1997 FORD F250 ESP

216 [GF22710(F )04/96]q
If necessary, add weight to the rear of the
vehicle or bed to obtain the above and to
comply with U.S. Federal Hydraulic Brake
Requirements, when aftermarket equipment is
added.
[GF22720(F )04/96]
q
The Front Axle Accessory Reserve Capacity
and the Total Accessory Reserve Capacity
listed on the Safety Compliance Certification
Label will help you to determine if the
addition of a snowplow will overload the
vehicle. The total of the weights of all
permanently installed accessories including
the snowplow mount, but not the snowplow
or any other easily removable accessories
must not exceed the Total Accessory Reserve
Capacity. Additionally, the portion of these
weights distributed to the front axles must
not exceed the Front Axle Accessory Reserve
Capacity.
[GF22730(F )04/96]
q
The weight of the snowplow and related
equipment should be properly matched to the
load capacity of your vehicle. The weight of
the installed equipment must not load the
vehicle beyond the GAWR and GVWR listed
on the Safety Compliance Certification Label.
[GF22750(F )04/96]
Equip your vehicle with lights that conform to
Federal and local regulations for snowplowing.
See your dealer for the correct type of wiring.
[GF22760(F )04/96]
Do not plow snow until your vehicle has been
driven 500 miles (800 km). Maintain the vehicle
and snowplow equipment in accordance with
their respective manufacturer's recommendations.
Refer to the notes under Scheduled Maintenance
Services when plowing snow for extended
periods.
File:09ltgff.ex
Update:Thu May 30 15:25:49 1996
ProCarManuals.com

246
*
[ER14500(F )01/96]
one third page art:0020939-B
[ER14600(F )04/96]
b. Turn the jack handle clockwise until the
wheel is completely off the ground.
[ER15300(F )01/96]
3. Remove the lug nuts with the lug nut
wrench.
[ER15400(F )01/96]
4. Replace the flat tire with the spare tire.
[ER15500(F )04/96]
If your vehicle has dual rear wheels, there are
locating pins on the hubs and wheels with
corresponding holes. When you put the wheel
back on, make sure the pins are lined up with
the proper holes.
[ER15700(F )01/96]
If your vehicle has single rear wheels, thread the
lug nuts on the wheel studs with the beveled
face toward the wheel. Use the lug nut wrench
to screw the lug nut snugly against the wheel
but do not tighten.
[ER15800(F )04/96]
If your vehicle has dual rear wheels, thread the
two-element swiveling lug nut on the wheel
studs with the flange face toward the wheel. Use
the lug nut wrench to screw the lug nut snugly
against the wheel but do not tighten.
File:10lterf.ex
Update:Tue May 28 08:49:52 1996
ProCarManuals.com

258vibration, or other indication that your vehicle
may need service. If you do notice something
unusual, see that your vehicle is serviced
promptly.
%
*
[MC01200(FM)01/96]
Precautions When Servicing Your
Vehicle
*
[MC01300(FM)01/96]
Be especially careful when inspecting or
servicing your vehicle. Here are some general
precautions for your safety:
*
[MC01400(FM)01/96]
q
If you must work with the engine running,
avoid wearing loose clothing or jewelry that
could get caught in moving parts. Take
appropriate precautions with long hair.
*
[MC01500(FM)01/96]
q
Do not work on a vehicle in an enclosed
space with the engine running, unless you are
sure you have enough ventilation.
*
[MC01600(FM)01/96]
q
Never get under a vehicle while it is
supported only by a jack. If you must work
under a vehicle, use safety stands.
*
[MC01700(FM)01/96]
q
Keep all lit cigarettes and other smoking
materials away from the battery and all
fuel-related parts.
*
[MC01800(FM)01/96]
If you disconnect the battery, the engine must
ªrelearnº its idle conditions before your vehicle
will drive properly. To find out how the engine
does this, seeBatteryin this chapter.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

268 [MC09000(F )04/96]If the above conditions do not apply, change
the engine oil and oil filter every 6 months or
5,000 miles (8,000 km), whichever comes first.
*
[MC09100(FM)02/96]
Refer to theMaintenance Schedulebooklet for
additional information.
[MC09200(F )04/96]
NOTE: Refer to thePower Stroke Diesel Engine
Owner's Guide Supplementfor oil
viscosity, filter application and oil and
filter change intervals.
%*
[MC09300(FM)04/96]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
*
[MC09400(FM)01/96]
RWARNING
Continuous contact with USED motor oil
has caused cancer in laboratory mice.
*
[MC09500(FM)01/96]
Protect your skin by washing with soap and
water.
%
*
[MC09600(FM)01/96]
Brake Fluid
*
[MC09625(FM)01/96]
Your vehicle is equipped with a brake fluid level
indicator in the master cylinder which lights the
BRAKE warning light on the instrument panel
when the brake fluid level is low.
*
[MC09650(FM)01/96]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake lining wears.
*
[MC09675(FM)01/96]
Check the brake fluid at least once a year. You
can do this by looking at the fluid level in the
plastic brake fluid reservoir on the master
cylinder. The fluid level should be at or near the
MAX mark.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

