(11) Remove the tape or plugs from the discharge
line fitting and condenser inlet port.
(12) Lubricate a new rubber O-ring seal with clean
refrigerant oil and install it on the discharge line fit-
ting. Use only the specified O-ring as it is made of a
special material for the R-134a system. Use only
refrigerant oil of the type recommended for the A/C
compressor in the vehicle.
(13) Connect the discharge line to the condenser
inlet port.
(14) Install and tighten the nut that secures the
discharge line fitting to the condenser. Tighten the
nut to 20 N´m (180 in. lbs.).
(15) Connect the wire harness connector to the A/C
pressure transducer.
(16) Reconnect the battery negative cable.
(17) Evacuate the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE - REFRIGERANT SYS-
TEM EVACUATE).
(18) Charge the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE - REFRIGERANT SYS-
TEM CHARGE).
INSTALLATION - 3.7L/4.7L AND 5.7L HEMI
ENGINE
(1) If removed, install the A/C pressure transducer
onto the discharge line using a new O-ring seal.
Tighten the transducer securely.
(2) Position the discharge line into the engine com-
partment.
(3) Remove the tape or plugs from the discharge
line fitting and the compressor outlet port.
(4) Lubricate a new rubber O-ring seal with clean
refrigerant oil and install it on the discharge line fit-
ting. Use only the specified O-ring as it is made of a
special material for the R-134a system. Use only
refrigerant oil of the type recommended for the A/C
compressor in the vehicle.
(5) Connect the discharge line to the compressor.
(6) Install and tighten the nut that secures the
discharge line to the compressor. Tighten the nut to
28 N´m (20 ft. lbs.).
(7) Remove the tape or plugs from the discharge
line fitting and condenser inlet port.
(8) Lubricate a new rubber O-ring seal with clean
refrigerant oil and install it on the discharge line fit-
ting. Use only the specified O-ring as it is made of a
special material for the R-134a system. Use only
refrigerant oil of the type recommended for the A/C
compressor in the vehicle.(9) Connect the discharge line to the condenser
inlet port.
(10) Install and tighten the nut that secures the
discharge line fitting to the condenser. Tighten the
nut to 20 N´m (180 in. lbs.).
(11) Connect the wire harness connector to the A/C
pressure transducer.
(12) Reconnect the battery negative cable.
(13) Evacuate the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE - REFRIGERANT SYS-
TEM EVACUATE).
(14) Charge the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE - REFRIGERANT SYS-
TEM CHARGE).
A/C EVAPORATOR
DESCRIPTION
The A/C evaporator is located in the HVAC hous-
ing, behind the instrument panel. The evaporator is
positioned in the HVAC housing so that all air that
enters the housing must pass over the fins of the
evaporator coils before it is distributed through the
system ducts and outlets. However, air passing over
the evaporator fins will only be conditioned when the
compressor is engaged and circulating refrigerant
through the evaporator tubes.
OPERATION
Refrigerant enters the A/C evaporator from the
fixed orifice tube as a low-temperature, low-pressure
mixture of liquid and gas. As air flows over the fins
of the A/C evaporator, the humidity in the air con-
denses on the fins, and the heat from the air is
absorbed by the refrigerant. Heat absorption causes
the refrigerant to boil and vaporize. The refrigerant
becomes a low-pressure gas before it leaves the A/C
evaporator.
The A/C evaporator cannot be repaired and, if
faulty or damaged, it must be replaced.
DRPLUMBING 24 - 59
A/C DISCHARGE LINE (Continued)

(1) Disconnect and isolate the battery negative
cable.
(2) Recover the refrigerant from the refrigerant
system (Refer to 24 - HEATING & AIR CONDITION-
ING/PLUMBING - STANDARD PROCEDURE -
REFRIGERANT RECOVERY).
(3) Disconnect the wire harness connector from the
A/C pressure transducer.
(4) Remove the nut that secures the discharge line
fitting to the condenser inlet port (Fig. 29).
(5) Disconnect the discharge line from the con-
denser.
(6) Remove the O-ring seal from the discharge line
fitting and discard.
(7) Install plugs in, or tape over the discharge line
fitting and condenser inlet port.
(8) Remove the bolt that secures the suction/dis-
charge line assembly to the A/C compressor.
(9) Disconnect the suction/discharge line assembly
from the A/C compressor.
(10) Remove the O-ring seals from the suction and
discharge line fittings and discard.
(11) Install plugs in, or tape over all of the opened
refrigerant line fittings and the compressor ports.(12) Remove the secondary retaining clip from the
spring-lock coupler that secures the suction line to
the accumulator outlet tube (Fig. 30).
(13) Using the proper A/C line disconnect tool, dis-
connect the suction line from the accumulator outlet
tube (Refer to 24 - HEATING & AIR CONDITION-
ING/PLUMBING/REFRIGERANT LINE COUPLER -
REMOVAL).
(14) Remove the O-ring seal from the accumulator
outlet tube fitting and discard.
(15) Install plugs in, or tape over the opened suc-
tion line and the accumulator outlet tube fitting.
(16) Remove the suction/discharge line assembly
from the engine compartment.
(17) If necessary, remove the A/C pressure trans-
ducer from the discharge line.
