1998 FORD EXPLORER Owners Manual

FluidFord Part
Name or
equivalentFord Part
NumberFord
Specification
Power steering
reservoirMotorcraft
MERCONtAT FXT-2-QDX MERCONt
Ford
conventional and
traction lok rear
axlesRefer to
footnotes 1, 2
and 3Refer to
footnotes 1, 2
and 3Refer to
footnotes 1, 2
and 3
Front axle 4x4 Gear Oil F1TZ-19580-A WSL-M2C191-A
Transfer case -
Four wheel
driveMotorcraft
MERCONtAT FXT-2-QDX MERCONt
5-speed manual
transmissionMotorcraft
MERCONtAT FXT-2-QDX MERCONt
Transfer case
Front Output
Slip ShaftPremium
Long-Life GreaseXG-1-G or K ESA-M1C75-B
14.0L vehicles with conventional and Traction-lok rear axles are filled
with Motorcraft SAE 80W90 Premium Rear Axle Lube, part number
XY-80W90±QL, Ford specification WSP-M2C197±A.
24.0L vehicles with limited slip differentials and all 5.0L applications use
rear axles that are filled with Motorcraft SAE 75W140 High Performance
Synthetic Rear Axle Lube, part number F1TZ-19580±B, Ford
specification WSL-M2C192±A.
34.0L vehicles with limited slip differentials and all 5.0L applications
must add 118 ml (4 oz) of additive friction modifier C8AZ-19B546±A,
Ford specification EST-M2C118±A to the rear axle whenever the axle has
been serviced.
Capacities and specifications
201

ENGINE DATA
Engine4.0L EFI
engine4.0L SOHC
engine5.0L engine
Cubic inches 245 245 302
Horsepower 160 @ 4200 rpm 205 @ 5000 rpm 215 @ 4200 rpm
Torque 225 lb. ft. @
2750 rpm250 lb. ft. @
3000 rpm288 lbs.ft. @
3300 rpm
Required fuel
grade87 octane 87 octane 87 octane
Firing order 1-4-2-5-3-6 1-4-2-5-3-6 1-3-7-2-6-5-4-8
Spark plug gap 1.3 mm-1.4 mm
(0.052-.056
inch)1.3 mm-1.4 mm
(0.052-.056
inch)1.3 mm-1.4 mm
(0.052-.056
inch)
Ignition system EDIS EDIS EDIS
Compression
ratio9.0:1 9.7:1 9.0:1
VEHICLE DIMENSIONS
Dimensions 4 Door mm (in.) 2 Door mm (in.)
(1) Overall length 4 788 (188.5) 4 536 (178.6)
(2) Overall width 1 783 (70.2) 1 783 (70.2)
(3) Maximum
height1 72.5 (67.9) 1 722 (67.8)
(4) Wheelbase 2 835 (111.6) 2 585 (101.8)
(5) Front track /
rear1 486/1 487 (58.5/58.5) 1 486/1 487 (58.5/58.5)
Capacities and specifications
202

4
1
3
5
2
Capacities and specifications
203

IDENTIFYING YOUR VEHICLE
Safety compliance label
The National Highway Traffic Safety
Administration Regulations require
that a Safety Compliance
Certification Label be affixed to a
vehicle and prescribe where the
Safety Compliance Certification
Label may be located. The Safety
Compliance Certification Label is
located on the front door latch pillar
on the driver's side.
Vehicle identification number
The vehicle identification number is
attached to a metal tag and is
located on the driver side
instrument panel.
Engine number
The engine number (the last eight numbers of the vehicle identification
number) is stamped on the engine block, transmission, frame and
transfer case (if so equipped).
MFD. BY FORD MOTOR CO. IN U.S.A.
EXT PNT: XXXXXX XXXXXX RC: XX DSO: XXXX F0000
BAR INT TR TP/PS R AXLE TR SPR T0000
X XX XXX X XX X XXXX
UTC
ÑFOHT-15294A10-GA
MAXIMUM LOAD=OCCUPANTS + LUGGAGE=XXXKG/XXXXLB
OCCUPANTS: X TOTAL X FR X 2ND X RR OCCUPANTS LUGGAGE
XX XXXKG/XXXXLB
TIRE: XXXX/XXXXX XXX X XXXKG/XXXXLB
PRESSURE (FR) XXX kPa/33 PSI COLD
PRESSURE (RR) XXX kPa/33 PSI COLD
TRAILER TOWING - SEE OWNER GUIDE
DATE: XXXXX GVWR:XXXXX LB/ XXXXX KG
VIN: XXXXXXXXXXXXXXXXX TYPE: XXXXXXXXXXXXXXX FGAWR: XXXXXX/XXXXXXX RGAWR: XXXXXXX/XXXXXXX
THIS VEHICLE CONFORMS TO ALL APPLICABLE FEDERAL
MOTOR VEHICLE SAFETY STANDARDS IN EFFECT ON THE
DATE OF MANUFACTURE SHOWN ABOVE.
XXXXXXXXXXXXXXXXX
AIR BAG
Capacities and specifications
204

