DLC 3 DI−4
− DIAGNOSTICSENGINE
1996 RAV4 (RM447U)
By switching the ECM to check mode when trouble-
shooting, the technician can cause the MIL to light
up for a malfunction that is only detected once or
momentarily (TOYOTA hand−held tester only) (See
page DI−3).
*2 trip detection logic:
When a logic malfunction is first detected, the mal-
function is temporarily stored in the ECM memory.
If the same malfunction is detected again during the
second drive test, this second detection causes the
MIL to light up.
The 2 trip repeats the same mode a 2nd time. (How-
ever, the IG switch must be turned OFF between the
1st trip and 2nd trip).
Freeze frame data:
Freeze frame data records the engine condition
when a misfire (DTC P0300 − P0304) or fuel trim
malfunction (DTC P0171, P0172), or other malfunc-
tion (first malfunction only), is detected.
Because freeze frame data records the engine
conditions (fuel system, calculator load, engine
coolant temperature, fuel trim, engine speed, ve-
hicle speed, etc.) when the malfunction is detected,
when troubleshooting it is useful for determining
whether the vehicle was running or stopped, the en-
gine warmed up or not, the air−fuel ratio lean or rich,
etc. at the time of the malfunction.
Priorities for Troubleshooting:
If troubleshooting priorities for multiple diagnostic
codes are given in the applicable diagnostic chart,
these should be followed.
If no instructions are given, troubleshoot DTC according to the
following priorities.
(1) DTC other than fuel trim malfunction (DTC P0171,
P0172), EGR (DTC P0401, P0402), and misfire
(DTC P0300 − P0304).
(2) Fuel trim malfunction (DTC P0171, P0172) and
EGR (DTC P0401, P0402).
(3) Misfire (DTC P0300 − P0304).
(b) Check the DLC3.
The vehicle’s ECM uses V.P.W. (Variable Pulse Width) for
communication to comply with SAE J1850. The terminal
arrangement of DLC3 complies with SAE J1962 and
matches the V.P.W. format.

S02459
− DIAGNOSTICSENGINE
DI−5
1996 RAV4 (RM447U) Terminal No.
Connection / Voltage or ResistanceCondition
2Bus  Line / Pulse generationDuring transmission
4Chassis Ground / ↔ Body Ground 1 Ω or lessAlways
5Signal Ground / ↔ Body Ground 1 Ω or lessAlways
16Battery Positive / ↔ Body Ground 9 ∼ 14VAlways
HINT:
If your display shows ”UNABLE TO CONNECT TO VEHICLE”
when you have connected the cable of the OBDII scan tool or
TOYOTA hand−held tester to DLC3, turned the ignition switch
ON and operated the scan tool, there is a problem on the ve-
hicle side or tool side.
If communication is normal when the tool is connected to
another vehicle, inspect DLC3 on the original vehicle.
If communication is still not possible when the tool is con-
nected to another vehicle, the problem is probably in the
tool itself, so consult the Service Department listed in the
tool’s instruction manual.
2. INSPECT DIAGNOSIS (Normal Mode)
(a) Check the MIL.
(1) The MIL comes on when the ignition switch is turned
ON and the engine is not running.
HINT:
If the MIL does not light up, troubleshoot the combination meter.
(2) When the engine is started, the MIL should go off.
If the lamp remains on,the diagnosis system has
detected a malfunction or abnormality in the sys-
tem.
(b) Check the DTC.
NOTICE:
TOYOTA hand−held tester only:
When the diagnosis system is switched from normal mode
to check mode, it erases all DTC and freezed frame data re-
corded in normal mode. So before switching modes, al-
ways check the DTC and freezed frame data, and note them
down.
(1) Prepare the OBDII scan tool (complying with SAE
J1978) or TOYOTA hand−held tester.
(2) Connect the OBDII scan tool or TOYOTA hand−
held tester to DLC3 at the lower of the instrument
panel.
(3) Turn the ignition switch ON and turn the OBDII scan
tool or TOYOTA hand−held tester switch ON.
(4) Use the OBDII scan tool or TOYOTA hand−held tes-
ter to check the DTC and freezed frame data, note
them down.
(5) See page DI−14 to confirm the details of the
DTC.