REMOVAL - 3.7L/4.7L AND 5.7L HEMI ENGINE
WARNING: REVIEW THE WARNINGS AND CAU-
TIONS IN THE FRONT OF THIS SECTION BEFORE
PERFORMING THE FOLLOWING OPERATION (Refer
to 24 - HEATING & AIR CONDITIONING/PLUMBING -
WARNING) and (Refer to 24 - HEATING & AIR CON-
DITIONING/PLUMBING - CAUTION).
Fig. 29 A/C Suction Line - 5.9L Diesel Engine
1 - CONDENSER
2 - NUT
3 - LIQUID LINE
4 - NUT
5 - PRESSURE TRANSDUCER WIRE CONNECTOR
6 - A/C COMPRESSOR
7 - BOLT
8 - SUCTION/DISCHARGE LINE ASSEMBLY
Fig. 30 Suction Line - A/C Accumulator
1 - RH INNER FENDER
2 - ACCUMULATOR INLET TUBE
3 - A/C LINE SECONDARY RETAINING CLIP
4 - EVAPORATOR OUTLET TUBE
5 - BOLTS (2)
6 - ACCUMULATOR
7 - SUCTION LINE
8 - A/C LOW PRESSURE SERVICE PORT
9 - A/C LINE SECONDARY RETAINING CLIP
DRPLUMBING 24 - 71
SUCTION LINE (Continued)

(1) Disconnect and isolate the battery negative
cable.
(2) Recover the refrigerant from the refrigerant
system (Refer to 24 - HEATING & AIR CONDITION-
ING/PLUMBING - STANDARD PROCEDURE -
REFRIGERANT RECOVERY).
(3) Remove the nut that secures the suction line
fitting to the compressor inlet port (Fig. 31) or (Fig.
32), depending on application.
(4) Disconnect the suction line from the compres-
sor.
(5) Remove the O-ring seal from the suction line
fitting and discard.
(6) Install plugs in, or tape over the suction line
fitting and compressor inlet port.
(7) Remove the secondary retaining clip from the
spring-lock coupler that secures the suction line to
the accumulator outlet tube (Fig. 33).
(8) Using the proper A/C line disconnect tool, dis-
connect the suction line from the accumulator outlet
tube (Refer to 24 - HEATING & AIR CONDITION-
ING/PLUMBING/REFRIGERANT LINE COUPLER -
REMOVAL).
(9) Remove the O-ring seal from the accumulator
outlet tube fitting and discard.(10) Install plugs in, or tape over the opened suc-
tion line and the accumulator outlet tube fitting.
INSTALLATION
INSTALLATION - 5.9L DIESEL ENGINE
(1) If removed, install the A/C pressure transducer
onto the discharge line using a new O-ring seal.
Tighten the transducer securely.
(2) Position the suction/discharge line assembly
into the engine compartment.
(3) Remove the tape or plugs from the suction line
and the accumulator outlet tube fitting.
(4) Lubricate a new rubber O-ring seal with clean
refrigerant oil and install it on the accumulator out-
let tube fitting. Use only the specified O-ring as it is
made of a special material for the R-134a system.
Use only refrigerant oil of the type recommended for
the A/C compressor in the vehicle.
(5) Connect the suction line to the accumulator
outlet tube (Refer to 24 - HEATING & AIR CONDI-
TIONING/PLUMBING/REFRIGERANT LINE COU-
PLER - INSTALLATION).
(6) Install the secondary retaining clip onto the
spring-lock coupler that secures the suction line to
the accumulator outlet tube.Fig. 31 A/C Discharge Line - 3.7L Shown, 4.7L
Typical
1 - NUT
2 - FRONT UPPER CROSSMEMBER
3 - A/C CONDENSER
4 - NUT (2)
5 - SUCTION LINE
6 - A/C COMPRESSOR
7 - A/C PRESSURE TRANSDUCER
8 - WIRE HARNESS CONNECTOR
9 - A/C DISCHARGE LINE
Fig. 32 A/C Suction Line - 5.7L Hemi Engine
1 - DISCHARGE LINE
2 - NUT
3 - CONDENSER
4 - NUT
5 - SUCTION LINE
6 - A/C COMPRESSOR
7 - NUT
8 - A/C PRESSURE TRANSDUCER
24 - 72 PLUMBINGDR
SUCTION LINE (Continued)

(7) Remove the tape or plugs from the suction and
discharge line fittings and the compressor ports.
(8) Lubricate new rubber O-ring seals with clean
refrigerant oil and install them on the suction and
discharge line fittings. Use only the specified O-rings
as they are made of a special material for the R-134a
system. Use only refrigerant oil of the type recom-
mended for the A/C compressor in the vehicle.
(9) Connect the suction/discharge line assembly to
the compressor.
(10) Install and tighten the bolt that secures the
suction/discharge line assembly to the compressor.
Tighten the bolt to 28 N´m (20 ft. lbs.).
(11) Remove the tape or plugs from the discharge
line fitting and condenser inlet port.
(12) Lubricate a new rubber O-ring seal with clean
refrigerant oil and install it on the discharge line fit-
ting. Use only the specified O-ring as it is made of a
special material for the R-134a system. Use only
refrigerant oil of the type recommended for the A/C
compressor in the vehicle.
