1998 BMW CONVERTIBLE Owners Manual

16

Cockpit
A
TO
360us306

Controls and features MaintenanceAt a glanceControls Car care Repairs Technical Data Index

17
1 Lamp switch 85
2 Foglamps 86
3 Horn, entire surface
4 Wiper/washer lever 61
5 Rear window defroster 91
6 Hazard warning system 22
7 Automatic cruise control

*
62
8 Adjust steering wheel

*
45
9 Turn signals, high beam headlamps
and headlamp flasher 60
10 Engine hood unlocking device 118

Cockpit

18

Instrument cluster

360us319

Controls and features MaintenanceAt a glanceControls Car care Repairs Technical Data Index

19
1 Fuel gauge with low-fuel
warning lamp 64
2 Indicator lamp for turn signals 20
3 Speedometer
4 Indicator and warning lamps for

d

Battery charge current 20

d

High beams 20

d

Engine oil pressure 20
5 Tachometer 63
Energy control 63
6 Coolant temperature gauge 64
7 Indicator and warning lamps for

d

Brake pad wear 20

d

Brake system hydraulics 21

d

Parking brake 21

d

Airbag 50
8 Indicator lamp for ASC+T 20
9 Indicator and warning lamps for

d

Automatic transmission

*
20

d

Warning lamp for Check Control

*

71

d

Please fasten seat belts

*
21

d

ABS 20
10 Trip odometer 63
11 Service Interval Display 64
12 Odometer 6313 Indicator lamps for

d

Foglamps

*
20

d

Emissions-related systems
indicator 21

d

Rollover protection system

*
21
14 Trip odometer reset button 63

Instrument cluster

20

Turn signal left/right, green

k

Flashes when the turn signals
are in operation.

Battery charge current, red

v

Goes out after the engine has
started.
If the lamp comes on during
normal vehicle operation:
The battery is no longer being charged.
Indicates a defect in the generator drive
belt or the charging circuit.

a

If the V-belt is defective, do not run
the coolant pump; overheating and
potential engine damage would result.
Contact your BMW Retailer.

c

High beam, blue

l
Lights up when the high beams
are switched on or the head-
lamp flashers are activated.
Engine oil pressure, redw
Goes out after the engine has
started. May come on briefly at
idle when the engine is hot,
but must go out again at higher engine
speed.
If the lamp comes on during normal vehi-
cle operation: stop vehicle and switch off
engine immediately. Check engine oil
level; if necessary, add oil. If oil level is
correct: contact your BMW Retailer.
Foglamps
*, green
t
Lights up whenever you switch
on the foglamps.
Airbags, redp
This lamp turns on for an oper-
ational check when you turn the
ignition key to position 1. If, at
the operation check, it does not go on,
or goes on while driving, have it checked
at your BMW Retailer.
Additional notes: Page 50
Automatic transmission
*, yellow
O
Goes out after the engine has
started.
Additional notes: Page 58
ASC+T (Automatic Stability
Control plus Traction), yellows
Goes out shortly after the igni-
tion is switched on:
System OK.
Additional notes: Page 84
ABS (Antilock Brake System),
yellowo
Goes out after the engine has
started. If the lamp comes on
during normal vehicle opera-
tion: ABS has been deactivated in
response to a system malfunction. Con-
ventional braking force remains unim-
paired.
Additional notes: Page 103
Brake pad wear, yellow#
Lights up when starter is actu-
ated and goes out when the
engine is started.
If the lamp comes on during normal
vehicle operation: replace brake pads
immediately.
a
Use only original BMW-approved
brake pads otherwise the vehicle
authorization is no longer valid.c
Indicator and warning lamps

At a glanceControls Car care Repairs Technical Data Index
21
Brake hydraulics, redn
Goes out after the engine has
started.
If the lamp comes on during
normal vehicle operation: low brake
fluid. Additional notes: Page 128
Parking brake, redm
Goes out after the engine has
started. Comes on when you
engage the parking brake.
Additional notes: Page 56
Emissions-related systemsY
Lamp goes out once engine
starts.
If this indicator lamp lights up
during normal vehicle operation, either
continuously or intermittently, this indi-
cates a fault in one of the emissions-
related electronic circuits. Although the
vehicle remains operational, you should
have the systems checked by a BMW
Retailer at the earliest possible opportu-
nity.
Please fasten safety belts
*, red
q
(With acoustic signal
if the
driverÕs belt is not buckled).
Lights up briefly when the
ignition key is turned, and then goes out
(in some models it goes out after you
fasten safety belts).
BMW Convertible
Rollover Protection System
*,
yellow
;
Goes out shortly after the igni-
tion is switched on:
System OK.
Indicator and warning lamps

22
The button flashes intermittently when
the hazard warning lamps are on.
The button is also illuminated whenever
the vehicle lighting is switched on.The warning triangle can be stored in
the luggage compartment in a storage
shelf at the right for convenient access.
a
Comply with legal requirements
concerning the need to carry a warning
triangle in the car.cOn the right in the luggage compart-
ment, on a shelf.
a
Some of the items in the first-aid
kit are suitable for use for a limited
period only. Therefore you should regu-
larly check the contents and replace
defective articles. These are available in
any pharmacy.
Comply with legal requirements con-
cerning the need to carry a first-aid kit in
the car.c
360de040Hazard warning system Hazard warning triangle*First aid kit*

At a glanceControls Car care Repairs Technical Data Index
23
Refueling Fuel specificationTo unlock the filler door in the event of a
central locking system failure, refer to
page152.a
When handling fuel, comply with
the safety regulations displayed by gas
stations.cUnleaded gasoline only.
Minimum octane requirement: 89 AKI
BMW engines are equipped with knock
sensors and automatically adapt to op-
erate with fuels of different octane rat-
ings, as long as the minimum octane
requirement is met.
Higher octane fuels will provide in-
creased performance and fuel econ-
omy, while the use of gasoline with a
lower octane rating will have an adverse
effect.
a
Never use leaded fuel, as it would
cause permanent damage to both the
catalytic converter and the engine-man-
agement systemÕs oxygen sensors.c
AKI = Anti Knock Index
360de010
