TRANSFER CASE - NV273
DESCRIPTION........................542
OPERATION..........................543
DIAGNOSIS AND TESTING - TRANSFER
CASE - NV273.......................543
REMOVAL............................544
DISASSEMBLY........................544
CLEANING...........................554
INSPECTION.........................554
ASSEMBLY...........................556
INSTALLATION........................568
SPECIFICATIONS
TRANSFER CASE - NV273.............568
SPECIAL TOOLS
TRANSFER CASE NV271/NV273.........569
EXTENSION HOUSING SEAL AND DUST BOOT
REMOVAL............................571
INSTALLATION........................571FLUID
STANDARD PROCEDURE - FLUID DRAIN AND
REFILL............................571
FRONT OUTPUT SHAFT SEAL
REMOVAL............................572
INSTALLATION........................572
MODE SENSOR
DESCRIPTION........................573
OPERATION..........................573
SELECTOR SWITCH
DESCRIPTION........................574
OPERATION..........................574
SHIFT MOTOR
DESCRIPTION........................575
OPERATION..........................575
REMOVAL............................575
INSTALLATION........................575
TRANSFER CASE - NV273
DESCRIPTION
The NV273 is an electronically controlled part-time
transfer case with a low range gear reduction system.
The NV273 has three operating ranges plus a NEU-
TRAL position. The low range system provides a gear
reduction ratio for increased low speed torque capa-
bility.
The geartrain is mounted in two aluminum case
halves attached with bolts. The mainshaft front and
rear bearings are mounted in aluminum case halves.
OPERATING RANGES
Transfer case operating ranges are:
²2WD (2-wheel drive)
²4HI (4-wheel drive)
²4LO (4-wheel drive low range)
²NEUTRAL
The 2WD range is for use on any road surface at
any time.The 4HI and 4LO ranges are for off road use only.
They are not for use on hard surface roads. The only
exception being when the road surface is wet or slip-
pery or covered by ice and snow.
The low range reduction gear system is operative
in 4LO range only. This range is for extra pulling
power in off road situations. Low range reduction
ratio is 2.72:1.
SHIFT MECHANISM
Operating ranges are selected with a dash
mounted shift selector switch. The shift selector
switch provides a input to the Transfer Case Control
Module (TCCM) to indicate the driver's desire to
change operating ranges. The TCCM uses this input,
along with input from the transfer case mounted
mode sensor and information from the vehicle's bus,
to determine if a shift is permitted. If the TCCM
decides the shift is permitted, the TCCM controls the
shift motor, mounted to the exterior of the transfer
case, to perform the shift.
21 - 542 TRANSFER CASE - NV273DR

COMPANION FLANGE AND EXTENSION HOUSING
(1) Install two bolts 180É apart into the front out-
put shaft companion flange.
(2) Place holder over the bolts and against the
companion flange (Fig. 3).
(3) Remove and discard the front companion flange
nut.
(4) Remove the companion flange from the front
output shaft. It may be necessary to use Flange
puller 8992 to remove the companion flange.
(5) Use a suitable chisel or pry tool to remove the
rear extension housing dust boot (Fig. 4).
(6) Use a suitable chisel or pry tool to remove the
rear extension housing seal.
(7) Remove rear extension bolts (Fig. 5).
Fig. 3 Remove Companion Flange Nut - Typical
1 - HOLDER 6719
2 - BOLTS
Fig. 4 Remove Extension Housing Dust Boot
1 - EXTENSION HOUSING
2 - DUST BOOT
Fig. 5 Remove Extension Housing Bolts
1 - EXTENSION HOUSING
2 - BOLTS
DRTRANSFER CASE - NV273 21 - 545
TRANSFER CASE - NV273 (Continued)

(3) Apply bead of MopartGasket Maker, or equiv-
alent, to mating surface of rear extension housing.
Keep sealer bead width to maximum of 3/16 inch. Do
not use excessive amount of sealer as excess could be
displaced into output bearing.