(13) Connect the discharge line to the condenser
inlet port.(14) Install and tighten the nut that secures the
discharge line fitting to the condenser. Tighten the
nut to 20 N´m (180 in. lbs.).
(15) Connect the wire harness connector to the A/C
pressure transducer.
(16) Reconnect the battery negative cable.
(17) Evacuate the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE - REFRIGERANT SYS-
TEM EVACUATE).
(18) Charge the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE - REFRIGERANT SYS-
TEM CHARGE).
INSTALLATION - 3.7L/4.7L AND 5.7L HEMI
ENGINE
(1) Position the suction line into the engine com-
partment.
(2) Remove the tape or plugs from the suction line
fitting and the compressor inlet port.
(3) Lubricate a new rubber O-ring seal with clean
refrigerant oil and install it on the suction line fit-
ting. Use only the specified O-ring as it is made of a
special material for the R-134a system. Use only
refrigerant oil of the type recommended for the A/C
compressor in the vehicle.
(4) Connect the suction line to the compressor.
(5) Install and tighten the nut that secures the
suction line to the compressor. Tighten the nut to 28
N´m (20 ft. lbs.).
(6) Remove the tape or plugs from the suction line
and the accumulator outlet tube fitting.
(7) Lubricate a new rubber O-ring seal with clean
refrigerant oil and install it on the accumulator out-
let tube fitting. Use only the specified O-ring as it is
made of a special material for the R-134a system.
Use only refrigerant oil of the type recommended for
the A/C compressor in the vehicle.
(8) Connect the suction line to the accumulator
outlet tube (Refer to 24 - HEATING & AIR CONDI-
TIONING/PLUMBING/REFRIGERANT LINE COU-
PLER - INSTALLATION).
(9) Install the secondary retaining clip onto the
spring-lock coupler that secures the suction line to
the accumulator outlet tube.
(10) Reconnect the battery negative cable.
(11) Evacuate the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE - REFRIGERANT SYS-
TEM EVACUATE).
(12) Charge the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE - REFRIGERANT SYS-
TEM CHARGE).
Fig. 33 A/C Accumulator - Typical
1 - RH INNER FENDER
2 - ACCUMULATOR INLET TUBE
3 - A/C LINE SECONDARY RETAINING CLIP
4 - EVAPORATOR OUTLET TUBE
5 - BOLTS (2)
6 - ACCUMULATOR
7 - SUCTION LINE
8 - A/C LOW PRESSURE SERVICE PORT
9 - A/C LINE SECONDARY RETAINING CLIP
DRPLUMBING 24 - 73
SUCTION LINE (Continued)

CCV HOSE
DESCRIPTION - 8.0L V-10
The 8.0L V-10 engine is equipped with a Crankcase
Ventilation (CCV) system. The CCV system performs
the same function as a conventional PCV system, but
does not use a vacuum controlled valve (PCV valve).
A molded vacuum tube connects manifold vacuum
to the top of the right cylinder head (valve) cover.
The vacuum tube connects to a fixed orifice fitting
(Fig. 2) of a calibrated size 2.6 mm (0.10 inches).
OPERATION - 8.0L V-10
A molded vacuum tube connects manifold vacuum
to the top of the right cylinder head (valve) cover.
The vacuum tube connects to a fixed orifice fitting
(Fig. 2) of a calibrated size 2.6 mm (0.10 inches). The
fitting meters the amount of crankcase vapors drawn
out of the engine.The fixed orifice fitting is grey
in color.A similar fitting (but does not contain a
fixed orifice) is used on the left cylinder head (valve)
cover. This fitting is black in color. Do not inter-
change these two fittings.
When the engine is operating, fresh air enters the
engine and mixes with crankcase vapors. Manifold
vacuum draws the vapor/air mixture through the
fixed orifice and into the intake manifold. The vapors
are then consumed during engine combustion.
EVAP/PURGE SOLENOID
DESCRIPTION
The duty cycle EVAP canister purge solenoid is
located in the engine compartment. It is attached to
the side of the Power Distribution Center (PDC).
OPERATION
The Powertrain Control Module (PCM) operates
the solenoid.
During the cold start warm-up period and the hot
start time delay, the PCM does not energize the sole-
noid. When de-energized, no vapors are purged. The
PCM de-energizes the solenoid during open loop oper-
ation.
The engine enters closed loop operation after it
reaches a specified temperature and the time delay
ends. During closed loop operation, the PCM ener-
gizes and de-energizes the solenoid 5 or 10 times per
second, depending upon operating conditions. The
PCM varies the vapor flow rate by changing solenoid
pulse width. Pulse width is the amount of time the
solenoid energizes. The PCM adjusts solenoid pulse
width based on engine operating condition.
REMOVAL
The duty cycle EVAP canister purge solenoid is
located in the engine compartment. It is attached to
the side of the Power Distribution Center (PDC) (Fig.
3).
(1) Disconnect electrical wiring connector at sole-
noid.
(2) Disconnect vacuum harness at solenoid (Fig. 3).
(3) Remove solenoid from mounting bracket.
INSTALLATION
(1) Install solenoid assembly to mounting bracket.
(2) Connect vacuum harness.
(3) Connect electrical connector.
