1997 HONDA ODYSSEY warning

If Your Engine Won't Start, Jump Starting
The Starter Operates Normally In this case, the starter motor'sspeed sounds normal, or even faster
than normal, when you turn the
ignition switch to START (III), but
the engine does not run.
Are you using the proper startingprocedure? Refer to Starting the
Engine on page 119.
Do you have fuel? Turn the
ignition switch to ON (II) for a
minute and watch the fuel gauge.
The low fuel level warning light may not be working, so you were
not reminded to fill the tank.
There may be an electrical problem, such as no power to the
fuel pump. Check all the fuses (see page 211).
If you find nothing wrong, you will
need a qualified technician to find
the problem. See Towing on page
215.
Jump Starting
If your car's battery has run down,
you may be able to start the engine by using a booster battery. Although
this seems like a simple procedure,
you should take several precautions.
You cannot start a Honda by pushing or pulling it. To jump start your car, follow these
directions closely:
1. Open the hood and check the physical condition of the battery(see page 164). In very cold
weather, check the condition of
the electrolyte. If it seems slushy or like ice, do not try jump starting
until it thaws.

If a battery sits in extreme cold, the electrolyte, inside can freeze.
Attempting to jump start with a frozen battery can cause it to rupture.

2. Turn off all the electrical acces-
sories: heater, A/C, stereo system,
lights, etc.
Put the transmission in Neutral or
Park and set the parking brake.

Taking Care of the Unexpected
A battery can explode if you do

not follow the correct procedure,
seriously injuring anyone nearby.
Keep all sparks, open flames,
and smoking materials away
from the battery.
NOTICEProCarManuals.comMain Menu Table of Contents s t

If Your Engine Overheats
The pointer of your car's tempera- ture gauge should stay in the mid-range under most conditions. It may
go higher if you are driving up a long steep hill on a very hot day. If it
climbs to the red mark, you should

determine the reason.

Driving with the temperature gauge
pointer at the red mark can cause serious damage to your engine. Your car can overheat for several
reasons, such as lack of coolant or a

mechanical problem. The only

indication may be the temperature

gauge climbing to or above the red mark. Or you may see steam or
spray coming from under the hood.

In either case, you should take

immediate action.
1. Safely pull to the side of the road.
Put the transmission in Neutral or
Park and set the parking brake.
Turn off the heating and cooling system and all other accessories.
Turn on the hazard warning indicators.
2. If you see steam and/or spray coming from under the hood, turnoff the engine.
3. If you do not see steam or spray, leave the engine running and
watch the temperature gauge. If the high heat is due to overloading (climbing a long, steep hill on a
hot day with the A/C running, for example), the engine should start
to cool down almost immediately. If it does, wait until the tempera-
ture gauge comes down to the mid-
point then continue driving.

Taking Care of the Unexpected

NOTICE

Steam and spray from an

overheated engine can

seriously scald you.

Do not open the hood if steam

is coming out.ProCarManuals.comMain Menu Table of Contents s t

Low Oil Pressure Indicator
This indicator should light when the ignition is ON (II), and go out after
the engine starts. It should never
come on when the engine is running.
If it starts flashing, it indicates that
the oil pressure dropped very low for
a moment, then recovered. If the indicator stays on with the engine
running, it shows that the engine has
lost oil pressure and serious engine
damage is possible. In either case,
you should take immediate action. Running the engine with low oil
pressure can cause serious mechanical damage almost immediately. Turn off
the engine as soon as you can safely get
the car stopped.
1. Safely pull off the road and shut off the engine. Turn on the hazard
warning indicators.
2. Let the car sit for a minute. Open the hood and check the oil level(see page 112). Although oil level
and oil pressure are not directly connected, an engine that is very
low on oil can lose pressure during cornering and other driving

maneuvers.