(4) Install extension housing (Fig. 85) onto the
rear case half.
(5) Install rear extension bolts (Fig. 86). Tighten
the bolts to 27-34 N´m (20-25 ft.lbs.).(6) Install the extension housing dust boot and
seal assembly with Installer 9037 and Handle C-4171
(Fig. 87).
Fig. 85 Install Extension Housing
1 - REAR CASE HALF
2 - EXTENSION HOUSING
Fig. 86 Install Extension Housing Bolts
1 - EXTENSION HOUSING
2 - BOLTS
Fig. 87 Install Extension Housing Seal
1 - EXTENSION HOUSING
2 - HANDLE C-4171
3 - INSTALLER 9037
DRTRANSFER CASE - NV273 21 - 567
TRANSFER CASE - NV273 (Continued)

EXTENSION HOUSING SEAL
AND DUST BOOT
REMOVAL
(1) Raise and support vehicle.
(2) Remove rear propeller shaft. (Refer to 3 - DIF-
FERENTIAL & DRIVELINE/PROPELLER SHAFT/
PROPELLER SHAFT - REMOVAL)
(3) Use a suitable chisel or pry tool to remove the
rear extension housing dust boot (Fig. 89).
(4) Use a suitable chisel or pry tool to remove the
rear extension housing seal.
INSTALLATION
(1) Clean fluid residue from sealing surface and
inspect for defects.
(2) Install the extension housing dust boot and
seal assembly with Installer 9037 and Handle C-4171
(Fig. 90).
(3) Install propeller shaft. (Refer to 3 - DIFFER-
ENTIAL & DRIVELINE/PROPELLER SHAFT/PRO-
PELLER SHAFT - INSTALLATION)
(4) Verify proper transfer case fluid level.
(5) Lower vehicle.
FLUID
STANDARD PROCEDURE - FLUID DRAIN AND
REFILL
The fill and drain plugs are both in the rear case
(Fig. 91).
(1) Raise vehicle.(2) Position drain pan under transfer case.
(3) Remove drain and fill plugs and drain lubri-
cant completely.
(4) Install drain plug. Tighten plug to 41-54 N´m
(30-40 ft. lbs.).
(5) Remove drain pan.
Fig. 89 Remove Extension Housing Dust Boot
1 - EXTENSION HOUSING
2 - DUST BOOT
Fig. 90 Install Extension Housing Seal
1 - EXTENSION HOUSING
2 - HANDLE C-4171
3 - INSTALLER 9037
Fig. 91 Drain and Fill Locations
1 - FILL HOLE
2 - DRAIN HOLE
DRTRANSFER CASE - NV273 21 - 571

INTERIOR
TABLE OF CONTENTS
page page
INTERIOR
CAUTION.............................62
4WD FLOOR SHIFT BOOT
REMOVAL.............................62
INSTALLATION.........................62
A-PILLAR TRIM/GRAB HANDLE
REMOVAL.............................63
INSTALLATION.........................63
B-PILLAR LOWER TRIM
REMOVAL.............................63
INSTALLATION.........................64
B-PILLAR UPPER TRIM
REMOVAL.............................64
INSTALLATION.........................64
CARPETS AND FLOOR MATS
REMOVAL.............................65
INSTALLATION.........................65
COAT HOOK
REMOVAL.............................66
INSTALLATION.........................66
COWL TRIM
REMOVAL.............................66
INSTALLATION.........................66
C-PILLAR LOWER TRIM
REMOVAL.............................66
INSTALLATION.........................67
C-PILLAR UPPER TRIM
REMOVAL.............................67
INSTALLATION.........................67
FLOOR CONSOLE
REMOVAL.............................67
INSTALLATION.........................67
HEADLINER
REMOVAL.............................68INSTALLATION.........................68
B-PILLAR GRAB HANDLE
REMOVAL.............................68
INSTALLATION.........................68
REAR CAB BACK PANEL TRIM
REMOVAL.............................68
INSTALLATION.........................69
REAR VIEW MIRROR
REMOVAL.............................69
INSTALLATION
INSTALLATION.......................70
INSTALLATION - REAR VIEW MIRROR
SUPPORT BRACKET...................70
SUN VISOR
REMOVAL.............................70
INSTALLATION.........................70
SUN VISOR SUPPORT
REMOVAL.............................70
INSTALLATION.........................71
BODY VENT
REMOVAL.............................71
INSTALLATION.........................71
REAR DOOR SILL TRIM COVER
REMOVAL.............................71
INSTALLATION.........................71
LOAD FLOOR
REMOVAL.............................71
INSTALLATION.........................72
LOAD FLOOR SUPPORT CYLINDER
REMOVAL.............................72
INSTALLATION.........................72
INTERIOR
CAUTION
CAUTION:: Do not attempt to remove interior trim
panels/moldings without first removing the neces-
sary adjacent panels. To avoid damaging the pan-
els, ensure that all the screws and clips are
removed before attempting to remove an interior
trim panel/molding. Trim panels are somewhat flex-
ible but can be damaged if handled improperly.