Fig. 2 FIXED ORIFICE FITTING - 8.0L V-10 ENGINE -
TYPICAL
1 - VACUUM TUBE
2 - FIXED ORIFICE FITTING
3 - COIL PACKS
4 - ORIFICE FITTING HOSE CONNECTIONS
25 - 12 EVAPORATIVE EMISSIONSDR

FUEL FILLER CAP
DESCRIPTION
The plastic fuel tank filler tube cap is threaded
onto the end of the fuel fill tube. Certain models are
equipped with a 1/4 turn cap.
OPERATION
The loss of any fuel or vapor out of fuel filler tube
is prevented by the use of a pressure-vacuum fuel fill
cap. Relief valves inside the cap will release fuel tank
pressure at predetermined pressures. Fuel tank vac-
uum will also be released at predetermined values.
This cap must be replaced by a similar unit if
replacement is necessary. This is in order for the sys-
tem to remain effective.
CAUTION: Remove fill cap before servicing any fuel
system component to relieve tank pressure. If
equipped with a Leak Detection Pump (LDP), or
NVLD system, the cap must be tightened securely.
If cap is left loose, a Diagnostic Trouble Code (DTC)
may be set.
REMOVAL
REMOVAL/INSTALLATION
If replacement of the 1/4 turn fuel tank filler tube
cap is necessary, it must be replaced with an identi-
cal cap to be sure of correct system operation.
CAUTION: Remove the fuel tank filler tube cap to
relieve fuel tank pressure. The cap must be
removed prior to disconnecting any fuel system
component or before draining the fuel tank.
LEAK DETECTION PUMP
DESCRIPTION
Vehicles equipped with JTEC engine control mod-
ules use a leak detection pump. Vehicles equipped
with NGC engine control modules use an NVLD
pump. Refer to Natural Vacuum - Leak Detection
(NVLD) for additional information.
The evaporative emission system is designed to
prevent the escape of fuel vapors from the fuel sys-
tem (Fig. 4). Leaks in the system, even small ones,
can allow fuel vapors to escape into the atmosphere.
Government regulations require onboard testing to
make sure that the evaporative (EVAP) system is
functioning properly. The leak detection system tests
for EVAP system leaks and blockage. It also performs
self-diagnostics. During self-diagnostics, the Power-
train Control Module (PCM) first checks the Leak
Detection Pump (LDP) for electrical and mechanical
faults. If the first checks pass, the PCM then uses
the LDP to seal the vent valve and pump air into the
system to pressurize it. If a leak is present, the PCM
will continue pumping the LDP to replace the air
that leaks out. The PCM determines the size of the
leak based on how fast/long it must pump the LDP
as it tries to maintain pressure in the system.
EVAP LEAK DETECTION SYSTEM COMPONENTS
Service Port: Used with special tools like the Miller
Evaporative Emissions Leak Detector (EELD) to test
for leaks in the system.
EVAP Purge Solenoid: The PCM uses the EVAP
purge solenoid to control purging of excess fuel
vapors stored in the EVAP canister. It remains closed
during leak testing to prevent loss of pressure.
EVAP Canister: The EVAP canister stores fuel
vapors from the fuel tank for purging.
EVAP Purge Orifice: Limits purge volume.
EVAP System Air Filter: Provides air to the LDP
for pressurizing the system. It filters out dirt while
allowing a vent to atmosphere for the EVAP system.
Fig. 3 EVAP / DUTY CYCLE PURGE SOLENOID
1 - MOUNTING BRACKET
2 - VACUUM HARNESS
3 - DUTY CYCLE SOLENOID
4 - TEST PORT CAP AND TEST PORT
DREVAPORATIVE EMISSIONS 25 - 13
EVAP/PURGE SOLENOID (Continued)

GEAR/RING GEAR/TONE RING -
INSTALLATION, PINION......3-108,3-137,3-164
GEAR/RING GEAR/TONE RING -
REMOVAL, PINION.........3-106,3-134,3-162
GEARSHIFT CABLE - DIAGNOSIS AND
TESTING....................21-210,21-368
GEARSHIFT CABLE - INSTALLATION....21-211,
21-370
GEARSHIFT CABLE - REMOVAL . . 21-210,21-369
GEARSHIFT CABLE, ADJUSTMENTS.....21-212,
21-370
GEAR/TONE RING - INSTALLATION,
PINION GEAR/RING.........3-108,3-137,3-164
GEAR/TONE RING - REMOVAL, PINION
GEAR/RING...............3-106,3-134,3-162