3. If necessary, add oil to bring the level back to the full mark on thedipstick (see page 148). 4. Start the engine and watch the oil
pressure indicator. If the lightdoes not go out within ten seconds,
turn off the engine. There is a
mechanical problem that needs to
be repaired before you can
continue driving. (See Towing on page 215.)
Taking Care of the Unexpected
NOTICE

LOW OIL PRESSURE INDICATORProCarManuals.comMain Menu Table of Contents s t

Tire Information

Traction
The traction grades, from highest to lowest, are A, B, and C, and they
represent the tire's ability to stop on
wet pavement as measured under controlled conditions on specified
government test surfaces of asphalt and concrete. A tire marked C may
have poor traction performance.
Warning: The traction grade as- signed to this tire is based on brak-
ing (straight ahead) traction tests
and does not include cornering (turning) traction.
Temperature

The temperature grades are A (the highest), B, and C, representing the
tire's resistance to the generation of
heat and its ability to dissipate heat
when tested under controlled conditions on a specified indoor
laboratory test wheel. Sustained high
temperature can cause the material of the tire to degenerate and reduce
tire life, and excessive temperature can lead to sudden tire failure. The
grade C corresponds to a level of
performance which all passenger car
tires must meet under the Federal Motor Vehicle Safety Standard No. 109. Grades B and A represent
higher levels of performance on the
laboratory test wheel than the
minimum required by law.
Warning: The temperature grade for

this tire is established for a tire that
is properly inflated and not over-

loaded. Excessive speed, underinfla-
tion, or excessive loading either
separately or in combination, can

cause heat build-up and possible tire

failure.

Technical InformationProCarManuals.comMain Menu Table of Contents s t

Index

DANGER, Explanation of................. ii
Dashboard........................................ 32
Dashboard Compartment............... 68
Daytime Running Lights................. 40
Dead Battery, What to Do............ 202
Defects, Reporting Safety............. 234
Defogger, Rear Window................. 43
Defrosting the Windows................. 79 DEXRON ®
III Automatic
Transmission Fluid.................... 157
Dimensions..................................... 220
Dimming the Headlights................ 40
Dipstick Automatic Transmission........... 157

Engine Oil................................... 112

Directional Signals........................... 41
Disabled, Towing Your Car If...... 215
Disc Brake Wear Indicators......... 125
Disposal of Used Oil...................... 151 Doors Locking and Unlocking............... 50
Power Door Locks....................... 50
DOT Tire Quality Grading........... 223
Drive Belts...................................... 170
Driving............................................ 117

Economy..................................... 114

In Bad Weather.......................... 126

In Foreign Countries................. 109

Economy, Fuel............................... 114

Emergencies on the Road............. 193
Battery, Jump Starting.............. 202

Changing a Flat Tire................. 195
Charging System Indicator ...... 207
Checking the Fuses................... 211
Low Oil Pressure Indicator...... 206
Malfunction Indicator Lamp .... 208
Manually Closing Sunroof........ 209
Overheated Engine................... 204

Emergency Brake............................ 65

Emergency Flashers....................... 43
Emission Controls......................... 225
Engine

Belts............................................. 170

Coolant Temperature Gauge ..... 38
Malfunction Indicator
Lamp................................. 34, 208

Oil Pressure Indicator......... 34, 206 Oil, What Kind to Use............... 148

Overheating................................ 204

Specifications............................. 221

Ethanol in Gasoline ....................... 109

Evaporative Emission Controls.... 225

Exhaust Fumes................................ 29

Expectant Mothers, Use of Seat
Belts by......................................... 10

Exterior, Cleaning the................... 186

Fabric, Cleaning............................. 188
Fan, Interior...................................... 74
Features, Comfort and Convenience................................. 73
Filling the Fuel Tank..................... 110
Filter
Air................................................ 160

Oil................................................ 150

First Gear Position......................... 122 Flashers, Hazard Warning.............. 43
Flat Tire, Changing a.................... 195
CONTINUEDProCarManuals.comMain Menu s t

Index

Fluids Automatic Transmission........... 157

Brake........................................... 158

Power Steering........................... 159
Windshield Washer................... 156
FM Stereo Radio
Reception...................................... 97

Folding the Second Seats ............... 58
Folding the Third Seats.................. 60
Foreign Countries, Driving in...... 109