REPORTING SAFETY DEFECTS (U.S. ONLY)
If you believe that your vehicle has
a defect that could cause a crash, or
could cause injury or death, you
should immediately inform the
National Highway Traffic Safety
Administration (NHTSA) in addition
to notifying Ford Motor Company.
If NHTSA receives similar complaints, it may open an investigation, and
if it finds that a safety defect exists in a group of vehicles, it may order a
recall and remedy campaign. However, NHTSA cannot become involved
in individual problems between you, your dealer or Ford Motor Company.
To contact NHTSA, you may either call the Auto Safety Hotline toll-free
at 1±800±424±9393 (202±366±0123 in the Washington D.C. area) or write
to:
NHTSA
U.S. Department of Transportation
400 Seventh Street
Washington D.C. 20590
You can also obtain other information about motor vehicle safety from
the Hotline.
Reporting safety defects
205

Air bag supplemental
restraint system ........................82
and child safety seats ..............83
description ................................82
disposal ......................................86
indicator light ...........................85
passenger air bag .....................84
Air conditioning
manual heating and air
conditioning system ............23,25
Air suspension
description ..............................106
All wheel drive (AWD) .............121
Ambulance packages ....................3
Anti-lock brake system (ABS)
description ..............................104
Anti-theft system ........................67
Autolamp system (see
Headlamps) .................................48
Automatic dimming mirror ...48,49
Battery .......................................175
voltage gauge ............................14
Brake fluid
checking and adding ..............164
Brakes ........................................104
anti-lock ...................................104
anti-lock brake system (ABS)
warning light ...........................104
fluid, checking and adding ....164
Brake-shift interlock .................107
Break-in period .............................2
Bulbs, replacing ........................186
headlamps ...............................187
specifications ..........................188
Cargo cover .................................57
Changing a tire .........................144
Child safety seats ........................87
built-in child seat ......91,92,96,97
Childproof locks ..........................52
Chime
headlamps on ............................11
Cleaning your vehicle ...............191built-in child seat ...................195
engine compartment ..............192
fabric ........................................194
instrument panel ....................194
plastic parts ............................194
safety belts ..............................194
tail lamps .................................194
washing ....................................191
waxing .....................................192
wheels ......................................194
windows ..................................196
woodtone trim ........................196
Climate control system
automatic temperature
control .........26,27,28,29,30,31,32
Clutch
fluid ..........................................165
Compass, electronic ...............45,46
calibration .................................48
set zone adjustment .................47
Console, description ...................54
Control trac 4WD system .........116
Controls ..................................53,54
Cupholder (s) .............................55
Defrost
rear window ..............................34
Driving under special
conditions .........................120,122
high water ........................120,123
slippery roads ....120,121,123,124
Emission control system ..........185
Engine ........................................202
service points ............158,159,160
Engine block heater .................102
Engine coolant
checking and adding .......166,167
disposal ....................................168
refill capacities ........................168
Engine oil ...........................160,163
changing oil and oil filter .......163
checking and adding .......160,162
Exhaust fumes ..........................103
Index
206