GEARTRAIN - ASSEMBLY, PLANETARY . . . 21-397
GEARTRAIN - CLEANING, PLANETARY . . . 21-396
GEARTRAIN - DESCRIPTION,
PLANETARY........................21-395
GEARTRAIN - DISASSEMBLY,
PLANETARY........................21-396
GEARTRAIN - INSPECTION, PLANETARY . 21-397
GEARTRAIN - OPERATION, PLANETARY . . 21-396
GEARTRAIN/OUTPUT SHAFT -
ASSEMBLY, PLANETARY..............21-244
GEARTRAIN/OUTPUT SHAFT -
DESCRIPTION, PLANETARY............21-241
GEARTRAIN/OUTPUT SHAFT -
DISASSEMBLY, PLANETARY...........21-242
GEARTRAIN/OUTPUT SHAFT -
INSPECTION, PLANETARY.............21-243
GEARTRAIN/OUTPUT SHAFT -
OPERATION, PLANETARY.............21-241
GENERAL - WARNINGS.............8W-01-7
GENERATOR / CHARGING SYSTEM -
SPECIFICATIONS, TORQUE.............8F-20
GENERATOR - DESCRIPTION...........8F-21
GENERATOR - INSTALLATION...........8F-24
GENERATOR - OPERATION.............8F-21
GENERATOR - REMOVAL...............8F-22
GENERATOR RATINGS, SPECIFICATIONS . . 8F-20
GENII - ASSEMBLY, TRANSFER CASE -
NV241............................21-428
GENII - ASSEMBLY, TRANSFER CASE -
NV244............................21-525
GENII - CLEANING, TRANSFER CASE -
NV241............................21-426
GENII - CLEANING, TRANSFER CASE -
NV244............................21-523
GENII - DESCRIPTION, TRANSFER CASE
- NV241...........................21-415
GENII - DESCRIPTION, TRANSFER CASE
- NV244...........................21-512
GENII - DIAGNOSIS AND TESTING,
TRANSFER CASE - NV241.............21-416
GENII - DISASSEMBLY, TRANSFER CASE
- NV241...........................21-417
GENII - DISASSEMBLY, TRANSFER CASE
- NV244...........................21-514
GENII - INSPECTION, TRANSFER CASE -
NV241............................21-426
GENII - INSPECTION, TRANSFER CASE -
NV244............................21-523
GENII - INSTALLATION, TRANSFER CASE
- NV241...........................21-438
GENII - INSTALLATION, TRANSFER CASE
- NV244...........................21-534
GENII - OPERATION, TRANSFER CASE -
NV241............................21-415
GENII - OPERATION, TRANSFER CASE -
NV244............................21-513
GENII - REMOVAL, TRANSFER CASE -
NV241............................21-417
GENII - REMOVAL, TRANSFER CASE -
NV244............................21-514
GENII - TRANSFER CASE, NV241.......21-438
GENII - TRANSFER CASE, NV244.......21-535
GLASS - DESCRIPTION, HEATED.........8G-1
GLASS - INSTALLATION, BACKLITE VENT . 23-87
GLASS - INSTALLATION, DOOR....23-20,23-30
GLASS - INSTALLATION, SIDE VIEW
MIRROR...........................23-43
GLASS - OPERATION, HEATED
...........8G-1
GLASS - REMOVAL, BACKLITE VENT
.....23-87
GLASS - REMOVAL, DOOR
........23-20,23-30
GLASS - REMOVAL, SIDE VIEW MIRROR
. . 23-42
GLASS RUN CHANNEL - INSTALLATION
. . 23-22,
23-31GLASS RUN CHANNEL - REMOVAL . 23-21,23-30
GLASS RUN WEATHERSTRIP -
INSTALLATION, FRONT DOOR...........23-92
GLASS RUN WEATHERSTRIP -
INSTALLATION, REAR DOOR............23-93
GLASS RUN WEATHERSTRIP -
REMOVAL, FRONT DOOR..............23-92
GLASS RUN WEATHERSTRIP -
REMOVAL, REAR DOOR...............23-93
GLOVE BOX - INSTALLATION...........23-52
GLOVE BOX - REMOVAL...............23-52
GLOVE BOX LAMP/SWITCH -
INSTALLATION.......................8L-28
GLOVE BOX LAMP/SWITCH - REMOVAL . . . 8L-27
GLOVE BOX LATCH - INSTALLATION.....23-52
GLOVE BOX LATCH - REMOVAL.........23-52
GOVERNOR - DESCRIPTION,
ELECTRONIC.......................21-197
GOVERNOR - INSTALLATION,
ELECTRONIC.......................21-200
GOVERNOR - OPERATION, ELECTRONIC . 21-198
GOVERNOR - REMOVAL, ELECTRONIC . . . 21-199
GRAB HANDLE - INSTALLATION,
B-PILLAR...........................23-68
GRAB HANDLE - REMOVAL, B-PILLAR....23-68
GRID LINE AND TERMINAL REPAIR -
STANDARD PROCEDURE...............8G-4
GRILLE - INSTALLATION...............23-40
GRILLE - INSTALLATION, COWL.........23-38
GRILLE - REMOVAL....................23-40
GRILLE - REMOVAL, COWL............23-38
