INSTALLATION
NOTE: If a replacement compressor is being
installed, be certain to check the refrigerant oil
level. See Refrigerant Oil Level in this group for the
procedures. Use only refrigerant oil of the type rec-
ommended for the compressor in the vehicle.
(1) Install the compressor onto the mounting
bracket.
(2) On the 3.7L and 4.7L engines, install and
tighten the bolts in the following sequence (Fig. 7):
²Install the inner front bolt #3 and hand tight-
ened.
²Install the outer front bolt #2 and hand tight-
ened.
²Install the rear bolt #1 and hand tightened.
²Tightened the inner front bolt #3 to 40 N´m (30
ft. lbs.).
²Tightened the outer front bolt #2 to 55 N´m (41
ft. lbs.).
²Tightened the rear bolt #1 to 55 N´m (41 ft. lbs.).
(3) For the 5.7L Hemi engine, install and tighten
the bolts in the following sequence (Fig. 8):
²Install the two long bolts into the mounting
bracket and hand tightened.
²Install the rear bolt and hand tightened.²Tightened the two long bolts to 40 N´m (30 ft.
lbs.).
²Tightened the rear bolt to 55 N´m (41 ft. lbs.).
(4) For the 5.7L Hemi engine, install the generator
and A/C compressor support bracket and retaining
nuts and bolts. Tighten the nuts and bolts securely.
(5) For the 5.9L diesel engine, install and tighten
the bolts in the following sequence (Fig. 9):
²Install the four bolts into the mounting bracket
and hand tightened.
²Tightened the four bolts to 24 N´m (17 ft. lbs.).
(6) Remove the tape or plugs from the opened
refrigerant line fittings and compressor ports.
(7) Lubricate new rubber O-ring seals with clean
refrigerant oil and install them on the suction and
discharge line fittings. Use only the specified O-rings
as they are made of a special material for the R-134a
system. Use only refrigerant oil of the type recom-
mended for the A/C compressor in the vehicle.
(8) Install the suction and discharge line fittings
onto the compressor.
(9) Install the bolt or nuts (depending on engine
application) that secure the suction and discharge
line fittings to the compressor. Tighten the bolt or
nuts to 28 N´m (20 ft. lbs.).
(10) Connect the wire harness connector to the
compressor clutch coil.
Fig. 7 A/C Compressor - 3.7L Shown, 4.7L Typical
1 - BOLT #1
2 - BOLT #2
3 - BOLT #3
4 - A/C COMPRESSOR
5 - A/C CLUTCH AND PULLEY
6 - MOUNTING BRACKET
Fig. 8 A/C Compressor - 5.7L Hemi
1 - BOLT (2)
2 - A/C COMPRESSOR
3 - BOLT
4 - MOUNTING BRACKET
DRPLUMBING 24 - 51
A/C COMPRESSOR (Continued)

(11) Install the serpentine drive belt (Refer to 7 -
COOLING/ACCESSORY DRIVE/DRIVE BELTS -
INSTALLATION).
(12) Reconnect the battery negative cable.
(13) Evacuate the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE).
(14) Charge the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE).
A/C CONDENSER
DESCRIPTION
The condenser is located in the air flow next to the
engine cooling radiator. The condenser is a heat
exchanger that allows the high-pressure refrigerant
gas being discharged by the compressor to give up its
heat to the air passing over the condenser fins.
OPERATION
When air passes through the condenser fins, the
high-pressure refrigerant gas within the A/C con-
denser gives up its heat. The refrigerant then con-
denses as it leaves the A/C condenser and becomes a
high-pressure liquid. The volume of air flowing over
the condenser fins is critical to the proper cooling
performance of the air conditioning system. There-fore, it is important that there are no objects placed
in front of the radiator grille openings at the front of
the vehicle or foreign material on the condenser fins
that might obstruct proper air flow. Also, any factory-
installed air seals or shrouds must be properly rein-
stalled following radiator or A/C condenser service.
The A/C condenser cannot be repaired and, if
faulty or damaged, it must be replaced.
REMOVAL
REMOVAL - 3.7, 4.7 AND 5.7L ENGINES
WARNING: REVIEW THE WARNINGS AND CAU-
TIONS IN THE FRONT OF THIS SECTION BEFORE
PERFORMING THE FOLLOWING OPERATION (Refer
to 24 - HEATING & AIR CONDITIONING/PLUMBING -
WARNING) and (Refer to 24 - HEATING & AIR CON-
DITIONING/PLUMBING - CAUTION).
