1998 BMW CONVERTIBLE mirror

Contents

At a glance
Controls and features

Cockpit16
Instrument cluster18
Indicator and warning
lamps20
Hazard warning system22
Hazard warning triangle22
First-aid kit22
Refueling23
Fuel specification23
CARB OBD II interface24
Tire inflation pressures25

Locks and security systems:

Keys30
Electronic immobilizing device35
Doors31
Trunk lid33
Luggage compartment34
Power windows35
Sliding/tilt sunroof36
Convertible top operation37

Adjustments:

Seats43
Steering wheel45
Mirrors46

Passenger safety systems:

Safety belts47
Child restraint system48
Installing child seats49
Airbags50
Child-safety locks52
Rollover protection system Ð
convertible52
Driving:

Steering/ignition lock54
Starting the engine54
Switching off the engine55
Parking brake56
Manual transmission57
Automatic transmission58
Turn signals/high beam60
Wiper/washer system61
Cruise control62

Everything under control:

Odometer63
Tachometer63
Energy control63
Fuel gauge64
Coolant temperature gauge64
Service Interval Display64
Multi-Information Display (MID)66
Outside temperature display
and digital clock68
Check Control71
Check Control with outside
temperature display and
digital clock74
Onboard computer77

Technology for driving comfort
and safety:

Automatic stability control
plus traction (ASC+T)84

28
Locks and security systems:
Keys30
Electronic vehicle immobilizer 30
Doors31
Luggage compartment lid33
Luggage compartment34
Power windows35
Sliding/tilt sunroof36
Convertible top operation37
Adjustments:
Seats43
Steering wheel45
Mirrors46
Passenger safety systems:
Safety belts47
Child restraint system48
Installing child seats49
Airbags50
Child-safety locks52
Rollover protection system Ð
convertible52Driving:
Steering/ignition lock54
Starting the engine54
Switching off the engine55
Parking brake56
Manual transmission57
Automatic transmission58
Turn signals/high beam60
Wiper/washer system61
Cruise control62
Everything under control:
Odometer63
Tachometer63
Energy control63
Fuel gauge64
Coolant temperature gauge64
Service Interval Display64
Multi-Information Display (MID)66
Outside temperature display
and digital clock68
Check Control71
Check Control with outside
temperature display and
digital clock74
Onboard computer77

46
Exterior mirrors1 Mirror switch for 4-way adjustment.
2 Switch for changing to the other
mirror:
dPush switch to left Ð driver's mirror.
dPush switch to right Ð passenger's
mirror.
You can also adjust the mirrors manu-
ally by pressing against the outer edges
of the lens.
a
The mirror on the passenger's side
features a lens with a more convex cur-
vature than the mirror installed on the
driver's door. When estimating the dis-
tance between yourself and other traffic,
bear in mind that the objects reflected in
the mirror are closer than they appear.
This means that estimations of the dis-
tance to following traffic should not be
regarded as precise.c
Electric heatersBoth mirrors are heated automatically
corresponding to the outside tempera-
ture with the ignition key in position 2.
Inside rearview mirrorTo reduce glare from behind during
night driving: tilt small lever to dimmed
position.Lighted make-up mirrorFold down the sun visor, slide the cover
panel to the side.
The mirror lamps operate from ignition
key position 1 onward.Sun visorsThese can be folded down toward the
windshield or swiveled out against the
side windows.
1
2
360de304
360de030
Mirrors

13 3
At a glanceControlsCar careRepairsTechnicalDataIndex
Waxing your carProtect the finish using carnauba or
synthetic-based waxes only.
The best way to determine when the
finish needs to be waxed is by noting
when water stops beading on the sur-
face.
You can use a glass cleaner to remove
any wax or silicone that may have been
left on the windows during waxing.b
A full range of car-care products is
available from your BMW Retailer.c
Paint damageYou can touch up small areas of dam-
age with BMW spray paint, a BWM
touch-up stick or BMW paint tape.
The paint color code for your car is pro-
vided on a sticker located next to the
type plate and on the first page of your
Service and Warranty Information book-
let.
Damage caused by flying stones,
scratches, etc. must be touched up
without delay to prevent rust from form-
ing.
If corrosion has started to form in an
area with paint damage, remove all rust
and clean the area, then prime the area
with a BMW Primer Stick. Finally, apply
the finish coat. Wait a few days, then
polish the repaired area. Finish by
applying a wax preservative.
More extensive paint damage should be
professionally repaired in accordance
with the manufacturer's instructions.
Your BMW Retailer uses original BMW
finish materials in accordance with offi-
cial repair procedures.
Caring for other vehicle compo-
nents and materialsLight-alloy wheels
* should be treated
with alloy wheel cleaner, particularly dur-
ing the winter months. Refrain from using
aggressive products containing acids,
strong alkalis or abrasives. Alloy wheels
should not be cleaned with a steam jet
operating at temperatures in excess of
140 5F (606) (note manufacturer's
instructions).
You can use window and glass cleaner to
clean inside window surfaces and mir-
rors without smearing and streaking.
Never use polishing pastes or abrasive
(quartz) cleansers on mirror lenses.
Clean plastic parts, imitation leather sur-
faces, the roof lining, the lenses of lamps,
the glass cover of the instrument panel
and all dull black sprayed parts with
water or products for the care of plastics.
Avoid soaking the headliner. Never use
solvents such as lacquer thinner, heavy-
duty grease remover, fuels, etc.
Rubber components should be cleaned
with water only; a rubber treatment or sil-
icone spray may also be applied.
Clean the wiper blades with soapy water.
The wiper blades should be replaced
twice a year, before and after the cold
season.
Caring for your car