GRILLE FRAME - INSTALLATION.........23-40
GRILLE FRAME - REMOVAL............23-40
GROUND - STANDARD PROCEDURE,
TESTING FOR A SHORT TO..........8W-01-9
GROUND AND SPLICE INFORMATION -
DESCRIPTION, CONNECTOR..........8W-01-7
GROUND ON FUSES POWERING
SEVERAL LOADS - STANDARD
PROCEDURE, TESTING FOR A SHORT
TO.............................8W-01-10
GROUND STRAP - DESCRIPTION, RADIO
NOISE SUPPRESSION..................8A-9
GROUND STRAP - INSTALLATION,
RADIO NOISE SUPPRESSION...........8A-10
GROUND STRAP - OPERATION, RADIO
NOISE SUPPRESSION..................8A-9
GROUND STRAP - REMOVAL, RADIO
NOISE SUPPRESSION..................8A-9
GROUNDS - DESCRIPTION, POWER......8E-10
GUIDE SEALS - DESCRIPTION, VALVE . 9-32,9-38
GUIDES - DESCRIPTION, VALVE....9-107,9-202
GUIDES AND SPRINGS - STANDARD
PROCEDURE, VALVES.................9-256
HALF SHAFT - CAUTION................3-20
HALF SHAFT - DIAGNOSIS AND TESTING . . 3-20
HALF SHAFT - INSTALLATION............3-21
HALF SHAFT - REMOVAL...............3-20
HALF SHAFT - SPECIAL TOOLS..........3-21
HALF SHAFT - SPECIFICATIONS..........3-21
HANDLE - INSTALLATION, A-PILLAR
TRIM/GRAB.........................23-63
HANDLE - INSTALLATION, B-PILLAR
GRAB..............................23-68
HANDLE - INSTALLATION, EXTERIOR
....23-21,
23-30
HANDLE - INSTALLATION, RELEASE
.......5-44
HANDLE - REMOVAL, A-PILLAR
TRIM/GRAB
.........................23-63
HANDLE - REMOVAL, B-PILLAR GRAB
....23-68
HANDLE - REMOVAL, EXTERIOR
. . . 23-20,23-30
HANDLE - REMOVAL, RELEASE
..........5-44
HANDLE ACTUATOR - INSTALLATION,
INSIDE
........................23-22,23-32
HANDLE ACTUATOR - REMOVAL, INSIDE
. 23-22,
23-31
HANDLE/BEZEL - INSTALLATION,
LUMBAR SUPPORT
...................23-82
HANDLE/BEZEL - REMOVAL, LUMBAR
SUPPORT
..........................23-82
HANDLE/LATCH REMOTE -
INSTALLATION, RELEASE
..............23-17
HANDLE/LATCH REMOTE - REMOVAL,
RELEASE
...........................23-17
HANDLING NON-DEPLOYED
SUPPLEMENTAL RESTRAINTS -
STANDARD PROCEDURE
...............8O-6HANDLING TUBING AND FITTINGS -
STANDARD PROCEDURE...............24-45
HANDS FREE MODULE - INSTALLATION....8T-2
HANDS FREE MODULE - REMOVAL.......8T-2
HARNESS - DIAGNOSIS AND TESTING,
WIRING..........................8W-01-7
HAZARD SWITCH - DESCRIPTION.......8L-14
HAZARD SWITCH - OPERATION.........8L-14
HCU (HYDRAULIC CONTROL UNIT) -
DESCRIPTION........................5-49
HCU (HYDRAULIC CONTROL UNIT) -
INSTALLATION........................5-50
HCU (HYDRAULIC CONTROL UNIT) -
OPERATION..........................5-49
HCU (HYDRAULIC CONTROL UNIT) -
REMOVAL...........................5-50
HEAD - CLEANING, CYLINDER.....9-200,9-251
HEAD - DESCRIPTION, CYLINDER . . 9-107,9-249
HEAD - INSPECTION, CYLINDER....9-200,9-252
HEAD - INSTALLATION, CYLINDER.......9-200
HEAD - INSTALLATION, LEFT CYLINDER . . 9-112
HEAD - INSTALLATION, RIGHT
CYLINDER..........................9-113
HEAD - LEFT - INSTALLATION,
CYLINDER...........................9-24
HEAD - LEFT - REMOVAL, CYLINDER......9-22
HEAD - OPERATION, CYLINDER.........9-199
HEAD - REMOVAL, CYLINDER.....9-200,9-249
HEAD - REMOVAL, LEFT CYLINDER......9-108
HEAD - REMOVAL, RIGHT CYLINDER.....9-110
HEAD - RIGHT - INSTALLATION,
CYLINDER...........................9-34
HEAD - RIGHT - REMOVAL, CYLINDER....9-33
HEAD COVER - INSTALLATION,
CYLINDER..........................9-255
HEAD COVER - REMOVAL, CYLINDER....9-255
HEAD COVER(S) - DESCRIPTION,
CYLINDER......................9-122,9-27
HEAD COVER(S) - INSTALLATION,
CYLINDER..................9-201,9-28,9-37
HEAD COVER(S) - REMOVAL, CYLINDER . 9-201,
9-28,9-37
HEAD GASKET - DIAGNOSIS AND
TESTING, CYLINDER...................9-21
HEAD GASKET FAILURE - DIAGNOSIS
AND TESTING, CYLINDER..............9-199
HEAD GASKET SELECTION - STANDARD
PROCEDURE........................9-281
HEADLAMP - INSTALLATION............8L-14
HEADLAMP - REMOVAL...............8L-14
HEADLAMP SWITCH - DESCRIPTION.....8L-14
