1998 FORD WINDSTAR ignition

Controls and Features
91
*
[CF14400(ALL)04/96]
NOTE: Do not place heavy objects in the cupholders.
*
[CF14500(ALL)05/96]
The controls on the steering column and wheel are designed to
give you easy access to the controls while you are driving.
*
[CF14600(ALL)01/96]
Ignition
%*
[CF14700(ALL)01/96]
Understanding the Positions of the Ignition
*
[CF14800(ALL)01/96]
13-1/2 pica
art:0040047-D
The ignition positions
% [CF14900(ALL)12/95]
ACCESSORY allows you to operate some of your vehicle's
electrical accessories while the engine is not running. For
example, you can use ACCESSORY to turn on the radio or
windshield wipers without starting the engine.
[CF15000(ALL)12/95]
LOCK locks the steering wheel and the gearshift lever.
*
[CF15100(ALL)06/96]
OFF allows you to shut off the engine and all accessories
without locking the steering wheel, or the gearshift lever.
*
[CF15200(ALL)01/96]
ON allows you to test your vehicle's warning lights to make
sure they work before you start the engine. The key returns to
the ON position once the engine is started and remains in this
position while the engine runs.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

92
[CF15300(ALL)12/95]
START cranks the engine. Release the key once the engine starts
so that you don't damage the starter. The key should return to
the ON position when you release it. The START position also
allows you to test the brake warning light.
%*
[CF15400(ALL)03/96]
Removing the Key From the Ignition
[CF15500(ALL)12/95]
LOCK is the only position that allows you to remove the key
from the ignition. The LOCK feature helps to protect your
vehicle from theft, because it also locks the steering wheel and
the gearshift lever when the key is removed.
%*
[CF15600(ALL)01/96]
If your key is stuck in the LOCK position, and you are unable
to turn it, move your steering wheel left or right until the key
turns freely.
*
[CF15700(ALL)01/96]
To remove your key from the ignition:
[CF15750(ALL)09/96]1.
Maintain firm pressure on the service brake and set parking
brake fully. (This will avoid ªbindingº or ªloadingº the
powertrain, which may result in an objectionable noise
during park disengagement.)
[CF15800(ALL)09/96]2.
Put the gearshift lever in P (Park).
*
[CF16000(ALL)06/96]3.
Turn the ignition key to LOCK.
*
[CF16100(ALL)03/96]4.
Remove the key.
[CF16200(ALL)09/96]
RWARNING
When you leave your vehicle, set the parking brake fully,
place the gearshift lever in P (Park), and shut off the
engine. Never park your vehicle in N (Neutral). If you do
not take these precautions, your vehicle may move
suddenly and injure someone.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

96
[CF18800(ALL)01/96]
Speed Dependent Wipers
[CF18900(ALL)01/96]
This feature compensates for the extra moisture that
accumulates on your windshield at higher speeds during rain.
At higher speeds, the Speed Dependent feature shortens the
delay between wipes when you use the variable interval wipers.
Delay will automatically adjust at speeds between 10 and
65 mph (16 and 105 km/h).
[CF19000(ALL)01/96]
The Speed Dependent feature comes disabled from the factory,
but can be activated at any time by using the following
procedure.
[CF19100(ALL)01/96]1.
Make sure the two front doors are securely closed.
[CF19200(ALL)09/96]2.
Insert the key into the ignition and turn first to the ON
position (the gauges on the instrument panel willnot
illuminate) and then back to the OFF position. Remove the
key and within 30 seconds, perform the following sequence:
[CF19300(ALL)01/96]3.
Press and hold the washer button on the end of the turn
signal lever.
[CF19400(ALL)01/96]4.
Within two seconds, put the key back in the ignition and
turn to the ON position.
[CF19500(ALL)01/96]5.
Hold the washer button down until a long (two second) tone
is heard. Release the button while the tone is active.
[CF19600(ALL)09/96]6.
After the long tone, a confirmation sequence will be heard.
One beep indicates the feature is inactive. Two beeps
indicates the feature is active.
[CF19700(ALL)01/96]
Repeat this procedure any time you want to cancel or reactivate
the Speed Dependent feature.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

Controls and Features
99 only upshift and downshift from 1st through 3rd gears. The
vehicle will always return to the overdrive operation mode
when the ignition is turned off and back on.
[CF21000(ALL)01/96]
If the lamp does not come on when the Overdrive ON/OFF
button is depressed or if the lamp flashes when you are driving,
have your vehicle serviced at the first opportunity. If this
condition persists, damage could occur to the transaxle.
%*
[CF21200(ALL)05/96]
Horn
[CF21300(ALL)01/96]
To sound the horn, press the center of the steering wheel. Check
the horn regularly to make sure it operates properly.
[CF21400(ALL)01/96]
13-1/2 pica
art:0050017-A
The horn pad
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

