Controls and Features
115
[CF35600(ALL)01/96]
Cancelling and reactivating the one-touch-down feature
[CF35700(ALL)01/96]
The one-touch-down power window feature can be cancelled
and reactivated at any time using the following procedure:
[CF35800(ALL)01/96]1.
Make sure the two front doors are securely closed.
[CF35900(ALL)01/96]2.
Insert the key into the ignition and turn first to the ON
position and then back to the OFF position. Remove the key
and within 30 seconds:
[CF36000(ALL)09/96]3.
Press the DOWN side of the driver's side window rocker
switch, gently and not all the way down.
[CF36100(ALL)01/96]4.
Within two seconds, put the key in the ignition.
*
[CF36500(ALL)01/96]
Manual Flip-Open Quarter Windows
[CF36600(ALL)01/96]
To open the flip-open quarter windows in the third row,
squeeze the upper and lower pads and pull the rear portion of
the latch toward you. Swing the latch forward and out, then
lock it into the open position by pushing rearward until you
hear a click. To close the windows, squeeze the upper and
lower pads and pull the handle inward. Release pads and push
the handle inward until you hear a click.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

116
[CF36700(ALL)01/96]
13-1/2 pica
art:0050083-A
Manual flip-open quarter window latch location
*
[CF36800(ALL)01/96]
Power Quarter Windows (If equipped)
[CF36900(ALL)09/96]
The power rear quarter vent windows operate with the ignition
in the ON or ACC positions. The vent windows are controlled
by the right and left switches located on the door panel. Press
the indented side of the switch to open the windows; press the
raised side of the switch to close the windows.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

126
%*
[CF44800(ALL)01/96]
Battery Saver
[CF44900(ALL)01/96]
When the ignition switch is turned to OFF, the vehicle will turn
off battery voltage to the interior lamps after 45 minutes. (The
exterior lamps are not affected.) The purpose is to minimize
extended battery drain if the lights have inadvertently been left
on or if a door or the glove box is not completely closed.
However, the timer will be immediately reset to another 45
minutes if any of the following occurs:
[CF45000(ALL)01/96]
n
any door is open or closed
[CF45100(ALL)01/96]
n
the front door handle is lifted (for Illuminated Entry only)
[CF45200(ALL)01/96]
n
taking the key IN or OUT of the ignition switch
[CF45300(ALL)01/96]
n
the Keyless Entry keypad is used
[CF45400(ALL)01/96]
n
the Remote Entry transmitter is activated
*
[CF45500(ALL)05/96]
Remote Entry System (If equipped)
[CF45600(ALL)08/96]
If your vehicle has the remote entry system, you can lock and
unlock the vehicle doors without using a key. The remote entry
system also has a personal alarm feature. The buttons that
control the system are located on the hand held transmitter that
comes with your vehicle.
*
[CF45700(ALL)05/96]
The system will work with up to four remotes. Your vehicle
came with two remotes. Additional remotes can be ordered
from your dealer.
*
[CF45800(ALL)01/96]
The remote entry features only operate with the ignition in the
OFF position.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

128
%*
[CF46600(ALL)03/96]
Activating the remote personal alarm
[CF46700(ALL)08/96]
If you wish to activate the remote personal alarm, press the
PANIC button. This will honk the horn and flash the tail lamps
and low beam headlamps for approximately two minutes and
forty-five seconds. You can turn it OFF by pressing the PANIC
button again on the same transmitter or by turning the ignition
key to the RUN position. If the alarm does not turn off, move
the transmitter closer to the vehicle and press the button again.
[CF46800(ALL)01/96]
When you use the remote entry UNLOCK, or PANIC buttons,
the illuminated entry system turns on the interior lights for 25
seconds. You can turn these lights off with the LOCK button or
by turning the ignition to the RUN position.
[CF46900(ALL)07/96]
Replacing the batteries
*
[CF47000(ALL)05/96]
The remote is powered by two coin type three-volt lithium 2016
batteries (included) that should last for several years of normal
use. If you notice a significant decrease in operating range, the
batteries should be replaced. Replacement batteries can be
purchased at most pharmacies, watch stores or at your Ford or
Lincoln-Mercury dealer.
*
[CF47100(ALL)01/96]
NOTE: The operating range of the remote entry system can
also be affected by weather conditions (such as very
cold temperatures) or structures around the vehicle
(buildings, other vehicles, radio towers, etc.). Typical
operating range will allow you to be up to 33 feet (10
meters) away from your vehicle.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