(1) Disconnect and isolate the battery negative
cable.
(2) Recover the refrigerant from the refrigerant
system (Refer to 24 - HEATING & AIR CONDITION-
ING/PLUMBING - STANDARD PROCEDURE -
REFRIGERANT RECOVERY).
(3) Remove the nut that secures the discharge line
fitting to the condenser inlet port (Fig. 10).
(4) Disconnect the discharge line from the con-
denser.
(5) Remove the seal from the discharge line fitting
and discard.
(6) Install plugs in, or tape over the discharge line
fitting and condenser inlet port.
(7) Remove the plastic cover from the condenser
outlet stud.
(8) Remove the nut that secures the liquid line fit-
ting to the condenser outlet.
(9) Disconnect the liquid line from the condenser.
(10) Remove the seal from the liquid line fitting
and discard.
(11) Install plugs in, or tape over the liquid line
fitting and condenser outlet port.
(12) Disconnect the wire harness connector from
the condenser cooling fan motor (Fig. 11).
(13) Remove the two bolts that secure the con-
denser to the front upper crossmember.
(14) Remove the condenser/cooling fan assembly
from the vehicle.
(15) Place the condenser/cooling fan assembly on a
flat work area and remove the four screws that
secure the cooling fan to the condenser.
(16) Separate the cooling fan from the condenser.
Fig. 9 A/C Compressor - 5.9L Diesel
1 - ENGINE BLOCK
2 - MOUNTING BRACKET
3 - A/C COMPRESSOR
4 - BOLT (4)
24 - 52 PLUMBINGDR
A/C COMPRESSOR (Continued)

REMOVAL - 5.9L DIESEL ENGINE
WARNING: REVIEW THE WARNINGS AND CAU-
TIONS IN THE FRONT OF THIS SECTION BEFORE
PERFORMING THE FOLLOWING OPERATION (Refer
to 24 - HEATING & AIR CONDITIONING/PLUMBING -
WARNING) and (Refer to 24 - HEATING & AIR CON-
DITIONING/PLUMBING - CAUTION).
(1) Disconnect and isolate the battery negative
cable.
(2) Recover the refrigerant from the refrigerant
system (Refer to 24 - HEATING & AIR CONDITION-
ING/PLUMBING - STANDARD PROCEDURE -
REFRIGERANT RECOVERY).
(3) Remove the plastic cover from the condenser
inlet stud.
(4) Remove the nut that secures the discharge line
fitting to the condenser inlet port (Fig. 12).
(5) Disconnect the discharge line from the con-
denser.
(6) Remove the seal from the discharge line fitting
and discard.
(7) Install plugs in, or tape over the discharge line
fitting and condenser inlet port.
(8) Remove the plastic cover from the condenser
outlet stud.
(9) Remove the nut that secures the liquid line fit-
ting to the condenser outlet.
(10) Disconnect the liquid line from the condenser.
(11) Remove the seal from the liquid line fitting
and discard.
(12) Install plugs in, or tape over the liquid line
fitting and condenser inlet port.
(13) Remove the four bolts that secure the con-
denser to the charge air cooler.
(14) Remove the condenser from the engine com-
partment.
INSTALLATION
INSTALLATION - 3.7, 4.7 AND 5.7L ENGINES
NOTE: If the condenser is replaced, add 30 millili-
ters (1 fluid ounce) of refrigerant oil to the refriger-
ant system. Use only refrigerant oil of the type
recommended for the compressor in the vehicle.
(1) Position the condenser cooling fan onto the A/C
condenser.
(2) Install and tighten the four screws that secure
the condenser cooling fan to the A/C condenser.
Tighten the screws to 2.2 N´m (20 in. lbs.).
(3) Carefully position the condenser/cooling fan
assembly into the engine compartment.
