1997 Lexus ES300 Service Procedures And Specifications: Engine

195
SECTION 6 ± 2
SERVICE PROCEDURES AND
SPECIFICATIONS
Engine
Specifications 196
Fuel 198
Facts about engine oil consumption 199
Used engine oil 201
Checking the engine oil level 201
Checking the engine coolant level 204

ENGINE
196
SPECIFICATIONS
±GENERAL
Model 1MZ±FE
Type 6 cylinder V type, 4 cycle, gasoline
Bore and stroke 87.5 X 83 mm (3.44 X 3.27 in.)
Displacement 2995 cm
3
(182.7 cu.in.)
Valve clearance (engine cold)
Intake 0.15 ± 0.25 mm (0.006 ± 0.010 in.)
Exhaust 0.25 ± 0.35 mm (0.010 ± 0.014 in.)
Drive belt tension (with Borroughs drive belt tension 115 + 20 lb.
gauge No. BT±33±73F)
±LUBRICATION SYSTEM
Oil capacity
Drain and refill
with filter 4.7 L (5.0 qt., 4.2 Imp.qt.)
without filter 4.5 L (4.8 qt., 4.0 Imp.qt.)
Oil grade API SH, Energy±Conserving II multigrade engine oil or
ILSAC multigrade engine oil
Recommended oil viscosity (SAE):

ENGINE
197 ±COOLING SYSTEM
Capacity 9.2 L (9.7 qt., 8.2 Imp.qt.)
Coolant type Ethylene ± glycol coolant (Do not use alcohol type.)
±FUEL
Fuel type Only UNLEADED
Research octane number 91 (Octane Rating 87) or higher
±IGNITION SYSTEM
Spark plug ±Make NIPPONDENSO PK20TR11
NGK BKR6EKPB11
±Gap 1.1 mm (0.043 in.)
±ELECTRICAL SYSTEM
Battery ± Maintenance type battery
Specific gravity reading at 205C (685F): 1.260 Fully charged
1.160 Half charged
1.060 Discharged
Charging rates Quick charge 15A max.
Slow charge 5A max.
± Non±maintenance battery
Open voltage at 205C (685F): 12.7V Fully charged
12.3V Half charged
11.9V Discharged
[Voltage that is checked 20 minutes after the key is
removed with all the lights turned off]
Charging rates 5A max.

ENGINE
198
FUEL
Fuel type
Your vehicle must use only unleaded gasoline.
To help prevent gas station mixups, your Lexus has a smaller
fuel tank opening. The special nozzle on pumps with
unleaded fuel will fit it, but the larger nozzle on pumps with
leaded gas will not.
NOTICE
Do not use leaded gasoline. Use of leaded gasoline
will cause the three±way catalytic converter to lose
its effectiveness and the emission control system to
function improperly. Also, this can increase
maintenance costs.
Octane number
Select Research Octane Number 91 (Octane Rating 87)
or higher. For improved vehicle performance, the use of
premium unleaded gasoline with a Research Octane
Number of 96 (Octane Rating 91) or higher is
recommended.
Use of unleaded fuel with an octane number or rating lower
than stated above will cause persistent heavy knocking. If
severe, this will lead to engine damage.If your engine knocks...
If you detect heavy knocking even when using the
recommended fuel, or if you hear steady knocking while
holding a steady speed on level roads, consult your Lexus
dealer.
However, now and then, you may notice light knocking for a
short time while accelerating or driving up hills. This is no
cause for concern.
Gasolines containing detergent additives
Lexus recommends use of gasolines that contain
detergent additives to avoid build±up of engine
deposits.
For further details, ask your Lexus dealer or a local gasoline
retailer.
Gasolines containing MTBE
Gasolines that contain MTBE (Methyl Tertiary±Butyl
Ether) are available on the market. If you use a gasoline
mixed with MTBE, make certain that it does not contain
more than 15% of MTBE.
If the use of gasolines containing MTBE causes poor
drivability and/or poor fuel economy, you should stop using
them.