102
%*
[CF22905(ALL)10/96]
To Turn Speed Control Off
*
[CF22907(ALL)10/96]
n
Press OFF,
*
[CF22909(ALL)10/96]
n
Turn off the vehicle ignition.
*
[CF22911(ALL)10/96]
Once speed control is switched off, the previously programmed
set speed will be erased.
*
[CF22913(ALL)10/96]
To Turn Speed Control On
*
[CF22915(ALL)10/96]
n
Press ON
*
[CF22921(ALL)10/96]
To Set a Speed
*
[CF22923(ALL)09/96]
Press SET ACCEL. For speed control to operate, the speed
control must be ON and the vehicle speed must be greater than
30 mph (48 km/h).
*
[CF22925(ALL)09/96]
If you drive up or down a steep hill, your vehicle speed may
vary momentarily slower or faster than the set speed. This is
normal.
*
[CF22927(ALL)09/96]
Speed control cannot reduce the vehicle speed if it increases
above the set speed on a downhill. If your vehicle speed is
faster than the set speed while driving on a downhill in
j
(Overdrive), you may want to shift to the next lower gear to
reduce your vehicle speed.
*
[CF22929(ALL)09/96]
If your vehicle slows down more than 10 mph (16 km/h) below
your set speed on an uphill, your speed control will disengage.
This is normal. Pressing RESUME will re-engage it.
*
[CF22931(ALL)09/96]
RWARNING
To keep your vehicle under control, do not use speed
control in heavy traffic or on roads that are winding,
slippery, or unpaved.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

104
*
[CF22963(ALL)09/96]
Indicator Light (If equipped)
*
[CF22965(ALL)09/96]
Lights when either the SET ACCEL or RESUME switches are
pressed and remains lit until it is either disengaged or turned
off.
%*
[CF27200(ALL)05/96]
Setting the Autolamp Delay System (If equipped)
[CF27301(ALL)10/96]
Autolamp delay allows the headlamps to remain on after the
vehicle is parked and the ignition is turned off. The slide knob
on the bottom of the mirror controls whether Autolamp is ON
or OFF as well as the length of the delay. The delay can be
adjusted from 1 second (far left position, but not OFF) up to 3
minutes (far right position). A green indicator on the lamp lets
you know that the headlamps are being controlled by the
Autolamp system.
[CF27700(ALL)10/96]
10-1/2 pica
art:0050157-B
The autolamp system
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

Controls and Features
105
[CF27800(ALL)01/96]
Setting the autolamp
[CF27901(ALL)10/96]
The headlamps can be adjusted to turn on earlier or later in the
day according to the amount of outside light reaching the
sensor inside the mirror. To turn the headlamps on using
Autolamp, perform the following procedure.
[CF28001(ALL)10/96]1.
Turn the ignition switch to the ON position and place the
Autolamp slide knob to OFF.
[CF28011(ALL)10/96]2.
Press and hold the MODE switch throughout the procedure.
The MODE switch is located in a hole on the bottom left
side of the mirror. It can be accessed with a paper clip or
similar object.
[CF28021(ALL)10/96]3.
Slowly slide the Autolamp slide knob to the right until the
headlamps turn on. To have the headlamps turn on earlier,
go to step 4. To have the headlamps turn on later, go to step
5.
[CF28031(ALL)10/96]4.
Slowly slide the Autolamp slide knob to the left until the
headlamps turn off. Go to step 6.
[CF28041(ALL)10/96]5.
Slowly slide the Autolamp slide knob to the right until the
headlamps turn off. Go to step 6.
[CF28051(ALL)10/96]6.
Release the MODE switch. The new setting will be stored in
permanent memory. If further change is required, you must
repeat the procedure from the beginning.
% [CF28700(ALL)01/96]
Front Dome Lamp
[CF28800(ALL)01/96]
Front dome lamp, rear cargo and second row reading lamp may
be turned on and off using the dimmer switch.
[CF28900(ALL)09/96]
The front dome lamp is located in the overhead console
between the driver and front passenger seats.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

Controls and Features
113
[CF34300(ALL)01/96]
10-1/2 pica
art:0050186-A
The power door lock switch in the cargo area
*
[CF34400(ALL)01/96]
NOTE: If the sliding door is open when all doors are locked
with the power door lock switch, the sliding door
automatically locks when it is closed.
*
[CF34500(ALL)01/96]
You can manually lock and unlock the doors using the manual
door locks to override the power locks.
%*
[CF34600(ALL)04/96]
Windows
[CF34700(ALL)01/96]
Power Windows with Accessory Delay (If equipped)
[CF34800(ALL)01/96]
Both of the front doors have a power control that opens and
closes the window on that door. The driver's door has master
controls that operate both front door windows. You must
initially place the ignition switch in the ON or ACC position to
use your power window controls. The Accessory Delay function
also allows the power windows to be operated for up to 30
seconds after the ignition key is removed or taken out of the
ON or ACC position. Accessory Delay will be cancelled,
however, if either of the front doors are opened.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996