Four-way Flashers........................... 43

Front End, Towing by Emergency Wrecker...................................... 215

Fuel.................................................. 108
Fill Door and Cap....................... 110

Gauge............................................ 38

Octane Requirement................. 108

Oxygenated................................ 108

Tank, Filling the......................... 110

Fuses, Checking the...................... 211

Gas Mileage, Improving................ 114

Gasohol........................................... 108
Gasoline.......................................... 108

Gauge............................................ 38

Octane Requirement................. 108
Tank, Filling the......................... 110
Gas Station Procedures................. 110
Gauges Engine Coolant Temperature .... 38

Fuel................................................ 38

Gearshift Lever Positions............. 120

Glass Cleaning............................... 189

Glove Box......................................... 53
Halogen Headlight Bulbs.............. 179 Hazard Warning Flashers............... 43
Headlights......................................... 40 Aiming......................................... 177
Daytime Running Lights............. 40
High Beam Indicator................... 36
High Beams, Turning on............ 40Low Beams, Turning on............. 40
Reminder Chime.......................... 40
Replacing Halogen Bulbs ......... 179

Turning on....................................
40

Head Restraints...............................
56Heating and Cooling........................ 74
High Altitude, Starting at.............. 119
High-Low Beam Switch .................. 40
Hood, Opening the ........................ 111
Horn................................................... 39
Hot Coolant, Warning about........ 152
Hydroplaning.................................. 129

Identification Number, Vehicle.... 218

If Your Car Has to be Towed....... 215

Ignition
Keys............................................... 49
Switch............................................ 49
Timing Control System............. 226
Indicator Lights, Instrument
Panel..............................................33

Infant Restraint................................ 22

Inflation, Proper Tire .................... 171

Inside Mirror.................................... 64

Inspection, Tire.............................. 173
Instrument Panel............................. 33

Instrument Panel Brightness......... 41

Interior Cleaning............................ 188
Interior Lights.................................. 70ProCarManuals.comMain Menu s t

Index

Tires Inspection................................... 173Replacing.................................... 174
Rotating....................................... 174
Snow............................................ 176
Specifications............................. 221
Transmission
Checking Fluid Level................ 157
Fluid Selection............................ 157
Identification Number............... 218
Shifting the Automatic.............. 120
Treadwear...................................... 223

Trip Meter........................................ 37

Turn Signals..................................... 41
Tools, Tire Changing.................... 195

Torn Seat Belts ................................ 11

Towing

A Trailer...................................... 130
Emergency Wrecker................. 215

Underside, Cleaning...................... 190
Unexpected, Taking Care
of the........................................... 193

Uniform Tire Quality Grading..... 223
Unleaded Gasoline......................... 108

Upholstery Cleaning...................... 188
Used Oil, How to Dispose of........ 151

Vanity Mirror................................... 68

Vehicle Capacity Load .................. 116

Vehicle Dimensions....................... 220

Vehicle Identification Number..... 218

Vehicle Storage.............................. 184

Ventilation......................................... 76
VIN.................................................. 218

Vinyl Cleaning................................ 188

Viscosity, Oil................................... 149 Operation...................................... 42
Washing.......................................... 186 Waxing and Polishing................... 187
Wheels Adjusting the Steering................ 44
Alignment and Balance............. 173
Compact Spare........................... 194
Wrench....................................... 197
Windows Cleaning...................................... 189
Operating the Power................... 62
Rear, Defogger............................ 44
Windshield Cleaning........................................ 42
Defroster...................................... 79
Wipers, Windshield Changing Blades........................ 166Operation...................................... 42
Rear Windshield Wiper and
Washer......................................43

Worn Tires..................................... 173
Wrecker, Emergency Towing...... 215
* : U. S. and Canada only
Warning Beepers
Key in Ignition.............................. 50

Seat Belts...................................... 34

WARNING, Explanation of.............. ii

Warning Labels, Location of.......... 30

Warranty Coverages*................... 233
Washer, Windshield Checking the Fluid Level......... 156ProCarManuals.comMain Menu s t