Fig. 10 A/C Discharge Line - 3.7L Shown, 4.7L/5.7L
Typical
1 - NUT
2 - FRONT UPPER CROSSMEMBER
3 - A/C CONDENSER
4 - NUT (2)
5 - SUCTION LINE
6 - A/C COMPRESSOR
7 - A/C PRESSURE TRANSDUCER
8 - WIRE HARNESS CONNECTOR
9 - A/C DISCHARGE LINE
Fig. 11 Condenser/Cooling Fan Assembly
1 - LH MOUNTING BOLT
2 - FRONT UPPER CROSSMEMBER
3 - LOWER MOUNTING FLANGE
4 - UPPER MOUNTING SCREW (2)
5 - LOWER MOUNTING SCREW (2)
6 - MOUNTING TABS
7 - CONDENSER COOLING FAN MOTOR
8 - COOLING FAN WIRE CONNECTOR
9 - RH MOUNTING BOLT
DRPLUMBING 24 - 53
A/C CONDENSER (Continued)

(4) Align the condenser lower mounting tabs to the
mounting flanges.
(5) Install the two bolts that secure the condenser/
cooling fan assembly to the upper front crossmember.
Tighten the bolts to 10.5 N´m (95 in. lbs.).
(6) Connect the wire harness connector to the con-
denser cooling fan motor.
(7) Remove the tape or plugs from the liquid line
fitting and condenser outlet port.
(8) Lubricate a new rubber O-ring seal with clean
refrigerant oil and install it on the liquid line fitting.
Use only the specified O-ring as it is made of a spe-
cial material for the R-134a system. Use only refrig-
erant oil of the type recommended for the A/C
compressor in the vehicle.
(9) Connect the liquid line to the condenser outlet
port.
(10) Install and tighten the nut that secures the
liquid line fitting to the condenser. Tighten the nut to
20 N´m (180 in. lbs.).
(11) Install the plastic cover onto the condenser
outlet stud.
(12) Remove the tape or plugs from the discharge
line fitting and condenser inlet port.(13) Lubricate a new rubber O-ring seal with clean
refrigerant oil and install it on the discharge line fit-
ting. Use only the specified O-ring as it is made of a
special material for the R-134a system. Use only
refrigerant oil of the type recommended for the A/C
compressor in the vehicle.
(14) Connect the discharge line to the condenser
inlet port.
(15) Install and tighten the nut that secures the
discharge line fitting to the condenser. Tighten the
nut to 20 N´m (180 in. lbs.).
(16) Reconnect the battery negative cable.
(17) Evacuate the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE - REFRIGERANT SYS-
TEM EVACUATE).
(18) Charge the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE - REFRIGERANT SYS-
TEM CHARGE).
INSTALLATION - 5.9L DIESEL ENGINE
NOTE: If the condenser is replaced, add 30 millili-
ters (1 fluid ounce) of refrigerant oil to the refriger-
ant system. Use only refrigerant oil of the type
recommended for the compressor in the vehicle.
(1) Position the condenser into the engine compart-
ment.
(2) Install the four bolts that secure the condenser
to the charge air cooler. Tighten the bolts to 10.5 N´m
(95 in. lbs.).
(3) Remove the tape or plugs from the liquid line
fitting and condenser outlet port.
(4) Lubricate a new rubber O-ring seal with clean
refrigerant oil and install it on the liquid line fitting.
Use only the specified O-ring as it is made of a spe-
cial material for the R-134a system. Use only refrig-
erant oil of the type recommended for the A/C
compressor in the vehicle.
(5) Connect the liquid line to the condenser outlet
port.
(6) Install and tighten the nut that secures the liq-
uid line fitting to the condenser. Tighten the nut to
20 N´m (180 in. lbs.).
(7) Install the plastic cover onto the condenser out-
let stud.
(8) Remove the tape or plugs from the discharge
line fitting and condenser inlet port.
(9) Lubricate a new rubber O-ring seal with clean
refrigerant oil and install it on the discharge line fit-
ting. Use only the specified O-ring as it is made of a
special material for the R-134a system. Use only
refrigerant oil of the type recommended for the A/C
compressor in the vehicle.
Fig. 12 Condenser - 5.9L Diesel Engine
1 - DISCHARGE LINE
2 - MOUNTING BOLT
3 - LIQUID LINE
4 - MOUNTING BOLT
5 - A/C CONDENSER
6 - MOUNTING BOLT
7 - MOUNTING BOLT
24 - 54 PLUMBINGDR
A/C CONDENSER (Continued)

(10) Connect the discharge line to the condenser
inlet port.
(11) Install and tighten the nut that secures the
discharge line fitting to the condenser. Tighten the
nut to 20 N´m (180 in. lbs.).
(12) Install the plastic cover onto the condenser
inlet stud.
(13) Reconnect the battery negative cable.
