1996 TOYOTA CELICA Owners Manual

4
1. Service reminder indicators or indicator lights
2. Tachometer
3. Odometer 4. Engine coolant temperature gauge
5. Fuel gauge
6. Trip meter
7. Trip meter reset knob
8. Speedometer
Instrument cluster overview
ProCarManuals.com

5
Indicator symbols on the instrument panel
Anti-lock
brake system warning light *1
Brake system warning light *1
Seat belt reminder light*1
Discharge warning light*1
Low oil pressure warning light*1
Malfunction indicator lamp*1
Low fuel level warning light *1
Open door warning light*1
SRS airbag warning light*1
Turn signal indicator lights
Headlight high beam indicator light
Overdrive-of f indicator light
Cruise control indicator light*2
*1: For details, see Service reminder indicators and warning
buzzersº in Chapter 1-5.
*
2: If this light flashes, see Cruise controlº in Chapter 1-6.
ProCarManuals.com

6ProCarManuals.com

Part 1Keys7
OPERATION OF
INSTRUMENTS AND
CONTROLSÐ
Chapter 1-2
Keys and Doors

Keys

Side doors

Power windows

Trunk lid/Back door

Hood

Fuel tank cap

Electric moon roof

Convertible top
Your vehicle is supplied with two
kinds of key.
1 Master keyÐThis key works in every
lock.
2 SubkeyÐThis key is for side doors.
To protect things locked in the glovebox,
trunk or luggage compartment when you
have your vehicle parked, leave the sub-
key with the attendant.
Since the side doors, trunk lid and back
door can be locked without a key, you
should always carry a spare master key in
case you accidentally lock your keys in-
side the vehicle.KEY NUMBER PLATE
Your key number is shown on the
plate. Keep the plate in a safe place
such as your wallet, not in the vehicle.
If you should lose your keys or if you need
additional keys, duplicates can be made
by a Toyota dealer using the key number.
You should also put a copy of the key
number with your important papers.
ProCarManuals.com

8
LOCKING AND UNLOCKING WITH
KEY
Insert the key into the keyhole and turn
it.
To lock: Turn the key forward.
To unlock: Turn the key backward.
Both side doors lock and unlock simulta-
neously with either side door. In the driv-
er 's door lock, turning the key once will un-
lock the driver's door and twice in
succession will unlock both side doors si-
multaneously.LOCKING AND UNLOCKING WITH IN-
SIDE LOCK KNOB
Move the lock knob.
To lock: Push the knob forward.
To unlock: Pull the knob backward.
Closing the side door with the lock knob in
the lock position will also lock the side
door. Be careful not to lock your keys in
the vehicle.
Vehicles with power door lock systemÐ
The side door cannot be locked if you
leave the key in the ignition switch.Driver's side
Passenger 's side
Side doors
ProCarManuals.com

9
LOCKING AND UNLOCKING WITH
POWER DOOR LOCK SWITCH
Push the switch.
To lock: Push the switch on the front side.
To unlock: Push the switch on the rear
side
Both doors lock or unlock simultaneously.
Before driving, be sure that the side
doors are closed and locked, espe-
cially when small children are in the
vehicle. Along with the proper use of
seat belts, locking the side doors
helps prevent the driver and passen-
gers from being thrown out from the
vehicle during an accident. It also
helps prevent the side doors from
being opened unintentionally. CAUTION
!
To avoid serious personal injury, you
must do the following.


Always make sure the head, hands
and other parts of the body of all oc-
cupants are kept completely inside
the vehicle before you close the
power windows. If someone's n eck,
head or hands gets caught in a clos-
ing window, it could result in a seri-
ous injury. When anyone closes the
power windows, be sure that they
operate the windows safely.

When small children are in the ve-
hicle, never let them use the power
window switches without supervi-
sion. Use the window lock button
to prevent them from making unex-
pected use of the switches.

Never leave small children alone in
the vehicle, especially with the igni-
tion key still inserted. They could
use the power window switches and
get trapped in a window. Unattended
children can become involved in se-
rious accidents. CAUTION
!
The windows can be operated with the
switch on each side door.
The power windows work when the igni-
tion
switch is in the ONº position. Howev-
er, if both side doors are closed, they work
for 60 seconds even after the ignition
switch is turned off. They stop working
when either side door is opened.
OPERATING THE DRIVER'S WINDOW
Use the switch on the driver's door.
Normal operation: The window moves
as long as you hold the switch.
To open: Lightly pull down the switch.
To close: Push up the switch.
Power windowsÐ
ÐPower window precautions ÐSide windows
ProCarManuals.com

10
Automatic operation (to open only):
Pull the switch completely down and then
release it. The window will fully open. To
stop the window partway, lightly push the
switch up and then release it. OPERATING
THE PASSENGERS' WIN-
DOW
Use the switch on the passenger's
door. The driver's door also has a
switch that controls the passengers'
window.
The window moves as long as you hold
the switch.
To open: Pull down the switch.
To close: Push up the switch.
If you push in the window lock button on
the driver's door, the passenger's window
cannot be operated.
Convertible modelsÐThe window lock
button also locks the quarter windows.For front passenger's use
For driver's use
ProCarManuals.com

11
The windows can be operated with
switches on the center console.
The windows move as long as you hold
the switch.
To open: Push on the lower side of the
switch.
To close: Push on the upper side of the
switch.To open the trunk lid or back door from
the outside, insert the master key and
turn it clockwise.
See Luggage stowage precautionsº in
Part 2 for precautions to observe in load-
ing luggage.
To close the trunk lid or back door, lower
it and press down on it. After closing the
trunk lid or back door, try pulling it up to
make sure it is securely closed.
Keep the trunk lid or back door closed
while driving. This not only keeps the
luggage from being thrown out but
also prevents exhaust gases from en-
tering the vehicle.
CAUTION!
To open the trunk lid or back door
from the driver's seat, pull up on the
lock release lever.
ÐLock release lever
ÐQuarter windows
(convertible) Trunk lid (c
oupe and convertible)/
Back door (liftback)Ð