ENGINE
199
Gasolines containing alcohol
Gasohol is a mixture of gasoline and ethanol. If you use
gasohol in your Lexus, be sure that it is unleaded, has
an octane rating no lower than 87 and does not contain
more than 10% ethanol. Lexus does not recommend the
use of gasolines containing methanol.
If you use gasoline containing methanol, use only gasoline
meeting the requirements above and also containing less
than 5% methanol with cosolvents and corrosion inhibitors
for methanol.
NOTICE
Do not use gasohol other than stated above. It
will cause fuel system damage or vehicle
performance problems.
If drivability problems are encountered (poor hot
starting, vaporizing, engine knock, etc.),
discontinue its use.
Take care not to spill gasohol during refueling.
Gasohol may cause paint damage.
Fuel tank capacity
70 L (18.5 gal., 15.4 Imp.gal.)
FACTS ABOUT ENGINE OIL
CONSUMPTION
Functions of engine oil
Engine oil has the primary function of lubricating and cooling
the inside of the engine, and plays a major role in maintaining
the engine in proper working order.
Engine oil consumption
It is normal that an engine should consume some
engine oil during normal engine operation. The causes
of oil consumption in a normal engine are as follows:
Oil is used to lubricate pistons, piston rings and cylinders.
A thin film of oil is left on the cylinder wall when a piston
moves downwards in the cylinder. High negative pressure
generated when the vehicle is decelerating sucks some of
the oil into the combustion chamber. This oil as well as
some part of the oil film left on the cylinder wall is burned
by the high temperature combustion gases during the
combustion process.
Oil is also used to lubricate the stems of the intake valves.
Some of this oil is sucked into the combustion chamber
together with the intake air and is burned along with the
fuel. High temperature exhaust gases also burn the oil
used to lubricate the exhaust valve stems.

ENGINE
200The amount of engine oil consumed depends on the
viscosity of the oil, the quality of the oil and the way the
vehicle is driven.
More oil is consumed under driving conditions such as high
speeds and frequent acceleration and deceleration.
A new engine consumes more oil, since its pistons, piston
rings and cylinder walls have not become conditioned.
When judging the amount of oil consumption, keep in
mind that the oil may have become diluted, making it
difficult to judge the true level accurately.
For example, if a vehicle is used for repeated short trips and
consumes a normal amount of oil, the dipstick may not show
any drop in the oil level at all, even after 1000 km (600 miles)
or more. This is because the oil is gradually becoming diluted
with fuel or moisture, making it appear that the oil level has
not changed.
The diluting ingredients evaporate out when the vehicle is
then driven at high speeds, as on an expressway, making it
appear that oil is excessively consumed after driving at high
speeds.
Importance of engine oil level check
One of the most important point in proper vehicle
maintenance is to keep the engine oil at the optimum level
so that oil function will not be impaired. Therefore, it is
essential that the oil level be checked regularly. Lexus
recommends that the oil level be checked every time you
refuel the vehicle.
NOTICE
Failure to check the oil level regularly could lead to
serious engine trouble due to insufficient oil.
For detailed information on oil level check, see ªChecking the
engine oil levelº on page 201.

ENGINE
201
USED ENGINE OIL
CAUTION!
Used engine oil contains potentially harmful
contaminants which may cause skin disorders
such as inflammation or skin cancer, so care
should be taken to avoid prolonged and repeated
contact with it. To remove used engine oil from
your skin, wash thoroughly with soap and water.
Do not leave used oil within the reach of children.
Dispose of used oil and used oil filters in a safe
and acceptable manner. Do not dispose of used
oil and used oil filters in household trash, in
sewers or onto the ground. Call your Lexus dealer
or a service station for information concerning
recycling or disposal.
CHECKING THE ENGINE OIL LEVEL
With the engine at operating temperature and turned
off, check the oil level on the dipstick.
1. To get a true reading, the vehicle should be on a level
spot. After turning off the engine, wait a few minutes for the
oil to drain back into the bottom of the engine.
2. Pull out the dipstick, and wipe it clean with a rag.
3. Reinsert the dipstick and push it in as far as it will go, or
the reading will not be correct.

ENGINE
202

Add oil O.K. Too full
4. Pull the dipstick out and look at the oil level on the end.
If it is between the full line ( ) and the low line ( ), it
is O.K.
If the oil level is below or only slightly above the low
level mark, add engine oil of the same type already in
the engine.
Remove the oil filler cap and add engine oil a little at a time,
checking the dipstick. The approximate quantity of oil
needed to fill between the low line and the full line on the
dipstick is indicated below for reference.
When the level reaches within the correct range, return the
filler cap and turn the cap clockwise until you hear a click.
Oil quantity. L (qt., Imp.qt.) 1.5 (1.6, 1.3)
NOTICE
Avoid overfilling, or the engine could be damaged.
Check the oil level on the dipstick once again after
adding oil.