(14) Evacuate the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE - REFRIGERANT SYS-
TEM EVACUATE).
(15) Charge the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE - REFRIGERANT SYS-
TEM CHARGE).
A/C CONDENSER FAN
REMOVAL - 3.7, 4.7 and 5.7L ENGINES
WARNING: REVIEW THE WARNINGS AND CAU-
TIONS IN THE FRONT OF THIS SECTION BEFORE
PERFORMING THE FOLLOWING OPERATION (Refer
to 24 - HEATING & AIR CONDITIONING/PLUMBING -
WARNING) and (Refer to 24 - HEATING & AIR CON-
DITIONING/PLUMBING - CAUTION).
(1) Disconnect and isolate the battery negative
cable.
(2) Recover the refrigerant from the refrigerant
system (Refer to 24 - HEATING & AIR CONDITION-
ING/PLUMBING - STANDARD PROCEDURE -
REFRIGERANT RECOVERY).
(3) Remove the nut that secures the discharge line
fitting to the condenser inlet port (Fig. 13).
(4) Disconnect the discharge line from the con-
denser.
(5) Remove the seal from the discharge line fitting
and discard.
(6) Install plugs in, or tape over the discharge line
fitting and condenser inlet port.
(7) Remove the plastic cover from the condenser
outlet stud.
(8) Remove the nut that secures the liquid line fit-
ting to the condenser outlet.
(9) Disconnect the liquid line from the condenser.
(10) Remove the seal from the liquid line fitting
and discard.
(11) Install plugs in, or tape over the liquid line
fitting and condenser inlet port.
(12) Disconnect the wire harness connector from
the condenser cooling fan motor (Fig. 14).
(13) Remove the two bolts that secure the con-
denser to the front upper crossmember.(14) Remove the condenser/cooling fan assembly
from the vehicle.
(15) Place the condenser/cooling fan assembly on a
flat work area and remove the four screws that
secure the cooling fan to the condenser.
(16) Separate the cooling fan from the condenser.
INSTALLATION - 3.7, 4.7 and 5.7L ENGINES
(1) Position the condenser cooling fan onto the A/C
condenser.
(2) Install and tighten the four screws that secure
the condenser cooling fan to the A/C condenser.
Tighten the screws to 2.2 N´m (20 in. lbs.).
(3) Carefully position the condenser/cooling fan
assembly into the engine compartment.
(4) Align the condenser lower mounting tabs to the
mounting flanges.
(5) Install the two bolts that secure the condenser/
cooling fan assembly to the upper front crossmember.
Tighten the bolts to 10.5 N´m (95 in. lbs.).
(6) Connect the wire harness connector to the con-
denser cooling fan motor.
(7) Remove the tape or plugs from the liquid line
fitting and condenser outlet port.
Fig. 13 A/C Discharge Line - 3.7L Shown, 4.7L/5.7L
Typical
1 - NUT
2 - FRONT UPPER CROSSMEMBER
3 - A/C CONDENSER
4 - NUT (2)
5 - SUCTION LINE
6 - A/C COMPRESSOR
7 - A/C PRESSURE TRANSDUCER
8 - WIRE HARNESS CONNECTOR
9 - A/C DISCHARGE LINE
DRPLUMBING 24 - 55
A/C CONDENSER (Continued)

(8) Lubricate a new rubber O-ring seal with clean
refrigerant oil and install it on the liquid line fitting.
Use only the specified O-ring as it is made of a spe-
cial material for the R-134a system. Use only refrig-
erant oil of the type recommended for the A/C
compressor in the vehicle.
(9) Connect the liquid line to the condenser outlet
port.
(10) Install and tighten the nut that secures the
liquid line fitting to the condenser. Tighten the nut to
20 N´m (180 in. lbs.).
(11) Install the plastic cover onto the condenser
outlet stud.
(12) Remove the tape or plugs from the suction
line fitting and condenser inlet port.
(13) Lubricate a new rubber O-ring seal with clean
refrigerant oil and install it on the suction line fit-
ting. Use only the specified O-ring as it is made of a
special material for the R-134a system. Use only
refrigerant oil of the type recommended for the A/C
compressor in the vehicle.
(14) Connect the suction line to the condenser inlet
port.
(15) Install and tighten the nut that secures the
suction line fitting to the condenser. Tighten the nut
to 20 N´m (180 in. lbs.).
