1997 FORD ASPIRE jacking

132 %
*
[ER05100(ALL)02/96]
Spare Tire Location
[ER05600(ALL)01/96]
The spare tire and tools are stored in the rear
luggage compartment, under the carpet and
floorboard.
[ER05700(ALL)01/96]
half page art:0032236-B
The location of the temporary spare tire and jacking
equipment
[ER07500(ALL)01/96]
one third page art:0030145-C
The tool kit in the spare tire compartment
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997

136 %
*
[ER08650(ALL)01/96]
Removing and Replacing the Tire
[ER08700(ALL)04/96]
1. Find the jacking location near the door of
the tire that you are changing. Position the
jack and turn the handle of the jack
clockwise until the wheel is completely off
the ground.
*
[ER08800(ALL)01/96]
WARNING
To lessen the risk of personal injury, do
not put any part of your body under the
vehicle while changing a tire. Do not start
the engine when your vehicle is on the
jack. The jack is only meant for changing
the tire.
[ER09200(ALL)01/96]
one third page art:0032213-A
Jack mounting position
[ER09600(ALL)04/96]
2. Remove the wheel lug bolts by using the lug
wrench. Never loosen the hub nuts. See the
illustration following Step 1Preparing to
Change the Tireif you are not sure where to
find the wheel bolts.
[ER09700(ALL)01/96]
3. Replace the flat tire with the spare tire. Keep
the retaining tool in place.
File:10icerf.ex
Update:Tue Mar 4 08:55:59 1997
