1998 FORD ESCORT Owners Manual

high pressure fluid could
penetrate the sealed parts and
cause damage.
²Do not spray with cold water to
avoid cracking the engine block
or other engine components.
²Cover the highlighted areas to
prevent water damage when
cleaning the engine.
²Never wash or rinse the engine
while it is running; water in the
running engine may cause
internal damage.
Cleaning plastic exterior parts
Use vinyl cleaner for routine
cleaning. Clean with a tar remover
if necessary. Do not clean plastic
parts with thinners, solvents or
petroleum-based cleaners.
Maintenance and care
177

Cleaning the exterior lamps
Wash with the same detergent as
the exterior of your vehicle. Use
glass cleaner or tar remover if
necessary.
To avoid scratching the lamps, do
not use a dry paper towel,
chemical solvents or abrasive
cleaners.
Cleaning the wiper blades
If the wiper blades do not wipe
properly, clean the windshield and
wiper blades with undiluted
windshield wiper solution or a mild
detergent. Rinse thoroughly with
clean water. To avoid damaging the
blades, do not use fuel, kerosene,
paint thinner or other solvents.
Cleaning the instrument panel
Clean with a damp cloth, then dry
with a dry cloth.
Avoid cleaner or polish that
increases the gloss of the upper
portion of the instrument panel.
The dull finish in this area helps
protect the driver from undesirable
windshield reflection.
Cleaning the interior fabric
Remove dust and loose dirt with a
whisk broom or a vacuum cleaner.
Remove fresh spots immediately.
Follow the directions that come
with the cleaner.
Maintenance and care
178

Cleaning and maintaining the
safety belts
Clean the safety belts with a mild
soap solution recommended for
cleaning upholstery or carpets. Do
not bleach or dye the belts,
because these actions may weaken
the belt webbing.
Check the safety belt system
periodically to make sure there are
no nicks, wear or cuts. If your
vehicle has been involved in an
accident, refer to theSafety belt
maintenancesection in the
Seating and safety restraints
chapter.
Cleaning the built-in child seat
(if equipped)
Clean with mild soap and water.
Do not use household cleaning
products because they may
weaken the safety belt webbing or
damage the vinyl parts of the seat.
The child seat liner is removable
and may be machine-washed and
air dried.
Maintenance and care
179

MOTORCRAFT PART NUMBERS
Component 2.0L SOHC engine 2.0L DOHC Zetec
engine
Air filter FA-1643 FA-1643
Fuel filter FG-862 FG-862
Battery BX-58C BXT-58
Oil filter FL-400-A FL-2005
PCV Valve EV-229 EV-224
Spark plugs* AGSF-34EE** AZFS-22FE***
* Refer to Vehicle Emissions Control Information (VECI) decal for
spark plug gap information.
**Replacement double platinum spark plug9EE9will replace9E9and
9EG9and9P9will replace9P9and9PG9suffixed plugs. Refer to the
Engine Data chart for spark plug gap specifications.
*** If a spark plug is removed for inspection, it must be reinstalled in
the same cylinder. Cylinders No. 1 and 2 have a ªFEº suffix. Cylinders
No. 3 and 4 have a F suffix. If a spark plug needs to be replaced, use
only spark plugs with the same service part number suffix letter ªFEº
as shown on the engine decal.
REFILL CAPACITIES
FluidFord Part
NameApplication Capacity
Brake fluid Ford High
Performance
DOT 3 Brake
FluidAll Fill to line in
reservoir
Engine coolant Ford Premium
Cooling System
FluidAutomatic
transaxles6.0L
(6.3 quarts)
Manual
transaxles5.0L
(5.3 quarts)
Capacities and specifications
180

FluidFord Part
NameApplication Capacity
Engine oil
(includes filter
change)Motorcraft 5W30
Super Premium
Motor OilZX2 4.25L
(4.5 quarts)
Sedan/wagon 3.8L
(4.0 quarts)
Fuel tank
capacityN/A All 48.5L
(12.8 gallons)
Power steering
fluidMotorcraft
MERCONtAT FAll Fill to line in
reservoir
Transmission
fluid
Motorcraft
MERCONtAT FAutomatic
transaxles3.9L
(4.1 quarts)
Manual
transaxles3.35L
(3.55 quarts)
Windshield
washer fluidUltra-Clear
Windshield
Washer
ConcentrateAll 2.2L
(2.32 quarts)
LUBRICANT SPECIFICATIONS
FluidFord Part
Name or
EquivalentFord Part
NumberFord
Specification
Brake master
cylinderHigh
Performance
DOT 3 Motor
Vehicle Brake
FluidC6AZ-19542-AB ESA-M6C25-A
Door latch, hood
latch, auxiliary
hood latch,
trunk latchMulti-Purpose
GreaseDOAZ-19584-AA ESR-M1C159-A
and
ESA-M1C93-A
Capacities and specifications
181

FluidFord Part
Name or
EquivalentFord Part
NumberFord
Specification
Lock cylinder Penetrating
lubricantE8AZ-19A501-B N/A
Automatic
transmissionMotorcraft
MERCONtAT FXT-2-QDX MERCONt
Manual
transmissionMotorcraft
MERCONtAT FXT-2-QDX MERCONt
Engine oil Motorcraft 5W30
Super Premium
Motor OilXO-5W30-QSP WSS-M2C153-G
and API
Certification
Mark
Constant
velocity jointsCV Joint Grease
(High Temp.)E43Z-19590-A ESP-M1C207-A
Engine coolant Ford Premium
Cooling System
FluidE2FZ-19549-AA ESE-M97B44-A
Power steering
reservoirMotorcraft
MERCONtAT FXT-2-QDX MERCONt
ENGINE DATA
Engine 2.0L-2V engine 2.0L-4V Zetec engine
Cubic inches 121 121
Horsepower 110 @ 5000 rpm 130 @ 5750 rpm
Torque 125 lb. ft. @
3750 rpm127 lb-ft. @ 4250 rpm
Required fuel grade 87 octane 87 octane
Firing order 1-3-4-2 1-3-4-2
Spark plug gap 1.3-1.4 mm
(0.052-.056 inch)1.22-1.32 mm
(0.048-.052 inch)
Ignition system DIS DIS
Capacities and specifications
182

Engine 2.0L-2V engine 2.0L-4V Zetec engine
Compression ratio 9.2:1 9.6:1
VEHICLE DIMENSIONS
Vehicle
dimensionsCoupe mm (in) Sedan mm (in) Wagon mm
(in)
(1) Overall
length4 451.0 (175.2) 4 432.3 (174.5) 4 392.0 (172.9)
(2) Overall
width1 712.0 (67.4) 1 681.0 (66.2) 1 701.0 (67.0)
(3) Overall
height1 328.4 (52.3) 1 351.0 (53.2) 1 369.1 (53.9)
(4) Wheelbase 2 499.0 (98.4) 2 499.0 (98.4) 2 499.0 (98.4)
(5) Track -
Front1 435.1 (56.5) 1 435.1 (56.5) 1 435.1 (56.5)
(5) Track - Rear 1 435.1 (56.5) 1 435.1 (56.5) 1 435.1 (56.5)
²Coupe and Sedan models
2
55
Capacities and specifications
183

²Coupe model
²Sedan model
4
3
1
1
4
Capacities and specifications
184
