1998 Lexus LS400 lexus LS400 1998 Engine / LEXUS 1998 LS400 OWNER'S MANUAL (OM50498U)

EXTERIOR EQUIPMENT
66
CAUTION
Make sure the cap is tightened securely to prevent fuel
spillage in case of an accident.
Use only a genuine Lexus fuel tank cap for replacement. It
has a builtin check valve to reduce fuel tank vacuum.
In case the opener is not actuated
15L008-2
Pull the manual lever toward the back.
This is used in case the fuel filler door cannot be opened due to a
discharged battery or other trouble.
MOON ROOF
15L0241
1
Open 2
Close
To slide open the moon roof, push the switch toward the back for
about 1 second. The moon roof will fully open. To stop partway,
push the same switch or push the ”TILT” switch.
The sun shade can be opened or closed manually. However, if you
open the moon roof, the sun shade will be opened with the moon
roof.
To close the moon roof, push the switch toward the front for
about 1 second. The moon roof will fully close. To stop partway,
push the same switch or push the ”TILT” switch.

EXTERIOR EQUIPMENT
67
15L025
1
Tilt up 2
Lower
To tilt up the rear end of the moon roof fully, push the switch on
the rear side or on the front side to lower it.
To operate the moon roof, the ignition key must be in the ”ON”
position.
Key off operation: Even if the ignition key is turned to the ”ACC”
or ”LOCK” position, the moon roof can be operated until any of the
doors is opened (or for about 45 seconds).
Operating the moon roof from outside the vehicle
The moon roof can be closed or opened using an ignition key.*
Insert the ignition key into the key hole on the driver’s door.
To close the moon roof: Turn the key in the locking direction and
hold it for a few seconds.To open the moon roof: Turn the key in the unlocking direction and
hold it for a few seconds.
NOTE: *This feature can be set inoperative, or sliding open or
tilting up can be selected. Ask your Lexus dealer for details.
Jam protection function
During closing operation, the moon roof stops and is open if
something gets caught into the roof opening.
If an impact is given to the moon roof, this function may work
without anything caught.
CAUTION
Never try jamming any part of your body to make the jam
protection function work intentionally.
The jam protection function may not work when something
gets caught just before the moon roof fully closed.

EXTERIOR EQUIPMENT
68
CAUTION
To avoid serious personal injury, you must do the following.
While the vehicle is moving, always keep the head, hands
and other parts of the body of all occupants away from the
roof opening. Otherwise, you could be seriously injured if
the vehicle stops suddenly or if the vehicle is involved in an
accident.
Always make sure nobody places his/her head, hands and
other parts of the body in the roof opening before you close
the roof. If someone’s neck, head or hands gets caught in
the closing roof, it could result in a serious injury. When
anyone closes the roof, first make sure it is safe to do so.
Never leave small children alone in the vehicle, especially
with the ignition key still inserted. They could use the moon
roof switches and get trapped in the roof opening.
Unattended children can become involved in serious
accidents.
Never sit on top of the vehicle around the roof opening.

SECTION 1 6
69
INSTRUMENTS AND CONTROLS
Comfort adjustment
Front seats 70. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Head restraints 73. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Tilt and telescopic steering wheel 76. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside rear view mirrors 77. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside rear view mirror 79. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Seat belts 80. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supplemental restraint system (SRS) 86. . . . . . . . . . . . . . . . . . . . . . . . . . .
Child restraint 98. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Driving position memory system 113. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

COMFORT ADJUSTMENT
70
FRONT SEATS
Front seat precautions
CAUTION
The SRS side airbags are installed in the driver and front
passenger seats. Observe the following precautions.
Do not lean over the front door when the vehicle is in use.
The side airbag inflates with considerable speed and force;
you may be killed or severely injured.
Do not modify or replace the seats or the surface of the seats
with side airbags. Such changes may disable the system, or
cause the side airbags to inflate, resulting in death or
serious injury. Consult your Lexus dealer.
Do not use accessories for the seats which cover the parts
where the side airbags should inflate. Such accessories may
prevent the side airbags from activating correctly, causing
death or serious injury.
Seat adjustment precautions
Adjust the driver’s seat so that the foot pedals, steering wheel and
instrument panel controls are within easy reach of the driver.
CAUTION
Do not adjust the seat while the vehicle is moving as the seat
may unexpectedly move and cause the driver to lose control
of the vehicle.
Be careful not to hit the seat against a passenger, luggage or
the rear seat.
NOTICE
Do not operate the control switch in more than one dimension
at a time. It may cause electrical overload.

COMFORT ADJUSTMENT
71
Adjusting front seats
16L1341
1
Seat position control switch, seat cushion angle and
height control switch
2
Seatback angle and head restraint control switch
3
Lumbar support control switch
Adjusting seat position
16L111
Move the control switch in the desired direction.
Releasing the switch will stop the seat in that position. Do not place
anything under the seat. It might interfere with the seat movement.

COMFORT ADJUSTMENT
72
Adjusting seatback angle
16L112
Move the control switch in the desired direction.
Releasing the switch will stop the seatback in that position.
CAUTION
To reduce the risk of sliding under the lap belt during a
collision, avoid reclining the seatback any more than needed.
The seat belts provide maximum protection in a frontal or rear
collision when the driver and the passenger are sitting up
straight and well back in the seats. If you are reclined, the lap
belt may slide past your hips and apply restraint forces
directly to the abdomen. Therefore, in the event of a frontal
collision, the risk of personal injury may increase with
increasing recline of the seatback.
Adjusting seat cushion angle and height
16L113
Move the control switch in the desired direction.
Releasing the switch will stop the seat cushion in that position.

COMFORT ADJUSTMENT
73
Adjusting lumbar support
16L114
Push the control switch on either side.
The amount of lumbar support will change as long as the switch is
pushed.
HEAD RESTRAINTS
Front seats (power type)
16L007
Move the control switch in the desired direction.
Releasing the switch will stop the head restraint in that position.
