− SUSPENSION AND AXLEREAR LEAF SPRING
SA−163
1996 TOYOTA T100 (RM449U)
(d) Remove the 2 shackle pin mounting nuts and washers.
Torque: 91 N·m (930 kgf·cm, 67 ft·lbf)
HINT:
At the time of installation, after stabilizing the suspension,
torque the nut.
(e) Remove the shackle pin, plate and bushings and rear leaf
spring.

Downloaded from www.Manualslib.com manuals search engine R06802
SA0IF−01
SA0617
FA0157
Z03060
FA0160
SA−164
− SUSPENSION AND AXLEREAR LEAF SPRING
1996 TOYOTA T100 (RM449U)
REPLACEMENT
1. REPLACE BUSHING
Using a socket wrench and press, replace the bushing.
2. REPLACE LEAF SPRING
(a) Bend to open the spring clip.
Using a chisel and hammer, pry up the spring clip.
(b) Remove the center bolt.
Hold the spring near the center bolt in a vise and remove
the center bolt.
(c) Replace the spring clip.
(1) Drill off the head of the rivet and drive it out.
(2) Install a new rivet into the holes of the leaf spring
and clip. Then rivet with a press.
(d) Install the center bolt.
(1) Align the leaf spring holes and secure the leaves
with a vise.
(2) Install the spring center bolt.
Torque: 44 N·m (450 kgf·cm, 33 ft·lbf)

Downloaded from www.Manualslib.com manuals search engine R04069
W00479
W00480
− SUSPENSION AND AXLEREAR LEAF SPRING
SA−165
1996 TOYOTA T100 (RM449U)
(e) Bend the spring clip.
Using a hammer, bend the spring clip into the position.
3. REPLACE SPRING BUMPER
(a) Remove rear wheel.
Torque: 103 N·m (1,050 kgf·cm, 76 ft·lbf)
(b) Remove spring bumper.
(1) STD 0.5 ton, Extra cab:
Remove the 2 bolts, spring bumper and spacers.
Torque: 29 N·m (300 kgf·cm, 22 ft·lbf)
HINT:
At the time of installation, install the spacers, as shown in the
illustration.
(2) STD 1.0 ton:
Remove the 2 bolts, spring bumper and bumper
block spacers.
Torque: 29 N·m (300 kgf·cm, 22 ft·lbf)
HINT:
At the time of installation, install the spacers, as shown in the
illustration.

Downloaded from www.Manualslib.com manuals search engine SA0IG−01
SA−166
− SUSPENSION AND AXLEREAR LEAF SPRING
1996 TOYOTA T100 (RM449U)
INSTALLATION
Installation is in the reverse order of removal (See page SA−162).
