1998 FORD RANGER Owners Manual

²2.5L
²Never wash or rinse the engine while it is running; water in the
running engine may cause internal damage.
Cleaning plastic exterior parts
Use vinyl cleaner for routine cleaning. Clean with a tar remover if
necessary. Do not clean plastic parts with thinners, solvents or
petroleum-based cleaners.
Cleaning the exterior lamps
Wash with the same detergent as the exterior of your vehicle. Use glass
cleaner or tar remover if necessary.
To avoid scratching the lamps, do not use a dry paper towel, chemical
solvents or abrasive cleaners.
Cleaning the wiper blades
If the wiper blades do not wipe properly, clean the wiper blades with
undiluted windshield wiper solution.
Clean the windshield with undiluted windshield wiper solution or a mild
non-abrasive detergent. Rinse thoroughly with clean water.
To avoid damaging the blades, do not use fuel, kerosene, paint thinner or
other solvents.
Maintenance and care
145

Cleaning the instrument panel
Clean with a damp cloth, then dry with a dry cloth.
Avoid cleaner or polish that increases the gloss of the upper portion of
the instrument panel. The dull finish in this area helps protect the driver
from undesirable windshield reflection.
Cleaning the interior fabric
Remove dust and loose dirt with a whisk broom or a vacuum cleaner.
Remove fresh spots immediately. Follow the directions that come with
the cleaner.
Cleaning and maintaining the safety belts
Clean the safety belts with a mild soap solution recommended for
cleaning upholstery or carpets. Do not bleach or dye the belts, because
these actions may weaken the belt webbing.
Check the safety belt system periodically to make sure there are no
nicks, wear or cuts. If your vehicle has been involved in an accident,
refer to theSafety belt maintenancesection in theSeating and safety
restraintschapter.
Underbody
Flush the complete underside of vehicle frequently. Keep body drain
holes unplugged. Inspect for road damage.
Inside windows
Use glass cleaner for the inside windows if they become fogged.
Cleaning mirrors
Do not clean your mirrors with a dry cloth or abrasive materials. Use a
soft cloth and mild detergent and water. Be careful when removing ice
from outside mirrors because you may damage the reflective surface.
Maintenance and care
146

MOTORCRAFT PART NUMBERS
Component 2.5L I4 engine 3.0L V6 engine 4.0L V6 engine
Air filter FA-1616 FA-1616 FA-1616
Fuel filter FG-872 FG-872 FG-872
Battery BXT-58 BXT-58 BXT-58
Oil filter FL-400S FL-400S FL-1A
PCV valve EV-147 EV-130 EV-225
Spark plugs* AWSF-32F** AWSF-32PP*** AGSF-22PP***
* Refer to Vehicle Emissions Control Information (VECI) decal for
spark plug gap information.
** Two spark plugs per cylinder required (eight total)
*** If any spark plug needs to be removed for inspection, it must be
re-installed in the same cylinder. Cylinders No.1, 2 and 3 have a ªPGº
suffix. Cylinders No. 4, 5 and 6 have a ªPº suffix. If any spark plug
needs to be replaced, use only spark plugs with the service part
number suffix letters ªPPº as shown on the engine decal.
Capacities and specifications
147

REFILL CAPACITIES
Fluid Ford Part
NameApplication
Capacity
Engine oil
(includes
filter
change)Motorcraft
5W30 Super
Premium Motor
Oil2.5L I4 and 3.0L
V6 engine4.3L (4.5 quarts)
4.0L V6 engine 4.7L (5.0 quarts)
Brake fluid High
Performance
DOT 3 Motor
Vehicle Brake
FluidAll
Fill to line on
reservoir
Power
steering
fluidMotorcraft
MERCONtAT FAll
Fill to range on
dipstick
Transmission
fluidMotorcraft
MERCONtAT F5-speed manual
2.65L (2.8 quarts)
Motorcraft
MERCONtV
AT F4x2 vehicles with
automatic9.0L (9.5 quarts)
4x4 vehicles with
automatic9.3L (9.8 quarts)
Engine
coolantFord Extended
Life Engine
Coolant
(DEX-COOL)2.5L I4 engine
without A/C6.2L (6.5 quarts)
2.5L I4 engine
with A/C6.8L (7.2 quarts)
3.0L V6 engine
without A/C9.0L (9.5 quarts)
3.0L V6 engine
with A/C9.6L (10.2 quarts)
4.0L V6 engine
without A/C7.4L (7.8 quarts)
4.0L V6 engine
with A/C8.1L (8.6 quarts)
Capacities and specifications
148