HEADLAMP SWITCH - INSTALLATION....8L-15
HEADLAMP SWITCH - OPERATION.......8L-14
HEADLAMP SWITCH - REMOVAL........8L-14
HEADLAMP SWITCH BEZEL -
INSTALLATION, INSTRUMENT PANEL.....23-56
HEADLAMP SWITCH BEZEL - REMOVAL,
INSTRUMENT PANEL..................23-56
HEADLAMP UNIT - ADJUSTMENTS......8L-16
HEADLAMP UNIT - INSTALLATION.......8L-15
HEADLAMP UNIT - REMOVAL...........8L-15
HEADLINER - INSTALLATION...........23-68
HEADLINER - REMOVAL...............23-68
HEADREST - INSTALLATION............23-80
HEADREST - REMOVAL................23-80
HEADREST SLEEVE - INSTALLATION.....23-81
HEADREST SLEEVE - REMOVAL.........23-81
HEAT SHIELDS - DESCRIPTION..........11-8
HEAT SHIELDS - INSTALLATION..........11-8
HEAT SHIELDS - REMOVAL.............11-8
HEAT STAKING - STANDARD
PROCEDURE.........................23-3
HEATED GLASS - DESCRIPTION..........8G-1
HEATED GLASS - OPERATION...........8G-1
HEATED MIRRORS - DESCRIPTION.......8G-6
HEATED MIRRORS - OPERATION.........8G-6
HEATED SEAT ELEMENT - DESCRIPTION . . . 8G-9
HEATED SEAT ELEMENT - DIAGNOSIS
AND TESTING.......................8G-10
HEATED SEAT ELEMENT - INSTALLATION . 8G-10
HEATED SEAT ELEMENT - OPERATION....8G-10
HEATED SEAT ELEMENT - REMOVAL
.....8G-10
HEATED SEAT MODULE - DESCRIPTION
....8E-6
HEATED SEAT MODULE - DESCRIPTION
. . 8G-13
HEATED SEAT MODULE - DIAGNOSIS
AND TESTING
........................8E-6
HEATED SEAT MODULE - DIAGNOSIS
AND TESTING
.......................8G-14
DRINDEX 15
Description Group-Page Description Group-Page Description Group-Page

WATER PUMP BYPASS - DESCRIPTION....7-59
WATER PUMP BYPASS - OPERATION......7-60
WATER SEPARATOR - DESCRIPTION,
FUEL FILTER........................14-50
WATER SEPARATOR - INSTALLATION,
FUEL FILTER........................14-50
WATER SEPARATOR - OPERATION, FUEL
FILTER.............................14-50
WATER SEPARATOR - REMOVAL, FUEL
FILTER.............................14-50
WATER TO OIL COOLER - REMOVAL......7-69
WATERDAM - INSTALLATION......23-25,23-34
WATERDAM - REMOVAL..........23-25,23-34
WATER-IN-FUEL INDICATOR -
DESCRIPTION.......................8J-45
WATER-IN-FUEL INDICATOR -
OPERATION.........................8J-45
WATER-TO-AIR COOLER - INSTALLATION . . 7-70
WEAR - STANDARD PROCEDURE,
MEASURING TIMING CHAIN............9-167
WEAR INDICATORS - DIAGNOSIS AND
TESTING, TREAD......................22-8
WEAR PATTERNS - DIAGNOSIS AND
TESTING, TIRE.......................22-8
WEAR, STANDARD PROCEDURE -
MEASURING TIMING CHAIN.............9-77
WEATHERSTRIP - INSTALLATION, DRIP
RAIL..............................23-91
WEATHERSTRIP - INSTALLATION, FRONT
DOOR GLASS RUN...................23-92
WEATHERSTRIP - INSTALLATION, REAR
DOOR GLASS RUN.....................23-93
WEATHERSTRIP - REMOVAL, DRIP RAIL . . 23-91
WEATHERSTRIP - REMOVAL, FRONT
DOOR GLASS RUN...................23-92
WEATHERSTRIP - REMOVAL, REAR
DOOR GLASS RUN...................23-93
WEATHERSTRIP RETAINER -
INSTALLATION, A-PILLAR..............23-91
WEATHERSTRIP RETAINER -
INSTALLATION, DRIP RAIL.............23-92
WEATHERSTRIP RETAINER - REMOVAL,
A-PILLAR...........................23-91
WEATHERSTRIP RETAINER - REMOVAL,
DRIP RAIL..........................23-92
WELD LOCATIONS - SPECIFICATIONS . . . 23-120
WELD PROCESS - SPECIFICATIONS......13-15
WHEEL - INSTALLATION, STEERING
......19-15
WHEEL - REMOVAL, STEERING
.........19-15
WHEEL ALIGNMENT - DESCRIPTION
.......2-1
WHEEL ALIGNMENT - OPERATION
.........2-2
WHEEL ALIGNMENT, SPECIAL TOOLS
......2-7
WHEEL ANTILOCK - DIAGNOSIS AND
TESTING, REAR
.......................5-48
WHEEL BALANCE - STANDARD
PROCEDURE, TIRE
....................22-4
WHEEL COVER - REMOVAL
............22-14WHEEL INSPECTION, DIAGNOSIS AND
TESTING...........................22-11
WHEEL INSTALLATION - STANDARD
PROCEDURE, DUAL REAR.............22-12
WHEEL REPLACEMENT - STANDARD
PROCEDURE........................22-12
WHEEL RUNOUT - DIAGNOSIS AND
TESTING, TIRE.......................22-1