(16) Reconnect the battery negative cable.
(17) Evacuate the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE - REFRIGERANT SYS-
TEM EVACUATE).(18) Charge the refrigerant system (Refer to 24 -
HEATING & AIR CONDITIONING/PLUMBING -
STANDARD PROCEDURE - REFRIGERANT SYS-
TEM CHARGE).
A/C DISCHARGE LINE
DESCRIPTION
The A/C discharge line is the refrigerant line that
goes from the A/C compressor to the A/C condenser.
The A/C discharge line for the 5.9L Diesel engine is
serviced as an assembly with the suction line. The
A/C discharge line has no serviceable parts except
the rubber O-ring seals.
CAUTION: Use only O-ring seals specified for the
vehicle. Failure to use correct O-ring seal will cause
the refrigerant system connection to leak.
The O-ring seals used on the connections are made
from a special type of rubber not affected by R-134a
refrigerant. The O-ring seals must be replaced when-
ever the A/C discharge line is removed and installed.
If the A/C discharge line is found to be leaking or
is damaged, it must be replaced.
REMOVAL
REMOVAL - 5.9L DIESEL ENGINE
WARNING: REVIEW THE WARNINGS AND CAU-
TIONS IN THE FRONT OF THIS SECTION BEFORE
PERFORMING THE FOLLOWING OPERATION (Refer
to 24 - HEATING & AIR CONDITIONING/PLUMBING -
WARNING) and (Refer to 24 - HEATING & AIR CON-
DITIONING/PLUMBING - CAUTION).
(1) Disconnect and isolate the battery negative
cable.
(2) Recover the refrigerant from the refrigerant
system (Refer to 24 - HEATING & AIR CONDITION-
ING/PLUMBING - STANDARD PROCEDURE -
REFRIGERANT RECOVERY).
(3) Disconnect the wire harness connector from the
A/C pressure transducer.
(4) Remove the nut that secures the discharge line
fitting to the condenser inlet port (Fig. 15).
(5) Disconnect the discharge line from the con-
denser.
(6) Remove the O-ring seal from the discharge line
fitting and discard.
(7) Install plugs in, or tape over the discharge line
fitting and condenser inlet port.
(8) Remove the bolt that secures the suction/dis-
charge line assembly to the A/C compressor.
Fig. 14 Condenser/Cooling Fan Assembly
1 - LH MOUNTING BOLT
2 - FRONT UPPER CROSSMEMBER
3 - LOWER MOUNTING FLANGE
4 - UPPER MOUNTING SCREW (2)
5 - LOWER MOUNTING SCREW (2)
6 - MOUNTING TABS
7 - CONDENSER COOLING FAN MOTOR
8 - COOLING FAN WIRE CONNECTOR
9 - RH MOUNTING BOLT
24 - 56 PLUMBINGDR
A/C CONDENSER FAN (Continued)

(9) Disconnect the suction/discharge line assembly
from the A/C compressor.
(10) Remove the O-ring seals from the suction and
discharge line fittings and discard.
(11) Install plugs in, or tape over all of the opened
refrigerant line fittings and the compressor ports.
(12) Remove the secondary retaining clip from the
spring-lock coupler that secures the suction line to
the accumulator outlet tube (Fig. 16).
(13) Using the proper A/C line disconnect tool, dis-
connect the suction line from the accumulator outlet
tube fitting (Refer to 24 - HEATING & AIR CONDI-
TIONING/PLUMBING/REFRIGERANT LINE COU-
PLER - REMOVAL).
(14) Remove the O-ring seal from the accumulator
outlet tube fitting and discard.
(15) Install plugs in, or tape over the opened suc-
tion line and the accumulator outlet tube fitting.
(16) Remove the suction/discharge line assembly
from the engine compartment.
(17) If necessary, remove the A/C pressure trans-
ducer from the discharge line.
REMOVAL - 3.7L/4.7L AND 5.7L HEMI ENGINE
WARNING: REVIEW THE WARNINGS AND CAU-
TIONS IN THE FRONT OF THIS SECTION BEFORE
PERFORMING THE FOLLOWING OPERATION (Refer
to 24 - HEATING & AIR CONDITIONING/PLUMBING -
WARNING) and (Refer to 24 - HEATING & AIR CON-
DITIONING/PLUMBING - CAUTION).
(1) Disconnect and isolate the battery negative
cable.