Floor mats ...................................55
Foglamps .....................................21
Four-Wheel Drive vehicles
control trac ........................34,116
special driving
instructions ......................118,119
Fuel
calculating fuel economy .......184
improving fuel economy ........134
octane rating ...........................183
quality ......................................184
safety information relating to
automotive fuels .....................182
Fuel gauge ...................................15
Fuel pump shut-off switch .......135
Fuse panels
instrument panel ....................138
power distribution box ...........141
Fuses ...................................136,137
Gauges, Mechanical ....................12
engine coolant temperature
gauge .........................................13
Hazard flashers .........................135
Head restraints ...........................74
Headlamps ...................................21
daytime running lights .............21
flashing ......................................22
high beam .................................22
Heating ........................................23
High beams
indicator light .............................9
Hood
release lever ............................157
Ignition
positions of the ignition ...........35
Instrument panel
lighting up panel and interior .22
Jump-starting
your vehicle .....................149,151
attaching cables ......................149
disconnecting cables ..............151Keyless entry system
autolock .....................................63
keypad .......................................64
locking and unlocking doors ....66
programming entry code ....65,66
Keys
key in ignition chime ...............11
Liftgate ........................................55
Lights, warning and indicator
air bag ..........................................8
anti-lock brakes (ABS) ..............8
anti-theft .....................................9
brake ............................................8
charging system ..........................9
check engine ............................6,7
cruise indicator .........................11
door ajar ....................................10
fuel reset .....................................7
overdrive off ..............................11
safety belt ...................................8
turn signal indicator ...................9
Load limits
trailer towing ..........................126
Lubricant specifications ...........200
Luggage rack .............................133
Manual transmission
driving .......................113,114,115
Message center ...........................16
economy button ........................18
english/metric button ..........16,17
reset button ..............................18
system check button ...........19,20
Mirrors
cleaning ...................................196
heated ........................................53
side view mirrors (power) .......52
Moon roof ....................................45
Motorcraft parts ........................197
Odometer .....................................13
Off road driving,
4-wheel drive ......................119,122
Index
207

Overhead console
compass/temperature display ..44
storage compartment ...............44
Panic alarm feature, remote
entry system ................................60
Parking brake ............................105
Power door locks ........................51
Power steering
fluid, checking and adding ....169
Rear window
washer .......................................42
Recreational towing, all wheels
on the ground ...........................133
Refill capacities for fluids ........198
Relays ........................................136
Remote entry system .................58
illuminated entry ......................63
locking/unlocking doors ...........59
replacement/additional
transmitters ..........................62,63
replacing the batteries .............62
Reporting safety defects ..........205
Safety restraints
automatic locking mode
(retractor) ............................78,79
extension assembly ..................80
for children ...............................86
lap and shoulder belts ........77,78
maintenance ..............................81
proper use .................................76
warning light and chime .........11,
80,81
Safety seats for children
attaching with tether straps ....91
automatic locking mode
(retractor) .................................88
tether anchorage hardware .....91
Seats ............................................72
adjusting the seat, power ........72
folding rear seats ......................75
lumbar support .........................74
rear seat access ........................74Servicing your vehicle ..............156
precautions when servicing ...156
Snowplowing .................................3
Special notice
utility-type vehicles ....................3
Speed control ..............................36
canceling a set speed ...............39
indicator light ...........................40
resuming a set speed ...............40
tap up/tap down .......................38
turning off .................................36
Speedometer ...............................12
Starting your vehicle ...........99,102
Storage compartments
overhead storage
compartment .............................44
Tachometer
mechanical cluster ...................14
Tilt steering wheel ......................41
Tires ....................................177,178
checking the pressure ............178
replacing ..................................180
rotating ....................................179
snow tires and chains ............181
treadwear ................................177
Traction-lok rear axle ........124,175
Trailer towing ............................126
tips ...........................................132
Transaxle
fluid, checking and adding
(manual) .................................173
Transfer case
fluid checking .........................174
Transmission .............................170
automatic operation .......107,108,
109,110,111,112
fluid, checking and adding
(automatic) .............................170
Trip odometer .............................14
Turn signal
lever ...........................................35
Vehicle dimensions ...................202
Index
208