4WD FLOOR SHIFT BOOT
REMOVAL
(1) Using a small pry bar or equivalent, remove
the insert, the nut and remove the shifter knob. (Fig.
2)
(2) Using a trim stick C-4755 or equivalent, pry up
the boot from the console. (Fig. 1)
INSTALLATION
(1) Position the shift boot over the shifter lever
fully seat onto the console.
23 - 62 INTERIORDR

(2) Install the shifter knob and nut and tighten to
27 N´m (20 ft. lbs.).
(3) Position the insert and seat into the knob fully.
A-PILLAR TRIM/GRAB HANDLE
REMOVAL
(1) Open the trim plugs and remove the bolts. (Fig.
3)
(2) Remove the a-pillar trim/grab handle from the
a-pillar.
INSTALLATION
(1) Position the bottom a-pillar locating tabs and
install the a-pillar trim.
(2) Install the bolts and tighten to 6 N´m (55 in.
lbs.).
(3) Close the trim plugs.
B-PILLAR LOWER TRIM
REMOVAL
(1) Remove the upper b-pillar trim. (Refer to 23 -
BODY/INTERIOR/B-PILLAR UPPER TRIM -
REMOVAL)
(2) Remove the cowl trim. (Refer to 23 - BODY/IN-
TERIOR/COWL TRIM - REMOVAL)
STANDARD CAB
(1) Remove the shoulder belt anchor bolt.
(2) Using a trim stick C-4755 or equivalent,
remove the lower b-pillar trim. (Fig. 4)
QUAD CAB
(1) Remove the rear door sill trim. (Refer to 23 -
BODY/INTERIOR/REAR DOOR SILL TRIM COVER
- REMOVAL)
(2) Using a trim stick C-4755 or equivalent,
remove the lower b-pillar trim.
Fig. 1 SHIFTER BOOT
1 - CONSOLE
2 - SHIFTER KNOB
3 - SHIFTER BOOT
Fig. 2 SHIFTER KNOB
1 - SHIFTER KNOB
2 - INSERT
3 - NUT
Fig. 3 A-PILLAR TRIM/GRAB HANDLE
1 - A-PILLAR
2 - A-PILLAR TRIM
3 - TRIM PLUG
4 - BOLTS (2)
DRINTERIOR 23 - 63
4WD FLOOR SHIFT BOOT (Continued)

INSTALLATION
(1) Route the shoulder belt through the slot in the
trim.
(2) Position the trim and seat the attachment clips
fully.
(3) Install the seat belt anchor bolt and tighten to
40 N´m (30 ft. lbs.).
(4) Install the upper c-pillar trim. (Refer to 23 -
BODY/INTERIOR/C-PILLAR UPPER TRIM -
INSTALLATION)
C-PILLAR UPPER TRIM
REMOVAL
(1) Remove the seat belt turning loop. (Refer to 8 -
ELECTRICAL/RESTRAINTS/SEAT BELT TURNING
LOOP ADJUSTER - REMOVAL)
(2) Using a trim stick C-4755 or equivalent,
remove the upper c-pillar trim. (Fig. 11)
INSTALLATION
(1) Position the upper c-pillar trim and seat the
attachment clips fully.
