Protecting Children

2. To activate the lockable retractor, slowly pull the shoulder part of the
belt all the way out until it stops,
then let the belt feed back into the
retractor (you might hear a
clicking noise as the belt retracts).
3. After the belt has retracted, tug on it. If the belt is locked, you will not
be able to pull it out. If you can pull
the belt out, it is not locked and
you will need to repeat these steps. 4. After confirming that the belt is
locked, grab the shoulder part of
the belt near the buckle and pull
up to remove any slack from the
lap part of the belt. Remember, if
the lap part of the belt is not tight,
the child seat will not be secure.
To remove slack, it may help to put weight on the child seat, or
push on the back of the seat while pulling up on the belt.
5. Push and pull the child seat
forward and from side to side to
verify that it is secure enough to
stay upright during normal driving

maneuvers. If the child seat is not

secure, unlatch the belt, allow it to

retract fully, then repeat these
steps.

To deactivate the locking mechanism in order to remove a

child seat, unlatch the buckle,

unroute the seat belt, and let the belt

fully retract.

Driver and Passenger Safety CONTINUEDProCarManuals.comMain Menu Table of Contents s t

Protecting Children

Installing an Infant Seat With the

Lap Belt

Seven-passenger model only
To install a rear-facing child seat with the lap belt, follow instructionnumber 1 on page 28 for routing and
latching the seat belt. Then pull hard
on the loose end of the belt to
remove any slack (it may help to put
weight on the child seat while pulling on the belt). Finally, follow
instruction number 5 of page 29 to
verify that the child seat is secure. Infant Seat Installation Tips
For proper protection, an infant must ride in a reclined, or semi-reclined
position. To determine the proper
reclining angle, check with the baby's doctor or follow the seat maker's
recommendations.
To achieve the desired reclining angle, it may help to put a rolled up
towel under the toe of the child seat,
as shown above. When properly installed a rear-facing
child seat may prevent the driver or
a front-seat passenger from moving
their seat as far back as
recommended (see page 10 ). Or it
may prevent them from locking theirseat-back in the desired upright
position (see page 11).
In either case, we recommend that
you place the child seat in another
back seating position, or leave the affected seat unoccupied. If the
problem cannot be solved, you may
wish to get a smaller rear-facing child seat.
Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Protecting Children
If it is necessary to put a forward-
facing child seat in the front, move
the vehicle seat as far to the rear as
possible, be sure the child seat is
firmly secured to the vehicle, and
that the child is properly strapped in
the seat.
Installing a Child Seat With a Lap/
Shoulder Belt

The lap/shoulder belts in the outer
back and front passenger seating
positions have a locking mechanism

that must be activated to secure a

child seat.

The following pages provide
instructions and tips on how to
secure a forward-facing child seat

with this type of seat belt.

See page 34 for how to secure a

forward-facing child seat with the lap

belt.
1. With the child seat in the desired
seating position, route the belt
through the child seat according
to the seat maker's instructions,
then insert the latch plate into the
buckle.
Driver and Passenger Safety
Improperly placing a forward-
facing child seat in the front seat can result in serious injury
or death if the airbags inflate.
If you must place a forward-
facing child seat in front, move
the vehicle seat as far back as possible and properly restrain
the child.ProCarManuals.comMain Menu Table of Contents s t

Protecting Children

2. To activate the lockable retractor, slowly pull the shoulder part of the
belt all the way out until it stops,
then let the belt feed back into the
retractor (you might hear a
clicking noise as the belt retracts).
3. After the belt has retracted, tug on it. If the belt is locked, you will not
be able to pull it out. If you can pull
the belt out, it is not locked and
you will need to repeat these steps. 4. After confirming that the belt is
locked, grab the shoulder part ofthe belt near the buckle and pull
up to remove any slack from the
lap part of the belt. Remember, if the lap part of the belt is not tight,
the child seat will not be secure. It may help to put weight on the
child seat, or push on the back of
the seat while pulling up on the
belt. 5. Push and pull the child seat
forward and from side to side to
verify that it is secure enough to stay upright during normal driving
maneuvers. If the child seat is not
secure, unlatch the belt, allow it to
retract fully, then repeat these
steps.

