch
Page 24
Ignition switch
Page 29
Speed control* Page 17
Power mirrors
CHECK
ENGINEO/D
OFF
Off
Res
Set
Acc
Coast
On
MIRRORS
NORMAL12
03
x 1000
4
5
6
7
8
000123
000010 20 3040506070
80
90
100
110
120
130MPH
20 4060
55
80120 100
140
160
180
200
EF 1
/
2
UNLEADED FUEL ONLY
BRAKE
CDW IIA2Instrum_en MM 5/15/97 7:43 PM Page 4

5
Instrumentation
Page 18
Clock Page 16
Rear window
defroster control*
On various models the
appearance and location of
some items may differ from
those shown here. However,
the page references given
still apply.
POWERAUDIOAM/FM
SCAN
SEEK 312645ANSSIDE1-2EJECTVOLUME
DEF
LO
HIOFFPNL/FLR
PANEL
A/CFLOOR
FLR
DEF

MAX
A/C
:
I0 20
Page 19
Climate control system Page 42
Anti-theft system status
indicator*
Electronic sound system;
refer to “Audio Guide”
* if equipped
CDW IIA2Instrum_en MM 5/15/97 7:43 PM Page 5

High beams
Illuminates when the headlamp
high beams are on.
Instrumentation
6Turn signal
Flashes when the left or right turn
signal or hazard lights are
activated.
Charging system
Briefly illuminates when the
ignition is turned on and the engine
is off. The light also illuminates
when the battery is not charging
properly and the vehicle may
require electrical system service.
000123
000010 20 3040506070
80
90
110
120
130
MPH
20 4060
55
80120 100
140
160
180
200100
EF 1
/
2
UNLEADED FUEL ONLY
12
03
x 1000
4
5
6
7
8
NORMAL
BRAKE
CHECK
ENGINE TRACTION
CONTROLO/D
OFF
INSTRUMENT CLUSTER
LIGHTS AND CHIMES
CDW IIA2Instrum_en MM 5/15/97 7:43 PM Page 6

Instrumentation
7 Safety belt
Illuminates when the ignition is
switched on as a reminder to fasten
the safety belts. For more
information, refer to
Safety belt
indicator light and warning
chime in the Seating and safety
restraints chapter.
O/D Off indicator
(Automatic transaxle only)
Illuminates and remains
illuminated when the transaxle
control switch (TCS) on the end of
the gearshift lever is pressed and
overdrive is turned off.
Indicates the status of the
transaxle and will flash steadily if a
malfunction is detected. If the
flashing persists, have your
transaxle serviced by your dealer
or a qualified service technician as
soon as possible.
If the condition persists, your
transaxle may be damaged.
TRACTION
CONTROLO/D
OFF
TRACTION
CONTROLO/D
OFF
Low coolant (if equipped)
Briely illuminates when the ignition
is turned on and the engine is off.
Illuminates when the engine
coolant level is low. Refer to the
Maintenance and care chapter to
check the engine coolant level.
CDW IIA2Instrum_en MM 5/15/97 7:43 PM Page 7

Instrumentation
8Check engine
Illuminates when the ignition is
turned on and the engine is off.
Also illuminates when the engine’s
emission control system requires
service or if the fuel filler cap is
not fitted correctly.
CHECK
ENGINE
CHECK
ENGINEAir bag readiness
Briefly illuminates when the
ignition is turned on. If the light
fails to illuminate, continues to
flash or remains on, have the
system serviced immediately.
000123
000010 20 3040506070
80
90
110
120
130
MPH
20 4060
55
80120 100
140
160
180
200100
EF 1
/
2
UNLEADED FUEL ONLY
12
03
x 1000
4
5
6
7
8
NORMAL
BRAKE
CHECK
ENGINE TRACTION
CONTROLO/D
OFF
Low fuel
Illuminates when the fuel level is
low.CHECK
ENGINE