(2) Install the seat belt turning loop. (Refer to 8 -
ELECTRICAL/RESTRAINTS/SEAT BELT TURNING
LOOP ADJUSTER - INSTALLATION)
FLOOR CONSOLE
REMOVAL
(1) Remove the 4WD shifter boot. (Refer to 23 -
BODY/INTERIOR/4WD FLOOR SHIFT BOOT -
REMOVAL)
(2) Using a trim stick C-4755 or equivalent, pry up
the transmission shifter boot from the console.
(3) Remove the transmission shifter extension.
(4) Remove the console inserts. (Fig. 12)
(5) Remove and discard the three bolts. (Fig. 13)
(6) Lift up on the back and remove the console.
INSTALLATION
(1) Position the front of the console up under the
instrument panel.
(2) Lower the back of the console and install three
new screws.
(3) Install the inserts.
(4) Install the transmission shifter extension.
(5) Position the transmission shifter boot in place
and seat the attachment clips fully.
(6) Install the 4WD shifter boot. (Refer to 23 -
BODY/INTERIOR/4WD FLOOR SHIFT BOOT -
INSTALLATION)
Fig. 12 FLOOR CONSOLE INSERTS
1 - BIN MAT INSERT
2 - STORAGE BIN/SHIFT BOOT
3 - CUP HOLDER MAT INSERT
4 - FLOOR CONSOLE
Fig. 13 FLOOR CONSOLE
1 - INSTRUMENT PANEL
2 - FLOOR CONSOLE
3 - BOLTS (3)
4 - SHIFTER LEVER
DRINTERIOR 23 - 67
C-PILLAR LOWER TRIM (Continued)

BLOCK - DIAGNOSIS AND TESTING,
BLOWER MOTOR RESISTOR............24-19
BLOCK - INSPECTION, ENGINE . 9-128,9-205,9-39
BLOCK - INSTALLATION, BLOWER
MOTOR RESISTOR...................24-19
BLOCK - INSTALLATION, BRAKE
JUNCTION...........................5-24
BLOCK - OPERATION, BLOWER MOTOR
RESISTOR..........................24-18
BLOCK - REMOVAL, BLOWER MOTOR
RESISTOR..........................24-19
BLOCK - REMOVAL, BRAKE JUNCTION....5-24
BLOCK HEATER - 5.9L DIESEL -
DESCRIPTION, ENGINE.................7-37
BLOCK HEATER - 5.9L DIESEL -
INSTALLATION, ENGINE................7-38
BLOCK HEATER - 5.9L DIESEL -
OPERATION, ENGINE...................7-38
BLOCK HEATER - 5.9L DIESEL -
REMOVAL, ENGINE....................7-38
BLOCK HEATER - DESCRIPTION, ENGINE . . . 7-36
BLOCK HEATER - DIAGNOSIS AND
TESTING, ENGINE.....................7-36
BLOCK HEATER - INSTALLATION,
ENGINE.............................7-37
BLOCK HEATER - OPERATION, ENGINE....7-36
BLOCK HEATER - REMOVAL, ENGINE......7-37
BLOCK REFACING - STANDARD
PROCEDURE, CYLINDER...............9-264
BLOWER MOTOR - DESCRIPTION.......24-28
BLOWER MOTOR - DIAGNOSIS AND
TESTING.............................24-28
BLOWER MOTOR - INSTALLATION.......24-31
BLOWER MOTOR - OPERATION.........24-28
BLOWER MOTOR - REMOVAL...........24-31
BLOWER MOTOR RESISTOR BLOCK -
DESCRIPTION.......................24-18
BLOWER MOTOR RESISTOR BLOCK -
DIAGNOSIS AND TESTING.............24-19
BLOWER MOTOR RESISTOR BLOCK -
INSTALLATION.......................24-19
BLOWER MOTOR RESISTOR BLOCK -