Fluid Ford Part
NameApplication
Capacity
Fuel tank N/A Regular cab
(Short wheel
base)62.8L (16.6 gallons)
Regular cab
(Long wheel
base)75.7L (20.0 gallons)
SuperCab 74.2L (19.6 gallons)
Transfer
Case FluidWarner 13±54 4x4 Vehicles
1.2L (1.25 quarts)
Front axle
fluidMotorcraft SAE
80W90 Axle
Lubricant4x4 vehicles with
2.5L I4 or 3.0L
V6 engine1.4L (1.5 quarts)
4x4 vehicles with
4.0L V6 engine1.7L (1.8 quarts)
Rear axle
fluid
1Motorcraft SAE
80W90 Rear
Axle LubricantAll
2.4-2.6L
(2.5-2.65 quarts)
Windshield
washer fluidUltra-Clear
Windshield
Washer
ConcentrateAll
Fill to line on
reservoir
1Add 118 ml (4 oz.) of additive friction modifier C8AZ-19B546±A, Ford
specification EST-M2C118±A for complete refill of Traction-Lok axles.
Service refill capacities are determined by filling the rear axle 6 mm to
14 mm (1/4 inch to 9/16 inch) below the bottom of the filler hole.
Capacities and specifications
149

LUBRICANT SPECIFICATIONS
ItemFord part
name or
equivalentFord part
numberFord
specification
Front axle75W90 Gear
LubeXY-
75W90-QLWSP-
M2C201-A
Rear axleMotorcraft
SAE 80W90
Rear Axle
Lube
1
F1TZ-
19580-BWSL-
M2C192-A
Brake fluid and clutch
fluid
(if equipped)High
Performance
DOT 3 Motor
Vehicle
Brake FluidC6AZ-
19542-
ABESA-
M6C25-A
and DOT 3
Engine coolantFord
Extended
Life Engine
Coolant
(DEX-COOL)F6AZ-
19544-AA or
BESE-
M97B44-A or
WSS-
M97B44-D
Engine oilMotorcraft
5W30 Super
Premium
Motor OilXO-5W30-BSP
or QSPWSS-
M2C153-G
and API
Certification
Mark
Hinges, latches, stricker
plates, fuel filler door
hinge and seat tracksMulti-Purpose
GreaseDOAZ-
19584-AA or
F5AZ-
19g209-AAESB-
M1C93-B or
ESB-
M1C159-A
Transmission
/steering/parking brake
linkages and pivots, brake
and clutch pedal shaft,
clutch pilot bearing and.
input shaft spline
(manual transmission).Premium
Long-Life
GreaseXG-1-C ESA-
M1C75-B
Capacities and specifications
150

ItemFord part
name or
equivalentFord part
numberFord
specification
Power steering fluid,
transfer case fluid and
transmission fluid
(manual)Motorcraft
MERCONt
AT FXT-2-QDX MERCONt
Automatic transmission
(4R44E and 5R55E)Motorcraft
MERCONtV
AT FXT-5-QM
MERCONtV
Windshield washer fluidUltra-clear
windshield
washer
concentrateC9AZ-
19550-ABESR-
M17P5-A
1Add 118 ml (4 oz.) of additive friction modifier C8AZ-19B546±A, Ford
specification EST-M2C118±A for complete refill of Traction-Lok axles.
ENGINE DATA
Engine 2.5L I4 engine 3.0L V6 engine 4.0L V6 engine
Cubic inches 153 182 245
Horsepower 119 @ 5000 rpm 150 @ 5000 rpm 160 @ 4200 rpm
Torque 146 lbs. ft. @
3000 rpm185 lbs. ft. @
3250 rpm225 lbs. ft. @
2750 rpm
Required fuel
grade87 octane 87 octane 87 octane
Firing order 1-3-4-2 1-4-2-5-3-6 1-4-2-5-3-6
Spark plug
gap1.07-1.17 mm
(0.042-.046 inch)1.07-1.17 mm
(0.042-.046 inch)1.3-1.4 mm
(0.052-.056 inch)
Ignition
systemEDIS EDIS EDIS
Compression
ratio9.4:1 9.14:1 9.0:1
Capacities and specifications
151

VEHICLE DIMENSIONS
Vehicle
dimensionsRegular Cab
Short Wheel
Base (SWB)
mm (in)Regular Cab
Long Wheel
Base (LWB)
mm (in)Supercab
mm (in)
(1) Overall length 4 763 (187.5) 5 093 (200.5) 5 153 (202.9)
(2) Overall width 1 785 (70.3) 1 785 (70.3) 1 785 (70.3)
(3) Overall height
4x2/4x41 575 (62.0) /
1 655 (65.2)1 586 (62.4) /
1 655 (65.2)1 585 (62.4) /
1 684 (66.3)
(4) Wheelbase 2 831 (111.4) 2 983 (117.4) 3 192 (125.7)
(5) Track - Front 1 486 (58.5) 1 486 (58.5) 1 485 (58.5)
(5) Track - Rear 1 455 (57.3) 1 455 (57.3) 1 455 (57.3)
2
5
3
Capacities and specifications
152