130
%*
[CF47800(ALL)01/96]
Illuminated Entry System (If equipped)
[CF47900(ALL)08/96]
This system will provide illumination of the vehicle's interior
courtesy lamps when the remote entry system is used to unlock
the door or sound the personal alarm. The system will
automatically turn off after approximately 25 seconds, when the
ignition is turned to the RUN or ACC position or when the lock
button on the transmitter is pressed.
[CF48000(ALL)01/96]
NOTE: The illuminated entry timer will not turn off the
courtesy lamps if they have been turned on by the
door and or dimmer switch.
% [CF48100(ALL)09/96]
Autolock
[CF48200(ALL)09/96]
The Autolock feature is part of your remote entry system and is
enabled at the factory. With the Autolock feature enabled, all of
the doors will automatically lock when:
[CF48300(ALL)09/96]
n
the vehicle doors and liftgate are closed
*
[CF48400(ALL)09/96]
n
the ignition key is turned to the ON position
[CF48500(ALL)09/96]
n
you shift into R (Reverse)
*
[CF48700(ALL)08/96]
n
one second has elapsed after the brake pedal is released
*
[CF48800(ALL)05/96]
The Autolock feature will repeat when:
[CF48900(ALL)01/96]
n
a door is opened and then all doors and the liftgate are
closed
[CF49000(ALL)08/96]
n
the brake pedal is released
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

Controls and Features
131
[CF49200(ALL)04/96]
The doors may not lock automatically at the correct time if the
driver:
[CF49300(ALL)04/96]
n
shifts through gears without pressing the brake
[CF49400(ALL)04/96]
n
shifts through gears quickly after starting the vehicle
[CF49500(ALL)04/96]
n
releases their foot from the brake while someone has stepped
out of the vehicle for a moment
[CF49610(ALL)08/96]
To activate/deactivate Autolock/Relock feature:
[CF49620(ALL)08/96]1.
Turn ignition from OFF to ON/ACC.
[CF49630(ALL)08/96]2.
Press power door ªUNLOCKº three times.
[CF49640(ALL)08/96]3.
Turn ignition from ON/ACC to OFF.
[CF49650(ALL)08/96]4.
Press power door ªUNLOCKº three times.
[CF49660(ALL)08/96]5.
Turn ignition from OFF to ON/ACC.
[CF49670(ALL)08/96]
A horn chirp indicates the activate/deactivate feature mode is
entered.
[CF49680(ALL)08/96]6.
Press power door ªUNLOCKº one time.
[CF49690(ALL)08/96]7.
Press power door ªLOCKº to switch between
Autolock/Relock.
[CF49700(ALL)08/96]
The user will hear a horn chirp followed by either a:
[CF49710(ALL)08/96]
n
long honk Ð autolock/relock activated.
[CF49720(ALL)08/96]
n
no honk Ð autolock/relock deactivated.
[CF49730(ALL)08/96]
After leaving the activate/deactivate mode, if autolock/relock
has been changed, there will be a horn chirp.
[CF50100(ALL)08/96]
To reactivate the Autolock system, simply repeat the instructions
for deactivating the system.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

132
% [CF50200(ALL)01/96]
Anti-Theft System (if equipped)
*
[CF50300(ALL)01/96]
When armed, this system helps protect your vehicle against
break-ins or theft.
%*
[CF50400(ALL)01/96]
When an unauthorized entry occurs, the system triggers and
will:
[CF50500(ALL)08/96]
n
flash the low beam headlamps, parking lamps, and alarm
indicator lamp
*
[CF50600(ALL)01/96]
n
honk the horn
*
[CF50700(ALL)01/96]
n
disable the starting circuit to prevent the vehicle from being
started
%*
[CF50800(ALL)07/96]
Arming the System
[CF50900(ALL)08/96]1.
Remove the key from the ignition.
[CF51100(ALL)08/96]2.
Lock the doors by using the power door lock switch. The
alarm indicator light will now glow steadily.
[CF51200(ALL)08/96]4.
Close all doors and liftgate. The alarm indicator light will
then remain on steadily for 30 seconds and then go out.
When the light starts flashing, the system is armed.
*
[CF51300(ALL)08/96]
NOTE: Be sure to close all doors completely. If not, the alarm
indicator light will remain on. Remember, your
anti-theft system is armed only after the alarm
indicator light remains on steadily for approximately
30 seconds after the last door is closed, and then goes
out.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

Controls and Features
133
[CF51400(ALL)08/96]
You can also arm the anti-theft system by following this
sequence:
*
[CF51500(ALL)08/96]1.
Remove the key from the ignition. The hood must be closed
to arm the system.
[CF51600(ALL)08/96]2.
Close all of the doors and liftgate.
[CF51700(ALL)08/96]3.
Press the remote entry transmitter LOCK button. The alarm
indicator will come on for 30 seconds to show the alarm is
arming and then flash to show that it has armed.
%*
[CF51900(ALL)03/96]
Disarming an Untriggered Anti-Theft System
[CF52000(ALL)01/96]
You can disarm the system by unlocking either front door or
the liftgate with your door key. Turn the key all the way to the
end of travel or the system will not disarm.
[CF52100(ALL)08/96]
You can also disarm the system by unlocking the driver's door
by using the UNLOCK button of the remote entry transmitter.
[CF52200(ALL)04/96]
If the system is armed and you remain in your vehicle, simply
insert the key into the ignition and turn it to ON. This disarms
the system and allows you to open the door and exit without
triggering the system.