OPERATION.........................24-18
BLOWER MOTOR RESISTOR BLOCK -
REMOVAL..........................24-19
BLOWER MOTOR SWITCH -
DESCRIPTION.......................24-20
BLOWER MOTOR SWITCH - DIAGNOSIS
AND TESTING.......................24-20
BLOWER MOTOR SWITCH - OPERATION . . 24-20
BODY - ADJUSTMENTS, VALVE........21-310
BODY - ASSEMBLY, VALVE......21-299,21-414
BODY & CABLE - DESCRIPTION,
ANTENNA...........................8A-4
BODY & CABLE - INSTALLATION,
ANTENNA...........................8A-6
BODY & CABLE - OPERATION, ANTENNA . . . 8A-4
BODY & CABLE - REMOVAL, ANTENNA....8A-6
BODY - CLEANING, VALVE......21-298,21-412
BODY - DESCRIPTION, THROTTLE.......14-36
BODY - DESCRIPTION, VALVE....21-267,21-408
BODY - DISASSEMBLY, VALVE . . . 21-287,21-410
BODY - INSPECTION, VALVE.....21-298,21-413
BODY - INSTALLATION, THROTTLE.......14-37
BODY - INSTALLATION, VALVE . . . 21-309,21-414
BODY - OPERATION, THROTTLE.........14-36
BODY - OPERATION, VALVE.....21-272,21-408
BODY - REMOVAL, THROTTLE..........14-36
BODY - REMOVAL, VALVE.......21-286,21-410
BODY AND CABLE - DIAGNOSIS AND
TESTING, ANTENNA
...................8A-4
BODY CODE PLATE - DESCRIPTION
.....Intro.-3
BODY ISOLATORS - INSTALLATION
......23-37
BODY ISOLATORS - REMOVAL
..........23-36
BODY LUBRICATION - STANDARD
PROCEDURE
.........................23-3
BODY OPENING DIMENSIONS -
SPECIFICATIONS
.....................23-99
BODY PANEL REPAIR - STANDARD
PROCEDURE, PLASTIC
.................23-3
BODY SIDE MOLDINGS - INSTALLATION
. . 23-36
BODY SIDE MOLDINGS - REMOVAL
......23-36
BODY, SPECIAL TOOLS
................23-14
BODY VENT - INSTALLATION
...........23-71
BODY VENT - REMOVAL
...............23-71
BOOST PRESSURE - DIAGNOSIS AND
TESTING, TURBOCHARGER
.............11-11BOOSTER - DESCRIPTION, POWER
BRAKE..............................5-29
BOOSTER - DIAGNOSIS AND TESTING,
HYDRAULIC..........................5-30
BOOSTER - DIAGNOSIS AND TESTING,
MASTER CYLINDER/POWER.............5-25
BOOSTER - INSTALLATION, HYDRO-
BOOST BRAKE........................5-32
BOOSTER - INSTALLATION, POWER
BRAKE..............................5-29
BOOSTER - OPERATION, POWER BRAKE . . . 5-29
BOOSTER - REMOVAL, HYDRO-BOOST
BRAKE..............................5-31
BOOSTER - REMOVAL, POWER BRAKE....5-29
BOOT - INSTALLATION, 4WD FLOOR
SHIFT..............................23-62
BOOT - INSTALLATION, EXTENSION
HOUSING SEAL AND DUST......21-476,21-571
BOOT - REMOVAL, 4WD FLOOR SHIFT....23-62
BOOT - REMOVAL, EXTENSION HOUSING
SEAL AND DUST..............21-476,21-571
BORE - DE-GLAZE - STANDARD
PROCEDURE, CYLINDER...............9-264
BORE HONING - STANDARD
PROCEDURE, CYLINDER...........9-128,9-38
BORE REPAIR - STANDARD
PROCEDURE, CAM...................9-267