FI3605
ONFlashing
0.13 Seconds OFF
DI−6
− DIAGNOSTICSENGINE
1996 RAV4 (RM447U)
NOTICE:
When simulating symptoms with an OBDII scan tool (Ex-
cluding TOYOTA hand−held tester) to check the DTC, use
normal mode. For codes on the DTC chart subject to ”2 trip
detection logic”, turn the ignition switch OFF after the
symptom is simulated the first time. Then repeat the simu-
lation process again. When the problem has been simu-
lated twice, the MIL lights up and the DTC are recorded in
the ECM.
3. INSPECT DIAGNOSIS (Check Mode)
HINT:
TOYOTA Hand−Held Tester only:
Compared to the normal mode, the check mode has an in-
creased sensitivity to detect malfunctions.
Furthermore, the same diagnostic items which are detected in
the normal mode can also be detected in the check mode.
(a) Check the DTC.
(1) Initial conditions.
Battery positive voltage 11 V or more.
Throttle valve fully closed.
Transmission in park or neutral position.
Air conditioning switched OFF.
(2) Turn ignition switch OFF.
(3) Prepare the TOYOTA hand−held tester.
(4) Connect the TOYOTA hand−held tester to DLC3 at
the lower of the instrument panel.
(5) Turn the ignition switch ON and push the TOYOTA
hand−held tester main switch ON.
(6) Switch the TOYOTA hand−held tester normal mode
to check mode. (Check that the MIL flashes.)
(7) Start the engine. (The MIL goes out after the engine
starts.)
(8) Simulate the conditions of the malfunction de-
scribed by the customer.
NOTICE:
Leave the ignition switch ON until you have checked the
DTC, etc.
(9) After simulating the malfunction conditions, use the
TOYOTA hand−held tester diagnosis selector to
check the DTC and freezed frame data, etc.
HINT:
Take care not to turn the ignition switch OFF. Turning the ignition
switch OFF switches the diagnosis system from check mode to
normal mode, so all diagnostic codes, etc. are erased.

− DIAGNOSTICSENGINE
DI−7
1996 RAV4 (RM447U)
(10) After checking the DTC, inspect the applicable cir-
cuit.
(b) Clear the DTC.
The following actions will erase the DTC and freezed
frame data.
(1) Operating the OBDII scan tool (complying with SAE
J1978) or TOYOTA hand−held tester to erase the
codes.
(See the OBDII scan tool’s instruction book for oper-
ating instructions.)
(2) Disconnecting the battery terminals or EFI fuse.
NOTICE:
If the TOYOTA hand−held tester switches the ECM from
normal mode to check mode or vice−versa, or it the ignition
switch is turned from ON to ACC or OFF during check
mode, the DTC and freezed frame data will be erased.
4. FAIL−SAFE CHART
If any of the following codes is recorded, the ECM enters fail−sate mode.
DTC No.Fail−Safe OperationFail−Safe Deactivation Conditions
P0105Ignition timing fixed at 5° BTDCReturned to normal condition
P0110Intake air temp. is fixed at 68°F (20°C)Returned to normal condition
P0115Engine coolant temp. is fixed at 176°F (80°C)Returned to normal condition
P0120VTA is fixed at 0°
The following condition must be repeated at least
2 times consecutively
When closed throttle position switch is ON:
0.1 V  VTA  0.95 V
P0325Max. timing retardationIgnition switch OFF
P1300Fuel cutIGF signal is detected for 1 ignition
5. CHECK FOR INTERMITTENT PROBLEMS
TOYOTA hand−held tester only:
By putting the vehicle’s ECM in check mode, 1 trip detection logic possible instead of 2 trip detection logic
and sensitivity to detect open circuit is increased. This makes it easier to detect intermittent problems.
(1) Clear the diagnostic trouble codes (See page DI−3)
(2) Set the check mode (See page DI−3)
(3) Perform a simulation test (See page IN−20)
(4) Check the connector and terminal inspection (See page IN−30)
(5) Visual check and contact pressure (See page IN−30)
(6) Handle the connector (See page IN−30)

