1998 FORD WINDSTAR ESP

Electronic Sound Systems
53
*
[AS12027(ALL)04/95]3.
Load discs into disc magazine slots (numbered 1 through 10)
one at a time with labeled surfaces upward, starting with
bottom slot number 1 (Figure 3).
[AS12030(ALL)05/95]
10-1/2 pica
art:0050267-A[AS12033(ALL)04/95]4.
Insert loaded disc magazine into chamber unit with the
arrow on top of the disc magazine pointing toward the
changer (Figure 4).Make sure magazine is fully inserted
into changer.
[AS12036(ALL)06/95]
7-1/2 pica art:0050268-A*
[AS12039(ALL)09/95]
NOTE: To remove one or more compact disc(s) from the disc
magazine, push the corresponding lever(s) (numbered
1 to 10 on the side of the disc magazine) to the left.
Disc(s) will partially come out for easy removal.
File:04wnass.ex
Update:Fri Sep 27 13:16:38 1996

62
*
[AS23160(ALL)02/96]
n
Using the ªSCANº function (Stereo Cassette Radio)
*
[AS23170(ALL)06/95]
Press the ªSCANº button to enter the scan mode. The radio
will begin scanning up the frequency band, stopping on each
listenable station for approximately a five-second sampling.
This continues until you press the ªSCANº button a second
time. The display flashes ªAMº or ªFM.º
*
[AS23200(ALL)03/96]
n
Setting the station MEMORY PRESET buttons
*
[AS23325(ALL)02/96]
Your radio is equipped with 5 station memory buttons.
These buttons can be used to select up to 5 preset AM
stations and 10 preset FM stations (5 in FM1 and 5 in FM2).
*
[AS23400(ALL)08/95]
Follow the easy steps below to set these buttons to the desired
frequencies:
*
[AS23500(ALL)06/96]1.
Select a band, then select a frequency.
*
[AS23700(ALL)06/96]2.
Press one of the memory preset buttons and hold the button
until the sound returns. That station is now held in memory
on that button.
*
[AS23800(ALL)06/96]3.
Follow the two steps above for each station memory preset
button you want to set.
*
[AS23900(ALL)03/96]
NOTE: If the vehicle's battery is disconnected, the clock and
station memory preset buttons will need to be reset.
*
[AS24000(ALL)10/95]
Adjusting the tone balance and speaker output of your
radio
*
[AS24100(ALL)02/96]
n
Increasing or decreasing bass response
*
[AS24225(ALL)02/96]
Push the ªAUDIOº button repeatedly until the display reads
ªBASS.º Push the right (+) side of the ªVOLUMEº button to
increase bass (more ªlowsº), and push the left (s) side to
decrease bass (less ªlowsº).
File:04wnass.ex
Update:Fri Sep 27 13:16:38 1996

Electronic Sound Systems
63
*
[AS24300(ALL)02/96]
n
Increasing or decreasing treble response
*
[AS24425(ALL)02/96]
Push the ªAUDIOº button repeatedly until the display reads
ªTREB.º Push the right (+) side of the ªVOLUMEº button to
increase the treble (more ªhighsº), and push the left (s) side
to decrease treble (less ªhighsº).
*
[AS24500(ALL)02/96]
Speaker features and operation
*
[AS24600(ALL)02/96]
n
Adjusting speaker balance
*
[AS24725(ALL)02/96]
Balance control allows you to adjust the sound distribution
between the right and left speakers. Push the ªAUDIOº
button repeatedly until the display reads ªBAL.º Push the
right (+) side of the ªVOLUMEº button to shift the sound to
the right speakers, and push the left (s) side to shift the
sound to the left speakers.
*
[AS24800(ALL)04/96]
n
Adjusting speaker fader
*
[AS24925(ALL)02/96]
Fade control allows you to adjust the sound distribution
between the front and rear speakers. Push the ªAUDIOº
button repeatedly until the display reads ªFADE.º Push the
right (+) side of the ªVOLUMEº button to shift the sound to
the front speakers, and push the left (s) side to shift the
sound to the rear speakers.
[AS24950(ALL)09/95]
NOTE: Illuminated bars in the display show relative levels of
bass and treble and positions of speaker balance and
fader functions for five seconds after adjustments are
made, then revert to volume level set.
%*
[AS25000(ALL)06/96]
Using the Controls of Your Cassette Tape Player
*
[AS25500(ALL)08/95]
How to insert a tape
[AS25600(ALL)05/95]
Insert a cassette (with theopen edge to the right) firmly into
the tape door opening, making sure the cassette is completely in
and ªseated.º
File:04wnass.ex
Update:Fri Sep 27 13:16:38 1996