(2) Recover the refrigerant from the refrigerant
system (Refer to 24 - HEATING & AIR CONDITION-
ING/PLUMBING - STANDARD PROCEDURE -
REFRIGERANT RECOVERY).
(3) Disconnect the wire harness connector from the
A/C pressure transducer (Fig. 17) or (Fig. 18),
depending on application.
(4) Remove the nut that secures the discharge line
fitting to the condenser inlet port.
(5) Disconnect the discharge line from the con-
denser.
(6) Remove the O-ring seal from the discharge line
fitting and discard.
Fig. 15 A/C Discharge Line - 5.9L Diesel Engine
1 - CONDENSER
2 - NUT
3 - LIQUID LINE
4 - NUT
5 - PRESSURE TRANSDUCER WIRE CONNECTOR
6 - A/C COMPRESSOR
7 - BOLT
8 - SUCTION/DISCHARGE LINE ASSEMBLY
Fig. 16 A/C Accumulator - Typical
1 - RH INNER FENDER
2 - ACCUMULATOR INLET TUBE
3 - A/C LINE SECONDARY RETAINING CLIP
4 - EVAPORATOR OUTLET TUBE
5 - BOLTS (2)
6 - ACCUMULATOR
7 - SUCTION LINE
8 - A/C LOW PRESSURE SERVICE PORT
9 - A/C LINE SECONDARY RETAINING CLIP
DRPLUMBING 24 - 57
A/C DISCHARGE LINE (Continued)

(7) Install plugs in, or tape over the discharge line
fitting and condenser inlet port.
(8) Remove the nut that secures the discharge line
fitting to the A/C compressor.
(9) Disconnect the discharge line from the com-
pressor.
(10) Remove the O-ring seal from the discharge
line fitting and discard.
(11) Install plugs in, or tape over the discharge
line fitting and compressor outlet port.
(12) Remove the discharge line from the engine
compartment.
(13) If necessary, remove the A/C pressure trans-
ducer from the discharge line.
INSTALLATION
INSTALLATION - 5.9L DIESEL ENGINE
(1) If removed, install the A/C pressure transducer
onto the discharge line using a new O-ring seal.
Tighten the transducer securely.
(2) Position the suction/discharge line assembly
into the engine compartment.
(3) Remove the tape or plugs from the suction line
and the accumulator outlet tube fitting.(4) Lubricate a new rubber O-ring seal with clean
refrigerant oil and install it on the accumulator out-
let tube fitting. Use only the specified O-ring as it is
made of a special material for the R-134a system.
Use only refrigerant oil of the type recommended for
the A/C compressor in the vehicle.
(5) Connect the suction line to the accumulator
outlet tube (Refer to 24 - HEATING & AIR CONDI-
TIONING/PLUMBING/REFRIGERANT LINE COU-
PLER - INSTALLATION).
(6) Install the secondary retaining clip onto the
spring-lock coupler that secures the suction line to
the accumulator outlet tube.
(7) Remove the tape or plugs from the suction and
discharge line fittings and the compressor ports.
(8) Lubricate new rubber O-ring seals with clean
refrigerant oil and install them on the suction and
discharge line fittings. Use only the specified O-rings
as they are made of a special material for the R-134a
system. Use only refrigerant oil of the type recom-
mended for the A/C compressor in the vehicle.
(9) Connect the suction/discharge line assembly to
the compressor.
(10) Install and tighten the bolt that secures the
suction/discharge line assembly to the compressor.
Tighten the bolt to 28 N´m (20 ft. lbs.).
Fig. 17 A/C Discharge Line - 3.7L Shown, 4.7L
Typical
1 - NUT
2 - FRONT UPPER CROSSMEMBER
3 - A/C CONDENSER
4 - NUT (2)
5 - SUCTION LINE
6 - A/C COMPRESSOR
7 - A/C PRESSURE TRANSDUCER
8 - WIRE HARNESS CONNECTOR
9 - A/C DISCHARGE LINE
Fig. 18 A/C Discharge Line - 5.7L Hemi Engine
1 - DISCHARGE LINE
2 - NUT
3 - CONDENSER
4 - NUT
5 - SUCTION LINE
6 - A/C COMPRESSOR
7 - NUT
8 - A/C PRESSURE TRANSDUCER
24 - 58 PLUMBINGDR
A/C DISCHARGE LINE (Continued)