S01830
Fuel Inlet Hose
P25066
− DIAGNOSTICSENGINE
DI−11
1996 RAV4 (RM447U)
7 Check fuel pressure.
PREPARATION:
(a) Be sure that enough fuel is in the tank.
(b) Turn ignition switch ON.
(c) Connect the TOYOTA hand−held tester to DLC3 on the
vehicle.
(d) Use ACTIVE TEST mode to operate the fuel pump.
(e) If you have no TOYOTA hand−held tester, connect the
positive (+) and negative (−) leads from the battery to the
fuel pump connector (See page SF−5).
CHECK:
Check for fuel pressure in the inlet hose when it is pinched off.
HINT:
At this time, you will hear a fuel flowing noise.
NG Proceed to page SF−5 and continue to trouble-
shoot.
OK
8 Check for spark.
PREPARATION:
(a) Disconnect the high−tension cord from spark plug.
(b) Remove spark plug.
(c) Install spark plug to high−tension cord.
(d) Disconnect injector connector.
(e) Ground the spark plug.
CHECK:
Check if spark occurs while engine is being cranked.
NOTICE:
To prevent excess fuel being injected from the injectors
during this test, do not crank the engine for more than 5 −
10 seconds at a time.
NG Proceed to page IG−1 and continue to trouble-
shoot.
OK
Proceed to matrix chart of problem systems
on page DI−20.

DI409−02
Vehicle Brought to Workshop
P.DI−126
Connect the OBD ll Scan Tool or TOYOTA Hand−Held Tester to DLC3
If your display shows ”UNABLE TO CONNECT TO VEHICLE” when you have
connected the scan tool/TOYOTA hand−held tester, inspect DLC3 P. DI−127
Check DTC and Freeze Frame Data (Pre−check)
Record or Print DTC and Freeze Frame Data P. DI−127
Clear DTC and Freeze Frame Data P. DI−127 Customer Problem Analysis
Visual Inspection
DTC CheckSymptom Simulation Setting the Check Mode Diagnosis P. DI−127
Problem Symptom Confirmation
P. IN−20 Symptom does
not occur
OK Codethe page number indicated in the bottom portion. See the
indicated pages for detailed explanations.
Preliminary Checkare titles of pages in the manual, with Item inside
Mechanical System Tests DTC Chart
Chapter 1
(Electronic)Manual Shifting Test
Matrix Chart of Symptoms Problems − P. DI−140
(On−vehicle)
 Pattern Select Signal Check  O/D Signal Check
InspectionCircuit(Off−vehicle) Chapter 2 Chapter 3
END Repair
Confirmation Test
Identification of ProblemParts Inspection P. DI−127
P. DI−127P. DI−127
P. DI−127
P. DI−127
P. DI−145 − DI−168 P. DI−141 1
2
P. DI−141P. DI−141 3
4
5
6
78
9
1011
12
13
14
16
18 15
17
Symptom occurs
OKNG
OKNG
NG
OK
OK OK
NG
NGNG
Step 2, 3, 4, 6, 9, 15, 18:
Diagnostic steps permitting the use of the TOYOTA
hand−held tester or TOYOTA brake−out−box.
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
DI−125
1996 RAV4 (RM447U)
AUTOMATIC TRANSAXLE (A241E)
HOW TO PROCEED WITH TROUBLESHOOTING
Trobleshoot in accordance with the procedure on the follwoing pages.

