115 [SS17200(F )01/96]
one third page art:0020638-C
Fastening occupant safety lap belts
[SS17300(F )01/96]
To fasten the belt, pull the belt across your hips
and insert the tongue into the correct buckle on
your seat until you hear a snap and feel it latch.
Make sure the buckle is securely fastened by
pulling tongue.
*
[SS17400(F )05/96]
Adjust the belt so that it fits snugly and as low
as possible around the hips:
*
[SS17500(F )01/96]
q
If you need to lengthen the belt, unfasten it
and repeat the procedure above.
*
[SS17600(F )01/96]
q
If you need to shorten the belt, pull on the
loose end of the webbing.
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

122 [SS26800(F )04/96]
RWARNING
If the shoulder belt cannot be properly
positioned, move the child to one of the
seats with a lap belt only (preferably in a
rear seat) and use the lap belt.
*
[SS26900(F )01/96]
Lap belts and the lap belt portion of lap and
shoulder belts should always be worn snugly
and below the hips, touching the child's thighs.
*
[SS27000(F )02/96]
RWARNING
Children should always ride with the
seatback in the fully upright position.
%*
[SS27100(F )01/96]
Safety Seats for Children
*
[SS27200(F )01/96]
Use a safety seat that is recommended for the
size and weight of the child. Always follow the
safety seat manufacturer's instructions when
installing and using the safety seat.
*
[SS27300(F )01/96]
Ford recommends the use of a child safety seat
having a top tether strap. Install the child safety
seat in a seating position which is capable of
providing a tether anchorage. For more
information on top tether straps seeAttaching
Safety Seats With Tether Strapsin this chapter.
[SS27400(F )01/96]
When installing a child safety seat, be sure to
use the correct safety belt buckle for that seating
position making sure the tongue is securely
fastened in the buckle and for a shoulder/lap
belt combination with a sliding tongue make
sure the retractor is in the ªautomatic locking
mode.º
*
[SS28300(F )05/96]
All child restraint systems are designed to be
secured in vehicle seats by lap belts or by the
lap portion of a lap-shoulder belt.
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

123
*
[SS28400(F )03/96]
RWARNING
If you do not properly secure the safety
seat, the child occupying the seat may be
injured during a collision or sudden stop.
An unsecured safety seat could also injure
other passengers.
*
[SS28500(F )03/96]
RWARNING
Carefully follow all of the manufacturer's
instructions included with the safety seat
you put in your vehicle. If you do not
install and use the safety seat properly,
the child may be injured in a sudden stop
or collision.
*
[SS28600(F )01/96]
RWARNING
Seatbacks should be upright for use with
child safety seats.
*
[SS28700(F )05/96]
RWARNING
Always keep the buckle release button
pointing upward and away from the child
seat, with the tongue between the child
seat and the release button as shown in
the following illustration.
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

127
*
[SS30300(F )01/96]
4. Insert the belt tongue into the buckle for that
seating position until you hear and feel the
latch engage. See Figure 3. Make sure tongue
is latched securely to buckle by pulling on
tongue.
*
[SS30400(F )01/96]
half page art:0011240-B
Buckling the belt
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

130
*
[SS31100(F )01/96]
7. Before placing the child in the child seat,
forcibly tilt the seat from side to side, and
tug it forward to make sure that the seat is
securely held in place. See Figure 7.
*
[SS31200(F )04/96]
half page art:0011244-B
Checking that the seat is secure
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

131
*
[SS31300(F )01/96]
8. Double check that the retractor is in the
automatic locking mode. Try to pull more
belt out of the retractor. If you cannot, the
belt is in the automatic locking mode. See
Figure 8.
*
[SS31400(F )04/96]
half page art:0011245-C
Checking the retractor
*
[SS31500(F )01/96]
9. Check to make sure that the child seat is
properly secured prior to each use. If the
retractor is not locked, repeat steps 4
through 7.
*
[SS31600(F )01/96]
To remove the retractor from automatic lock
mode, allow webbing to retract fully to its
stowed position and the retractor will
automatically switch back to the vehicle sensitive
locking mode for normal adult usage.
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

132
*
[SS31700(F )05/96]
Installing a Child Safety Seat at the Center
Seating Position with Locking Adjustable
Lap Belt
*
[SS31800(F )01/96]
1. Lengthen the lap belt. To lengthen the belt,
hold the tongue so that its bottom is
perpendicular to the direction of webbing
while sliding the tongue up the webbing.
*
[SS31900(F )01/96]
2. Place the child safety seat in the center
seating position.
*
[SS32000(F )01/96]
3. Route the tongue and webbing through the
child seat according to the child seat
manufacturer's instructions.
*
[SS32100(F )01/96]
4. Insert the belt tongue into the proper buckle
for the center seating position until you hear
a snap and feel it latch. Make sure the
tongue is securely fastened to the buckle by
pulling on tongue.
*
[SS32200(F )01/96]
5. Push down on the child seat while pulling
on the loose end of the lap belt webbing to
tighten the belt.
*
[SS32300(F )01/96]
6. Before placing the child into child seat,
forcibly tilt the child seat from side-to-side
and in forward directions to ensure that the
seat is held securely in place. If the child
seat moves excessively, repeat steps 5
through 6, or properly install the child seat
in a different seating position.
File:06ltssf.ex
Update:Tue May 28 08:44:33 1996
ProCarManuals.com

134 [SS36000(F )04/96]If a tethered seat is installed in the front seat,
Ford recommends placement of the tethered
safety seat in the center front seating position,
with the tether strap secured to the center rear
lap belt tongue or to the webbing of the buckled
center rear lap belt behind the child safety seat.
[SS36100(F )04/96]
The rear lap/shoulder safety belts should not be
used to secure the tether strap of a safety seat
located in the front seat.
*
[SS36200(F )01/96]
RWARNING
Follow these precautions to decrease the
chance of injury in an accident.
*
[SS36400(F )03/96]
In SuperCabs equipped with Center Facing Jump
Seats, the tether strap anchor bracket should be
installed only at the center of the cab's back
panel with the child seat in the front center
seating position. Installing an anchor bracket at
the right rear of the cab may increase risk of
injury to an occupant of the right rear center
facing jump seat in the event of a collision or
sudden stop. If a tethered child seat is installed
in the right front seating position, secure the
tether strap to the webbing of the buckled right
rear lap belt.
*
[SS36500(F )01/96]
RWARNING
Do not install a child seat in a center
facing jump seat.