CONTINUED
Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Protecting Children

To deactivate the locking
mechanism in order to remove a

child seat, unlatch the buckle,

unroute the seat belt, and let the belt

fully retract.
Installing a Child Seat With the Lap

Belt

Seven-passenger model only
To install a forward-facing child seat with the lap belt, follow instructionnumber 1 on page 32 for routing and
latching the seat belt. Then pull hard on the loose end of the belt to
remove any slack (it may help to put
weight on the child seat while pulling on the belt). Finally, follow
instruction number 5 on page 33 to
verify that the child seat is secure.
Additional Precautions for Small

Children
Never hold a small child on your

lap. If you are not wearing a seat
belt in a crash, you could be
thrown forward into the dashboard and crush the child.
If you are wearing a seat belt, the
child can be torn from your arms
during a crash. For example, if the
vehicle crashes into a parked
vehicle at 30 mph (48 km/h), a 30 Ibs (14 kg) child will become a
900 Ibs (410 kg) force, and you will
not be able to hold it.
Never put a seat belt over yourself

and a child. During a crash, the
belt could press deep into the child and cause very serious injuries.

Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Protecting Children

If you decide that a child can safely
ride up front, be sure to:
Carefully read the owner's manual,
and make sure you understand all
seat belt instructions and all safety
information. Move the vehicle seat to the rear-
most position.
Have the child sit up straight with
their back against the seat and
their feet on, or near the floor. Check that the child's seat belt is
properly positioned and secured.
Closely supervise the child. Even
mature children sometimes need
to be reminded to fasten their seat
belt or sit properly. Using Child Seats with Tethers
Your Honda has several attachment points that allow a tether-style childseat to be installed. Since a tether can provide additional
security, we recommend using a
tether whenever one is required or available. (Tethers are required in
Canada. U.S. owners may check with
the child seat maker to determine
whether a tether is available for a particular child seat.)
U.S. Models
Two tether attachment points are located on the tailgate sill that allowa tether-style child seat to be
installed on the third seat. Use thedimensions in the illustration to
locate the attachment point you want to use. Cut a 7/8 inch (22 mm)diameter hole.
Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Protecting Children

Install the anchor plate and
mounting hardware. The hardware is available for purchase from your
Honda dealer (part number 82410-

SE3-C01).

When installing tether hardware, make sure the toothed washer is on
the bottom of the bolt. Tighten the
bolt to:16 lbf.ft (22 N .
m, 2.2 kgf.m)
To attache
the tether to the child
seat, follow the child seat maker's

instructions.

If you are not sure how to install the
tether, or you need mounting
hardware, contact your Honda dealer.
Canadian Models

Your Honda has attachment pointsfor a tether-style child seat to beinstalled on the second or third seat
as shown.
Second Seat Installation:

There are three attachment points available for the seven-passenger
model, and two attachment pointsavailable for the six-passenger model.
To use a tether-style child seat in the second seat, the third seat must be
stored in the floor recess (see page 60). You will find a U-shaped slit in
the carpeting at each attachment
point. Select the attachment point
you want to use, and pull up the carpeting at the slit. Attach the
tether strap to the mounting hook and make sure it is secure.

CONTINUED
Driver and Passenger SafetyProCarManuals.comMain Menu Table of Contents s t

Additional Information About Your Seat Belts
Seat Belt System Components

All the seat belts in the 6-passenger model are lap/shoulder belts. In the7-passenger model, the center
position of the bench-type second seat has a lap belt.
The system also includes alight on the instrument
panel to remind you and your
passengers to fasten your belts. If
the driver's seat belt is not fastened
before the ignition is turned ON (II), the light will come on and a beeper
will also sound. The beeper will stop after a few seconds, but the light will
stay on until the driver's seat belt is

fastened.
Lap/Shoulder Belt
This seat belt has a single belt that goes over your shoulder, across your
ches
t and
across your hips.
To fasten the belt, insert the latch plate into the buckle, then tug on the
belt to make sure the buckle is

latched.

To unlock the belt, push the red PRESS button on the buckle.Guide the belt across your body to
the door pillar. After exiting the
vehicle, be sure the belt is out of the way and will not get closed in the

door.

All lap/shoulder belts have an emergency locking retractor.
In normal driving, the retractor lets
you move freely in your seat while it
keeps some tension on the belt. During a collision or sudden stop,
the retractor automatically locks the
belt to help restrain your body.
All the lap/shoulder belts except the driver's have an additional locking
mechanism that must be activated to secure a child seat. (See pages 28 and 32 for instructions on how to
secure child seats with this type of
seat belt.)
If the shoulder part of the belt is
pulled all the way out, the locking
mechanism will activate. The belt
will retract, but it will not allow a passenger to move freely.
Driver and Passenger Safety CONTINUEDProCarManuals.comMain Menu Table of Contents s t
