1997 TOYOTA RAV4 Owners Manual

55
2. Fully extend the shoulder belt to put itin the lock mode. When the belt is then
retracted slightly, it cannot be ex- tended.
To hold the convertible seat securely,
make sure the belt is in the lock mode be-
fore letting the belt to retract.3. While pressing the convertible seat firmly against the seat cushion and
seatback, let the shoulder belt retract
as far as it will go to hold the convert-
ible seat securely.
CAUTION!
Make sure the seat belt is securely
locked. Also make sure the child
restraint system is secure by
pushing and pulling it in different
directions. Follow all the installa-
tion instructions provided by its
manufacturer.

56
4. To remove the convertible seat, pressthe buckle-release button and allow
the belt to retract completely. The belt will move freely again and be ready to work for an adult or older child passen-
ger.(C) BOOSTER SEAT INSTALLATION A booster seat is used in forward-fac-
ing position only.
CAUTION!
A forward-facing child restraint
system should be put on the front
seat only when it is unavoidable.
Always move the seat as far back
as possible because the force of a
deploying airbag could cause
death or serious injury to the child.

57
1. Sit the child on a booster seat. Run thelap and shoulder belt through or
around the booster seat and child fol- lowing the instructions provided by its
manufacturer and insert the tab intothe buckle taking care not to twist the belt.
Make sure the shoulder belt is correctly
across the child's shoulder and that the
lap belt is positioned as low as possible on
child's hips. See Seat beltsº for details.
CAUTION!
Always make sure the shoulder
belt is positioned across the cen-
ter of child's shoulder. The belt
should be kept away from child's
neck, but not falling off child's
shoulder. Failure to do so could re-
duce the amount of protection in
an accident and cause serious in- juries in a collision.
High-positioned lap belts and
loose-fitting belts both could cause serious injuries due to slid-
ing under the lap belt during a col-
lision. Keep the lap belt positioned
as low on hips as possible.
For child's safety, do not place the
shoulder belt under child's arm.
After inserting the tab, make sure
the tab and buckle are locked and
that the lap and shoulder portions
of the belt are not twisted.
Do not insert coins, clips, etc. in
the buckle as this may prevent you
from properly latching the tab and buckle.
If the seat belt does not function
normally, it cannot protect your
child from injury. Contact your To-
yota dealer immediately. Do not
use the seat until the seat belt isfixed.

58
2. To remove the child restraint system,press the buckle-release button and
allow the belt to retact.If your child restraint system requires
the use of a top strap, latch the hook
onto the anchor bracket and tighten
the top strap.
See the following instructions to install the
anchor brackets.2-door models
4-door models
ÐTop strap anchors and locations

59
On the luggage compartment floor
a. Using the illustration as a guide, run your fingers across the luggage compart-
ment floor itself to locate the position of the bolts underneath. b. Remove the bolt.
c. Insert a 10 mm (0.4 in.) spacer and tighten down the anchor bracket for your
child restraint system with a bolt. Torque
the bolt to 16.5-24.7 N
Vm (1.68-2.52 kgr-
V m, 12.2-18.2 ft Vlbf).
To comply with Canada Motor Vehicle
Safety Standards, vehicles sold in Cana-
da are provided with a bracket set in the
glovebox, designed for use with any of the
2 anchor locations shown in the illustra- tion.
If your child restraint system does not pro-
vide any of the necessary parts, ask your
Toyota dealer. (See -Child restraint sys- temº.)
If you remove the anchor brackets when
the child restraint system is necessary no
longer, replace the bolts in the holes to
prevent entry of exhaust emissions, water
or dirt.
To change the steering wheel angle,
hold the steering wheel, push down
the lock release lever, tilt the steering
wheel to the desired angle and release
the lever.
CAUTION!
Do not adjust the steering wheel
while the vehicle is moving.
After adjusting the steering wheel,try moving it up and down to make sure it is locked in position.
Adjust the mirror so you can just see
the side of your vehicle in the mirror. Be careful when judging the size or dis- tance of any object seen in the outside
rear view mirror on the passenger's side.
It is a convex mirror with a curved surface.
Any object seen in a convex mirror will
look smaller and farther away than when
seen in a flat mirror.
Tilt steering wheel Outside rear view mirrorsÐ

59
On the luggage compartment floor
a. Using the illustration as a guide, run your fingers across the luggage compart-
ment floor itself to locate the position of the bolts underneath. b. Remove the bolt.
c. Insert a 10 mm (0.4 in.) spacer and tighten down the anchor bracket for your
child restraint system with a bolt. Torque
the bolt to 16.5-24.7 N
Vm (1.68-2.52 kgr-
V m, 12.2-18.2 ft Vlbf).
To comply with Canada Motor Vehicle
Safety Standards, vehicles sold in Cana-
da are provided with a bracket set in the
glovebox, designed for use with any of the
2 anchor locations shown in the illustra- tion.
If your child restraint system does not pro-
vide any of the necessary parts, ask your
Toyota dealer. (See -Child restraint sys- temº.)
If you remove the anchor brackets when
the child restraint system is necessary no
longer, replace the bolts in the holes to
prevent entry of exhaust emissions, water
or dirt.
To change the steering wheel angle,
hold the steering wheel, push down
the lock release lever, tilt the steering
wheel to the desired angle and release
the lever.
CAUTION!
Do not adjust the steering wheel
while the vehicle is moving.
After adjusting the steering wheel,try moving it up and down to make sure it is locked in position.
Adjust the mirror so you can just see
the side of your vehicle in the mirror. Be careful when judging the size or dis- tance of any object seen in the outside
rear view mirror on the passenger's side.
It is a convex mirror with a curved surface.
Any object seen in a convex mirror will
look smaller and farther away than when
seen in a flat mirror.
Tilt steering wheel Outside rear view mirrorsÐ

60
CAUTION!
Do not adjust the mirror while the
vehicle is moving. It may cause the
driver to mishandle the vehicle and
an accident may occur resulting inpersonal injuries.
To adjust a mirror, use the switches.
1. Master switchÐTo select the mirror to be adjusted Place the switch at Lº (left) or Rº (right)
2. Control switchÐTo move the mirror push the switch in the desired direc-tion.
If the engine is not running, the key must be in the ACCº position.
If ice should jam the mirror, do not operate the control or scrape the
mirror face. Use a spray de-icer to free the mirror.
NOTICE
ÐPower rear view mirror control

61
The rear view mirrors can be folded
backward for parking in restricted areas.
To fold the rear view mirror, push back- ward.
CAUTION!
Do not drive with the mirrors folded
backward. Both the driver and pas-
senger side rear view mirrors must
be extended and properly adjusted
before driving.
To reduce glare from the headlights of
the vehicle behind you during night
driving, operate the lever on the lower
edge of the mirror. Daylight drivingÐLever at position 1
The reflection in the mirror has greater
clarity at this position. Night drivingÐLever at position 2 Remember that by reducing glare you
also lose some rear view clarity.
Anti-glare
inside rear view
mirror
ÐFolding rear view mirrors