BORE REPAIR - STANDARD
PROCEDURE, CYLINDER...............9-265
BOX - INSTALLATION, CARGO..........23-37
BOX - INSTALLATION, GLOVE...........23-52
BOX - INSTALLATION, WITH CARGO . 8L-22,8L-23,
8L-24,8L-7,8L-9
BOX - INSTALLATION, WITHOUT CARGO . . 8L-22,
8L-23,8L-24,8L-8,8L-9
BOX - REMOVAL, CARGO..............23-37
BOX - REMOVAL, GLOVE..............23-52
BOX - REMOVAL, WITH CARGO....8L-22,8L-24,
8L-7,8L-9
BOX - REMOVAL, WITHOUT CARGO.....8L-22,
8L-23,8L-24,8L-7,8L-9
BOX - TIE DOWN - INSTALLATION,
CARGO............................23-38
BOX - TIE DOWN - REMOVAL, CARGO....23-38
BOX LAMP/SWITCH - INSTALLATION,
GLOVE.............................8L-28
BOX LAMP/SWITCH - REMOVAL, GLOVE . . 8L-27
BOX LATCH - INSTALLATION, GLOVE.....23-52
BOX LATCH - REMOVAL, GLOVE.........23-52
B-PILLAR GRAB HANDLE -
INSTALLATION.......................23-68
B-PILLAR GRAB HANDLE - REMOVAL....23-68
B-PILLAR LOWER TRIM - INSTALLATION . . 23-64
B-PILLAR LOWER TRIM - REMOVAL.....23-63
B-PILLAR UPPER TRIM - INSTALLATION . . 23-64
B-PILLAR UPPER TRIM - REMOVAL......23-64
BRACKET - INSTALLATION, REAR VIEW
MIRROR SUPPORT...................23-70
BRACKET - INSTALLATION, STEERING
COLUMN OPENING SUPPORT...........23-60
BRACKET - REMOVAL, STEERING
COLUMN OPENING SUPPORT...........23-60
BRACKETS - INSTALLATION, SEAT BACK
REAR - FOOTMANS LOOP..............23-85
BRACKETS - REMOVAL, SEAT BACK
REAR - FOOTMANS LOOP..............23-85
BRAKE - CLEANING, REAR DRUM IN
HAT ................................5-39
BRAKE - DESCRIPTION, CONTROLLER
ANTILOCK...........................8E-3
BRAKE - DESCRIPTION, PARKING........5-36
BRAKE - INSPECTION, REAR DRUM IN
HAT ................................5-39
BRAKE - INSTALLATION, CONTROLLER
ANTILOCK...........................8E-3
BRAKE - OPERATION, CONTROLLER
ANTILOCK...........................8E-3
BRAKE - OPERATION, PARKING..........5-36
BRAKE - REMOVAL, CONTROLLER
ANTILOCK
...........................8E-3
BRAKE BLEEDING - STANDARD
PROCEDURE, ABS
.....................5-46
BRAKE BOOSTER - DESCRIPTION,
POWER
.............................5-29
BRAKE BOOSTER - INSTALLATION,
HYDRO-BOOST
.......................5-32
BRAKE BOOSTER - INSTALLATION,
POWER
.............................5-29BRAKE BOOSTER - OPERATION, POWER . . . 5-29
BRAKE BOOSTER - REMOVAL,
HYDRO-BOOST.......................5-31
BRAKE BOOSTER - REMOVAL, POWER....5-29
BRAKE CABLE - INSTALLATION, FRONT
PARKING............................5-38
BRAKE CABLE - INSTALLATION, REAR
PARK...............................5-38
BRAKE CABLE - REMOVAL, FRONT
PARKING............................5-36
BRAKE CABLE - REMOVAL, REAR PARK . . . 5-37
BRAKE CALIPER ADAPTER MOUNT -
INSTALLATION, DISC...................5-22
BRAKE CALIPERS - DESCRIPTION, DISC . . . 5-16