64
*
[AS25700(ALL)12/95]
How to locate a desired track on the tape
[AS25800(ALL)09/95]
NOTE: The tape track number indicated in the display does
not necessarily correspond to the tape track or side
number on the cassette label. It is used only to
indicate when the tape mechanism reverses tracks.
[AS25896(ALL)12/93]
Using the Automatic Music Search (ªAMSº) function with
cassette tape player (if your display shows numerals)
*
[AS25897(ALL)03/96]
Press and hold the ªAMSº button (ªAMSº will appear in the
display). Then, push the left
hbutton to rewind to the
beginning of the current selection or press the right
gbutton
to fast forward to the beginning of the next selection.
*
[AS25900(ALL)09/95]
n
Fast forwarding the tape
*
[AS26000(ALL)04/96]
Push the right
gbutton to fast forward the tape.
*
[AS26100(ALL)08/95]
n
Rewinding the tape
*
[AS26200(ALL)04/96]
Push the left
hbutton to rewind the tape.
[AS26300(ALL)12/93]
Using the Automatic Music Search (ªAMSº) function with
cassette tape player (if your display shows arrows)
[AS26310(ALL)10/95]
Press and hold the ªAMSº button. Then, push the
appropriate fast-wind button, depending upon the direction
of the tape travel arrow in the display. For example, if the
tape travel arrow is pointing to the left, push the right (
g)
button to rewind to the beginning of the current selection. If
the tape travel arrow is pointing to the right, press the right
(
g) button to fast forward to the beginning of the next
selection.
File:04wnass.ex
Update:Fri Sep 27 13:16:38 1996

82
[CF07600(ALL)01/96]
NOTE: The compressor will not operate when the outside
temperature is less than about45ÊF (7ÊC).
% [CF07700(ALL)01/96]
Rear Climate Control System (If equipped)
[CF07800(ALL)01/96]
If your vehicle is equipped with a rear climate control system,
the rear seat occupants can select their own personal fan speed
settings.
[CF07900(ALL)01/96]
The rear seat climate control system is controlled from the main
climate control system on the instrument panel. If the rear
passenger compartment climate control knob in the front climate
control panel is set in OFF, the fan in the rear seat climate
control system will also be off. If the knob is set in any of the
fan speed positions (Medium Low, Medium High, or High), air
will be discharged from the rear seat vents at the corresponding
speed. However, when the knob is set at REAR CTRL, rear seat
passengers can control their own fan speed.
[CF08000(ALL)01/96]
7-1/2 pica art:0050048-D
Rear fan control knob
[CF08100(ALL)01/96]
The rear passenger compartment climate control panel has a Fan
Speed Knob which controls the speed (Low, Medium Low,
Medium High, or High) at which air is discharged from the
registers whenever the Rear Control Knob on the front panel
climate control panel is in REAR CTRL.
[CF08200(ALL)08/96]
Front passengers determine the temperature and location of the
airflow for rear passengers by setting the Rear Control in the
front climate control panel in either a heat or cool mode.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

