1996 TOYOTA SUPRA Owners Manual

161. Get the tool bag out of the console box.
In the tool bag, you will find a special kit
consisting of:
Wrench and handle
ÐFor turning the center lock and the
front and rear bolts
Caps ÐFor covering the front bolts
PlugsÐFor stopping up the rear holes
2. Face the LOOSENº side of the
handle toward you and insert the
wrench into the handle .3. Unlock the center lock by inserting
the wrench and turning it a 1/4 turn counterclockwise.
Before detaching the sport roof from the
vehicle, fully open both of the side doorsand windows, and clear the seats.

17
4. Loosen the bolts in the order shown
by turning the wrench counterclock-
wise. Then lift up the front edge of the sport roof and lift off the roof forward.
Be careful not to get your hands or
fingers caught between the sport
roof and the vehicle body when de-
taching the roof.
CAUTION!
NOTICE
Take care not to hit the sport roof against the vehicle body to avoid
damage to the roof when detaching the roof.
5. After removing the roof, put the caps on the front bolts and insert the
plugs into the rear holes .
Do not stick your head, arms or
any objects out of the opening
while the vehicle is moving.
Never attempt to remove the roof
while driving.
Do not sit on top of the vehicle
around the opening.
CAUTION!
1. Open the back door and set up the rear holders as shown above.
Before stowing the roof in the luggage
compartment, be sure to remove the lug-
gage cover. (See Luggage coverº in Chapter 1-8.)ÐStowing in luggage compartment

18
2. Put in the roof from the left side
as shown. Then insert the front edge
of the roof in the front holders, and
engage the rear edge with the rear holders.
Put the front edge on the triangle marks of the front holders.
To engage the rear edge of the roof with
the rear holders, put the rear edge on the holders while pushing the front edge fully forward against the front holders.
To minimize the risk of personal in-
jury, make sure all four corners of
the roof are securely locked in the
holders after installation.
CAUTION!
NOTICE
To avoid damaging the roof panel, do not press on the center of the
stowed roof panel and do not put anything on the stowed roof panel.
ÐReinstalling on vehicle

19
1. Lift up the rear edge while pushing
the roof fully forward, then pull the
front edge out of the holders. Remove
the roof from the right side as shown.
After removing the roof, put back the rear
holders by pulling up the lock release knob.
NOTICE
Do not operate the knob until the roof has been removed.
2. Place the rear edge on first and then
the front edge.
Before installation, be sure to take the
caps and plugs off.
CAUTION!
To minimize the risk of personal in-
jury, make sure all four corners are
securely fixed on the brackets afterinstallation.

20
3. Tighten the bolts and lock the cen-
ter lock in the order shown. (See
ÐDetaching from vehicleº for de-
tails.) Note that all five connections need to be
tight to secure the sport roof. Reverse the wrench handle so the
TIGHTENº side faces toward you and
turn it clockwise.
Check that the roof is correctly installed by
lightly trying to move the roof.
Put the wrench, handle, caps and plugs back in the tool bag in the console box.
Make sure to tighten all four bolts
and to lock the center lock when
installing the sport roof.
CAUTION!

Part 1Front seatsÐ
ÐSeat adjustment precautions
Seats
21
OPERATION OF INSTRUMENTS AND CONTROLSÐ
Chapter 1-3 Seats, Seat belts,Steering wheeland Mirrors
Seats
Front seats
Fold-down rear seat
Seat heaters
Seat belts
SRS airbags
Child restraint
Tilt steering wheel
Outside rear view mirrors
Anti-glare inside rear view mirror
While the vehicle is being driven, all ve-
hicle
occupants should have the seatback
upright, sit well back in the seat and prop-
erly wear the seat belts provided.
CAUTION
Do not drive with the vehicle occu- pants not properly seated, such as
sitting on top of a folded-down seatback, or in the luggage
compartment. Persons not proper-
ly seated and restrained by seat
belts can be severely injured in the event of emergency braking or a collision.
During driving, do not let passen- gers stand up or move around be-
tween seats. Balance can be un-
steady and severe injuries can oc-
cur in the event of emergency brak-
ing or a collision.! Adjust the driver's seat so that the foot
pedals, steering wheel and instrument
panel
controls are within easy reach of the
driver.CAUTION
Adjustments should not be made
while the vehicle is moving, as the
seat may unexpectedly move and
cause the driver to lose control of
the vehicle.
When adjusting the seat, be carefulnot to hit the seat against a passen-
ger, luggage or rear seat.
After adjusting the seat position, try sliding it forward and backward
to make sure it is locked in posi- tion.
After adjusting the seatback, exert
body pressure to make sure it is
locked in position.
Do not put objects under the seats
as they may interfere with the seat-
lock mechanism or unexpectedly
push up the seat position adjusting
lever; the seat may suddenly move,
causing the driver to lose control of
the vehicle.
While adjusting the seat, do not put
your hands under the seat or near
the moving parts. You may jam
your hands or fingers.!

22
ADJUSTING SEAT POSITION
Pull the lock release lever up. Then
slide the seat to the desired position
with slight body pressure and release
the lever.
ADJUSTING SEATBACK ANGLE
Lean forward and pull the lock release
lever. Then lean back to the desired
angle and release the lever.
CAUTION!
To reduce the risk of sliding under
the lap belt during a collision, avoid
reclining the seatback any more
than needed. The seat belts provide
maximum protection when the driv-
er and the passenger are sitting up
straight and well back in the seats.
If you are reclined, the lap belt may
slide past your hips and apply re-
straint forces directly to the abdo-
men. Therefore, in the event of a
frontal collision, the risk of personal
injury may increase with increasing
recline of the seatback.
ÐAdjusting front seat (power seat)
ÐAdjusting front seat(manual seat)

23
ADJUSTING SEAT POSITION
Move the control switch to the desired direction. Releasing the switch will stop the move in
that position.
Do not place anything under the front
seats. It might interfere with the seatmovement.
ADJUSTING SEATBACK ANGLE
Move the control switch to the desired direction. Releasing the switch will stop the move in
that position.
CAUTION!
To reduce the risk of sliding under the
lap belt during a collision, avoid re-
clining the seatback any more than
needed. The seat belts provide maxi-
mum protection when the driver and
the passenger are sitting up straight
and well back in the seats. If you are
reclined, the lap belt may slide past
your hips and apply restraint forces
directly to the abdomen. Therefore, in
the event of a frontal collision, the risk
of personal injury may increase with
increasing recline of the seatback.
ADJUSTING SEAT CUSHION ANGLE
Turn the knob either way.
Lift seatback lock release leverÐthe
seatback will tilt forward. This allows passengers to get into or out
of the rear seat easily. After passengersare in, lift up on the seatback.
CAUTION!
After putting back the seatback, try
pushing the seatback forward and rearward to make sure it is secured
in place.
For easy access to the rear seat, do this.
1. Lift the seatback lock release lever or press the release pedal.
The seat will slide forward slightly.
2. Move the seat to the front-most posi- tion.
After passengers are in, lift up the seat- back and return the seat until it locks.
CAUTION!
After putting back the seat, try
pushing the seat forward and rear-
ward to make sure it is secured inplace.
Never allow anyone to rest their
foot on the release pedal while the
vehicle is moving.
ÐMoving passenger's seat for rear seat entry
ÐTilting driver's seatbackfor rear seat entry