14 4
License plate lamps 5 watt bulb
dScrew out the screws and remove
the handle.
dPress the bulb holder to the left and
remove.
dExtract the bulb from the contacts.
Front interior lamp Interior lamp with reading lamps:
(Bulbs 10 watt)
dInterior lamp: use a screwdriver to
press out the lens at the left recess.
Extract the bulb from the contacts.
dReading lamp: remove the entire
lamp from the trim, remove the con-
tact strip and gently press against
the lamp while turning it to the left to
remove.b
When reinstalling first, engage the
housing then the lens.c
Rear interior lampsBMW Sedan, Coupe
Without reading lamp
5 watt bulb
dPull the lamp out of the trim.
dFold up the reflector and remove the
bulb.
With reading lamp
*
6 watt bulbdPull the lamp out of the trim.
dFold up the PCB and remove the
bulb.
Illuminated make-up mirror
*
10 watt bulb
dRemove lamp housing (use a screw-
driver if necessary).
dReplace bulb.
360de121Bulb replacement

172
Note: This index does not correspond to the original manual in all details
IIce warning
66
Identification mark, tires
113
Ignition
54
Ignition key
30
Ignition switch 54
Independent ventilation
81
Indicator lights
20
Inflation pressure 25
, 111
Inside mirror
46
Inside rearview mirror
46
INSPECTION
64
Installing child seats
49
Instrument
18
Instrument lighting
85
Interior lights
86
, 144
Interior lights,
Replace bulbs 144
Intermittent wiper switch
61
JJack
146
Jump start
153
KKeys
30
Kickdown
59
LLeather care
135
LED Light-emitting diodes

110
Length
161
License plate light,
Replace bulb
144Light switch
85
Light-emitting diode LED

110
Limit
80
Loading 98
Lock buttons
31
Locks, care 105
Lowbeam headlight
85
Lowbeam headlights,
Replace lights
141
Low-fuel warning light
64
Luggage straps
34
Lumbar support 45
MM+S-Tires
114
Maintenance 64
, 130
Make-up mirror
46
Manual transmission
57
Capacity
166
Manually controlled
recirculated-air
91
Maximum speed 163
Micro-filter
92
MID Multi-information
display
66
, 67
, 68
, 69
Mirror heating
46
Mirrors
46
Multifunction switch
60
Multi-information display
MID
66
, 67
, 68
, 69
OOdometer
63
OilCapacity
166
Oil additives 125
Oil change interval,
Refer to the service
booklet
124
Oil consumption
124
Oil dipstick
124
Oil filter change
166
Oil filter renewal 166
Oil level, indicator light
20
Oil pressure, indicator light

20
OIL SERVICE
64
Oil, power steering
128
On-board computer 77
, 78
,
79
, 80
, 81
, 82
, 83
Operating
31
Outside rearview mirror
46
Outside temperature
66
, 78
Display
66
Outside temperature
indicator 68
PPaintwork, care
132
Paintwork, dirt and
contaminants 132
Paintwork, minor repairs

133
Paintwork, waxing
133
Parking brake
56
Parking light 85
Parking light,
Replace bulb 141Parking lights
60
Parking, Winter 106
Passenger airbag 50
Payload, maximum 163
Pocket light
93
Power door locks
31
Power steering, oil 128
Pressure, tire
25
Pressure, tires 111
Procedure
147
RRadiator
166
Reading lights
86
Rear backrest,
folding
95
Rear foglight
86
, 143
Reclining seat
43
Refueling
23
Remote control
On-board computer
83
Remove mist
Windshields
91
Replacement keys
30
Reverse
57
Rims
113
, 115
Road performance
163
Roof load, approved 163
Roof load, permissible 163
Roof rack
107
Roof-mounted luggage rack

107
Rubber parts
105
Rubber seals and
Everything from A to Z