86
%*
[CF10325(ALL)08/96]
Traction Control (If equipped)
[CF10350(ALL)08/96]
Traction Control can help improve your traction on slippery
surfaces, but always operate your vehicle within reasonable
limits. Abrupt changes in acceleration, deceleration, turning, or
combinations of these maneuvers can cause your vehicle to
behave differently than anticipated, especially when road
conditions vary.
[CF10375(ALL)08/96]
To turn Traction Control off, press the button located in the
center of the instrument panel.
[CF10380(ALL)08/96]
Traction Control can be turned back on by pressing the button
again or by restarting the engine.
% [CF10700(ALL)01/96]
Exterior Lamps
*
[CF10800(ALL)05/96]
To turn on the headlamps, parking lamps, marker lamps, tail
lamps, license plate lamps and instrument panel lamps, use the
headlamp knob, to the left of the instrument cluster.
*
[CF10900(ALL)05/96]1.
Turn the headlamp knob to the first position to turn on the
parking lamps, tail lamps, license plate lamps, marker lamps
and instrument panel lamps.
*
[CF11000(ALL)05/96]2.
Turn the headlamp knob to the second position to turn on
the headlamps in addition to the parking lamps, tail lamps,
license plate lamps, marker lamps and instrument panel
lamps.
File:05wncfs.ex
Update:Tue Oct 8 10:20:34 1996

168
%*
[SS19000(ALL)05/96]
The Importance of Being Properly Seated
*
[SS19100(ALL)05/96]
In a collision, the air bag must inflate extremely fast to help
provide additional protection for you. In order to do this, the
air bag must inflate with considerable force. If you are not
seated in a normal riding position with your back against the
seatback, the air bag may not protect you properly and could
possibly hurt you as it inflates.
*
[SS19200(ALL)05/96]
Your vehicle is equipped with a right front passenger air bag.
Air bags deploy with great force, faster than the blink of an eye.
Front passengers, especially children and small adults, must
never sit on the front edge of the seat, stand near the glove
compartment of the instrument panel, or lean over near the air
bag cover when the vehicle is moving. All occupants should sit
with their backs against the seatback, move the seat to the most
rearward position if possible and use the safety belts. Children
weighing less than 40 lbs. (18 kg) always should use child or
infant seats.
%*
[SS19300(ALL)07/96]
RWARNING
When installing forward-facing child seats in the front
seat, always move the passenger seat as far back from the
instrument panel as possible. Never install rear-facing
child seats or rear-facing infant seats in the front seat.
*
[SS19400(ALL)05/96]
The force of the rapidly inflating passenger air bag could push
the top of the rear-facing seat against the vehicle seatback,
armrests or console. Rear-facing infant seats must always be
secured in the rear seat.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996

Seating and Safety Restraints
169
*
[SS19500(ALL)05/96]
RWARNING
Do not place objects or mount equipment on or near the
air bag cover that may come in contact with an inflating
air bag. Failure to follow this instruction may increase
the risk of personal injury in the event of a collision.
*
[SS19600(ALL)05/96]
For further information about the proper mounting of
equipment in the front seat of this vehicle, please refer to Ford's
brochure entitledSome Important Information About Air Bag
Supplemental Restraint Systemwhich can be obtained by calling
Helm Inc. at 1-800-782-4356. Ask for brochure FPS-8602.
*
[SS19700(ALL)05/96]
For additional important safety information on the proper use of
seat belts, child seats, and infant seats, please read the other
sections of this chapter of the Owner Guide, especially sections
entitledSafety Belts for ChildrenandSafety Seats for Children.
%*
[SS19800(ALL)05/96]
How Does the Air Bag Supplemental Restraint System
Work?
*
[SS19900(ALL)05/96]
The Air Bag Supplemental Restraint System consists of the
driver and passenger air bags, impact sensors, a system
diagnostic module, a readiness light and tone, and the electrical
wiring which connects the components.
[SS20000(ALL)04/96]
The driver air bag is in the center of the steering wheel and is
indicated by the letters ªSRS.º The right front passenger seat air
bag is in the upper right-hand section of the instrument panel
ledge above the glove compartment. The letters ªSRSº appear
there. Both air bags are designed to stay out of sight until they
are activated.
File:06wnsss.ex
Update:Fri Oct 11 10:48:20 1996