BRAKE CALIPERS - OPERATION, DISC.....5-16
BRAKE FLUID CONTAMINATION -
DIAGNOSIS AND TESTING..............5-23
BRAKE FLUID LEVEL - STANDARD
PROCEDURE.........................5-23
BRAKE FLUID, SPECIFICATIONS..........5-23
BRAKE HOSE - INSTALLATION, FRONT.....5-13
BRAKE HOSE - INSTALLATION, REAR......5-12
BRAKE HOSE - REMOVAL, REAR.........5-11
BRAKE INDICATOR - DESCRIPTION,
BRAKE/PARK........................8J-19
BRAKE INDICATOR - DIAGNOSIS AND
TESTING...........................8J-20
BRAKE INDICATOR - OPERATION,
BRAKE/PARK........................8J-19
BRAKE JUNCTION BLOCK -
INSTALLATION.........................5-24
BRAKE JUNCTION BLOCK - REMOVAL.....5-24
BRAKE LAMP SWITCH - DESCRIPTION....8L-9
BRAKE LAMP SWITCH - DIAGNOSIS
AND TESTING.......................8L-10
BRAKE LAMP SWITCH - INSTALLATION . . . 8L-11
BRAKE LAMP SWITCH - OPERATION......8L-9
BRAKE LAMP SWITCH - REMOVAL......8L-10
BRAKE PROPORTIONING -
DESCRIPTION, ELECTRONIC VARIABLE....5-49
BRAKE PROPORTIONING - OPERATION,
ELECTRONIC VARIABLE................5-49
BRAKE ROTOR, DIAGNOSIS AND
TESTING - DISC......................5-32
BRAKE SHOES - ADJUSTMENT, PARKING . . 5-41
BRAKE, SPECIFICATIONS - BASE.........5-10
BRAKE SYSTEM - DIAGNOSIS AND
TESTING, BASE........................5-2
BRAKE TRANSMISSION SHIFT
INTERLOCK - ADJUSTMENTS....21-196,21-365
BRAKE TRANSMISSION SHIFT
INTERLOCK - DIAGNOSIS AND
TESTING....................21-196,21-364
BRAKE TRANSMISSION SHIFT
INTERLOCK SYSTEM - DESCRIPTION . . . 21-196,
21-364
BRAKE TRANSMISSION SHIFT
INTERLOCK SYSTEM - OPERATION.....21-196,
21-364
BRAKE/PARK BRAKE INDICATOR -
DESCRIPTION.......................8J-19
BRAKE/PARK BRAKE INDICATOR -
OPERATION.........................8J-19
BRAKES - ABS - DESCRIPTION...........5-45
BRAKES - ABS - OPERATION............5-45
BRAKES, SPECIAL TOOLS - BASE.........5-5
BREAK-IN - STANDARD PROCEDURE,
A/C COMPRESSOR CLUTCH............24-10
BREATHER - INSTALLATION,
CRANKCASE
........................9-243
BREATHER - REMOVAL, CRANKCASE
.....9-242
BUCKLE - INSTALLATION, FRONT
OUTBOARD SEAT BELT
................8O-38
BUCKLE - REMOVAL, FRONT OUTBOARD
SEAT BELT
.........................8O-37
BUILT-IN INDICATOR TEST - STANDARD
PROCEDURE
........................8F-10
BUMPER - INSTALLATION, FRONT
........13-2
BUMPER - INSTALLATION, JOUNCE
.......2-43
BUMPER - INSTALLATION, REAR
.........13-4
BUMPER - REMOVAL, FRONT
............13-2
BUMPER - REMOVAL, JOUNCE
...........2-43
BUMPER - REMOVAL, REAR
.............13-3
BUMPERS (3500) - INSTALLATION,
AUXILIARY SPRING
....................2-43
BUMPERS (3500) - REMOVAL,
AUXILIARY SPRING
....................2-43
4 INDEXDR
Description Group-Page Description Group-Page Description Group-Page
