1997 FORD F150 Audio Guide

Audio systems 2
Controls and features 6
Display 22
Care and cleaning 24
Radio frequency information 26
Warranties and service 27
Index 28
Table of Contents
1

AUDIO OPTIONS
Electronic stereo radio
Electronic stereo cassette
FM 1ST
VOL – PUSH ON
AM
FMBASS TREBBAL FADECLK
SEEK
TUNESCAN
123 4 5 6
REW
1FF
2SIDE 1-2
3
FM 1ST
VOL – PUSH ON
AM
FMBASS TREBBAL FADE
CLK
SEEK
TUNESCAN
456
DOLBY SYSTEMEJTAPE
Audio systems
2

Stereo cassette with CD DJ
REW
1FF
2SIDE 1-2
3
FM 1ST
VOL – PUSH ON
AM
FMBASS TREBBAL FADE
AUTO
SET CLK
SEEK
TUNE
DISCSSCAN
4
DOLBY SYSTEMEJTAPE CD
COMP5SHUFFLE
6
Audio systems
3

SYSTEM FEATURES
Electronic
Search
Radio (ESR)
Electronic
Search Radio
with Cass-
ette (ESC)
ESC with
CD DJ
(Compact Disc
Changer)Name
Radio Station
Memory Preset
AM/FM Select
Bass Adjust
Treble Adjust
Speaker
Balance Adjust
Speaker
Fade Adjust
Seek Function
Tune Adjust
Scan Function
Tape Eject4
4
4
4
4
4
4
4
44
4
4
4
4
4
4
4
4
44
Volume/Power
Control444
4
4
4
4
4
4
4
4
4
1
23456
AM
FM
BASS
TREB
BAL
FADE
TUNETUNE
DISCS
SEEK
SCAN
EJ
4= Feature included on audio system
VOL – PUSH ON
Audio System Feature Audio System
or
Audio systems
4

Electronic Search
Radio (ESR)
Electronic Search
Radio with
Cassette (ESC)
ESC with CD DJ
(Compact Disc
changer)Name
Tape Play Select
CD Play Select
Rewind Function
Fast Forward
Function
Tape Direction
Select
Dolby® Noise
Reduction
Compression Adjust
Shuffle Feature
Autoset Memory
Preset
Clock44
4
44
44
44
44
4
4
4
4 4
4
4
TAPE
CD
REW
1
FF
2
SIDE 1-2
3
COMP5
SHUFFLE
6
AUTO
SET
CLK
= Feature included on audio system
4or
or
CLK
Audio System Feature Audio System
Audio systems
5

CONTROLS AND FEATURES
Volume/power control
Press the control to turn the audio
system on or off.
Turn control to raise or lower
volume.
If you turn off the ignition before
turning off the audio system, the
audio system will come back on at
a preset medium level volume
when the ignition switch is turned
back on. If you wish to maintain
your preset volume level, turn the
audio system off with the power
control before switching off the
ignition.
Radio station memory preset
The radio is equipped with six
station memory preset controls.
These controls can be used to
select up to six preset AM stations
VOL – PUSH ON
VOL – PUSH ON
Controls and features
6

and twelve FM stations (six in FM1
and six in FM2).
Setting memory preset stations
1. Select the frequency band with
the AM/FM select control.
2. Select a station. Refer toTune
adjustorSeek functionfor more
information on selecting a station.
3. Press and hold a memory preset
control until the sound returns,
indicating the station is held in
memory on the control you
selected.
Autoset memory preset (if
equipped)
Autoset allows you to set strong
radio stations without losing your
original manually set preset
stations. This feature is helpful on
trips when you travel between
cities with different radio stations.
AM
FMBASS TREB
1
23456
Controls and features
7

AM/FM select
The AM/FM select control works in
radio, tape and CD modes (if
equipped).
AM/FM select in radio mode
This control allows you to select
AM or FM frequency bands. Press
the control to switch between AM,
FM1 or FM2 memory preset
stations.
AM/FM select in tape mode
Press this control to stop tape play
and begin radio play.
AM/FM select in CD mode
Press this control to stop CD play
and begin radio play.
You can switch from CD play to
tape play be simply inserting a
tape into the cassette deck.
AM
FMBASS TREB
AM
FMBASS TREB
Controls and features
8