Q08848
DI−128
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
1996 RAV4 (RM447U)
The diagnosis system operates in normal mode
during normal vehicle use, and also has a check
mode for technicians to simulate malfunction symp-
toms and perform troubleshooting. Most DTCs use
2 trip detection logic (*) to prevent erroneous detec-
tion. By switching the ECM to check mode when
troubleshooting, the technician can cause the MIL
to light up for a malfunction that is only detected
once or momentarily (TOYOTA hand−held tester)
(See page DI−127).
*2 trip detection logic:
When a logic malfunction is first detected, the mal-
function is temporarily stored in the ECM memory.
If the same malfunction is detected again during the second test
drive, this second detection causes the MIL to light up.
2. Normal Mode:
INSPECT DIAGNOSIS
(a) Check the MIL.
(1) The MIL lights up when the ignition switch is turned
ON and the engine is not running.
HINT:
If the MIL does not light up, troubleshoot the combination meter
(See page BE−2).
(2) When the engine starts, the MIL should go off. If the
lamp remains on, the diagnosis system has de-
tected a malfunction or abnormality in the system.
(b) Check the DTC.
NOTICE:
TOYOTA hand−held tester only:
When the diagnostic system is switched from the normal
mode to the check mode, it erases all DTCs and freezed
frame data recorded in the normal mode. So before switch-
ing modes, always check the DTCs and freezed frame data,
and note them down.
(1) Prepare the OBD II scan tool (complying with SAE
J1978) or TOYOTA hand−held tester.
(2) Connect the OBD II scan tool or TOYOTA hand−
held tester to the DLC3.
(3) Turn the ignition switch ON and turn the OBD II scan
tool or TOYOTA hand−held tester switch ON.
(4) Use the OBD II scan tool or TOYOTA hand−held
tester to check the DTCs and freezed frame data.
Note them down (For operating instructions, see
the OBDII scan tool’s instruction book.).

FI3605
013 sec. ON
OFF
− DIAGNOSTICSAUTOMATIC TRANSAXLE (A241E)
DI−129
1996 RAV4 (RM447U)
(5) See page DI−138 to confirm the details of the
DTCs.
NOTICE:
When simulating symptoms with an OBD II scan tool (ex-
cluding TOYOTA hand−held tester) to check the DTCs, use
the normal mode. For codes on the DTC chart subject to ”2
trip detection logic”, turn the ignition switch off after the
symptoms have been simulated for the first time. Then re-
peat the simulation process again. When the program has
been simulated twice, the MIL lights up and the DTCs are
recorded in the ECM.
3. Check Mode:
INSPECT DIAGNOSIS
HINT:
TOYOTA hand−held tester only:
Compared to the normal mode, the check mode has high sens-
ing ability to detect malfunctions.
Furthermore, the same diagnostic items which are detected in
the normal mode can also be detected in the check mode.
(a) Check the DTC.
(1) Initial conditions.
Battery positive voltage 11 V or more
Throttle valve fully closed
Transaxle in the PARK position
Air conditioning switched off
(2) Prepare the TOYOTA hand−held tester.
(3) Connect the TOYOTA hand−held tester to the
DLC3.
(4) Turn the ignition switch ON and switch the TOYOTA
hand−held tester ON.
(5) Switch the TOYOTA hand−held tester from the nor-
mal mode to the check mode (Check that the MIL
flashes.).
(6) Start the engine (The MIL goes off after the engine
start.).
(7) Simulate the conditions of the malfunction de-
scribed by the customer.
NOTICE:
Leave the ignition switch ON until you have checked the
DTCs, etc.
(8) After simulating the malfunction conditions, use the
TOYOTA hand−held tester diagnosis selector to
check the DTCs and freezed frame data, etc.
HINT:
Take care not to turn the ignition switch OFF.
Turning the ignition switch off switches the diagnosis system
from check mode to normal mode, so all DTCs, etc. are erased.
(9) After checking the DTC, inspect the applicable cir-
cuit.