277 % [MC13000(FM)04/96]
NOTE: Do not use an engine coolant that does
not meet all 14 requirements of Ford
Specification ESE-M97B44-A. The use
of an improper coolant may void your
warranty for the engine cooling system.
Use only a premium nationally
recognized brand name engine coolant.
*
[MC13050(FM)04/96]
Ford Motor Company expressly authorizes the
Ford Rotunda engine coolant recycling process
and chemicals. If you choose to use recycled
coolant, use only Ford Rotunda recycled engine
coolant or an equivalent recycled engine coolant
that is certified by the supplier to meet Ford
specification ESE-M97B44-A.
%*
[MC13100(FM)04/96]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
%*
[MC13150(FM)01/96]
Use Ford Premium Cooling System Fluid or an
equivalent engine coolant that meets Ford
Specification ESE-M97B44-A. Do not use alcohol
or methanol antifreeze and do not use engine
coolant mixed with alcohol or methanol
antifreeze. If you do not use the proper coolant,
the aluminum radiator on your vehicle will
corrode.
*
[MC13200(FM)01/96]
Leave the engine coolant in all year. Make sure
that the coolant will not freeze at the
temperature level in which you drive during
winter months. Keep a mixture of engine coolant
in your engine that has a protection rating of at
least-34ÊF (-37ÊC), orwhatever protection rating
is appropriate for the climate in which you live.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

284
*
[MC22150(FM)01/96]
Wipe off the dipstick cap, pull the dipstick out
and wipe the indicator end clean. Put the
dipstick back into the filler tube and make sure
it is fully seated. Pull the dipstick out and read
the fluid level.
*
[MC22200(FM)01/96]
When checking fluid at normal operating
temperature, the fluid level should be within the
crosshatched area on the dipstick. When the
vehicle has not been driven, and outside
temperature is above50ÊF (10ÊC), thefluid level
should be between the holes on the dipstick.
%*
[MC22250(FM)01/96]
Adding Automatic Transmission Fluid
*
[MC22300(FM)01/96]
The fluid type is stamped on the dipstick.
Before adding any fluid, be sure that the
correct type will be used.
*
[MC22350(FM)01/96]
Add fluid in 1/2 pint (.25L) increments through
the filler tube to bring the level to the correct
area on the dipstick. If an overfill occurs, excess
fluid should be removed by a qualified
technician.
%*
[MC22400(FM)04/96]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

291
*
[MC27430(FM)01/96]
Traction A B C
*
[MC27440(FM)01/96]
The traction grades, from highest to lowest, are
A, B, and C, and they represent the tire's ability
to stop on wet pavement as measured under
controlled conditions on specified government
test surfaces of asphalt and concrete. A tire
marked C may have poor traction performance.
Warning: The traction grade assigned to this tire
is based on braking (straight ahead) traction tests
and does not include cornering (turning)
traction.
*
[MC27460(FM)01/96]
Temperature A B C
[MC27470(FM)03/96]
The temperature grades are A (the highest), B,
and C, representing the tire's resistance to the
generation of heat and its ability to dissipate
heat when tested under controlled conditions on
a specified indoor laboratory test wheel.
Sustained high temperature can cause the
material of the tire to degenerate and reduce tire
life, and excessive temperature can lead to
sudden tire failure. The grade C corresponds to
a level of performance which all passenger car
tires must meet under the Federal Motor Vehicle
Safety Standard No. 109. Grades B and A
represent higher levels of performance on the
laboratory test wheel than the minimum
required by law. Warning: The temperature
grade for this is established for a tire that is
properly inflated and not overloaded. Excessive
speed, underinflation, or excessive loading, either
separately or in combination, can cause heat
buildup and possible tire failure.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com

302
%*
[MC38925(FM)01/96]
Emission Control System
*
[MC38950(F )01/96]
Your vehicle is equipped with a catalytic
converter which enables your vehicle to comply
with applicable exhaust emission requirements.
*
[MC38975(FM)01/96]
RWARNING
Exhaust leaks may result in the entry of
harmful and potentially lethal fumes into
the passenger compartment. Under
extreme conditions excessive exhaust
temperatures could damage the fuel
system, the interior floor covering, or
other vehicle components, possibly
causing a fire.
*
[MC39000(F )01/96]
To make sure that the catalytic converter and the
other emission control parts continue to work
properly:
*
[MC39075(FM)01/96]
q
Avoid running out of fuel.
*
[MC39100(FM)01/96]
q
Do not turn off the ignition while your
vehicle is moving, especially at high speeds.
*
[MC39125(FM)02/96]
q
Have the services listed in theMaintenance
Schedulebooklet performed according to the
specified schedule. The scheduled
maintenance services are required because
they are considered essential to the life and
performance of your vehicle and to its
emissions system.
*
[MC39150(FM)01/96]
In general, maintenance, replacement, or service
of the emissions control devices or systems in
your new Ford Motor Company vehicle or
engine may be performed at your expense by
any automotive repair establishment or
individual using automotive parts equivalent to
those which your vehicle or engine was
originally equipped.
File:11ltmcf.ex
Update:Tue May 28 08:52:04 1996
ProCarManuals.com
