− IGNITION (3RZ−FE)DISTRIBUTOR
IG−11
1996 TOYOTA T100 (RM449U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page IG−8)

Downloaded from www.Manualslib.com manuals search engine IG0LB−01
IG−12
− IGNITION (3RZ−FE)DISTRIBUTOR
1996 TOYOTA T100 (RM449U)
INSTALLATION
1. CHECK NO. 1 CYLINDER TO TDC/COMPORESSION
If necessary, remove the cylinder head cover, and check these
conditions:
Turn the crankshaft pulley clockwise and align its
groove with the timing mark ”0” of the oil pump cov-
er.
Verify that the timing marks with 1 and 2 dots are in
straight line on the cylinder head surface as shown
in the illustration.
If not, turn the crankshaft 1 revolition (360 °) and align the mark
as above.
2. INSTALL DISTRIBUTOR
(a) Install a new O−ring to the distributor.
HINT:
Always use a new O−ring when installing the distributor.
(b) Align the protrusion of the distributor housing with the
groove on the driven gear.
(c) Apply a light coat of engine oil on the O−ring.
(d) Install the distributor with the 2 bolts.
Torque: 19 N·m (195 kgf·cm, 14 ft·lbf)
3. INSTALL DISTRIBUTOR CAP
4. RECONECT HIGH−TENSION CORDS TO DISTRIBU-
TOR CAP
5. CONNECT DISTRIBUTOR CONNECTOR
6. CHECK IGNITION TIMING (See page EM−11)

Downloaded from www.Manualslib.com manuals search engine Z11309BAA
IG03K−03
P14953
− IGNITION (3RZ−FE)CRANKSHAFT POSITION SENSOR
IG−13
1153 Author: Date:
1996 TOYOTA T100 (RM449U)
CRANKSHAFT POSITION SENSOR
REMOVAL
1. REMOVE ENGINE UNDER COVER
2. REMOVE GENERATOR
(See page CH−7)
3. REMOVE GENERATOR BRACKET
Remove the 3 bolts and bracket.
Torque:
Bolt A: 74.5 N·m (760 kgf·cm, 55 ft·lbf)
Bolt B: 18 N·m (180 kgf·cm, 13 ft·lbf)
4. DISCONNECT CRANKSHAFT POSITION SENSOR
CONNECTOR
5. REMOVE CRANKSHAFT POSITION SENSOR
(a) Remove the 2 bolts and crankshaft position sensor.
Torque: 8.5 N·m (85 kgf·cm, 74 in.·lbf)
(b) Remove the O−ring.
HINT:
At the time assembly, please refer to the following items.
Install the crankshaft position sensor with a new gasket.
Always use a new O−ring when installing the crankshaft
position sensor.
Apply a light coat of engine oil the O−ring.

Downloaded from www.Manualslib.com manuals search engine P16211
Ohmmeter
NENE
IG03L−02
IG−14
− IGNITION (3RZ−FE)CRANKSHAFT POSITION SENSOR
1996 TOYOTA T100 (RM449U)
INSPECTION
NOTICE:
”Cold” and ”Hot” in these sentences express the tempera-
ture of the sensors themselves. ”Cold” is from −10°C
(14°F) to 50°C (122°F) and ”Hot is from 50°C (122°F) to
100°C (212°F).
INSPECT CRANKSHAFT POSITION SENSOR
RESISTANCE
Using an ohmmeter, measure the resistance between termi-
nals.
Resistance (NE and NE):
Cold: 1,630 − 2,740 Ω
Hot: 2,065 − 3,225 Ω
If the resistance is not as specified, replace the crankshaft posi-
tion sensor.

Downloaded from www.Manualslib.com manuals search engine IG03M−01
− IGNITION (3RZ−FE)CRANKSHAFT POSITION SENSOR
IG−15
1996 TOYOTA T100 (RM449U)
INSTALLATION
Installation is in the reverse order of removal (See page IG−13).

