1997 FORD WINDSTAR steering

108
%*
[CF21200(ALL)05/96]
Horn
[CF21300(ALL)01/96]
To sound the horn, press the center of the steering wheel. Check
the horn regularly to make sure it operates properly.
[CF21400(ALL)01/96]
13-1/2 pica
art:0050017-A
The horn pad
%*
[CF21500(ALL)05/96]
Hazard Flasher Switch
[CF21600(ALL)01/96]
The hazard flasher switch is located on top of the steering
column.
*
[CF21700(ALL)01/96]
To use the hazard flasher:
*
[CF21800(ALL)01/96]1.
Push the HAZARD switch; you will see the turn signal
arrows flash.
*
[CF21900(ALL)01/96]2.
To stop the hazard flashers, push the HAZARD switch again.
File:05wncfs.ex
Update:Wed Jul 31 15:55:37 1996

Controls and Features
109
%*
[CF22000(ALL)05/96]
Tilt Steering (If equipped)
[CF22100(ALL)01/96]
With the tilt steering option, you can move your steering wheel
up or down.
[CF22200(ALL)01/96]
17-1/2 pica
art:0050101-A
Tilt steering release lever location
[CF22300(ALL)04/96]
To change the position of the steering column:
[CF22400(ALL)04/96]1.
Make sure your vehicle is stopped.
[CF22500(ALL)04/96]2.
Pull the tilt release lever on the column toward you.
[CF22600(ALL)01/96]3.
Tilt the steering wheel up or down until you find the best
position for you.
[CF22700(ALL)04/96]4.
Release the lever to lock the wheel in place.
File:05wncfs.ex
Update:Wed Jul 31 15:55:37 1996

110
[CF22800(ALL)01/96]
Be sure the steering wheel is locked in place. It can only be
adjusted to specific positions. Do not adjust the steering wheel
while the vehicle is in motion.
%*
[CF22900(ALL)03/96]
Speed Control (If equipped)
*
[CF23000(ALL)05/96]
The speed of the vehicle cannot be automatically controlled until
the vehicle speed is at or above 30 mph (48 km/h).
[CF23100(ALL)01/96]
When driving in hilly terrain, at high elevations, or when
pulling a trailer, it may be desirable to drive in the Overdrive
Lockout mode. This can be done by depressing the O/D button
on the end of the gearshift lever. Driving in this mode helps
prevent excessive transaxle shifting and helps speed control to
maintain speed when going down steep hills.
*
[CF23200(ALL)05/96]
Use of radio transmitting equipment that is not Federal
Communications Commission (FCC) or in Canada the Canadian
Radio and Telecommunications Commission (CRTC) approved
may cause the speed control to malfunction. Therefore, use only
properly installed FCC (CRTC in Canada) approved radio
transmitting equipment in your vehicle.
*
[CF23300(ALL)09/95]
NOTE: Do not shift to N (Neutral) when using the speed
control. This will cause the engine to overspeed.
File:05wncfs.ex
Update:Wed Jul 31 15:55:37 1996

Controls and Features
111
[CF23400(ALL)01/96]
13-1/2 pica
art:0050018-A
The speed control switches on the steering wheel
*
[CF23500(ALL)05/96]
To set the speed control:
[CF23600(ALL)04/96]1.
Find the speed control switches on the steering wheel.
[CF23700(ALL)04/96]2.
Press and release the ON switch.
[CF23800(ALL)04/96]3.
Accelerate to the desired speed above 30 mph (50 km/h)
using the accelerator pedal.
*
[CF23900(ALL)01/96]4.
Make sure you are driving faster than 30 mph (50 km/h).
[CF24000(ALL)01/96]5.
Press SET ACCEL and release it immediately. This will set
your speed. If you keep this switch pressed, your speed will
continue to increase and will not be set at the desired speed.
[CF24100(ALL)01/96]6.
Take your foot off the accelerator pedal. Your vehicle will
maintain the speed you set.
*
[CF24200(ALL)05/96]
If you drive up or down a steep hill, your vehicle may
momentarily slow down or speed up, even though the speed
control is on. This is normal.
File:05wncfs.ex
Update:Wed Jul 31 15:55:37 1996

218
*
[TO01500(ALL)12/95]3.
DO NOT depress the accelerator pedal when starting your
engine. DO NOT use the accelerator until after the engine is
running and you are ready to drive away.
[TO01600(ALL)12/95]4.
Turn the key to the START position until the engine starts.
(Release the key after the engine has started and it will
return to the ON position.)
[TO01700(ALL)12/95]
If you have difficulty in turning the key, rotate the steering
wheel slightly to relieve any binding.
%*
[TO01800(ALL)01/96]
For a cold engine:
*
[TO01900(ALL)01/96]
n
At temperatures10ÊF (-12ÊC) andbelow:If the engine does
not start infifteen (15) secondson the first try, turn the key
to OFF, wait approximately ten (10) seconds so you do not
flood the engine, then try again.
*
[TO02000(ALL)01/96]
n
At temperaturesabove10ÊF(-12ÊC):If the engine does not
start infive (5) secondson the first try, turn the key to OFF,
wait approximately ten (10) seconds so you do not flood the
engine, then try again.
*
[TO02100(ALL)01/96]
For a warm engine:
*
[TO02200(ALL)01/96]
n
Do not hold the key in the START position for more than
five (5) secondsat a time. If the engine does not start within
five (5) seconds on the first try, turn the key to the OFF
position. Wait a few seconds after the starter stops, then try
again.
*
[TO02300(ALL)01/96]
Whenever you start your vehicle, release the key as soon as the
engine starts. Excessive cranking could damage the starter.
*
[TO02400(ALL)01/96]
After you start the engine, let it idle for a few seconds.Keep
your foot on the brake pedaland release the parking brake.
Put the gearshift lever in gear, slowly release the brake pedal
and drive away in the normal manner.
File:08wntos.ex
Update:Thu Jul 18 11:01:04 1996