WHEEL SPEED SENSOR - DESCRIPTION,
FRONT..............................5-47
WHEEL SPEED SENSOR - DIAGNOSIS
AND TESTING, REAR...................5-49
WHEEL SPEED SENSOR -
INSTALLATION, FRONT.................5-48
WHEEL SPEED SENSOR -
INSTALLATION, REAR..................5-48
WHEEL SPEED SENSOR - OPERATION,
FRONT..............................5-47
WHEEL SPEED SENSOR - REMOVAL,
FRONT..............................5-48
WHEEL SPEED SENSOR - REMOVAL,
REAR...............................5-48
WHEEL WITH MATCHING TIRE -
DESCRIPTION, FULL SIZE, SPARE.......22-15
WHEELHOUSE SPLASH SHIELD -
INSTALLATION, FRONT................23-41
WHEELHOUSE SPLASH SHIELD -
INSTALLATION, REAR.................23-41
WHEELHOUSE SPLASH SHIELD -
REMOVAL, FRONT....................23-41
WHEELHOUSE SPLASH SHIELD -
REMOVAL, REAR.....................23-41
WHEELS - DESCRIPTION..............22-11
WHEELS - INSTALLATION, REAR DUAL....5-35
WHEELS - OPERATION................22-11
WHEELS - REMOVAL, REAR DUAL........5-34
WIND NOISE - DIAGNOSIS AND TESTING . . 23-2
WINDOW DEFOGGER RELAY -
DESCRIPTION, REAR..................8G-2
WINDOW DEFOGGER RELAY -
INSTALLATION, REAR..................8G-4
WINDOW DEFOGGER RELAY -
OPERATION, REAR....................8G-3
WINDOW DEFOGGER RELAY -
REMOVAL, REAR.....................8G-3
WINDOW DEFOGGER SWITCH -
DESCRIPTION, REAR..................8G-4
WINDOW DEFOGGER SWITCH -
OPERATION, REAR....................8G-4
WINDOW DEFOGGER SYSTEM -
DIAGNOSIS AND TESTING, REAR.........8G-2
WINDOW MOTOR - REMOVAL..........8N-20
WINDOW REGULATOR - MANUAL -
INSTALLATION..................23-27,23-35
WINDOW REGULATOR - MANUAL -
REMOVAL.....................23-26,23-35
WINDOW REGULATOR - POWER -
INSTALLATION..................23-26,23-34WINDOW REGULATOR - POWER -
REMOVAL.....................23-25,23-34
WINDOW SWITCH - DIAGNOSIS AND
TESTING...........................8N-20
WINDOW SWITCH - INSTALLATION......8N-21
WINDOW SWITCH - REMOVAL..........8N-20
WINDOWS - DESCRIPTION, POWER.....8N-19
WINDOWS - DIAGNOSIS AND TESTING,
POWER............................8N-19
WINDOWS - OPERATION, POWER.......8N-19
WINDSHIELD SAFETY PRECAUTIONS,
WARNING..........................23-88
WIPER & WASHER SYSTEM - CLEANING . . 8R-6
WIPER & WASHER SYSTEM -
DIAGNOSIS AND TESTING..............8R-6
WIPER & WASHER SYSTEM -
INSPECTION.........................8R-7
WIPER ARM - DESCRIPTION...........8R-17
WIPER ARM - INSTALLATION...........8R-18
WIPER ARM - OPERATION.............8R-18
WIPER ARM - REMOVAL..............8R-18
WIPER BLADE - DESCRIPTION..........8R-18
WIPER BLADE - INSTALLATION.........8R-20
WIPER BLADE - OPERATION...........8R-19
WIPER BLADE - REMOVAL.............8R-19
WIPER HIGH/LOW RELAY -
DESCRIPTION.......................8R-20
WIPER HIGH/LOW RELAY - DIAGNOSIS
AND TESTING.......................8R-21
WIPER HIGH/LOW RELAY -
INSTALLATION......................8R-22
WIPER HIGH/LOW RELAY - OPERATION . . 8R-20
WIPER HIGH/LOW RELAY - REMOVAL....8R-21
WIPER MODULE - DESCRIPTION........8R-22
WIPER MODULE - INSTALLATION.......8R-23
WIPER MODULE - OPERATION..........8R-23
WIPER MODULE - REMOVAL...........8R-23
WIPER ON/OFF RELAY - DESCRIPTION . . . 8R-24
WIPER ON/OFF RELAY - DIAGNOSIS AND
TESTING...........................8R-25
WIPER ON/OFF RELAY - INSTALLATION . . . 8R-26
WIPER ON/OFF RELAY - OPERATION.....8R-25
WIPER ON/OFF RELAY - REMOVAL......8R-26
WIPERS/WASHERS - DESCRIPTION
.......8R-1
WIPERS/WASHERS - OPERATION
........8R-4
WIRE SPLICING - STANDARD
PROCEDURE
.....................8W-01-15
WIRING - DESCRIPTION, TRAILER TOW
. . 8L-24
WIRING DIAGRAMS - DESCRIPTION,
HOW TO USE
.....................8W-01-1
WIRING HARNESS - DIAGNOSIS AND
TESTING
.........................8W-01-7
WIRING/TERMINAL, SPECIAL TOOLS
. . 8W-01-10
WORN THREADS - STANDARD
PROCEDURE, REPAIR
DAMAGED OR
...........9-190,9-240,9-9,9-94
DRINDEX 37
Description Group-Page Description Group-Page Description Group-Page