Downloaded from www.Manualslib.com manuals search engine IG – IGNITION (5VZ-FE)

IGNITION SYSTEM IG-1
IGNITION COIL IG-6
CAMSHAFT POSITION SENSOR IG-9
CRANKSHAFT POSITION SENSOR IG-12

Downloaded from www.Manualslib.com manuals search engine IG03Z−04
SPARK TEST
CHECK CONNECTION OF IGNITION COIL AND
CHECK RESISTANCE OF HIGH−TENSION
TRY ANOTHER IGNITER Maximum resistance; 25 kΩ per cord CORD (See step 2.)
CHECK POWER SUPPLY TO IGNITION COIL
AND IGNITER
1. Turn ignition switch to ON.
2. Check that there is battery voltage at
ignition coil positive (+) terminal.
Check wiring between ECM, distributor
CHECK RESISTANSE OF IGNITION COIL
(See step 4.)
Resistance: Cold
PrimaryHot
0.67 − 1.05 Ω0.85 − 1.23 Ω
POSITION SENSOR
(See step 5)
Resistance: Cold
G and GHot
835 − 1,400 Ω1,060 − 1,645 Ω CHECK RESISTANSE OF CAMSHAFT
POSITION SENSOR
(See page IG−13)
Resistance: Cold
NE and NEHot
1,630 − 2,740 Ω2,065 − 3,225 Ω CHECK RESISTANSE OF CRANKSHAFT
CHECK IGT SIGNAL FROM ECM
(See page DI−144)
OK NO
BAD
OK
OK
OK
OK
OK
Connect securely.
Replace the cord(s).
Check wiring between ignition switch
to ignition coil and igniter.
Replace the ignition coil.
Replace the camshaft position sensor.
Replace the crankshaft position sensor.
and igniter, and then try another ECM.
BAD
BAD
BAD
BAD
BAD
BAD
IGNITER
Secondary 9.3 − 16.0 kΩ11.7 − 18.8 kΩ
− IGNITION (5VZ−FE)IGNITION SYSTEM
IG−1
1156 Author: Date:
1996 TOYOTA T100 (RM449U)
IGNITION SYSTEM
ON−VEHICLE INSPECTION
NOTICE:
”Cold” and ”Hot” in the following sentences express the
temperature of the coils themselves. ”Cold” is from −10°C
(14°F) to 50°C (122°F) and ”Hot” is from 50°C (122°F)
to 100°C (212°F).
1. INSPECT SPARK TEST
Check that the spark occurs.
(1) Disconnect the high−tension cords from the spark
plug.
(2) Remove the spark plug.
(3) Install the spark plug to each high−tension cord.
(4) Ground the spark plug.
(5) Check if spark occurs while engine is being
cranked.
NOTICE:
To prevent excess fuel being injected from the injectors
during this test, do not crank the engine for more 1 − 2 se-
conds at a time.
If the spark does not occur, perform the test as follows:

Downloaded from www.Manualslib.com manuals search engine P23940
P20581
P20439
Ohmmeter IG−2
− IGNITION (5VZ−FE)IGNITION SYSTEM
1157 Author: Date:
1996 TOYOTA T100 (RM449U)
2. INSPECT HIGH−TENSION CORDS
(a) Remove the air cleaner cap and MAF meter assembly.
(b) Disconnect the high−tension cords from the spark plugs.
Disconnect the high−tension cords at the rubber boot.
DO NOT pull on the cords.
NOTICE:
Pulling on or bending the cords may damage the conduc-
tor inside.
(c) Disconnect the high−tension cords from the ignition coils.
(1) Using a screwdriver, lift up the lock claw and discon-
nect the holder from the ignition coils.
(2) Disconnect the high−tension cord at the grommet.
DO NOT pull on the cord.
NOTICE:
Pulling on or bending the cords may damage the conductor
inside.Do not wipe any of the oil from the grommet after the
high−tension cord is disconnected.
(d) Inspect the high−tension cord resistance.
Using an ohmmeter, measure the resistance.
Maximum resistance:
25 kΩ per cord
If the resistance is greater than maximum, check the terminals.
If necessary, replace the high−tension cord.