228
%*
[GF04100(ALL)01/96]
Steering Your Vehicle
*
[GF04200(ALL)01/96]
Your vehicle has power steering. Power steering uses energy
from the engine to help steer your vehicle.
*
[GF04300(ALL)01/96]
Never hold the steering wheel in the extreme right or left
position for more than five seconds if the engine is running.
This can damage the power steering pump.
%*
[GF04400(ALL)03/96]
If the amount of effort needed to steer your vehicle changes at a
constant vehicle speed, have the power steering system checked.
If the power steering system breaks down (or if the engine is
turned off), you can steer the vehicle manually but it takes more
effort.
*
[GF04500(ALL)01/96]
NOTE: After any severe impact such as striking large
potholes, sliding into curbs on icy roads, or a collision
involving the front end, have the front suspension
and steering checked for possible damage.
%*
[GF04600(ALL)01/96]
Automatic Transaxle Operation
%*
[GF04700(ALL)05/96]
Putting Your Vehicle in Gear
[GF04800(ALL)01/96]
Your vehicle's gearshift lever is on the steering column. The
OVERDRIVE ON/OFF button is located on the end of the
gearshift lever. You can put the gearshift lever in any one of
several positions.
File:09wngfs.ex
Update:Thu Jul 18 11:01:42 1996

Roadside Emergencies
259
[ER05200(ALL)01/96]
17-1/2 pica
art:0050215-D
The relay box cover located under the instrument panel
%*
[ER05300(ALL)01/96]
Changing a Flat Tire
*
[ER05400(ALL)02/96]
If you get a flat tire while you are driving, do not apply the
brake heavily. Instead, gradually decrease the speed. Hold the
steering wheel firmly and slowly move to a safe place on the
side of the road. Park on a level spot, turn off the ignition, set
the parking brake, and turn on the hazard flashers.
% [ER05500(ALL)01/96]
Using the Spare Tire
*
[ER05600(ALL)01/96]
Your vehicle has a temporary spare tire (unless you ordered the
optional full-size spare tire). This spare tire is smaller than a
regular tire and is designed for emergency use only. Use it only
when you get a flat tire and replace it as soon as you can. This
spare tire is marked with the words TEMPORARY USE ONLY
so that you can easily identify it.
File:10wners.ex
Update:Tue Jul 9 12:14:55 1996

296
*
[MC11200(ALL)05/96]
Leave the coolant in all year. Make sure that the coolant will
not freeze at the temperature level in which you usually drive
during winter months. Keep an engine coolant in your engine
that has a protection rating of at leasts20ÊF (s29ÊC).
*
[MC11300(ALL)05/96]
To find out how much engine coolant mixture your vehicle's
coolant system can hold, seeRefill CapacitiesinCapacities and
Specificationschapter.
[MC11400(ALL)01/96]
You may add water by itself only in an emergency, but you
should replace it with a 50/50 mixture of water and coolant as
soon as possible.
*
[MC11500(ALL)05/96]
Have your dealer check the engine cooling system for leaks if
you have to add engine coolant more than once a month, or
you have to add more than a quart (liter) at a time.
%*
[MC11600(ALL)01/96
]
Checking Hoses
*
[MC11700(ALL)01/96]
Inspect all engine and heater system hoses for deterioration,
leaks and loose clamps before adding or replacing engine
coolant. Make whatever repairs or replacements are necessary
using Motorcraft parts or their equivalents.
%*
[MC11800(ALL)05/96
]
Engine Coolant Drain and Flush
[MC11900(ALL)01/96]
To drain and flush your engine coolant, youMUSTsee your
Ford dealer or refer to the procedure in the service manual.
Failing to do so could result in engine damage.
% [MC12000(ALL)04/96]
Power Steering Fluid
*
[MC12100(ALL)01/96]
Check the level of the power steering fluid at least twice a
year (i.e., every Spring and Fall).
*
[MC12200(ALL)01/96]
To check the level of your power steering fluid:
[MC12300(ALL)01/96]1.
Start the engine and let it run until the power steering fluid
reaches normal operating temperature. The power steering
fluid will reach the right temperature after at least five
minutes of idling or at least one mile (1 km) of driving.
File:11wnmcs.ex
Update:Mon Jul 8 14:29:32 1996
